The Soul Of Computer Technology

SL-56H5 / H1 USER MANUAL

USER NOTICE

This User‘s Guide & Technical Reference is for assisting system

manufacturers and end-users in setting up and installing the

mainboard.

Every effort has been made to ensure that the information in this

manual is accurate. Soltek Computer Inc. is not responsible for

printing or clerical errors. Information in this document is subject to

change without notice and does not represent a commitment on

the part of Soltek Computer Inc.

No part of this manual may be reproduced, transmitted, translated

into any language in any form or by any means, electronic or

mechanical, including photocopying and recording, for any purpose

without the express written permission of Soltek Computer Inc.

Companies and products mentioned in this manual are for identifi-

cation purpose only. Product names appearing in this manual may

or may not be registered trademarks or copyrights of their respec-

tive companies.

Soltek computer inc. Provides this manual “As is “ without warranty

of any kind, either express or implied, including but not limited to

the implied warranties or conditions of merchantability or fitness

for a particular purpose. In no event shall Soltek computer inc. Be

liable for any loss or profits, loss of business, loss of use or data,

interruption of business, or for indirect, special, incidental, or con-

sequential damages of any kind, even if Soltek computer inc. Has

been advised of the possibility of such damages arising from any

defect or error in this manual or product.

Product Model : SL-56H5 / H1

Manual Revision : V1.0

Release Date : February 2000

• Intel Pentium, Pentium MMX are trademarks of Intel Corporation.

• VIA Apollo MVP3 is trademark of VIA Corporation.

• Cyrix MII, 6x86(L) are trademarks of Cyrix Corporation.

• AMD K6, K6-2, K6-2+, K6-III are trademarks of AMD Corporation.

• Acrobat Reader is trademark of Adobe Corporation.

• Norton AntiVirus, Norton Ghost are trademarks of Symantec Corporation.

SOLTEK AROUND THE WORLD

SOLTEK COMPUTER INC.

Address : 7F, No. 306-3, Ta-Tung Rd, Sec. 1, Hsi-Chih, Taipei-

Hsien, Taiwan, R.O.C.

Telephone : 886-2-2642-9060

Fax : 886-2-2642-9065

E-mail : [email protected]

Web site : http://www.soltek.com.tw

SOLTEK KOREA INC.

Address : 1002, Chungjin Bldg. 53-5 Wonhyo-Ro, 3-Ka,

Yongsan-Ku Seoul 140-113, Korea

Telephone : 82-2-32717400

Fax : 82-2-32717405

E-mail : [email protected]

SOUL TECHNOLOGY EUROPE B.V.

Address : Sydneystraat 52-54 3047 BP Rotterdam, the Neth-

erlands

Telephone : 31-10-2457492

Fax : 31-10-2457493

MOKA HOLDING B.V.

Address : De Run 4428 5503 LR Veldhoven, the Netherlands

Telephone : 31-402-556150

Fax : 31-402-546006

56H5 / 56H1

C O N T E N T

SOLTEK COMPUTER INC. ............................................. 3

SOLTEK KOREA INC. ..................................................... 3

MOKA HOLDING B.V. ..................................................... 3

SOUL TECHNOLOGY EUROPE B.V. ............................. 3

CHAPTER 1

INTRODUCTION ................................................. 6

1-1 ITEM LIST CHECKUP ..................................................... 6

1-2 CPU.................................................................................. 6

1-3 CHIPSET ......................................................................... 6

1-4 MEMORY CAPABILITY ................................................... 6

1-5 BIOS DESCRIPTION ....................................................... 7

1-6 MOTHERBOARD DESCRIPTION ................................... 7

1-7 MOTHERBOARD LAYOUT ............................................. 8

CHAPTER 2

HARDWARE SETUP.......................................... 10

2-1 VOLTAGE ADJUSTMENT ............................................. 10

• CPU Vcore Setting ........................................................... 10

• CPU Bus Clock Setting .................................................... 10

• CPU Bus Ratio Setting...................................................... 11

2-2 JUMPERS SETTING ......................................................11

• FAN#: Onboard FAN(12V) Connector .............................. 11

• JP5 / JP6: CPU Single / Dual Voltage Select ..................11

• JP10 / JP11: USB Port Select ......................................... 12

• JP12: Clear CMOS Data .................................................. 12

• JP15: Power Lost Resume .............................................. 12

• JWOL1: Wake On LAN(WOL) Connector ................... 1213

2-3 CONNECTORS ............................................................. 13

2-3.1 J2 / J3 ........................................................................ 13

56H5 / 56H1

2-3.2 EXTERNAL CONNECTOR ....................................... 13

2-3.3 2nd USB CONNECTOR ............................................ 14

2-3.4 ATX POWER SUPPLY CONNECTOR ...................... 15

CHAPTER 3

SOFTWARE SETUP ........................................... 16

3-1 ABOUT SOLTEK SUPPORT CD .................................. 16

3-2 HARDWARE MONITOR INSTALLATION ...................... 16

3-3 VIA CHIPSET DRIVER INSTALLATION (4-in1 Driver) 18

CHAPTER 4

BIOS SETUP ........................................................ 22

4-1 INTRODUCE THE BIOS ................................................ 22

4-2 WHAT IS BIOS SETUP ................................................. 22

4-3 HOW TO RUN BIOS SETUP......................................... 22

4-4 WHAT IS CMOS ............................................................ 23

4-5 WHAT IS POST ............................................................. 23

4-6 UPDATE THE BIOS....................................................... 23

4-6.1 BEFORE UPDATE THE BIOS ................................... 23

4-6.2 UPDATE YOUR BIOS ................................................ 23

4-6.3 COMMON ERRORS ................................................... 24

4-7 CMOS SETUP UTILITY ................................................. 26

4-7.1 STANDARD CMOS SETUP ....................................... 27

4-7.2 BIOS FEATURES SETUP .......................................... 29

4-7.3 CHIPSET FEATURES SETUP ................................... 33

4-7.4 POWER MANAGEMENT SETUP .............................. 36

4-7.5 PnP/PCI CONFIGURATION ....................................... 40

4-7.6 LOAD SETUP DEFAULTS ......................................... 43

4-7.7 INTEGRATEDPERIPHERALS ................................... 44

4-7.8 SUPERVISOR/USER PASSWORD ........................... 48

4-7.9 IDE HDD AUTO DETECTION .................................... 49

4-7.10 SAVE & EXIT SETUP............................................... 49

4-7.11 EXIT WITHOUT SAVING .......................................... 49

56H5 / 56H1

CHAPTER 1

INTRODUCTION

1-1 ITEM LIST CHECKUP

• Soltek Motherboard

• Soltek Support CD

• Soltek User’s Manual

• Soltek 2-in-1 Bonus Pack CD

• Soltek 2-in-1 Bonus Pack Manual

• 1.44MB floppy ribbon cable

• Ribbon cable for master and slave UltraDMA/33&UltraDMA/66 IDE

devices

1-2 CPU

• Supports Intel Pentium MMX CPUs at 166 ~ 233MHz.

• Supports Cyrix 6x86(L) CPUs at PR133+ ~ PR200+.

• Supports Cyrix 6x86(MII) CPUs at 300 ~ 466.

• Supports AMD K6-2 CPUs at 300 ~ 550MHz.

• Supports AMD K6-III CPUs at 400 ~ 550MHz.

• Supports IDT C6 CPUs at 200 ~ 300MHz.

• Supports 66/ 75/ 83/ 95/ 97/ 100/ 112/ 133 MHz CPU clock.

1-3 CHIPSET

• VIA Apollo MVP3 chipset.

• VIA 686A south bridge chip that supports UATA33/66, Hardware

Monitor function.

• PCI Rev 2.1 and APM 1.1/1.2 compliant.

• AGP v2.0(1x, 2x transfer mode) compliant.

1-4 MEMORY CAPABILITY

• Memory range from 4MB(minimum) to 768MB(maximum) with DRAM

Table Free configuration.

• Supports SDRAM with 8ns / 10ns.

56H5 / 56H1

• Provides 3 pcs of 168pin DIMM sockets(3.3V unbuffered 4 clock type).

1-5 BIOS DESCRIPTION

• Award BIOS.

• Supports Plug & Play (PnP).

• FLASH MEMORY for easy upgrade.

• Supports Advanced Power Management (APM) Rev 1.2 function.

• Supports Advanced Configuration Power Management Interface

(ACPI) Rev 1.0 function.

• Year 2000 compliant.

1-6 MOTHERBOARD DESCRIPTION

• Built-in onboard 512K(56H5) / 1MB(56H1) write back cache with

Piplelined Burst SRAMs.

• ATX form factor with 18.5cm x 30.5cm.

• 4 PCI Master slots, 2 ISA slots, 1 AGP slot, 1 AMR slot.

• One floppy port supports up to 2.88MB.

• 4x Built-in USB(Universal Serial Bus) controller.

• Ultra ATA33/66 bus master IDE supports up to 4 IDE devices.

(Including ZIP / LS-120 floppy devices)

• 2x 16550A Built-in fast UART compatible serial port connectors.

• Built-in SPP / EPP / ECP parallel port connectors.

• Built-in standard IrDA TX / RX header.

• Peripherals boot function with ATX power.

• Supports WOL(Wake On LAN) function. (To support WOL function,

the ATX power supply must support at least 5V standby voltage and

720mA current.)

• Supports Modem Ring Up function.

• Supports SCSI CD-ROM boot up function.

• Supports Power Lost Resume function.

• Integrated Hardware Monitor function.

56H5 / 56H1

1-7 MOTHERBOARD LAYOUT

• Motherboard Default Setting: AMD K6-2 350/100MHz

1 3

2 1

8 7

JP3

JP5 JP6

1 3

JP8

JP9

3 3

1 1

JP15

1 3 JP12

1 3

JP10 1 3 JP11

JFAN2

JFAN1

SPK RST PWR/LED TURBO LED

HD/LED IR PWR SUSPEND

JWOL1

AGP

PCI 1

PCI 2

PCI 3

PCI 4

DI 1

DI 2

DI 3

FDD1

IDE2

IDE1

SOCKET 7

ATX POWER

ISA1

ISA2

FLASH BIOS

Battery

Clock

Generator

LPT1

CO 1 CO 2 PS/2

OUSE

PS/2

K/B

upper

lower

USB1

USB0

upper

lower

Pipelined

Burst

SRA

Pipelined

Burst

SRA

VIA

598

Apollo VP3

VIA

686A

SW1

ON DIP

1 2 3 4 5 6

A R

USB2

2 16

1 15

56H5 / 56H1

WATCH OUT !!!

1. Please refer to your processor installation or other

documentation attached with your CPU for detailed

installing instruction.

2. Installing a heat sink and cooling fan is necessary

for proper heat dissipation from your CPU. Uncor-

rected installation may result in overheating and

damage of your CPU.

3. Before changing the setting of CPU Vcore from

BIOS program, user SHOULD make sure of correct

specification both of CPU CLOCK and RATIO.

Uncorrected setting may cause damage to your

CPU.

56H5 / 56H1

1 1 1

2.0V 2.4V 2.8V 3.2V

3.3V

3.4V

3.5V

2.9V

3.0V

3.1V

2.5V

2.6V

2.7V

2.1V

2.2V

2.3V

JP3 JP3 JP3 JP3

Vcore

Voltage

Vcore

Voltage

Vcore

Voltage

Vcore

Voltage

K6-2 400

(or below)

K6-III MMX, 6x86L

K6 166/200

6x86MX(MII)

K6-2 233

IDT C6

Pentium

(P54C),

6x86, K5

CHAPTER 2

HARDWARE SETUP

2-1 VOLTAGE ADJUSTMENT

• CPU Vcore Setting

• CPU Bus Clock Setting

OFF

1 2 3 4 5 6

JP8

JP9

OFF

1 2 3 4 5 6

JP8

JP9

OFF

1 2 3 4 5 6

JP8

JP9

66 Hz 75 Hz 83 Hz

OFF

1 2 3 4 5 6

JP8

JP9

OFF

1 2 3 4 5 6

JP8

JP9

OFF

1 2 3 4 5 6

JP8

JP9

95 Hz 97 Hz 100 Hz

1 2 3 4 5 6

JP8

JP9

OFF

1 2 3 4 5 6

JP8

JP9

112 Hz 133 Hz

CPU CLOCK SELECT

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere SOLTEK Hauptplatine Handbücher

SOLTEK

SOLTEK SL-55D5 Gebrauchs- und Pflegehandbuch

SOLTEK

SOLTEK SL-85DRV3 Bedienungsanleitung

SOLTEK

SOLTEK SL-85SID Bedienungsanleitung

SOLTEK

SOLTEK SL-61A Gebrauchs- und Pflegehandbuch

SOLTEK

SOLTEK SL-67EV1 Gebrauchs- und Pflegehandbuch

SOLTEK

SOLTEK SL-52D2 Bedienungsanleitung

SOLTEK

SOLTEK SL-85ERV4-R Bedienungsanleitung

SOLTEK

SOLTEK SL-54A2-S Bedienungsanleitung

SOLTEK

SOLTEK SL-865G3 Bedienungsanleitung

SOLTEK

SOLTEK SL-85DR-C Bedienungsanleitung

SOLTEK

SOLTEK SL-65EP Bedienungsanleitung

SOLTEK

SOLTEK SL-65KVB Bedienungsanleitung

SOLTEK

SOLTEK SL-55F5 Bedienungsanleitung

SOLTEK

SOLTEK B9A-FGR Bedienungsanleitung

SOLTEK

SOLTEK SL-85LIR Bedienungsanleitung

SOLTEK

SOLTEK SL-67G60 Gebrauchs- und Pflegehandbuch

SOLTEK

SOLTEK SL-65MIV Bedienungsanleitung

SOLTEK

SOLTEK SL-65ME-T Bedienungsanleitung

SOLTEK

SOLTEK SL-67D Bedienungsanleitung

SOLTEK

SOLTEK SL-56D1 Bedienungsanleitung

SOLTEK

SOLTEK SL-K890-754G Bedienungsanleitung

SOLTEK

SOLTEK 86SP2 Bedienungsanleitung

SOLTEK

SOLTEK 865Pro-FGR Bedienungsanleitung

SOLTEK

SOLTEK SL-75DRV3/75DRV3+ Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
