STARFRIT 024227 Montageanleitung

INSTRUCTIONS FOR USE AND CARE P. 3

INSTRUCTIONS POUR L’USAGE ET L’ENTRETIEN

P.11

INSTRUCCIONES DE USO Y MANTENIMIENTO P.19

ELECTRIC OSCILLATING FOOD PROCESSOR

ROBOT CULINAIRE OSCILLANT ÉLECTRIQUE

PROCESADOR DE ALIMENTOS ELÉCTRICO OSCILANTE

OPERATING AND SAFETY INSTRUCTIONS

Item no. Voltage (V) Wattage (W) Frequency (Hz)

024227 120 300 60

IMPORTANT SAFEGUARDS

READ THE INSTRUCTIONS BELOW BEFORE USE

WARNING: To reduce the risk of ﬁre, electrical shock, serious personal injury

and/or property damage:

A. To protect against electrical shock, do not immerse the power cord, plug

or product in water or expose to other liquids.

B. Keep the product out of the reach of children and pets. This product is not

intended for use by children. Close adult supervision is necessary when

any appliance is used near children. DO NOT leave the product unattended

while it is in use.

C. DO NOT operate the product if it has a damaged power cord or plug,

or after the appliance malfunctions or has been damaged in any manner.

DO NOT attempt to examine or repair this product yourself.

For further assistance, please contact customer service to the following

address: www.starfrit.com/en/contact-us

D. Always unplug the appliance from the electrical outlet when not in use,

before changing parts, cleaning, or moving the appliance. To disconnect,

switch lever to OFF “ ” Pull directly on the plug – DO NOT pull on the

power cord.

E. DO NOT plug or unplug the product into/from the electrical outlet with a

wet hand.

F. Connect the power plug to an easily accessible outlet so that the appliance

can be unplugged immediately in the event of an emergency.

G. DO NOT use attachments not recommended or sold by the product

manufacturer.

H. DO NOT use with programmable devices.

I. This product is intended for indoor; household use only.

DO NOT use outdoors or for any other purpose.

J. DO NOT use appliance for anything other than its intended use.

K. DO NOT allow the power cord to hang (e.g. over the edge of a table or

counter) or touch hot surfaces.

L. DO NOT place the product on or near a hot gas or electric burner, or in a

heated oven or microwave oven.

M. Always use the processor on a ﬂat, level and stable surface. DO NOT move

the chopper while it is in use.

N. The blades are sharp, must handle with care.

O. Make sure the blade and the bowl are securely placed before locking the

lid into the base.

P. DO NOT attempt to remove the bowl from the base while in use.

Q. DO NOT operate the appliance for more than 1 minute continuously.

Allow the appliance to rest 3 minutes between each use.

R. DO NOT operate the processor if empty.

S. DO NOT operate with hot food, always allow food to cool down

T. To avoid injuries, do not place the blade assembly directly on the motorized

base. Always place the cup and blade assembly onto the motorized base.

SAVE THESE INSTRUCTIONS FOR

FUTURE REFERENCE

POLARIZED PLUG: This appliance is equipped with a polarized plug (one blade is wider than

the other). As a safety feature to reduce the risk of electrical shock, this plug is intended to ﬁt in

a polarized outlet only one way. If the plug does not ﬁt fully in the outlet, reverse the plug. If it

still does not ﬁt, contact a qualiﬁed electrician. DO NOT attempt to defeat this feature or modify

the plug in any way. If the plug ﬁts loosely into the AC outlet or if the AC outlet feels warm,

DO NOT use that outlet.

SPECIAL INSTRUCTIONS: A short power supply cord is provided to reduce the risk of becoming

entangled in or tripping over a longer cord.

AN EXTENSION CORD MAY BE USED IF CARE IS EXERCISED IN THEIR USE:

• Minimize the risk of overheating by using the shortest UL or ETL listed cord possible.

• The marked electrical rating must be at least as great as that of the product.

• Never use a single extension cord to operate more than one appliance.

• Arrange the longer cord so that it will not drape over a countertop or tabletop where it can

be tripped over, snagged, or pulled on unintentionally (especially by children).

• DO NOT alter the plug. DO NOT attempt to defeat the safety purpose of the polarized plug.

DESCRIPTION

1. Bowl

2. Base

3. Lid

4. ON/OFF Switch

5. S-Blade

6. Scoop

Fig. 1

Fig. 2

BEFORE INITIAL USE

WARNING: Blades are sharp, handle with care. DO NOT plug the appliance into an electrical

outlet before it’s ready to be used.

WARNING: For safety purposes, always place blade before putting food.

NOTE: Remove all parts & accessories and dispose of packaging.

1. Turn clockwise to unlock the lid from the processor bowl then carefully pull upward to remove

the measuring scoop.

2. Turn counterclockwise and lift to remove the blade from the processor bowl.

3. Turn clockwise to remove and unlock the processor bowl from the motorized base.

4. Wash all removable parts & accessories in hot soapy water and dry thoroughly or place in

the dishwasher.

NOTE: DO NOT immerse the motorized base or the power cord in water or any other liquids.

WARNING: The blade is very sharp, so be careful when removing the blade and cleaning!

5. Wipe the motorized base with a damp cloth and dry thoroughly.

6. Place back the bowl onto the motorized base and lock it by rotating counterclockwise.

Insert the blade into the bowl post and ensure it is correctly settled. Ensure the lid is

securely in place on the bowl by turning counterclockwise. Place back the scoop on the lid.

SPEED CONTROL (Refer to Fig. 1)

• Flick switch upward to “|” for Low Speed.

TIP: Use Low Speed to obtain a thick, chunky texture.

• Press and HOLD switch by pressing downwards to “ ” for High Speed.

TIP: Use High Speed longer for a creamy, smooth texture.

• Tap switch to “ ” for Pulse

• Leave switch at “ ” for OFF.

NOTE: The recommended maximum operating time for each speed is 1 minute consecutive.

Allow 3 minutes rest in between operations.

NOTE: To stop the appliance, move switch to “ ”.

BLADE ASSEMBLY

WARNING: The blade is sharp, please handle with care.

• Lock in the container to the base.

• Place blade onto the pillar ﬁrmly.

• Lock in the lid for the appliance to be functional.

SPOON ASSEMBLY AND USE

• Carefully lift the handle of the spoon to unclip from lid or, gently press on the clip from

underneath the lid to release spoon.

HOW TO USE

READ THE INSTRUCTIONS BEFORE USE

WARNING: For safety purposes, always place blade before putting food.

1. Align the tabs on the processor bowl with the L-slots on the motorize base. Turn the

processor bowl counterclockwise to lock onto the base.

2. Place the blade over the shaft in the center of the processor bowl and press down and

twist clockwise to securely lock into operating position.

3. Place the desired ingredients in the processor bowl.

NOTE: Cut the fruits/vegetables into small pieces.

NOTE: To achieve optimal results when grinding raw meat, use the continuous button to

grind up to 200 g of meat at a time.

4. Lock the lid on the processor bowl, aligning the L-Slots on the lid with the tabs on the

processor bowl. Turn the lid counterclockwise to securely lock onto the bowl.

CAUTION: The appliance has a locking mechanism that prevents the appliance from

operating or blade from turning if the lid is not securely attached to the base.

5. Plug the appliance into a standard 120-volt AC electrical outlet.

6. Select the desired speed control. Press lever downwards for PULSE “ ”, short bursts

used for processing ice, fruits or frozen vegetables. For continuous processing, lift the lever

to “|” for LOW speed or hold lever at “ ” for HIGH speed to obtain the desired texture

(lever will return to “ ” position automatically once “ ” is released).

WARNING: The recommended maximum operating time for each speed is 1 minute

consecutive. Allow 3 minutes rest in between operations.

7. Use the wet ingredient adder located under the spoon to add liquid ingredients while

processing, if desired.

8. When the ingredients are processed to the desired consistency, turn o the appliance, “ ”.

9. Once the stainless-steel blade has stopped turning, remove the lid from the processor bowl

by turning clockwise and lifting o.

10. Remove the blade from the processor bowl by turning counterclockwise and lifting it o.

11. Remove the bowl from the base by turning it clockwise and lifting it. Pour the mixture in a

bowl or use it as you want in your recipe.

12. Clean parts and accessories immediately after each use.

PROCESSING GUIDE

FOOD OPERATION NOTE

Celery and carrot Pulse to desired size. Cut into ½ inch-long pieces.

Bread for crumbs

Process. Pulse to break up,

then process continuously until

desired crumb size is reached.

Use day-old, hard bread for dry

crumbs, fresh bread for moist crumbs.

Cut or break into pieces no larger

than 1 inch. For buttered crumbs, add

1 teaspoon of melted butter per slice

after crumbs have started to form,

and process to combine and coat

Fruits cooked; fresh or

frozen thawed berries

Process. Pulse to break up,

then process continuously until

desired consistency.

Cooked fruits may be processed to

make baby foods or purées; liquid

may be added for consistency.

To process fresh or frozen thawed

berries for sauce, pulse to chop, then

process until puréed (sugar may be

added to taste).

Garlic Process. Pulse to desired

consistency.

Peel garlic cloves ﬁrst. Scrape work

bowl sides and bottom as needed.

Nuts Process. Pulse to chop to

desired consistency.

Toast nuts ﬁrst for maximum ﬂavor.

Allow to cool completely before

chopping. Up to ½ cup.

Onions Process. Pulse 5–10 times to

process to desired size.

Peel; cut into ¾ inch or smaller pieces

of similar size.

Vegetables cooked

Process. Pulse 5–10 times

to chop, then process

continuously until desired

consistency is reached.

Cook vegetables until tender.

Process to a smooth purée for baby

food or sauces; may need to add

liquid for consistency.

Meat Process. Pulse to desired result Diced meat, no more than 200 g at

a time.

TIPS AND RECOMMENDATIONS

NOTE: For best results read the following tips:

• DO NOT overﬁll the processor bowl.

• DO NOT attempt to process ﬁrm food such as cheese or coee beans or mixing dough.

• DO NOT process hot food or liquids.

• Cut fruits and vegetables into small pieces.

• Place ingredients in the following order: Liquids, frozen ingredients, fresh ingredients.

• For liquid ingredients, ﬁll container with a maximum volume of ¾ cup.

• If the blade stops spinning, unplug the appliance immediately. Mix the food in the bowl.

If the blade is still obstructed add some liquid or reduce the solid food.

CLEANING AND MAINTENANCE

WARNING: Ensure the appliance is unplugged from the electrical outlet and the blade has

stopped turning before handling or cleaning the appliance.

1. Disassemble all parts & accessories.

2. Wash in soapy, hot water or place in the top rack of the dishwasher. Wash after each use.

NOTE: DO NOT place the motorized base or cord in a dishwasher.

3. Dry all the parts & accessories thoroughly.

4. Wipe the motorized base with a soft, damp cloth and dry thoroughly.

5. Reassemble the processor for compact storage.

6. For safe storage, always store the blade in the bowl.

WARNING: Blades are sharp handle with care while cleaning. Use a brush to clean the blades

to avoid injuries. DO NOT touch blades with bare hands.

TROUBLESHOOTING

Problem Possible cause Solution

Processor is not

functioning.

Processor is not plugged in. Plug the appliance into an a 120 v outlet.

Bowl and/or lid is not

properly locked in.

Lock in the bowl and/or lid properly

with the L-Locks.

Food not processed

evenly

Ingredients were not

similar size.

Ensure ingredients are precut to

similar sizes.

WARRANTY

1-YEAR LIMITED WARRANTY.

This warranty covers any defects in materials and workmanship for a period of one (1) year

from the date of the original purchase. Please retain your original receipt as a proof of the

purchase date. Any complaints must be registered within the warranty period. The product will

be repaired, replaced (parts or entire appliance) or refunded at our sole discretion.

Shipping charges may apply.

This warranty does not cover normal wear of parts or damage resulting from any of the following:

Negligent use or misuse of the product including failure to clean the product regularly, use

for commercial purposes, accident, use on improper voltage or current, use contrary to the

operating instructions, disassembly, repair or altercation by anyone other than a STARFRIT

authorized service agent.

Stains, discoloration and minor scratches on the inside and outside of the utensil constitute

normal use, do not aect performance, and are not covered by this warranty.

Decisions as to the cause of damage are the responsibility of STARFRIT. All decisions will be ﬁnal.

RECIPES

VEGAN PESTO

INGREDIENTS:

• 2 cups of fresh basil

• 1 cup of extra virgin olive oil

• ½ cup of pine nuts

• 4 cloves of garlic

• Salt and Black Pepper to liking

PREPARATION:

1. Add basil, pine nuts and garlic to the processor.

Pulse 4-5 times.

2. Add ½ cup of extra virgin olive oil.

Add or reduce quantity to desired consistency.

3. Place mixture into the pesto container.

4. Mix in salt and black pepper to liking.

For Non Vegan, add grated 3 oz Parmesan or Romano cheese.

CHIMICHURRI

INGREDIENTS:

• 1 cup of extra virgin olive oil

• 1 cup of fresh parsley

• 6 cloves of garlic

• 3 small hot chilli pepper

• 10 g of fresh oregano

• 2.5 oz of red wine vinegar or lemon juice

• Salt and black pepper to liking

PREPARATION:

1. Introduce parsley, garlic, hot chilli pepper and oregano

into processor bowl. Pulse to preferred consistency.

2. Place Chimichurri into container.

3. Mix in extra virgin olive oil, red wine vinegar (or lemon juice).

4. Add salt and pepper to liking.

Use to marinate meats (e.g., Chicken Breast for Pan Frying or Baking)

or topping for steak before serving).

Inhaltsverzeichnis

Sprachen:

Andere STARFRIT Küchenmaschine Handbücher

STARFRIT

STARFRIT 024220 Montageanleitung

Beliebte Küchenmaschine Handbücher anderer Marken

INNOLIVING

INNOLIVING INN-727 Bedienungsanleitung

Berkel

Berkel C32 Bedienungsanleitung

Beko

Beko CHP5554W Bedienungsanleitung

KitchenAid

KitchenAid 5KFP0719 Bedienungsanleitung

QUIGG

QUIGG KM 2017Wi.20 Bedienungsanleitung

Lakeland

Lakeland PRESS AND CHOP 31557 Bedienungsanleitung

Bosch

Bosch MMR08 GB Series Bedienungsanleitung

HOFFEN

HOFFEN Chef Express T9532 Bedienungsanleitung

Garland

Garland 852 ZG Bedienungsanleitung

Robot Coupe

Robot Coupe CL50 Gourmet Bedienungsanleitung

SAPIRHOME

SAPIRHOME SP-1111-K Bedienungsanleitung

Moulinex

Moulinex DJ3051 Bedienungsanleitung

Bosch

Bosch MUM5 Bedienungsanleitung

cecotec

cecotec Mambo Touch Bedienungsanleitung

KitchenAid

KitchenAid 9KFC0516 Bedienungsanleitung

Black & Decker

Black & Decker hc 300 Montageanleitung

Gorenje

Gorenje SBR 1000 DV Bedienungsanleitung

Arzum

Arzum AR 1128 Bedienungsanleitung
