SOLTEK SL-75LIV Bedienungsanleitung
R
The Soul Of Computer Technology
SL-75LIV USER MANUAL v1.0
Product Model : SL-75LIV
Manual Revision : V1.0
Release Date : July 001
• AMD Athlon ThunderbirdTM, and DuronTM processors are trademarks of AMD Corporation.
• VIA, VT8 01A APOLLO PLE133 and VT82C 8 B are trademarks of VIA Corporation.
T
NOTICE
his Users Guide & Technical Reference is to help system manu-
facturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for print-
ing or clerical errors. Information in this document is subject to
change without notice and does not represent a commitment on the
part of Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek Computer Inc. provides this manual “As is “ without warranty
of any kind, either express or implied, including but not limited to the
implied warranties or conditions of merchantability or fitness for a
particular purpose. In no event shall Soltek Computer Inc. be liable
for any loss or profits, loss of business, loss of use or data, interruption of
business, or for indirect, special, incidental, or consequential damages of
any kind, even if Soltek Computer Inc. has been advised of the possibility
of such damages arising from any defect or error in this manual or product.
Copyright © 2001 So tek Computer Inc. A Rights Reserved.
SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 30 -3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei-
Hsien, Taiwan, R.O.C.
Telephone : 88 -2-2 42-90 0
Fax : 88 -2-2 42-90 5
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOUL TECHNOLOGY EUROPE B.V.
Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-
erlands
Telephone : 31-10-2457492
Fax : 31-10-2457493
E-mail : [email protected]
Web site : http://www.soultech-europe.com
75LIV
4
C O N T E N T
CHAPTER 1 INTRODUCTION ................................................. 8
1-1 MAINBOARD SPECIFICATION .................................................. 9
1-1.1 PROCESSOR ....................................................................... 9
1-1.2 CHIPSET .............................................................................. 9
1-1.3 ADVANCED HIGH-PERFORMANCE DRAM CONTROLLER 9
1-1.4 INTEGRATED HIGH PERFORMANCE 2D/3D GRAPHICS . 9
CONTROLLER ..................................................................... 9
1-1.5 AWARD BIOS V .0 ............................................................... 9
1-1. SOUND CONTROLLER ..................................................... 10
1-1.7 MULTI-I/O FUNCTION ........................................................ 10
1-1.8 POWER MANAGEMENT ................................................... 10
1-1.9 HARDWARE MONITOR ..................................................... 10
1-1.10 EXPANSION SLOTS .........................................................11
1-1.11 FORM FACTOR .................................................................11
1-1.12 OTHERS ............................................................................11
1-2 MOTHERBOARD LAYOUT --- 75LIV ....................................... 12
1-3 CHIPSET DIAGRAM--- 75LIV................................................... 13
CHAPTER 2 HARDWARE SETUP......................................... 15
2-1 CPU INSTALLATION ................................................................ 1
2-2 MEMORY INSTALLATION ........................................................ 17
2-3 HDD/FDD INSTALLATION ........................................................ 18
2-4 SWITCH SETTING FOR CPU FREQUENCY AND VOLTAGE. 20
2-4.1 Information On AMD Socket 4 2 Processor ....................... 20
2-4.2 CPU External Frequency Setting (By SW1) ....................... 21
2-4.3 Processor Core Voltage Select (By SW2 DIP1-DIP ) ........ 22
2-4.4 Frequency Ratio Select (By SW3 DIP1-DIP4) .................... 23
2-5 JUMPER SETTING FOR DEVICES ON BOARD ..................... 24
2-5.1 JBAT1 For Clear CMOS Data ............................................. 24
5
2- CONNECTORS CONFIGURATIONS ....................................... 25
2- .1 On Board FAN Connector (FAN1, FAN2, FAN3) ................ 25
2- .2 WOL1 Wake On LAN .......................................................... 2
2- .3 CD-ROM Audio Connector (CD_IN1/CD_IN2) ................... 2
2- .4 Complex Header NJP1 ...................................................... 27
2- .5 Chassis Panel Connector .................................................. 28
2- . ATX Power Supply Connector............................................. 29
2- .7 PS/2 Mouse And PS/2 Keyboard ........................................ 29
2- .8 Serial Ports ......................................................................... 30
2- .9 USB2 Header...................................................................... 31
2-7 IRQ DESCRIPTION .................................................................. 32
CHAPTER 3 SOFTWARE SETUP ......................................... 34
3-1 VIA CHIPSET DRIVER INSTALLATION (4-IN-1 DRIVER) ....... 35
3-2 ONBOARD VGA DRIVER INSTALLATION ............................... 38
3-2.1 Install KLE133 VGA Driver For Windows 95/98/SE ............ 38
3-2.2 Install KLE133 VGA Driver For Windows NT4.0 ................. 38
3-2.3 Install KLE133 VGA Driver For Windows ME .................... 39
3-2.4 Install KLE133 VGA Driver Windows 2000 ........................ 39
3-3 AC’97 AUDIO CODEC INSTALLATION .................................... 40
CHAPTER 4 BIOS SETUP ..................................................... 42
4-1 WHAT IS BIOS SETUP............................................................. 43
4-2 HOW TO RUN BIOS SETUP .................................................... 43
4-3 WHAT IS CMOS ....................................................................... 43
4-4 WHAT IS POST ........................................................................ 43
4-5 BIOS UPGRADE....................................................................... 43
4-5.1 Before Upgrading BIOS ...................................................... 44
4-5.2 Upgrade Process ................................................................ 44
75LIV
6
4- BIOS SETUP --- CMOS SETUP UTILITY................................. 48
4- .1 CMOS SETUP UTILITY ...................................................... 48
4- .2 STANDARD CMOS SETUP................................................ 49
4- .3 ADVANCED BIOS FEATURES ........................................... 52
4- .4 ADVANCED CHIPSET FEATURES .................................... 57
4- .5 INTEGRATED PERIPHERALS ........................................... 3
4- . POWER MANAGEMENT SETUP....................................... 8
4- .7 PNP / PCI CONFIGURATION............................................. 75
4- .8 SMARTDOC ANTI-BURN SHIELD ..................................... 78
4- .9 FREQUENCY/VOLTAGE CONTROL ................................. 80
4- .10 LOAD OPTIMIZED DEFAULTS ........................................ 82
4- .11 SET SUPERVISOR / USER PASSWORD ........................ 83
4- .12 SAVE & EXIT SETUP ....................................................... 84
4- .13 EXIT WITHOUT SAVING .................................................. 84
APPENDICES ......................................................................... 86
APPENDIX-1 TECHNICAL TERMS ............................................... 87
APPENDIX-2 IDENTIFYING BIOS VERSION AND BIOS PART
NUMBER................................................................. 88
APPENDIX-3 IDENTIFYING MAINBOARD MODEL NUMBER ..... 90
7
Mainboard
Support CD
User’s Manual
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
ATA /100 IDE Cable
RS232 Cable
FDD Cable
ITEMLIST CHECKUP
75LIV
8
CHAPTER 1
INTRODUCTION
• This chapter briefly introduces the characteristics of this mainboard.
It includes the information regarding the chipset, CPU types, built-in
functions and layout. Users will have more ideas about mainboards
after reading this chapter.
This chapter contains the fo owing topics :
1-1 MAINBOARD SPECIFICATION
1-2 MAINBOARD LAYOUT
1-3 CHIPSET DIAGRAM
Chapter 1 Introduction
9
1-1.1 PROCESSOR
• Supporting AMD AthlonTM Thunderbird processors up to 1.5GHz.
• Supporting AMD AthlonTM Duron processors up to 1.2GHz.
• Supporting processor VID (voltage ID) and FID (frequency ID) auto
detection.
• Supporting AMD AthlonTM processor with 200 and 2 MHz Front Side
bus.
• Supporting AMD AthlonTM 4 processors (Palomino).
1-1.2 CHIPSET
• North Bridge VIA VT83 1 (KLE-133) system controller High Performance
Athlon CPU Interface.
• South Bridge VIA VT82C 8 B PCI to ISA bridge.
1-1.3 ADVANCED HIGH-PERFORMANCE DRAM CONTROLLER
• Supporting PC133 and PC100 SDRAM up to 3 DIMMs.
• 4-bit data width and 3.3V DRAM interface.
• Supporting up to 7 8MB memory space.
• Supporting different DRAM types may be used in mixed combinations.
1-1.4 INTEGRATED HIGH PERFORMANCE 2D/3D GRAPHICS
CONTROLLER
• 4-bit Single Cycle 2D/3D Graphics Engine.
• Supporting 8 Mbytes of Frame Buffer.
• Integrated 24 bit 230MHz True Color DAC.
• Extended Screen Resolutions up to 1 00x1200.
• Extended Text Mode 80 or 132 columns by 25/30/43/ 0 rows.
• Supporting full AGP v2.0 capability.
1-1.5 AWARD BIOS V6.0
• Plug & Play V1.0.
• Flash Memory for easy upgrade.
• BIOS writing protection.
• Year 2000 compliant.
• SMARTDOC ANTI-BURN SHIELD.
• RedStorm Overclocking Tech.
1-1 MAINBOARD SPECIFICATION
75LIV
10
1-1.6 SOUND CONTROLLER
• SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio
Controller with Codec onboard.
1-1.7 MULTI-I/O FUNCTION
• Two Ultra DMA 33/ /100 Master Mode PCI EIDE ports.
• Two UART’s for Complete Serial Ports.
• Dedicated IR connector:
-- Third serial port dedicated to IR function either through the two complete serial
ports or the third dedicated port Infrared-IrDA (HPSIR) and ASK (Amplitude Shift
Keyed) IR.
• Multi-mode parallel connector supporting:
-- Standard mode, ECP and EPP.
• Floppy Disk connector supporting:
-- Two FDDs connector with drive swap support .
• Universal Serial Bus connector supporting:
-- USB v1.1 and Intel Universal HCI v1.1 compatible.
-- 2 built-in USB connectors and one USB Header (USB2) which requires an optional
USB cable to provide 2 more optional USB ports.
• PS/2 Keyboard connector.
• PS/2 Mouse connector.
1-1.8 POWER MANAGEMENT
• ACPI 1.0 compliant (Advanced Configuration and Power Interface).
• APM V1.2 compliant (Legacy power management).
• Supporting ACPI POS mode (Power On Suspend).
• Supporting Wake On LAN (WOL) & Wake On Modem (WOM).
• Supporting real time clock (RTC) with date alarm, month alarm, and century
field.
1-1.9 HARDWARE MONITOR
• Programmable control, status, to provide monitoring and alarm for flexible
desktop management of hardware temperature (software provided in
support CD).
• 5-positive voltage.
• 2 Fan-speeds statuses monitoring.
Inhaltsverzeichnis
Andere SOLTEK Hauptplatine Handbücher
SOLTEK
SOLTEK SL-865G3 Bedienungsanleitung
SOLTEK
SOLTEK SL-53A2 Gebrauchs- und Pflegehandbuch
SOLTEK
SOLTEK SL-KT880E-GR Bedienungsanleitung
SOLTEK
SOLTEK 86SP3 Bedienungsanleitung
SOLTEK
SOLTEK SL-54U5 Gebrauchs- und Pflegehandbuch
SOLTEK
SOLTEK SL-85MIR3 Bedienungsanleitung
SOLTEK
SOLTEK SL-85DRV+ Bedienungsanleitung
SOLTEK
SOLTEK SL-65DVB Bedienungsanleitung
SOLTEK
SOLTEK SL-75DRV-X Bedienungsanleitung
SOLTEK
SOLTEK SL-65MV Gebrauchs- und Pflegehandbuch
SOLTEK
SOLTEK 85MR3 Bedienungsanleitung
SOLTEK
SOLTEK KT400 Bedienungsanleitung
SOLTEK
SOLTEK SL-67EZ Gebrauchs- und Pflegehandbuch
SOLTEK
SOLTEK SL-65MIV-C Bedienungsanleitung
SOLTEK
SOLTEK SL-65DRV Bedienungsanleitung
SOLTEK
SOLTEK SL-65KV2-T Bedienungsanleitung
SOLTEK
SOLTEK SL-65LIV-T Bedienungsanleitung
SOLTEK
SOLTEK SL-B9D-FGR Bedienungsanleitung
SOLTEK
SOLTEK SL-85MR2 Bedienungsanleitung
SOLTEK
SOLTEK SL-65GS Bedienungsanleitung
Beliebte Hauptplatine Handbücher anderer Marken
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Bedienungsanleitung
Gigabyte
Gigabyte GA-9IVDT Bedienungsanleitung
Texas Instruments
Texas Instruments ADS8372EVM Bedienungsanleitung
Commell
Commell MS-C73 Bedienungsanleitung
IBT Technologies
IBT Technologies MB860 Bedienungsanleitung
Nvidia
Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung
