Quick Start Guide
English
CUH-7116B 7029915
Welcome to the future of play.
Rear view
Connect to your TV.
Follow steps to below to connect your PlayStation®4 system to
your TV. You must use the supplied HDMI cable for the connection.
Let's get started
AC IN connector HDMI OUT port HDMI input port
HDMI™ cable
AC power cord
To an electricity supply
You can transfer saved data from your current PS4™ system to your new PS4™
system. If you intend to do this, we recommend completing the data transfer
during the initial set up process for your new system. If you do it later, any
saved data on the new system will be lost. For guidance on transferring data
and the types of data you can transfer, refer to the User’s Guide.
manuals.playstation.net/gb/04.html
2
Connect to the Internet.
We recommend use of a LAN cable (sold separately) for a more
stable network connection.
If you prefer to use a wireless connection (Wi-Fi), don't connect a
LAN cable.
Get the most out of your PS4™ system by connecting to the Internet. You’ll be
able to play games online and connect with Friends.*1
Rear view
LAN port
LAN cable
(sold separately)
Type of connection:
Router Internet connected device
such as a modem
To the Internet
3
EN
Front view
Power button/Power indicator
Turn on your TV and set the input to HDMI.
Turn on your PS4™ system by pressing the
(power) button.
The power indicator blinks blue, and then turns white.
If your TV does not display a picture when the power indicator turns white,
restart your system. Press the (power) button for at least 7 seconds to turn
off your system, and then turn it on again.
4
Connect your DUALSHOCK®4 wireless controller
to your system using the USB cable, and then
press the (PS) button.
Your controller pairs with your system and turns on.
• You'll need to pair a controller when you use it for the first time and when
you use your controller on another PS4™ system. If you want to use two or
more controllers, you must pair each controller.
• After you've paired your controller, you can disconnect the USB cable and use
your controller wirelessly.
• It's possible to use up to four controllers at the same time. When you press
the (PS) button, the light bar glows in your assigned colour. The first
controller to connect is blue, with subsequent controllers glowing red, green,
and pink.
Front view
USB port USB port
USB cable
PS button
5
EN
Make it your own.
You're almost done! Follow the on-screen instructions to set up an
Internet connection, set the date and time, and configure other
settings - then select [Start Now] from the setup screen.
After you set up your Internet connection, a system software
update may automatically download. Future updates will improve
performance and add new features.
Will a child be using your PS4™ system? If so, be sure to read the
"Parental controls" section.
To later change any settings that you skipped, select (Settings) from the
function screen.
6
If children will be using the PS4™ system, parents or guardians can
restrict access to certain content or features using parental
controls.
For details on what can be restricted and how to set restrictions,
refer to the User's Guide.
manuals.playstation.net/gb/01.html
You can restrict the use of games that have age limitations by
setting the parental control level according to the following table.
Europe, Africa and India
Player’s Age Under
33-6 7-11 12-15 16-17 18 and
over
PS4™ Parental
Control Setting 1 2 3 5 7 9
Highest game age
rating
Germany
Player’s Age Under 6 6-11 12-15 16-17 18 and
over
PS4™ Parental
Control Setting 1 3 5 7 9
Highest game age
rating
Parental controls
7
EN
Portugal
Player’s Age Under
44-5 6-11 12-15 16-17 18 and
over
PS4™ Parental
Control Setting 1 2 3 5 7 9
Highest game age
rating
8
Take a look around
Function screen
Access PS4™ system features,
including notifications, your
Friends, and settings.
Content info screen
The latest information about the
selected content is displayed.
Up button
Up button
Down button
Down button
Home screen
Content area
Access your games and other
content.
9
EN
Start the game
Insert a disc. Select the game from the content area to start
playing.
Return to the home screen from a game
To return to the home screen without ending a game, press the
(PS) button.
To resume playing the game, select it from the content area.
End the game
Press and hold the (PS) button, and then select [Close
Application] from the quick menu that appears.
Eject the disc
Press the (eject) button.
Front view
Let's play
Front view
Eject button
10
