USER MANUAL

LM2SPYPOINT

ABOUT US

SPYPOINT’s mission is to oer you products that are easy to use, innovative,

aordable, and of exceptional quality. Our products are mainly used in the

hunting eld and residential and commercial safety elds. They are distributed

and appreciated on all continents and are continuously growing. Prosperous

and respected, SPYPOINT is a company that is constantly developing new

technologies and that remains attentive to its customer’s needs to oer

cutting-edge products with concrete solutions to improve hunting and

outdoor activities.

LM2 PRESENTATION

The LM2 is the evolution of the revolution, with its roots in the wildly popular

LINK-MICRO family of cellular trail cameras that changed the entire industry

on its way to becoming the most popular cellular trail camera of all time. The

LM2 is true to the legacy of aordable, reliable, and easy-to-use cellular trail

cameras that has made SPYPOINT an industry leader.

The LM2 uses cellular network connectivity to communicate information to

the user via the SPYPOINT app such as:

• Photos take by the camera since the last sync

• Camera status

• Camera settings

The LM2 is compact but robust and connects to the LTE cellular network

available in the area. Crisp 20 MP photos, an easy to use interface, and

optimized antenna round out a camera that delivers far more than the

price would indicate.

THANK YOU FOR CHOOSING A SPYPOINT PRODUCT

This User Manual will introduce you to the features of your new LM2 and will

guide you through the acquisition of its functionalities so that you can use it to

its full potential.

Our priority is to oer outstanding service to our customers. If you need

technical support for your camera, here is how to contact us:

Contact our chat service directly on the SPYPOINT site (in the lower right-

hand corner of the Support section, by clicking on the “Start Chat” window,

www.spypoint.com).

• Monday to Friday — 8:30 a.m. to 8:00 p.m.

• Saturday-Sunday — 8:30 a.m. to 5:30 p.m.

Go to www.spypoint.com/en/support for more information about our devices.

JOIN THE SPYPOINT COMMUNITY

www.facebook.com/SPYPOINT

www.twitter.com/SPYPOINTcamera

www.youtube.com/SPYPOINTtrailcam

www.instagram.com/spypointcamera

www.tiktok.com/@spypointcamera

introduction

LM2SPYPOINT

Components ..........................................................................................4

Features...................................................................................................6

Power Supply........................................................................................7

Memory Card ........................................................................................8

Preparation............................................................................................9

Activation ............................................................................................ 10

Installation.......................................................................................... 11

Starting Your Camera..................................................................... 12

Conguration..................................................................................... 13

Verication.......................................................................................... 15

Tool – Accessories – Options....................................................... 17

Transferring Files to a Computer.............................................. 18

Oered Accessories ........................................................................ 19

Troubleshooting............................................................................... 20

Warranty............................................................................................... 23

Regulation........................................................................................... 24

Disposal & frequency..................................................................... 25

Table Of Content

LM2SPYPOINT

qAntenna

wDetection lens

emicroSD card slot

rLight sensor

tDelay light

yPhoto lens

uLED

iOFF/ON switch

oSTATUS light

aSIM card slot

sBattery compartment

dSlot for installation strap

fDoor

gLocking latch

hCable lock hole

j12 V jack

kScrew-thread for standard

¼"-20 tripod mount

lBattery holder

Components

LM2SPYPOINT

ANTENNA

Captures the cellular signal.

DETECTION LENS

Enlarges the detection area of the camera’s motion sensor.

MICROSD CARD SLOT

Space to insert the microSD card (not included)

needed to save photos.

LIGHT SENSOR

Detects the ambient lighting conditions for taking pictures:

in colors during the day, black and white at night.

DELAY LIGHT

During installation, once the signal is found, this light ashes for 30

seconds to allow the user to walk away without being photographed.

PHOTO LENS

Image sensor.

LED

3 powerful LEDs that illuminate at night for clear

black and white photos.

OFF/ON SWITCH

Allows the user to turn the camera OFF/ON.

STATUS LIGHT

During installation, it ashes to indicate to the user the strength of the

cellular signal. During regular operation, it indicates that the camera is

recording or transferring les.

SIM CARD SLOT

Space to insert a SIM card. It is necessary to activate cellular functions.

The SIM card, pre-installed and pre-activated, is included with the camera.

It is important to use a SPYPOINT SIM card (supplied by SPYPOINT),

otherwise the cellular functions of the camera will be inoperative.

BATTERY COMPARTMENT

Space to insert the battery holder.

SLOT FOR INSTALLATION STRAP

Allows the camera to be installed using

the included installation strap.

DOOR

Provides access to the battery compartment,

microSD card, STATUS light, and OFF/ON switch.

LOCKING LATCH

Allows you to lock and open the door.

CABLE LOCK HOLE

Allows you to install a #CLM-6FT padlock cable

to secure the unit (sold separately).

12 V JACK

Allows you to insert a power cord connected

to an external 12 V source.

SCREWTHREAD FOR STANDARD

¼"20 TRIPOD MOUNT

Allows you to attach a standard tripod from ¼"-20.

BATTERY HOLDER

Removable device in which the 8 AA batteries

are inserted (not included with the camera).

Components

LM2SPYPOINT

CELLULAR TRANSMISSION

Network LTE

Transmission plan

Transmission of your photos to your

SPYPOINT application by cellular network.

Visit www.spypoint.com/plans to choose

a plan that suits you.

Camera conguration Fully congurable remotely with the free

SPYPOINT app.

PHOTO RECORDING

Photo resolution 20 MP

Photo le format JPG

Time-lapse mode No

Multi-shot mode Up to 2 photos per detection

Info bar Date, time, temperature (°C/°F), moon

phase, SPYPOINT logo, and camera model

Capture mode Colors by day, black and white by night

VIDEO RECORDING

Video mode No

AUDIO RECORDING

Audio mode No

MEMORY

Internal memory None

External memory microSD card up to 32 GB (not included)

VIEWING

On the SPYPOINT app or on the website www.spypoint.com/en/manage

POWER SOURCES

Alkaline or lithium AA

non-rechargeable batteries 8 x AA (not included)

Lithium battery pack Lithium battery pack #LIT-10

(not included)

External 12 V battery

12 V battery

Optional accessories available at SPYPOINT:

#KIT6V-12V, #KIT-12V, #BATT-12V

Solar panel lithium battery Solar panel lithium battery #SPLB-22

(not included)

DETECTION SYSTEM

Movement detector Infrared

Detection angle 42°

Detection range Up to 27 meters/90 feet

Trigger speed 0.5 seconds

Delay between each detection Adjustable from Instant to 30 minutes

ILLUMINATION OPTIONS

LED 3 powerful LEDs

Night light range Up to 27 meters/90 feet

Exposure Automatic adjustment of the infrared

illumination

PHYSICAL DIMENSIONS

7.9 cm (H) x 11.2 cm (W) x 5.6cm (D) 3.1’’ (H) x 4.4’’ (W) x 2.2’’ (D)

RECOMMENDATIONS

Operating temperature -30 °C to 50 °C (-22 °F to 131 °F)

Storage temperature -40 °C to 60 °C (-40 °F to 140 °F)

Features

LM2SPYPOINT

CHOOSING A POWER SOURCE

4 options are available to you:

• Alkaline or lithium AA batteries

• Rechargeable battery 12 V (#KIT-12V sold separately)

• Rechargeable battery pack 3.7 V (#LIT-10 sold separately)

• Solar panel lithium battery 12 V (#SPLB-22 sold separately)

NOTE

We suggest using a SPYPOINT #LIT-10 rechargeable lithium battery pack with

your camera. It oers a longer battery life than AA batteries, and saves money

over the life of the camera.

FOR BEST RESULTS AND NO LEAKAGE

• Use only new alkaline or lithium batteries.

• Do not mix new and old batteries.

• Do not use rechargeable AA batteries

(their lower voltage can generate operational issues).

HOW TO INSTALL AA BATTERIES PROPERLY

• Unlock the latch and open the LM2 door.

• Remove the battery compartment by grasping

it by the 2 small notches on the side and pulling

it out (see photo).

• Insert the AA batteries into the battery holder

following polarity (+) and (-) indications.

• Place the battery holder back into the battery

compartment. Side notches

SPLB-22 – SOLAR PANEL

LITHIUM BATTERY COMBO UNIT

• Combines solar panel and lithium

battery into one unit to reduce wires

and setup time.

• Plugs directly into camera to provide

extensive, ongoing battery life for

your camera so you can avoid visits.

• Additional jacks and plugs allows for

device exibility.

MANAGING VARIOUS CAMERA

POWER SUPPLY

If you choose to plug an external 12 V battery (#KIT-12V, sold separately)

into your camera, it becomes your camera’s new primary power source.

The AA batteries will only be used once the 12 V battery is depleted.

You can check the battery level of your device:

• In the application: on the home page, you will see the battery charge level

for each of your devices. You can access more details on the status of your

battery by going to the STATUS page. When the battery logo turns red, we

suggest that you change the batteries before it is completely drained.

• On the device: as soon as the device is switched on, when the STATUS light

ashes orange, it indicates that the battery level is low.

Power Supply

LM2SPYPOINT

INSTALLING A MEMORY CARD (NOT INCLUDED)

The use of a memory card is necessary for the operation of the camera. It is used to save pictures and other

camera status les. Note that photos in their original format are kept on the memory card. The photos sent

to your application are lighter versions. You can retrieve your photos at any time by removing the card from

the device and transferring the contents to another device (e.g.: computer).

Your camera requires a microSD memory card, with a maximum capacity of 32 GB, sold separately. Here is a

table showing the approximate quantity of photos that can be recorded on the card, according to dierent

memory card capacities.

INSERTING YOUR MEMORY CARD

Before inserting the microSD card into your camera, it must be formatted via a computer to ensure

proper operations. Visit www.spypoint.com/en/support if you need help formatting your microSD card.

• Ensure the camera is turned OFF.

• Find the microSD card slot. It is located on the left, above the battery compartment (see photo).

• Insert a microSD card (up to 32GB) in the microSD card slot with the metal contacts facing down.

• The card is inserted correctly when a click is heard.

REMOVING YOUR MEMORY CARD

• Before removing a memory card, always turn your camera OFF

to prevent les from on the card from being deleted or damaged.

• To remove the card, push it lightly into the camera until you hear a click.

Then take it out of the device.

MEMORY 4 GB 8 GB 16 GB 32 GB

PHOTOS 20 MP 190 380 760 1 520

Memory Card

LM2SPYPOINT

ACTIVATING YOUR CAMERA

Before you can use your camera, you must activate it.

To do so, you will need the activation code.

FINDING THE ACTIVATION CODE

The activation code is located inside the LM2’s battery compartment.

Activation code

Preparation



SCREW IN ANTENNA

The antenna doesn't come installed. Please insert as shown in the photo.

LM2SPYPOINT

Activation

SPYPOINT APP - NEW USERS

On your mobile device or a computer, use the web browser and navigate to www.spypoint.com, select

“LOGIN” in the top navigation menu. On the displayed“SPYPOINT” page, select “CREATE AN ACCOUNT“,

ll out the required elds, then log in. Once your account is created you can either continue to use the web

version of the application or you can switch to the mobile application.

If you choose to use the SPYPOINT app to activate your device, follow these steps:

1. On Google PlayTM or the App StoreTM, search for“SPYPOINT”.

2. Download and install the app on your smartphone or tablet.

3. Start the app. Select “LOGIN”. Enter your account information and select “LOGIN”.

4. Select the “CAMERAS” tab at the bottom of the screen and press the orange +button.

5. In the list, select “LM2” then follow the steps to scan your data matix code.

6. When complete, you will see the camera in the camera list.

If you choose to use our SPYPOINT website to activate your device, follow these steps:

1. On the www.spypoint.com website, select “LOGIN”in the top navigation menu. On the displayed

“SPYPOINT” page, login using your account information. Then press the “LOGIN” button.

2. Select the +sign on the far right of the page; in the list, select “LM2” then follow the steps.

3. When complete, you will see the device in your camera list.

CHOOSING A PHOTO TRANSMISSION PLAN FOR YOUR CAMERA

Go to www.spypoint.com/en/spypoint-experience/plans to read the latest oers

and choose the plan that suits you.

Andere Handbücher für LM2

Inhaltsverzeichnis

Andere Spypoint Scouting-Kamera Handbücher

Spypoint

Spypoint FORCE-PRO Bedienungsanleitung

Spypoint

Spypoint LINK-EVO? LINK-EVO-V Bedienungsanleitung

Spypoint

Spypoint LINK-EVO Bedienungsanleitung

Spypoint

Spypoint Solar-Dark Bedienungsanleitung

Spypoint

Spypoint FLEX-S Bedienungsanleitung

Spypoint

Spypoint FORCE-PRO-S Bedienungsanleitung

Spypoint

Spypoint mini-LIVE Bedienungsanleitung

Spypoint

Spypoint Solar-Dark Bedienungsanleitung

Spypoint

Spypoint FL-7 Bedienungsanleitung

Spypoint

Spypoint SMART-PRO Bedienungsanleitung

Spypoint

Spypoint S-WiFi model Bedienungsanleitung

Spypoint

Spypoint LM2 Bedienungsanleitung

Spypoint

Spypoint FORCE-11 Bedienungsanleitung

Spypoint

Spypoint SMART Bedienungsanleitung

Spypoint

Spypoint LINK-MICRO-LTE Bedienungsanleitung

Spypoint

Spypoint Force-Dark Bedienungsanleitung

Spypoint

Spypoint LIVE-3G Bedienungsanleitung

Spypoint

Spypoint LINK-MICRO-S-LTE Bedienungsanleitung

Spypoint

Spypoint CELL-LINK Bedienungsanleitung

Spypoint

Spypoint SOLAR-W Bedienungsanleitung

Spypoint

Spypoint LINK-DARK Bedienungsanleitung

Spypoint

Spypoint SDB-85 Bedienungsanleitung

Spypoint

Spypoint LINK-EVO Leitfaden

Spypoint

Spypoint FORCE-10 Bedienungsanleitung

Beliebte Scouting-Kamera Handbücher anderer Marken

Nestbox

Nestbox C13 Bedienungsanleitung

Wildview

Wildview STC-TGL1 Bedienungsanleitung

Stealth Cam

Stealth Cam CORE STC-Z3IRTL Bedienungsanleitung

Suntek

Suntek HC-800M Bedienungsanleitung

Duramaxx

Duramaxx 10029765 Bedienungsanleitung

Brecom

Brecom C2400 Bedienungsanleitung

BlazeVideo

BlazeVideo A280W Bedienungsanleitung

Bestok

Bestok 5210GM Bedienungsanleitung

GardePro

GardePro X60P Bedienungsanleitung

Delta-Opti

Delta-Opti HC-SG880MK-18MHD Bedienungsanleitung

PNI

PNI HUNTING 280C Bedienungsanleitung

Muddy

Muddy Pro-Cam 14 Bedienungsanleitung

Bresser

Bresser 3310006 Bedienungsanleitung

Recon Outdoors

Recon Outdoors HS410 Bedienungsanleitung

Braun

Braun 57660 Bedienungsanleitung

Wildgame

Wildgame Shadow Bedienungsanleitung

Hieha

Hieha WiFi900Pro Montageanleitung

Bushnell

Bushnell 119437 Bedienungsanleitung
