Speco WIDE DYNAMIC RANGE CVC624WDR Bedienungsanleitung

Wide Dynamic Range

Dome Camera

CVC624WDR

200 N Hi h

200

Amityville, NY 11701

631-957-8700

www.specotech.com

WARNING & CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED

SERVICE

PERSONNEL

CAUTION

The lighting flash with an arrowhead symbol, within an equilateral triangle is

Intended to alert the user to the presence of un-insulated “dangerous voltage”

within the product’s enclosure that may be of sufficient magnitude to constitute

ariskofelectricshocktopersons____________________________________

The exclamation point within an equilateral triangle is intended to alert the user

to the presence of important operating and maintenance (serving) instructions

the

literature

accompanying

the

appliance

SERVICE

PERSONNEL

_____________

the

literature

accompanying

the

appliance

_________________

INFORMATION -This equipment has been tested and found to company with

limits for a class a digital device Pursuant to part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful

Interference When the equipments operated in a commercial environment.

This equipment generates, uses, and Can Radiate radio frequency energy and

if not installed and used in accordance with the instruction manual, may Cause

Harmful interference to radio communications. Operation of this equipment in a

id ti l

lik l

hfl

it f

hi h

DO NOT use power sources other than that specified.______

res

area

lik

ocause

arm

erence

Casetheuserwillberequiredtocorrecttheinterferenceathisownexpense.

WARNING – Change or modification not expressly approved by the manufacturer could void

the user’s authority to operate the equipment__________________________________

CAUTION : To prevent electric shock and risk of fire hazards.

NOT

expose

this

appliance

rain

moisture

000

NOT

expose

this

appliance

rain

moisture

000

This installation should be made by a qualified service person and should conform to all local codes.

CONTENTS

Package Contents 4

Precautions 5

Camera Installation 6-7

OSD Menu Tree

Features 8

OSD Menu Details 10-12

Troubleshooting 13-14

Specifications 15

Dimensions 16

Warranty 17

PACKAGE CONTENTS

Please make sure that the following items are included

in the package:

1 CVC624WDR Camera

2 Mounting Screws

1 Video Test Connector

Please leave this manual with the end-user for future

reference.

COMPATIBILITY

DFM Series

“A” type Box

Electrical Box is not included in the

acka

e but

Is compatible with the camera

PRECAUTIONS

•THIS CAMERA SHOULD BE ONLY INSTALLED BY QUALIFIED

PERSONNEL

•TO PREVENT A FIRE OR ELECTRICAL HAZARD PLEASE USE

PROPER POWER CABLE

•DO NOT CLEAN THE DOME COVER WITH AN ABRAISIVE

CLEANING MATERIAL - PLEASE USE A SOFT CLOTH OR

TISSUE TO CLEAN THE DOME COVER

•THERE ARE NO USER-SERVICEABLE PARTS INSIDE.

PLEASE DO NOT DISASSEMBLE THIS CAMERA OTHER THAN

TO MAKE INITIAL ADJUSTMENTS

•

PLEASE USE A UL APPROVED REGULATED 12 VOLT DC

•

PLEASE

USE

APPROVED

REGULATED

VOLT

POWER SUPPLY

•PLEASE USE APPROPRIATE LOW VOLTAGE POWER CABLE

TO PREVENT FIRE OR ELECTRICAL SHOCK

•PLEASE INSURE THAT YOUR INSTALLATION AREA CAN

SUPPORT THE WEIGHT OF THE CAMERA

•PLEASE HANDLE THIS CAMERA CAREFULLY:

- DON’T USE A STRONG OR ABRASIVE DETERGENT WHEN

CLEANING THE CAMERA.

- DON’T EXPOSE THE CAMERA TO DIRECT SUN

CAMERA INSTALLATION

CONNECT POWER CABLE

1. WHEN USING 12 VOLTS DC (constant voltage 500 mA)

2. CONNECT VIDEO CABLE

CONNECT BNC CABLE TO THE BNC JACK

DC 12V Power Supply

Power Input :RED

Center : (+)

CONNECT

BNC

CABLE

THE

BNC

JACK

CAMERA INSTALLATION

MECHANICAL

(1) Vari-focal Lens

(2) JOY STICK

(1) VARI-FOCAL LENS

Adjust between TÅÆW (TELE ÅÆ WIDE) to set the

angle (focal length). Set the focus by adjusting ∞ÅÆN

(3) Video Test Terminal

NOTE: BOTH OF THE ABOVE ADJUSTMENTS GET LOCKED

INTO POSITION THROUGH THE USE OF "LOCKING HANDLES".

(2) JOY STICK

TO SET THE OSD (ON SCREEN DISPLAY) , PRESS THE JOY

STICK FOR ONE SECOND AND SET AS DESCRIBED

IN THE MANUAL

(3) VIDEO TEST TERMINAL

FEATURES

1. Superior Wide Dynamic Image Qualit

It has very Wide Dynamic Range by using the Pixim ORCA Chip Set.

Film-like colors are achieved under various Light conditions even in

High Dynamic range scenes , Dynamic Range achieves a maximum

of 120dB.

2 Digital Pixel System

Digital

Pixel

System

Each pixel is processed independently to get clear and usable

images.

3. OSD control

Every function is controlled by OSD menu

- Automatic white balance

utomatic gain control (max 60dB)

- Slow shutter, AGC on/off

- Line lock phase control

- Lens type control

- Auto exposure control

4 High Resolution

High

Resolution

540 lines of horizontal resolution and 460 lines of vertical resolution.

** Pixim and Digital Pixel System are registered trademarks of

Pixim, Inc.

OSD MENU TREE

SPECO MAIN MENU

PRESETS

DEFAULT / INDOOR / OUTDOOR / CUSTOM

SET UP ID

ID POSITION : (UP-LEFT / UP-CENTER / UP-RIGHT

DOWN-LEFT / DOWN-RIGHT)

CAMERA ID : 8 CHARACTER

DISPLAY ID : (OFF / ON)

LENS SELECT

WDR

WB CONTROL

AUTO

OFF

ATW(Range 2K~11K)

MANUAL

MANUAL : (WDR BIAS Range -20 to 20 / WDR RANGE 0 to 36)

LOW LIGHT

SPECIAL

AWB

MANUAL (Range 2K ~11K)

VIDEO : (NTSC / PAL)

FLIP : (OFF / ON)

SLOW SHUTTER : (SHUTTER LIMIT Range OFF~X32 / AGC CONTROL Range 0 to 60)

AUTO D/N

EXIT MENU

FLIP

(OFF

ON)

SYNC : (L,LOCK / INT / INT2)

BACK LIGHT : (OFF / ON : BACK LIGHT ZONES)

RESOLUTION : (NORMAL / HIGH / C_NORMAL / C_HIGH)

COLOR MODE : (COLOR / B/W)

SHARPNESS : ON (Range -8 to 8) / OFF

EXIT NO CHANGE

SAVE NEW AND EXIT

RESTORE FACTORY SETTING

RELEASE VERSION

OSD MENU DETAILS

1. OSD MENU ENTER / EXIT

A. OSD MENU ENTER

• Push Center Key for 2 seconds

B. OSD MENU EXIT

• Press EXIT Menu from Main Menu

• If Pressing Set Key for 2 seconds from Main Menu appears.

In this case, just press Set Key.

C. 'SAVE' and 'QUIT‘

• Left or Right Key - Selecting Menu

• Up or Down Key - Returning to Menu

1. Press the SET key to access the main setup mode.

2. Select the desired feature using the UP or Down key.

3 Change the status of the selected feature using the LEFT or

Change

the

status

the

selected

feature

using

the

LEFT

RIGHT key.

A. PRESETS

• DEFAULT : Optimized for normal scenes

• INDOOR : Optimized for indoor scenes with windows and/or

2. MAIN MENU

glass door to capture details both indoors and outdoors.

• OUTDOOR : Optimized for sunny outdoor scene to capture detail

both in bright areas and shadows.

• CUSTOM : Change the value of the customer.

B. SETUP ID

• DISPLAY ID

ON :The ID name will displayed in the monitor

:The

name

will

displayed

the

monitor

- OFF : The name will not displayed in the monitor.

• CAMERA ID : Enter up to 8 characteristic.

• ID POSITION : Select the screen position of the camera ID.
