Sony CDX-MP40 Installation/Connection Bedienungsanleitung

Signal-to-noise ratio 90 dB

Frequency response 10  20,000 Hz

Wow and lutter Below measurable limit

General

Design and Speci ications subject to change without notice.

CD Player Section

Tuning range 87.5  107.9 MHz

Antenna terminal External antenna connector

Intermediate requency 10.7 MHz/450kHz

Usable sensitivity 9 dB

Selectivity 75 dB at 400 kHz

Signal-to-noise ratio 67 dB (stereo), 69 dB (mono)

Harmonic distortion at 1 kHz 0.5% (stereo), 0.3% (mono)

Separation 33 dB at 1 kHz

Frequency response 30  15,000 Hz

Tuning range 530  1,710 kHz

Antenna terminal External antenna connector

Intermediate requency 10.7 MHz/450 kHz

Sensitivity 30 µV

Outputs Speaker outputs (sure seal connectors)

Speaker impedance 4  8 ohms

Maximum power output 52 W × 4 (at 4 ohms)

Outputs Audio outputs ( ront/rear)

Power antenna relay control terminal

Power ampli ier control terminal

Inputs Telephone ATT control terminal

Remote controller input terminal

BUS control input terminal

BUS audio input terminal

Antenna input terminal

Tone controls Low: ±10 dB at 60 Hz (XPLOD)

Mid: ±10 dB at 1 kHz (XPLOD)

High: ±10 dB at 10 kHz (XPLOD)

Power requirements 12 V DC car battery (negative ground)

Dimensions Approx. 178 × 50 × 180 mm

(7 1/8 × 2 × 7 1/8 in.) (w/h/d)

Mounting dimensions Approx. 182 × 53 × 161 mm

(7 1/4 × 2 1/8 × 6 3/8 in.) (w/h/d)

Mass Approx. 1.2 kg (2 lb. 10 oz)

Supplied accessories Card remote commander RM-X115

Parts or installation and connections

Front panel case (1)

This unit cannot be connected to a digital preampli ier or an equalizer which is

Sony BUS system compatible.

CDX-MP40

FM/AM Compact Disc Player

Power Amplifier Section

Note

2003 SONY MOBILE

PRODUCT GUIDE

 XM Ready

 XT-XM1Control

 SSIR-EXA Tuner

 MP3 & CD-R/RW Playback

 Front & Rear Preouts

 Blue 13-segment negative LCD, clock

 Flip-down Detachable Face

 52W x 4 High Power

 8 s, 1-Bit D/A Converter

 Active Servo Control

 60 Degree Install

 18FM + 12AM memory presets

 CD/MD Control w/Custom File memory, CD Text

 DSO, EQ3

 Supplied Wireless Card Remote (RM-X115)

 Optional Wired Rotary Remote (RM-X4S)

 Indicates step-up

MS Section

Audio Power Specifications

POWER OUTPUT AND TOTAL HARMONIC DISTORTION

23.2 watts per channel minimum continuous average power into 4 ohms, 4 channels driven rom 20 Hz to 20 kHz with no more than 5%

total harmonic distortion.

Plug shown with wires acing viewer.

Pin Number Wire Color Description

1 White Le t ront +

2 Green Le t rear +

3 Purple Right rear +

4 Gray Right ront +

5 Blue/white AMP Remote

6 Blue ANT Remote

7 Red Accessory

8 Black Ground

9 White/black Le t ront -

10 Green/black Le t rear -

11 Purple/black Right rear -

12 Gray/black Right ront -

13 Sky blue ATT

16 Yellow Battery

Harness Plug Configuration

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15

178 mm (7)

2003 SONY MOBILE

PRODUCT GUIDE

CDX-MP40

FM/AM Compact Disc

50 mm (2)

Fuse (10A)

162 mm (6 3/8)

50 mm (2)

Design and Speci ications subject to change without notice.

Remote IN

Audio OUT Rear

BUS Audio IN

Audio OUT Front

BUS Control IN

178 mm (7 1/4)

47 mm (1 7/8)

53 mm ( 2 1/16)

88 mm (3 7/16)

33 mm (1 5/16)

27 mm (1 1/16)
