Sony DSX-GS80 Bedienungsanleitung

5-006-640-11(1)

DSX-GS80

FM/AM

Bluetooth® Car Audio

Owner’s Record

The model and serial numbers are located on the

bottom of the unit.

Record these numbers inthe spaces provided below.

Refer tothese numbers whenever you call upon your

Sony dealer regarding this product.

Model No. DSX-GS80

Serial No.

Operating Instructions GB

Mode d’emploi FR

To cancel the demonstration (DEMO) display,

seepage 8.

For the connection/installation, see page 13.

Pour annuler l’affichage dedémonstration

(DEMO), reportez-vous à lapage XX.

Pour leraccordement/l’installation, reportez-vous à

la page XX.

2GB

The nameplate indicating operating voltage,

etc., is located on the bottom of the chassis.

The validity of the CEmarking is restricted to

only those countries where it islegally

enforced, mainly in the countries EEA

(European Economic Area) and Switzerland.

Warning

For safety, be sure toinstall this unit in

the dashboard of the car as the left side

ofthe unit becomes hot during use.

For details, see “Connection/

Installation” (page 13).

FOR THE CUSTOMERS IN THE USA.

NOT APPLICABLE IN CANADA,

INCLUDING IN THE PROVINCE OF

QUEBEC.

POUR LES CLIENTS AUX ÉTATS-UNIS.

NON APPLICABLE AU CANADA, Y

COMPRIS LA PROVINCE DE QUÉBEC.

This equipment has been tested and

found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the

FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses, and can

radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined by

turning the equipment off and on, the

user is encouraged to try to correct the

interference by one or more of the

following measures:

– Reorient or relocate the receiving

antenna.

– Increase the separation between the

equipment and receiver.

– Connect the equipment into an outlet

on a circuit different from that to which

the receiver is connected.

– Consult the dealer or an experienced

radio/TV technician for help.

You are cautioned that any changes or

modifications not expressly approved in

this manual could void your authority to

operate this equipment.

3GB

This device complies with part 15 of FCC

Rules and Innovation, Science and Economic

Development Canada’s licence-exempt

RSS(s). Operation is subject to the following

two conditions:

(1) this device may not cause harmful

interference, and

(2) this device must accept any interference

received, including interference that may

cause undesired operation.

This transmitter must not be co-located or

operated in conjunction with any other

antenna ortransmitter.

This equipment complies with FCC/ISED

radiation exposure limits set forth for an

uncontrolled environment and meets the

FCC radio frequency (RF) Exposure

Guidelines and RSS-102 ofthe ISED radio

frequency (RF) Exposure rules as this

equipment has very low levels of RF energy.

If you have any questions about this

product:

Visit: https://www.sony.com/electronics/

support

Contact: Sony Customer Information Service

Center at1-800-222-7669

Write: Sony Customer Information Service

Center 12451 Gateway Blvd., Fort Myers, FL

33913

Supplier’s Declaration ofConformity

Trade Name: SONY

Model: DSX-GS80

Responsible Party: Sony Electronics Inc.

Address: 16535 Via Esprillo, San Diego, CA

92127 U.S.A.

Telephone Number: 858-942-2230

This device complies with part 15 of the FCC

rules. Operation issubject to the following

two conditions:

(1) This device may not cause harmful

interference, and

(2) this device must accept any interference

received, including interference that may

cause undesired operation.

For the State of California, USA only

Perchlorate Material – special handling may

apply, See

www.dtsc.ca.gov/hazardouswaste/

perchlorate

WARNING: Do not ingest

battery, Chemical Burn Hazard.

The remote commander contains a

coin/button cell battery. If the coin/button

cell battery is swallowed, it can cause severe

internal burns in just 2 hours and can lead to

death.

Keep new and used batteries away from

children. If the battery compartment does

not close securely, stop using the product

and keep it away from children.

If you think batteries might have been

swallowed or placed inside any part of the

body, seek immediate medical attention.

Note on the lithium battery

Do not expose the battery to excessive heat

such as direct sunlight, fire or the like.

Warning ifyour car’s ignition hasno

ACC position

Be sure toset the AUTO OFFfunction.

The unit willshut off completely and

automatically in the set time after the

unit is turned off and the clock is

displayed (i.e. press and hold OFFfor 1

second), which prevents battery drain. If

you do not set the AUTO OFF function,

press and hold OFFuntil the display

disappears each time you turn the

ignition off.

Disclaimer regarding services offered

by third parties

Services offered by third parties may be

changed, suspended, or terminated without

prior notice. Sony does not bear any

responsibility inthese sorts of situations.

Caution

IN NOEVENT SHALL SONY BE LIABLE FOR

ANY INCIDENTAL, INDIRECT OR

CONSEQUENTIAL DAMAGES OR OTHER

DAMAGES INCLUDING, WITHOUT

LIMITATION, LOSS OF PROFITS, LOSS OF

REVENUE, LOSS OF DATA, LOSS OF USE OF

THE PRODUCT OR ANY ASSOCIATED

EQUIPMENT, DOWNTIME, AND PURCHASER’S

TIME RELATED TO ORARISING OUT OF THE

USE OF THIS PRODUCT, ITS HARDWARE

AND/OR ITS SOFTWARE.

Dear customer, this product includes a radio

transmitter.

Please check your vehicle operation manual

or contact the manufacturer of your vehicle

or your vehicle dealer, before you install this

product into your vehicle.

Emergency calls

This BLUETOOTH car handsfree and the

electronic device connected to the

handsfree operate using radio signals,

cellular, and landline networks aswell as

user-programmed function, which cannot

guarantee connection under all conditions.

Therefore do notrely solely upon any

electronic device for essential

communications (such as medical

emergencies).

On BLUETOOTH communication

Microwaves emitting from a BLUETOOTH

device may affect the operation of

electronic medical devices. Turn off this

unit and other BLUETOOTH devices in the

following locations, as it may cause an

accident.

– where inflammable gas is present, in a

hospital, train, airplane, or petrol station

– near automatic doors or a fire alarm

This unit supports security capabilities that

comply with the BLUETOOTH standard to

provide a secure connection when the

BLUETOOTH wireless technology is used,

but security may not be enough

depending on the setting. Be careful when

communicating using BLUETOOTH wireless

technology.

We do not take any responsibility for the

leakage of information during BLUETOOTH

communication.

If you have any questions or problems

concerning your unit that are not covered in

this manual, consult your nearest Sony

dealer.

Important notice

4GB

5GB

Guide to Parts and Controls

PTY (program type)

Select PTY in RDS.

(browse)

Enter the browse mode during playback.

(Not available when a USB device in

AndroidTM mode oriPod is connected.)

Front panel release button

SRC (source)

Turn on the power.

Change the source.

OFF

Press and hold for 1 second to turn the

source off and display the clock.

Press and hold for more than 2 seconds

to turn off the power and the display.

If the unit is turned off and the display

disappears, operation by the remote

commander is not available.

Control dial

PUSH ENTER

Enter the selected item.

Press SRC, rotate then press to change

the source (timeout in2 seconds).

Open the setup menu.

VOICE

Press andhold for more than 2

seconds to activate voice dial, voice

recognition (Android smartphone

only), or the Siri function (iPhone only).

 Disc slot

 Display window

 USB port







/ (SEEK–/+)

Tune in radio stations automatically.

Press and hold totune manually.

/(prev/next)

/(fast-reverse/fast-forward)

(back)

Return to theprevious display.

MODE

CALL

Enter the call menu. Receive/end a call.

Press and hold for more than 2 seconds

to switch the BLUETOOTH signal.

Receptor for the remote commander

Main unit



Rotate toadjust the volume.

Front panel removed (inner panel)

6GB

Number buttons (1to6)

Receive stored radio stations. Press and

hold to store stations.

ALBUM /

Skip an album for audio device. Press and

hold to skip albums continuously.

(Not available when a USB device in

Android mode oriPod is connected.)

Press to thumbs up, orto thumbs

down inPandora®.

(repeat)

(Not available when a USB device in

Android mode is connected.)

(shuffle)

(Not available when a USB device in

Android mode is connected.)

MIC

(play/pause)

EXTRA BASS

Reinforces bass sound in synchronization

with the volume level. Press to change

the EXTRA BASS setting: [1], [2], [OFF].

AUX input jack

DSPL (display)

Press to change display items.

SCRL (scroll)

Press and hold to scroll a display item.

The VOL (volume) + button has a tactile dot.

SOUND

Open the SOUND menu directly.

Press and hold to open the setup menu.

///

Select a setup item, etc.

ENTER

Enter the selected item.

Press and hold for more than 2 seconds

to establish or terminate the “Sony |

Music Center” function.

/(prev/next)

+/– (album +/–)

VOL (volume) +/–

Remove the insulation film before use.

RM-X231 Remote commander



















 RESET (inner panel)



7GB

Detaching the Front Panel

You can detach the front panel of this unit to

prevent theft.

1Press and hold OFF until the unit

turns off, press the front panel

release button , then pull the panel

towards you to remove.

Caution alarm

If you turn theignition switch to theOFF

position without detaching the front panel,

the caution alarm will sound for a few

seconds. Thealarm will only sound ifthe

built-in amplifier is used.

Getting Started

Attaching the front panel

Resetting the Unit

Before operating the unit for the first time,

or after replacing the car battery or

changing connections, you must reset the

unit.

Press RESET on the inner panel with a ball-

point pen, etc., after detaching the front

panel.

Note

Resetting the unit will erase the clock setting and

some stored contents.

Pairing with a Bluetooth®

Device

When connecting a BLUETOOTH device for

the first time, mutual registration (called

“pairing”) isrequired. Pairing enables this

unit and other devices to recognize each

other. This unit can connect two

BLUETOOTH devices (two mobile phones,

ora mobile phone and anaudio device).

1 Press MENU, then rotate and press

the control dial to select [BLUETOOTH]

[PAIRING] [DEVICE 1]/[DEVICE 2]*.

flashes while theunit is in pairing

standby mode.

* [DEVICE 1]or[DEVICE 2] will be changed to

the paired device name after pairing is

complete.

2Perform pairing on the BLUETOOTH

device so it detects this unit.

3 Select your model name shown in

the display of the BLUETOOTH device*.

When pairing is made, stays lit.

* If passkey input is required on the

BLUETOOTH device, input [0000].



8GB

select [GENERAL], then press it.

2 Rotate the control dial to select [DEMO],

then press it.

3 Rotate the control dial to select

[DEMO-OFF], then press it.

The setting is complete.

4Press (back) twice.

The display returns to normal reception/

play mode.

Canceling the Demonstration

Mode

You can cancel the demonstration display

which appears when the source isoffand the

clock is displayed.

1 Press MENU, rotate the control dial to

Updating the Firmware

To update thefirmware, visit thesupport site on

theback cover, then follow the online

instructions.

Notes

 Using a USB device (not supplied) isrequired for

updating the firmware. Store the updater in the USB

device, and connect the device to the USB port, then

perform the update operation.

Updating the firmware takes a few minutes to

complete. During the update, do not turn the

ignition to theOFF position, nor remove the USB

device.

About Help Guide

For details on the functions and operations that are

not covered in this manual, refer to Help Guide.

http://xxxxxxxxx

9GB

Precautions

• Do not leave the front panel or audio

devices on the dashboard.

• When the unit is turned on, the power

antenna (aerial) extends automatically.

• Do not splash liquid onto the unit.

Additional Information

• You can connect tothe following iPod

models. Update your iPod devices tothe

latest software before use.

• Use of the Made for Apple badge means

that an accessory has been designed to

connect specifically to the Apple product(s)

identified in the badge, and has been

certified by the developer to meet Apple

performance standards. Apple is not

responsible for the operation of this device

or its compliance with safety and

regulatory standards.

Please note that the use of this accessory

with an Apple product may affect wireless

performance.

If you have any questions or problems

concerning your unit that are not covered in

this manual, consult your nearest Sony

dealer.

Playback order of audio files

Folder (album)

Audio file (track)

About iPod

Compatible Model Bluetooth® USB

iPhone XR 

iPhone Xs max 

iPhone Xs 

iPhone X 

iPhone 8 

iPhone 8 Plus 

iPhone 7 

iPhone 7 Plus 

iPhone SE 

iPhone 6s 

iPhone 6s Plus 

iPhone 6 

iPhone 6 Plus 

iPhone 5s 

iPhone 5c 

iPhone 5 

iPhone 4s 

iPod touch

(6th generation) 

iPod touch

(5th generation) 

iPod nano

(7th generation) 

Compatible iPhone/iPod models

10GB

Maintenance

Replacing the lithium battery (CR2025)

of the remote commander

When the battery becomes weak, the range

of the remote commander becomes shorter.

CAUTION

Danger of explosion if battery is incorrectly

replaced. Replace only with the same or

equivalent type.

Note onthe lithium battery

Keep the lithium battery out of the reach of

children. Should the battery beswallowed,

immediately consult a doctor.

Cleaning the connectors

Avoid touching the connectors directly. The

unit may not function properly if the

connectors between the unit and the front

panel are not clean. Inorder to prevent

this, detach the front panel (page 7)and

clean the connectors with a cotton swab.

Do not apply too much force. Otherwise, the

connectors may be damaged.

Note

For safety, do not remove the front panel while

driving.

Specifications

FOR THE CUSTOMERS IN THE USA. NOT

APPLICABLE IN CANADA, INCLUDING IN

THE PROVINCE OF QUEBEC.

POUR LES CLIENTS AUX ÉTATS-UNIS.

NON APPLICABLE AU CANADA, Y

COMPRIS LA PROVINCE DE QUÉBEC.

AUDIO POWER SPECIFICATIONS

CTA2006 Standard

Power Output: 45 Watts RMS ×

4 at 4 Ohms < 1% THD+N

SN Ratio: 80dBA

(reference: 1 Watt into 4 Ohms)

Tuner section

Tuning range: 87.5 MHz – 107.9 MHz

Usable sensitivity: 8dBf

Signal-to-noise ratio: 73 dB

Separation: 50 dBat 1 kHz

Tuning range: 530kHz – 1,710 kHz

Sensitivity: 26 μV

+ side up

Lithium battery (CR2025)

USB Player section

Interface: USB (High-speed)

Maximum current:

Front: 1 A

Rear: 1.5 A

Maximum number ofrecognizable files

(tracks): 10,000

Compatible Android Open Accessory

protocol (AOA): 2.0

Corresponding codec:

MP3 (.mp3)

Bit rate: 8 kbps – 320 kbps (Supports

VBR (Variable Bit Rate))

Sampling rate: 16 kHz – 48 kHz

WMA (.wma)

Bit rate: 32 kbps – 192 kbps (Supports

VBR (Variable Bit Rate))

Sampling rate: 32 kHz, 44.1 kHz,

48 kHz

AAC (.m4a, .mp4)

Bit rate: 8 kbps – 320 kbps

Sampling rate: 11.025 kHz – 48 kHz

WAV (.wav)

Bit depth: 16 bit

Sampling rate: 44.1 kHz, 48 kHz

Andere Handbücher für DSX-GS80

Inhaltsverzeichnis

Andere Sony Autoradiosystem Handbücher

Sony

Sony XDP-PK1000 Bedienungsanleitung

Sony

Sony DSX-B41D Bedienungsanleitung

Sony

Sony XS-GTR120L Bedienungsanleitung

Sony

Sony CDX-565MXRF Operating Instruction correction: multi-session... Bedienungsanleitung

Sony

Sony Pressman TCM-5000EV Bedienungsanleitung

Sony

Sony SCXXES-Z50 Bedienungsanleitung

Sony

Sony DSX-GS900 Bedienungsanleitung

Sony

Sony XAV-A1 - Av Center Bedienungsanleitung

Sony

Sony XM-1502SX - Stereo Power Amplifier Installationsanleitung

Sony

Sony CDX-M9900 Operating Instructions (primary... Produkthandbuch

Sony

Sony XPlod MEX-BT5000 Installationsanleitung

Sony

Sony CDX-GT54UIW - Cd Receiver Mp3/wma/aac Player Bedienungsanleitung

Sony

Sony DVX-11A - Car Mp3/dvd/cd Single Player Bedienungsanleitung

Sony

Sony GT620U - CDX Radio / CD Bedienungsanleitung

Sony

Sony XR-C6220R Produkthandbuch

Sony

Sony CDX-5V661 Bedienungsanleitung

Sony

Sony XDP-MU110 Bedienungsanleitung

Sony

Sony MEX-BT2800 - Bluetooth Audio System Bedienungsanleitung

Sony

Sony CDX-454RF - Compact Disc Changer System Produkthandbuch

Sony

Sony XR-1790 Bedienungsanleitung

Sony

Sony MEX-BT2900 Bedienungsanleitung

Sony

Sony MEX-BT4700U Produkthandbuch

Sony

Sony BluetoothH MEX-BT5100 Bedienungsanleitung

Sony

Sony XAV-70BT Produkthandbuch

Beliebte Autoradiosystem Handbücher anderer Marken

JL Audio

JL Audio Stealthbox SB-CAN-G2MVX3D/10TW3 Bedienungsanleitung

Clarion

Clarion PU-9836A Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric AR0M Bedienungsanleitung

Insignia

Insignia NS-HD5113 Bedienungsanleitung

Clarion

Clarion BTD3341 Bedienungsanleitung

USA SPECS

USA SPECS PA11-VW6 Bedienungsanleitung

Kenwood

Kenwood KCD-BT6544U/UY Bedienungsanleitung

JVC

JVC KD-DB912BT Bedienungsanleitung

Philips

Philips CSQ405/98 Bedienungsanleitung

Alpine

Alpine TDM-7544 Bedienungsanleitung

Autotek

Autotek TransAm TA 1400 Bedienungsanleitung

Clarion

Clarion PN-3124N-A Bedienungsanleitung

Denso TEN

Denso TEN FT0108A Bedienungsanleitung

Pyle

Pyle PLD57MU Bedienungsanleitung

Harman

Harman Chrysler Radio Navigation System RB4 Bedienungsanleitung

Clarion

Clarion VS735 Bedienungsanleitung

JVC

JVC KW-R910BT Bedienungsanleitung

Eclipse

Eclipse CD2000 Bedienungsanleitung
