EDITING CONTROL UNIT

BVE-700

INSTALLATION MANUAL

1st Edition

Serial No. 10001 and Higher

BVE-700

!WARNING

This manual is intended for qualified service personnel only.

To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so. Refer all servicing to

qualified service personnel.

!WARNUNG

Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.

Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die

Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei

Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung

dazu besitzen.

!AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin

de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les

réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.

Pour toute réparation faire appel à une personne compétente uniquement.

Attention-when the product is installed in Rack:

1. Prevention against overloading of branch circuit

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

make sure that the rack does not overload the supply

circuit.

2. Providing protective earth

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

confirm that the outlet is provided with a suitable

protective earth connection.

3. Internal air ambient temperature of the rack

When this product is installed in a rack, please make

sure that the internal air ambient temperature of the

rack is within the specified limit of this product.

4. Prevention against achieving hazardous

condition due to uneven mechanical loading

When this product is installed in a rack, please make

sure that the rack does not achieve hazardous

condition due to uneven mechanical loading.

1 (E)

BVE-700

Table of Contents

Manual Structure

Purpose of this manual ........................................................................................ 2 (E)

Related manuals................................................................................................... 2 (E)

Trademarks .......................................................................................................... 2 (E)

Installation

1-1. Operating Environment .........................................................................1-1 (E)

1-2. Power Supply ........................................................................................1-1 (E)

1-3. Installation Space ..................................................................................1-2 (E)

1-4. Matching Connectors and Cables..........................................................1-4 (E)

1-5. Input/Output Signals of Connectors......................................................1-5 (E)

1-6. Switch Settings on Boards and LED Description .................................1-8 (E)

1-7. Rack Mounting....................................................................................1-11 (E)

1-8. Installing the BKE-701 .......................................................................1-12 (E)

2 (E) BVE-700

Purpose of this manual This manual is the installation manual of Editing Control Unit BVE-700.

This manual is intended for use by trained system and service engineers, and

describes the information on installing the BVE-700.

Related manuals Beside this Installation Manual, the following manuals are available for the unit.

.User’s Guide (Supplied with BVE-700)

This manual describes the application and operation of the unit.

.Operation Manual (Supplied with BVE-700)

This manual describes the overview, system connection examples, and specifica-

tions of the unit.

.BKE-701 Installation Manual (Supplied with BKE-701)

This manual describes the information related to the installation of the unit.

.BVE-700/BKE-701 Maintenance Manual (Available on request)

This manual describes the information that premise the service of BVE-700/BKE-

701 based on components replaced.

Trademarks Trademarks and registered trademarks used in this manual are follows.

Windows is a registered trademark of Microsoft Corporation.

.IBM is a registered trademark of International Business Machine, Inc.

.Ethernet is a registered trademark of Xerox Corporation.

Manual Structure

1-1 (E)

BVE-700

1-1. Operating Environment

Operating guaranteed temperature : +5 dC to +35 dC

Performnace guaranteed temperature : +10 dC to +30 dC

Operating humidity : 10 % to 90 %

(relative humidity)

Storage temperature : _20 dC to +60 dC

Mass : 10 kg

Prohibited locations

.Areas where the unit will be exposed to direct sunlight or

any other strong lights.

.Dusty areas

.Areas where it is subject to vibration.

.Areas with strong electric or magnetic fields.

.Areas near heat sources.

.Areas where is subjected to electricity noise.

.Areas where is subjected to static electricity noise.

Ventilation

The inside of the BVE-700 is cooled by a fan (rear and

sides).

The power supply can be damaged if the exhaust vent (rear

panel) and air intake (front panel) are blocked or the fan is

stopped.

Therefore, leave a blank space of more than 10 cm in the

front and back of the BVE-700.

1-2. Power Supply

1. Power specifications

A switching regulator is used for the power supply of this

unit. The voltage within the range of 100 V to 240 V can

be used without changing the supply voltage.

Power requirements : AC 100 to 240 V ±10 %

50/60 Hz

Current consumption : Maximum 2.5 A

(with all optional boards installed)

As the inrush current at turn-on is the maximum 25 A (at

100 V/50 A (at 200 V), the capacity of the AC power must

be commensurate in it.

If the capacity of the AC power is not the adequately large,

the breaker of the AC power at the supply side will operate

or the unit will abnormally operate.

Installation

2. Recommended Power Cord

.The power cord is not supplied with the BVE-700. Be

sure to use the power cord that is applicable to places in

the area.

To avoid a fire or an electric shock, be sure to use the

designated power cord.

.Do not damage the power cord.

Otherwise, a fire or electric shock may result.

Required Parts for the U.S.A. and Canada

1Power cord : !1-551-812-11

Required Parts for Europe

1Power cord : !1-782-929-21

AC inlet

1-2 (E) BVE-700

1-3. Installation Space

Processor unit

26.5

520

440

465

57.2

375

482

61 380

17.5

132.4

Unit : mm

1-3. Installation Space

1-3 (E)

BVE-700

Control panel unit

Unit : mm

340

315.5

281

277.2

315

16.9

1-3. Installation Space

1-4 (E) BVE-700

1-4. Matching Connectors and Cables

Use the following connectors, cables, or equivalents when connecting cables to the unit.

Panel indication Connector name Matching connector and cable

Name Sony part No.

Processor unit

PLAYER-1 D-sub 9-pin, Female D-sub 9-pin, Male

PLAYER-2 Connector 9-pin, Male 1-560-651-00*1

PLAYER-3 Junction Shell 9-pin 1-561-749-00

RECORDER

MIXER

SWER

Processor unit

EDL D-sub 9-pin, Male D-sub 9-pin, Female

Connector 9-pin, Female 1-563-815-21

Junction Shell 9-pin 1-561-749-00

Processor unit

GPI D-sub 15-pin, Female D-sub 15-pin, Male

Connector 15-pin, Male 1-564-600-11*1

Junction Shell 15-pin 1-563-376-11

Processor unit

SDI INPUT BNC, 75 ZBNC, 75 Z

SDI OUTPUT 5C-FB coaxial cable*3

Processor unit

REF VIDEO BNC, 75 ZBNC, 75 Z

5C-2V coaxial cable*4

Processor unit/Control panel unit

PANEL D-sub 25-pin, Female D-sub 25-pin, Male

Connector 25-pin, Male 1-560-904-11*1

Junction Shell 25-pin 1-563-377-11

Processor unit

NETWORK RJ-45 modular jack*2__

*1 : To use plugs, the following crimp contacts are required.

AWG #18 to #22 : 1-566-493-21

AWG #22 to #24 : 1-564-774-11

AWG #24 to #30 : 1-564-775-11

*2 : Conforms to the IEEE 802.3 Ethernet 10BASE-T/100BASE-TX standards.

*3 : It is recommend to use the 5C-FB coaxial cable of Fujikura America Inc. or Fujikura Europe Ltd.

*4 : It is recommend to use the 5C-2V coaxial cable of Fujikura America Inc. or Fujikura Europe Ltd.

1-4. Matching Connectors and Cables

1-5 (E)

BVE-700

1-5. Input/Output Signals of Connectors

The input/output signals of the connectors at the rear panel

are as follows.

.Processor unit

PLAYER-1

PLAYER-2

PLAYER-3

RECORDER

MIXER

SWER : RS-422A (D-sub 9-pin, Female)

Pin No. Signal Function

1 GND Ground

2RX_Received data (_)

3TX+Transmitted data (+)

4 GND Ground

5_No Connection

6 GND Ground

7 RX+ Received data (+)

8TX_Transmitted data (_)

9_No Connection

EDL : RS-232C (D-sub 9-pin, Male)

Pin No. Signal Function

1_No Connection

2 RXD Received data

3 TXD Transmitted data

4_No Connection

5 GND Ground

6_No Connection

7 RTS (Not used at present)

8 CTS (Not used at present)

9_No Connection

_ EXT VIEW _

GPI : D-sub 15-pin, Female

Pin No. Signal Function

1 GND Ground

2 OUT-1A Relay output-1A

3 OUT-2A Relay output-2A

4 OUT-3 (TTL) Open collector output-3

5 OUT-4 (TTL) Open collector output-4

6 IN-1 (TTL) Input-1

7 IN-3 (TTL) Input-3

8 GND Ground

9 OUT-1B Relay output-1B

10 OUT-2B Relay output-2B

11 _No Connection

12 _No Connection

13 GND Ground

14 IN-2 (TTL) Input-2

15 IN-4 (TTL) Input-4

EXT VIEW

1-5. Input/Output Signals of Connectors

1-6 (E) BVE-700

PANEL : D-sub 25-pin, Female

Pin No. Signal Function

1 GND Ground

2 12 V Panel Power Supply

3RX+Received data (+)

4 GND Ground

5TX_Transmitted data (_)

6 12 V Panel Power Supply

7 12 V Panel Power Supply

8_No Connection

9 GND Ground

10 GND Ground

11 GND Ground

12 GND Ground

13 GND Ground

14 12 V Panel Power Supply

15 12 V Panel Power Supply

16 RX_Received data (_)

17 GND Ground

18 TX+Transmitted data (+)

19 12 V Panel Power Supply

20 GND Ground

21 _No Connection

22 GND Ground

23 12 V Panel Power Supply

24 12 V Panel Power Supply

25 GND Ground

NETWORK : 10BASE-T/100BASE-TX (8-pin, Modular jack)

Pin No. Signal Function

1TX+Transmitted data (+)

2TX_Transmitted data (_)

3RX+Received data (+)

4_No Connection

5_No Connection

6RX_Received data (_)

7_No Connection

8_No Connection

EXT VIEW

_ EXT VIEW _

1-5. Input/Output Signals of Connectors

Andere Handbücher für BVE-700

Inhaltsverzeichnis

Andere Sony Steuereinheit Handbücher

Sony

Sony FCB-ER8550 Bedienungsanleitung

Sony

Sony FCB-CX20DP Bedienungsanleitung

Sony

Sony HXCU-100 Bedienungsanleitung

Sony

Sony PWS-100 Bedienungsanleitung

Sony

Sony FCB-EV7300 Bedienungsanleitung

Sony

Sony RM-450 Bedienungsanleitung

Sony

Sony HDCU-700A Konfigurationshandbuch

Sony

Sony CCU-550A Bedienungsanleitung

Sony

Sony DCU-8000 Bedienungsanleitung

Sony

Sony BKM-16R Bedienungsanleitung

Sony

Sony CCU-TX50 Bedienungsanleitung

Sony

Sony BKMA-7045 Bedienungsanleitung

Sony

Sony HXCU-TX70 Bedienungsanleitung

Sony

Sony RM-450 Bedienungsanleitung

Sony

Sony BKS-R1617 Bedienungsanleitung

Sony

Sony BKM-104 Bedienungsanleitung

Sony

Sony BKNW-26 Bedienungsanleitung

Sony

Sony RMU-01 Bedienungsanleitung

Sony

Sony BKM-17R Bedienungsanleitung

Sony

Sony BKM-15R Bedienungsanleitung

Sony

Sony BVE-700 Bedienungsanleitung

Sony

Sony HDCU3100 Bedienungsanleitung

Sony

Sony HXCU-FB80 Bedienungsanleitung

Sony

Sony CCP-6224 CCP-6324 MKS-8010B MKS-8011AMKS-8013A MKS-8014A MKS-8015A MKS-8017AMKS-8018A MKS-8019A MKS-8020A... Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung

Flyron

Flyron FN-BC04 Bedienungsanleitung
