SOHO Internet Camera

User’s Guide

Version 1.0

TABLE OF CONTENTS

ABOUT THIS GUIDE...........................................................5

1. INTRODUCTION..............................................................6

FEATURES AND BENEFITS .........................................................7

UNPACKING THE PACKAGE .......................................................9

SYSTEM REQUIREMENT...........................................................10

PHYSICAL DESCRIPTION ..........................................................11

2. HARDWARE INSTALLATION.................................15

TTACHING THE

AMERA TO THE

TAND

...............................15

CONNECTING THE ETHERNET CABLE ......................................16

ATTACHING THE POWER SUPPLY ............................................16

3. SECURITY.........................................................................17

4. APPLICATION OF THE CAMERA .......................18

APPLICATIONS .........................................................................19

APPLICATION DIAGRAMS OF THE CAMERA.............................20

5. USING THE CAMERA .................................................22

WEB CONFIGURATION UTILITY...............................................22

SYSTEM ADMINISTRATION ......................................................24

VIEW VIDEO – ACTIVEX MODE..............................................43

VIEW IMAGE – JAVA MODE ....................................................44

6. IPVIEW SE ........................................................................46

INSTALLATION.........................................................................46

GETTING STARTED ..................................................................52

HOW TO ADD A CAMERA ........................................................54

HOW TO CHANGE CAMERA .....................................................59

CONNECT/DISCONNECT THE IMAGE........................................60

HOW TO DELETE A CAMERA ...................................................63

EXTRA INFORMATION..............................................................64

HOW TO ADJUST THE PROPERTY SETTING ..............................65

ADJUST THE RECORDING SETTING..........................................71

7. APPENDIX.........................................................................72

AFREQUENTLY ASKED QUESTIONS........................................72

BPING YOUR IP ADDRESS ....................................................75

CTROUBLE SHOOTING ............................................................76

DTIME ZONE TABLE ...............................................................80

EXPLUG CONTROL INSTALLATION.........................................82

FADJUST INTERNET CAMERA FOCUS .....................................86

GSPECIFICATION.....................................................................87

HGLOSSARY OF TERMS ..........................................................89

ABOUT THIS GUIDE

This manual provides instructions and illustrations on how to use

your SOHO Internet Camera, includes:

 Chapter 1, Introduction, provides the general information

on the camera.

 Chapter 2, Hardware Installation, describes the hardware

installation procedure for the camera.

 Chapter 3, Security, explains the security feature of the

camera.

 Chapter 4, Application of the Camera, provides the

illustrations of the camera’s applications.

 Chapter 5, Using the Camera, guides you through the

configuration using the web browser.

 Chapter 6, IPView SE, helps you to install and use the

software.

 Chapter 7, Appendix.

Please note that the illustrations or setting values in this manual

are FOR YOUR REFERENCE ONLY. The actual settings and

values depend on your system and network. If you are not sure

about the respective information, please ask your network

administrator or MIS staff for help.

INTRODUCTION

Thank you for purchasing the SOHO Internet Camera, a camera

device that can be connected directly to an Ethernet or Fast

Ethernet network. Compared to the conventional PC Camera, the

Internet Camera features a built-in CPU and web-based solutions

that can provide a cost-effective solution to transmit real-time

high-quality video images and sounds for monitoring. The

Internet Camera can be managed remotely, accessed and

controlled from any PC/Notebook over the Intranet or Internet via

a web browser. The simple installation procedures and web-

based interface allow you to integrate it into your network easily.

With comprehensive applications supported, the Internet Camera

is your best solution for remote monitor, high quality, and high

performance video images.

Features and Benefits

Simple To Use

The Internet Camera is a standalone system with built-in CPU

requiring no special hardware or software such as PC frame

grabber cards. The Internet Camera supports both ActiveX mode

(for Internet Explorer users) and Java mode (for Internet Explorer

and Netscape Navigator users). Therefore, all that is required is a

web browser software such as Internet Explorer 5.0 or above or

Netscape 6.0 or above. Just plug and view the picture from your

Internet Camera with a valid IP Address.

Support Variety of Platforms

The Internet Camera supports TCP/IP networking, SMTP e-mail,

HTTP and other Internet related protocols, and can be utilized in

a mixed operating system environment such as Windows, Unix,

and Mac. It can be integrated easily into other www/Intranet

applications.

Web Configuration

Applying a standard web browser, the administrator can configure

and manage the Internet Camera directly from its own web page

via the Intranet or Internet. Up to 64 users name and password

are permitted with privilege setting controlled by the

administrator.

Remote Utility

The powerful IPView SE application assigns the administrator

with a pre-defined user ID and password, allowing the

administrator to modify the Internet Camera settings from the

remote site via Intranet or Internet. When new firmware is

available, you can also upgrade remotely over the network for

added convenience. Users are also allowed to monitor the image,

and take snapshots.

Broad Range of Applications

With today’s high-speed Internet services, the Internet Camera

can provide the ideal solution for live video images over the

Intranet and Internet for remote monitoring. The Internet Camera

allows remote access from a web browser for live image viewing

and allows administrator to manage and control the Internet

Camera anywhere and any time in the world. Apply the Internet

Camera to monitor various objects and places such as homes,

offices, banks, hospitals, child-care centers, amusement parks and

other varieties of industrial and public monitoring. The Internet

Camera can also be used for intruder detection; in addition, it can

capture still images for archiving and many more applications.

Unpacking the Package

Unpack the package and check all the items carefully. In addition

to this User’s Guide, be certain that you have:

 One SOHO Internet Camera

 One Installation CD-ROM

 One Quick Installation Guide

 One AC power adapter suitable for your country’s electric

power

 One Camera Stand

 One RJ-45 Ethernet Cable

If any item contained is damaged or missing, please contact your

local dealer immediately. Also, keep the box and packing

materials in case you need to ship the unit in the future.

System Requirement

Networking

 10Base-T Ethernet or 100Base-TX Fast Ethernet.

Accessing the Camera

For Web Browser Users

 Operating System: Microsoft® Windows® 98SE/ME/

2000/XP

 CPU: Intel Pentium II, 266 MHz or above

 Memory Size: 32MB (64MB recommended)

 Resolution: 800x600 or above

 Microsoft® Internet Explorer 5.0 or above (ActiveX &

JAVA Mode – Image View for Windows OS and JAVA

Mode – Image View for other OS); Netscape 6.0 or above

(JAVA Mode – Image View)

For IPView SE Application Users

 Operating System: Microsoft® Windows® 98SE/ME/

2000/XP.

 CPU: Intel Pentium III, 450 MHz or above

 Memory Size: 128 MB (256 MB recommended)

 Resolution: 800x600 or above
