White paper

August 2011

R800a, R800at, R88i, R800x

™ PLAY

White paper | Xperia™ PLAY

2 August 2011

This document is published by Sony Ericsson Mobile

Communications AB, without any warranty*. Improvements and

changes to this text necessitated by typographical errors,

inaccuracies of current information or improvements to programs

and/or equipment, may be made by Sony Ericsson Mobile

Communications AB at any time and without notice. Such changes

will, however, be incorporated into new editions of this document.

Printed versions are to be regarded as temporary reference copies

only.

This document may reference services or applications provided by

third parties. Use of such programming or services may require

separate registration with the third party provider and may be

subject to additional terms of use. For applications accessed on or

through a third-party website, please review such website’s terms of

use and applicable privacy policy in advance. Sony Ericsson does

not warrant or guaranty the availability or performance of any third-

party websites or offered services.

Some features described in this document are not supported by all

networks and/or service providers in all areas. Please contact your

network operator or service provider to determine availability of any

specific service or feature and whether additional access or usage

fees apply.

*All implied warranties, including without limitation the implied

warranties of merchantability or fitness for a particular purpose, are

excluded. In no event shall Sony Ericsson or its licensors be liable

for incidental or consequential damages of any nature, including but

not limited to lost profits or commercial loss, arising out of the use of

the information in this document.

This White paper is published by:

Sony Ericsson Mobile Communications AB,

SE-221 88 Lund, Sweden

www.sonyericsson.com

granted a license to download and/or print a

copy of this document.

Any rights not expressly granted herein are

reserved.

Eightth released version (August 2011)

Publication number: 1244-5887

Purpose of this document

Sony Ericsson product White papers are intended to give an overview of a product and provide details in

relevant areas of technology.

Document history

Sony Ericsson Developer World

For the latest Sony Ericsson technical documentation and development tools, go to

www.sonyericsson.com/developer

Version

August 2011 Eighth released version Version 8

White paper | Xperia™ PLAY

3 August 2011

Table of contents

Product overview ........................................................................................................4

Sony Ericsson Xperia™ PLAY - Slide out to wow .................................................4

Xperia™ Play gaming controls ..............................................................................5

Facts – dimensions, weight, performance and networks ......................................6

Categorised feature list ..........................................................................................8

Technologies in detail ...............................................................................................10

Device-to-device communications (local) ...........................................................10

Bluetooth™ wireless technology ......................................................................10

Wi-Fi® ...............................................................................................................11

DLNA Certified™ (Digital Living Home Alliance)*..............................................12

Gaming ................................................................................................................13

Messaging ...........................................................................................................14

MMS (Multimedia Messaging Service)..............................................................14

Email .................................................................................................................14

Positioning – location based services .................................................................15

Synchronisation (OMA DS, EAS, Google Sync) ...................................................15

Hearing Aid Compatibility (HAC) ..........................................................................15

Multimedia (audio, image and video) ...................................................................17

Web browser .......................................................................................................18

Trademarks and acknowledgements ..................................................................19

White paper | Xperia™ PLAY

4 August 2011

Product overview

Sony Ericsson Xperia™ PLAY - Slide out to wow

Slot home the winning goal. Conquer the demon dragons. Hit the ground with guns blazing. Or even work,

if you have to. Simply switch from calls, emails and Internet browsing, to playing your favourite console

games. On Xperia™ PLAY. The full-featured PlayStation™ certified Android™ smartphone with a 4”

screen and real console controls that’s designed to do everything you need. So you can immerse yourself

in the glorious games you want.

Geared up for gaming

Slide out the controls and smash the volley into the top corner. Or crush the enemy in close quarter

combat. In superb stereo sound. Pass like a pro using dedicated gaming keys and view the action on the

whole screen, without your fingers getting in the way. High octane action brought to life with a fast 1GHz

processor and powerful Adreno 205 graphics processor. The crispest colours and true 3D gaming

graphics. Couldn’t be better, could it?

Feast on the fun

What’s your game? Full flowing football on FIFA 10? Or full contact karate with Bruce Lee: Dragon

Warrior? Play the preloaded games, or download what you want from Sony and other top gaming

publishers. Choose from thousands of games on Android Market™. Speak, search, read, play, enjoy. With

more than 100,000 apps available you won’t have time to get bored.

Want more? Get instant access to Google™ mobile services like YouTube™, Google Maps™, Gmail™, or

find what you want on the web with Google Voice Search™. The latest of everything on a smartphone

that’s made for gamers.

White paper | Xperia™ PLAY

5 August 2011

Xperia™ Play gaming controls

Control the game from the palm of your hand. With the unique gaming control design of Sony

Playstation® transformed into Xperia™ Play you will have a gaming experience hard to resist.

Gaming control keys

1. Left trigger

2. Directional buttons

3. Game menu

4. Touch screen

5. Touch pad

6. Button

7. Button

8. Button

9. Button

10. Select key

11. Right trigger

12. Start key

5678910 12

White paper | Xperia™ PLAY

6 August 2011

Facts – dimensions, weight, performance and

networks

Operating system Google™ Android 2.3 (Gingerbread)

Processor 1 GHz Scorpion ARMv7

Size 119 × 62 ×16 mm

Weight 175 grams

Available colours Black

White

Main screen

Colours 16,777,216 colour TFT

Resolution 480×854 pixels

Size (diagonal) 4 inches

Input mechanisms

Text input On-screen QWERTY keyboard

Touch screen Capacitive (multi-touch)

Gesture control Yes

Memory

Phone memory Up to 400 MB

Memory card support microSD™, up to 32 GB

Camera

Camera resolution 5.1 megapixel

Photo flash Yes – LED

Video recording Yes – 480p

Sensors

Accelerometer Yes

Proximity sensor Yes

Ambient light sensor Yes

Magnetometer Yes

eCompass™ Yes

White paper | Xperia™ PLAY

7 August 2011

* Values are according to GSM Association Battery Life Measurement Technique.

NOTE: Battery performance may vary depending on network conditions and configurations, and phone

usage.

Networks

R800a UMTS HSPA 800 (Band VI), 850 (Band V), 1900 (Band II),

2100 (Band I)

GSM GPRS/EDGE 850, 900, 1800, 1900

R800at UMTS HSPA 800 (Band VI), 850 (Band V), 1900 (Band II),

2100 (Band I)

GSM GPRS/EDGE 850, 900, 1800, 1900

R800i UMTS HSPA 900 (Band VIII), 2100 (Band I)

GSM GPRS/EDGE 850, 900, 1800, 1900

R800x CDMA2000®, cdmaOne, EVDO

Data transfer speeds

GSM GPRS (GPRS MS Class 10/

AT&T Class 10)

Up to 80 kbps (download). Up to 20 kbps (upload)

GSM EDGE (E-GPRS MS Class

12)

Up to 237 kbps (download). Up to 59 kbps (upload)

UMTS HSPA (HS-DSCH Cat. 8

download)

Up to 7.2 Mbps

UMTS HSPA (E-DCH Cat. 6

upload)

Up to 5.76 Mbps

1XEV-DO Up to 3.1 Mbps (download). Up to 1.8 Mbps (upload)

Talk time (GSM) Up to 8 hours 25 min*

Standby time (GSM) Up to 425 hours*

Talk time (UMTS) Up to 6 hours 25 min*

Standby time (UMTS) Up to 413 hours*

Talk time (CDMA2000®) Up to 7 hours 40 min*

Standby time (CDMA2000®) Up to 405 hours*

Game play time (Java) Up to 5 hours 35 min

MP3 playback Up to 30 hours 35 min

Battery 1500 mAh

White paper | Xperia™ PLAY

8 August 2011

Categorised feature list

* This service is not available in all markets.

**Available for R800a, R800at, R800i.

***Available for R800x

Camera

5.1 megapixel camera

Auto focus

Flash/Photo light

Front-facing camera (VGA)

Geo tagging

Send to web

Video light

Video recording

Music

Album art

Bluetooth™ stereo (A2DP)

Google Music player***

Music tones (MP3/AAC)

PlayNow™ service*

Sony Ericsson Music player**

Stereo speakers

TrackID™ music recognition*

Internet

Android Market™*

Bookmarks

Google™ search*

Google Voice™ Search*

Pan & zoom

Web browser (Webkit)

Communication

Call list

Conference calls

Facebook™ application (from

Android Market™)

Facebook inside Xperia™ 2.0

Google Talk™ video chat*

Noise Shield

Polyphonic ringtones

Speakerphone

Sony Ericsson Timescape™**

Twitter™ application (from

Android Market™)*

Vibrating alert

Video chat ready

Messaging

Android Cloud to Device

messaging (C2DM)

Conversations

Google Mail™*

Instant messaging

Multimedia messaging (MMS)

Predictive text input

Sound recorder

Text messaging (SMS)

Design

Auto rotation

Keyboard (on-screen, 12 key)

Keyboard (on-screen, QWERTY)

Live wallpaper

Picture wallpaper

Screenshot capturing

Swipe to write

Touch screen

White paper | Xperia™ PLAY

9 August 2011

* This service is not available in all markets.

** Requires Facebook™application installed on the device.

*** Available for R800a, R800at, R800i.

Entertainment

3D games

Accelerated Adobe Flash Video

Dedicated gaming keys

Gesture gaming

Motion gaming

Sony Entertainment Networks*

Video streaming

YouTube™*

Organiser

Alarm clock

Calculator

Calendar

Document editors

Document readers

E-Manual

Flight mode

Google Calendar™*

Google Gallery 3D*

Infinite button***

Phonebook

Setup guide

Widget manager

Connectivity

3.5 mm audio jack

aGPS*

Bluetooth™ technology

DLNA Certified™***

Google Latitude™*

Google Location Service*

Google Maps™ with Street View*

Media Transfer Protocol support

Micro USB Support

Native USB tethering*

Modem

Synchronisation via Facebook™**

Synchronisation via Google

Sync™*

Synchronisation via Microsoft®

Exchange ActiveSync®

Synchronisation via Sony

Ericsson Sync***

USB High Speed 2.0 support

USB mass storage

USB OTG

Wi-Fi®

Wi-Fi® Hotspot functionallity*

White paper | Xperia™ PLAY

10 August 2011

Technologies in detail

NOTE: The information outlined below is general and levels of compliance to standards and specifications

may vary between products and markets. For more information, contact Sony Ericsson Developer World

or your Sony Ericsson contact person where applicable.

Device-to-device communications (local)

Bluetooth™ wireless technology

Bluetooth™ profiles supported Advanced Audio Distribution Profile

Audio/Video Control Transport Protocol

Audio/Video Distribution Transport Protocol

Audio/Video Remote Control Protocol

Generic Audio/Video Distribution Profile

Hands-Free Profile

Headset Profile

Object Push Profile

Phone Book Access Profile

RFCOMM with TS 07.10

Serial Port Profile

Core version and supported

core features

v2.1 + EDR

Connectable devices All products supporting Bluetooth™ version 1.2 or higher

and at least one of the profiles above.

Andere Handbücher für XPERIA PLAY R800x

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Sony Ericsson Handy Handbücher

Sony Ericsson

Sony Ericsson W302 Walkman Kurzanleitung

Sony Ericsson

Sony Ericsson Z610i Bedienungsanleitung

Sony Ericsson

Sony Ericsson WT19i Kurzanleitung

Sony Ericsson

Sony Ericsson Aino Bedienungsanleitung

Sony Ericsson

Sony Ericsson K800i Bedienungsanleitung

Sony Ericsson

Sony Ericsson P1c Bedienungsanleitung

Sony Ericsson

Sony Ericsson K790 Einrichtungshandbuch

Sony Ericsson

Sony Ericsson Cyber-Shot K770 Bedienungsanleitung

Sony Ericsson

Sony Ericsson J120 Bedienungsanleitung

Sony Ericsson

Sony Ericsson Walkman W715 Bedienungsanleitung

Sony Ericsson

Sony Ericsson Z550c Bedienungsanleitung

Sony Ericsson

Sony Ericsson CYBER-SHOT C510 Bedienungsanleitung

Sony Ericsson

Sony Ericsson K530i Bedienungsanleitung

Sony Ericsson

Sony Ericsson Walkman W8 Service-Handbuch

Sony Ericsson

Sony Ericsson Walkman W580i Kurzanleitung

Sony Ericsson

Sony Ericsson Z310 Bedienungsanleitung

Sony Ericsson

Sony Ericsson R800i Bedienungsanleitung

Sony Ericsson

Sony Ericsson T258c Bedienungsanleitung

Sony Ericsson

Sony Ericsson K660i Bedienungsanleitung

Sony Ericsson

Sony Ericsson W880i Bedienungsanleitung

Sony Ericsson

Sony Ericsson XPERIA X8 Bedienungsanleitung

Sony Ericsson

Sony Ericsson Z500 Series Bedienungsanleitung

Sony Ericsson

Sony Ericsson Cyber-Shot K770 Bedienungsanleitung

Sony Ericsson

Sony Ericsson J100a Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
