Sony CDX-L550V Bedienungsanleitung

Operating Instructions

Návod k obsluze

Instrukcje Obsługi

Kullanım kılavuzu

Инструкция по эксплуатации

FM/MW/LW Compact Disc Player

CDX-L550X CDX-L550V

CDX-L550

For installation and connections, see the supplied installation/connections manual.

Informace o instalaci a zapojení naleznete v přiložené příručce Instalace/zapojení.

Szczegóły dotyczące instalacji i podłączeń, proszę sprawdzić w dostarczonym,

osobnym podreczniku.

Kurma ve bağlantı işlemleri için ünite beraberındeki Kurma/Bagiantıiar kıiavuzuna

bakınız.

Перед установкой и подсоединениями прочитайте прилагаемую инструкцию по

установке и подсоединению.

3-227-661-32 (1)

Compact Disc

Player

Welcome!

Thank you for purchasing this Sony Compact

Disc Player. You can enjoy its various features

even more with:

•CD TEXT information (displayed when a CD

TEXT disc* is played).

• Optional controller accessories

Rotary commander RM-X4S

*A CD TEXT disc is an audio CD that includes

information such asthe disc name, artist name, and

track names. This information is recorded on the

disc.

Table of Contents

Location of controls . . . . . . . . . . . . . . . . . . . 4

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Notes on discs . . . . . . . . . . . . . . . . . . . . . . . . 6

Getting Started

Resetting the unit. . . . . . . . . . . . . . . . . . . . . . 7

Detaching the front panel . . . . . . . . . . . . . . . 7

Setting the clock . . . . . . . . . . . . . . . . . . . . . . 8

CD Player

Playing a disc. . . . . . . . . . . . . . . . . . . . . . . . . 9

Display items. . . . . . . . . . . . . . . . . . . . . . . . . 9

Playing tracks repeatedly

—Repeat Play . . . . . . . . . . . . . . . . . . . . 10

Playing tracks in random order

—Shuffle Play . . . . . . . . . . . . . . . . . . . . 10

Radio

Storing stations automatically

—Best Tuning Memory (BTM). . . . . . . 10

Receiving the stored stations. . . . . . . . . . . . 11

Storing only the desired stations . . . . . . . . . 11

RDS

Overview of RDS . . . . . . . . . . . . . . . . . . . . 12

Automatic retuning for best reception results

—AF function . . . . . . . . . . . . . . . . . . . . 13

Receiving traffic announcements

—TA/TP . . . . . . . . . . . . . . . . . . . . . . . . 14

Presetting RDS stations with AF and TA

setting. . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Tuning in stations by programme type

—PTY . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Setting the clock automatically

—CT . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Other Functions

Using the rotary commander. . . . . . . . . . . . 16

Adjusting the sound characteristics . . . . . . 18

Quickly attenuating the sound . . . . . . . . . . 18

Changing the sound and display settings

—Menu . . . . . . . . . . . . . . . . . . . . . . . . . 18

Selecting the sound position

—My Best sound Position (MBP) . . . . 19

Setting the equalizer . . . . . . . . . . . . . . . . . . 20

Additional Information

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 21

Removing the unit. . . . . . . . . . . . . . . . . . . . 21

Specifications . . . . . . . . . . . . . . . . . . . . . . . 22

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 23

Error displays/Messages. . . . . . . . . . . . . . . 24

Location of controls

Refer to the pages listed for details.

: During Playback : During radio reception : During menu mode

aVolume control dial 14

bMBP button 19

cZ(eject) button (located on the front side

of the unit, behind the front panel) 9

dSOURCE (Power on/Radio/CD) button

8, 9, 10, 11, 14, 20

eDisplay window

fMENU button 8, 10, 14, 16, 19, 20

gS (SCROLL) button 9

hOPEN button 7, 9

iPTY (DSPL) (programme type/display

mode change) button

12, 15

jEQ7 button 20

kRESET button (located on the front side of

the unit, behind the front panel) 7

lNumber buttons

(3) REP 10

(6) SHUF 10

10, 11, 13, 14

mMODE button

10, 11, 14

nSOUND button 18, 19

oAF button 13, 14

pTA button 14

qOFF (Stop/Power off) button*7, 9

rENTER button

8, 10, 14, 15, 16, 19, 20

*Warning when installing in a car without

an ACC (accessory) position on the

ignition switch

After turning off the ignition, be sure to press

(OFF) on the unit for 2 seconds to turn off the

clock display.

Otherwise, the clock display does not turn off

and this causes battery drain.

CD RADIO MENU

CDX-L550X/L550V/L550

OFF

PTY

SOUND

ENTER

MBP

SOURCE

REP

SHUF

MODE

EQ 7

SEEK

DSPL

SEEK

OPEN

SCROLL

RADIO

sPRESET buttons (+/–)

11, 12, 15

8, 10, 14, 16, 19, 20

tSEEK buttons (–/+)

11, 13

8, 16, 18, 19, 20

Precautions

• If your car was parked in direct sunlight, allow

the unit to cool off before operating it.

• Power aerials will extend automatically while

the unit is operating.

If you have any questions or problems

concerning your unit that are not covered in this

manual, please consult your nearest Sony dealer.

Moisture condensation

On a rainy day or in a very damp area, moisture

condensation may occur inside the lenses and

display of the unit. Should this occur, the unit

will not operate properly. In such a case, remove

the disc and wait for about an hour until the

moisture has evaporated.

To maintain high sound quality

Be careful not to splash juice or other soft drinks

onto the unit or discs.

OFF

PTY

SOUND

ENTER

SEEKSEEK

OPEN

DSPL

SCROLL

(SEEK)

(–): to select

leftwards/

(SEEK)

(+): to select

rightwards/

(PRESET)

(+): to select upwards

In menu mode, the currently selectable button (s)

of these four are indicated with a “ M” in the display.

(PRESET)

(–): to select downwards

RADIO

Notes on discs

•To keep the disc clean, do not touch the surface.

Handle the disc by its edge.

•Keep your discs in their cases or disc

magazines when not in use.

Do not subject the discs to heat/high

temperature. Avoid leaving them in parked cars

or on dashboards/rear trays.

•Do not attach labels, or use discs with sticky

ink/residue. Such discs may stop spinning

when used, causing a malfunction, or may ruin

the disc.

•Discs with non-standard shapes (e.g., heart,

square, star) cannot be played on this unit.

Attempting to do so may damage the unit. Do

not use such discs.

•You cannot play 8cm CDs.

•Before playing, clean the discs with a

commercially available cleaning cloth. Wipe

each disc from the centre out. Do not use

solvents such as benzine,thinner, commercially

available cleaners, or antistatic spray intended

for analog discs.

Notes on CD-R/CD-RW discs

•You can play CD-Rs (recordable CDs)

designed for audio use on this unit.

Look for this mark to distinguish CD-Rs for

audio use.

This mark denotes that a disc is not for audio

use.

•Some CD-Rs (depending on the equipment

used for its recording or the condition of the

disc) may not play on this unit.

•You cannot play a CD-R that is not finalized*.

*A process necessary for a recorded CD-R disc to

be played on the audio CD player.

•You cannot play CD-RWs (rewritable CDs) on

this unit.

Getting Started

Resetting the unit

Before operating the unit for the first time or

after replacing the car battery, you must reset the

unit.

Remove the front panel and press the RESET

button with a pointed object, such as a ballpoint

pen.

Note

Pressing the RESET button will erase the clock setting

and some stored contents.

Detaching the front panel

You can detach the front panel of this unit to

protect the unit from being stolen.

Caution alarm

If you turn the ignition switch to the OFF

position without removing the front panel, the

caution alarm will beep for a few seconds.

If you connect an optional amplifier and do not

use the built-in amplifier, the beep sound will be

deactivated.

1Press (OFF)*.

CD playback or radio reception stops (the key

illumination and display remain on).

*If your car has no ACC position on the ignition

switch, be sure to turn the unit off by pressing

(OFF) for 2 seconds to avoid car battery drain.

2Press (OPEN), then slide the front panel

to the right, and gently pull out the left

end of the front panel.

Notes

•If you detach the panel while the unit is still turned

on, the power will turn off automatically to prevent

the speakers from being damaged.

•Do not drop or put excessive pressure on the front

panel and its display window.

•Do not subject the front panel to heat/high

temperature or moisture. Avoid leaving it in parked

cars or on dashboards/rear trays.

Tip

When carrying the front panel with you, use the

supplied front panel case.

continue to next page t

RESET button

Attaching the front panel

Place hole Aof the front panel onto the spindle

Bon the unit, then lightly push the left side in.

Press (SOURCE) (or insert a CD) to operate the

unit.

Note

Do not put anything on the inner surface of the front

panel.

Setting the clock

The clock uses a 24-hour digital indication.

Example: To set the clock to 10:08

1Press (MENU), then press either side of

(PRESET) repeatedly until “CLOCK”

appears.

1Press (ENTER).

The hour indication flashes.

2Press either side of (PRESET) to set

the hour.

3Press the (+) side of (SEEK).

The minute indication flashes.

4Press either side of (PRESET) to set

the minute.

2Press (ENTER).

The clock starts. After the clock setting is

completed, the display returns to normal play

mode.

Tips

•You can set the clock automatically with the RDS

feature (page 16).

•When D.INFO mode is set to ON, the time is always

displayed (page 18).

CD Player

Playing a disc

1Press (OPEN) and insert the disc

(labelled side up).

2Close the front panel.

Playback starts automatically.

If a disc is already inserted, press (SOURCE)

repeatedly until “CD”appears to start playback.

Note

When the last track on the disc is over, playback

restarts from the first track of the disc.

Display items

When the disc/track changes, any prerecorded

title* of the new disc/track is automatically

displayed (if the Auto Scroll function is set to

“ON,”names exceeding 8 characters will be

scrolled (page 18)).

*Only for CD TEXT discs with the artist name.

Notes

•Some characters cannot be displayed.

•For some CD TEXT discs with very many

characters, information may not scroll.

•This unit cannot display the artist name for each

track of a CD TEXT disc.

Tip

When Auto scroll is set to OFF and the disc/track

name is changed, the disc/track name does not scroll.

To Press

Stop playback (OFF)

Eject the disc (OPEN) then Z

Skip tracks

–Automatic

Music Sensor

(SEEK) (./>)

[once for each track]

Fast-forward/

reverse

–Manual Search

(SEEK) (m/M)

[hold to desired point]

To Press

Switch display

item (RTY/DSPL)

Scroll display item (SCROLL)

Displayable items

•Music source

•Clock

•Function

Displayable items

•Elapsed playback time

•Disc name/artist name*

•Track title*

Playing tracks repeatedly

— Repeat Play

The current track will repeat itself when it

reaches the end.

During playback, press (3) (REP) until

“REP-ON“appears in the display.

Repeat Play starts.

To return to normal play mode, select “REP-

OFF.”

Playing tracks in random

order

— Shuffle Play

You can select to play the tracks on the current

disc in random order.

During playback, press (6) (SHUF)

repeatedly until “SHUF-ON“appears in

the display.

Shuffle Play starts.

To return to normal play mode, select “SHUF-

OFF.”

Radio

The unit can store up to 6 stations per band

(FM1, FM2, FM3, MW, and LW).

Caution

When tuning in stations while driving, use Best

Tuning Memory to prevent accidents.

Storing stations

automatically

— Best Tuning Memory (BTM)

The unit selects the stations with the strongest

signals within the selected band, and stores them

in the order of their frequency.

1Press (SOURCE) repeatedly to select the

radio.

2Press (MODE) repeatedly to select the

band.

3Press (MENU), then press either side of

(PRESET) repeatedly until “BTM”

appears.

4Press (ENTER).

A beep sounds when the setting is stored.

Notes

•If only a few stations can be received due to weak

signals, some number buttons will retain their former

settings.

•When a number is indicated in the display, the unit

starts storing stations from the one currently

displayed.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Sony Autoempfänger Handbücher

Sony

Sony DSX-S210X Bedienungsanleitung

Sony

Sony XR-C540RDS Bedienungsanleitung

Sony

Sony CDX-GT450U Produkthandbuch

Sony

Sony CDX-M600 - Fm/am Compact Disc Player Bedienungsanleitung

Sony

Sony XR-7150 Bedienungsanleitung

Sony

Sony WX-C5000 Bedienungsanleitung

Sony

Sony MDX-C6400R Bedienungsanleitung

Sony

Sony CDX-CA690X Bedienungsanleitung

Sony

Sony CDX-MP450X Primary User Manual (English Bedienungsanleitung

Sony

Sony AVD-S50 Bedienungsanleitung

Sony

Sony CDX-GT410U - Fm/am Compact Disk Player Produkthandbuch

Sony

Sony CDX-L450X Operating Instructions (English,... Produkthandbuch

Sony

Sony CDX-CA600X Bedienungsanleitung

Sony

Sony CDX-GT54UIW - Cd Receiver Mp3/wma/aac Player Bedienungsanleitung

Sony

Sony XR-CA350X - Fm-am Cassette Car Stereo Bedienungsanleitung

Sony

Sony CDX-GT240 Bedienungsanleitung

Sony

Sony Bluetooth 4-158-429-31(1) Bedienungsanleitung

Sony

Sony CDX-F605X - Fm/am Compact Disc Player Produkthandbuch

Sony

Sony XR-CA650X - Fm-am Cassette Car Stereo Bedienungsanleitung

Sony

Sony Xplod CDX-F7700 Bedienungsanleitung

Sony

Sony CDX-R3300 - Fm/am Compact Disc Player Bedienungsanleitung

Sony

Sony XR-C7220R Bedienungsanleitung

Sony

Sony CDX-CA730X Bedienungsanleitung

Sony

Sony CDX-GT440U - Fm/am Compact Disc Player Bedienungsanleitung

Beliebte Autoempfänger Handbücher anderer Marken

Motorola

Motorola VWA63 Bedienungsanleitung

Nextar

Nextar D3201 Bedienungsanleitung

Alpine

Alpine CDE-163BT Bedienungsanleitung

Pioneer

Pioneer DEH-P645R Bedienungsanleitung

Axxera

Axxera XDMA7600 Betriebsanleitung

XM OnyX Bedienungsanleitung

Sound Storm

Sound Storm STM93R Bedienungsanleitung

Soundstream

Soundstream VIR-5000 Bedienungsanleitung

Avson

Avson MKT Platform Bedienungsanleitung

Pioneer

Pioneer DVH-P500UB Bedienungsanleitung

JVC

JVC KD-AHD69 Bedienungsanleitung

Blaupunkt

Blaupunkt SANTIAGO CR 87 Bedienungsanleitung

XFIRE AUDIO

XFIRE AUDIO BMW42S Bedienungsanleitung

VDO

VDO CD 2253 Bedienungsanleitung

Volvo

Volvo 13 84 580 Bedienungsanleitung

ZENEC

ZENEC ZE-160DVD Bedienungsanleitung

Medion

Medion Car Audio Bedienungsanleitung

Philips

Philips CEM5000 Bedienungsanleitung
