Speco O4MD3 Bedienungsanleitung

Quick Start Guide

O4MD3

1Warning and Caution

■ If the product does not work properly, please contact your

dealer or the nearest service center. Never attempt to disassemble

the camera yourself. Any unauthorized changes or modifications

could void the warranty.

■ Do not allow water or liquid intrusion into the camera.

■ All installation and operation here should conform to local

electrical safety codes. Make sure the device is firmly installed

on the wall or ceiling.

■ Do not use camera beyond specified voltage range.

■ Do not drop the camera or subject it to physical shock.

■ Avoid touching the camera lens.

■ If cleaning is necessary, please use cleaning cloth to wipe it

gently.

■ Do not aim the camera at the sun or extremely bright light

sources.

■ Do not place the camera in extremely hot or cold environments

and dusty and damp locations . Do not expose it to highly

electromagnetic radiation.

■ Do not block any ventilations.

Package

Overview

3 Overview

Ethernet connector

CVBS connector

Reset

Micro SD card slot

MIC in connector

DC power connector

Camera Quick start guide

CD Plastic plug ×2

Drill template Wall mounting bracket

Screwdriver

2 tapping screws PA 4×25

* 1 It is recommended to install the security cap for outdoor installations.

* 2 DC 12V power supply is not required if a PoE switch or injector is used to power

the camera.

► Connecting Network Cable

① Loosen the nut from the main element.

② Run the network cable (without RJ 45 connector) through both

elements. Then crimp the cable with RJ 45 connector.

③ Connect the cable to the hermetic connector. Then tighten the nut

and the main cover.

DC12V

Security Cap

Installation

* Before you start, please make sure that the wall or ceiling is strong enough

to withstand three times the weight of the camera and bracket.

① Loosen the lock screw of the bracket and then remove the

mounting base from the bracket.

② Loosen the screws to remove the lower dome from the camera.

Lower Dome

Lock screw

Mounting base

③ Pull the cables through the bracket. Then fix the camera onto the

bracket with the screws provided.

④ Fix the mounting base of the bracket onto the wall with the screws.

⑥Adjust the camera to obtain an optimum angle . Before adjustment,

preview the image of the camera on a monitor.

⑤ Connect the cables. Then attach the bracket onto the mounting

base and fasten them with the lock screw.

Rotation 0°~350°

Pan 0°~360°

Tilt 0°~70°

Web Operation and Login

● Operation

IP Scanner can search for the device on the local network.

① Make sure that the camera and the PC are connected to the same

local network. The camera is set to DHCP by default.

② Install IP Scanner from the CD and run it after installation.

⑦ Install the lower dome back to the camera with the screws.

③ In the device list, you can view the IP address, model number, and

MAC address of each device. Select the applicable device and double

click to open up the web viewer. You can also manually enter the IP

address in the address bar of the web browser.

The login interface is shown above. Default user name is admin and

password is 1234. After logging in, follow directions to install

applicable plugins.
