Starkey tour Bedienungsanleitung
OPERATIONS MANUAL
mini BTE
(Behind-The-Ear)
Table of Contents
Overview
Features, Controls and Identification ................................. 4
mini BTE Overview ............................................................. 5
Preparation
Batteries ............................................................................. 6
Battery Indicator Tones....................................................... 8
Tamper Resistant Battery Compartment ............................ 8
Insertion and Removal
Custom Earmold ............................................................. 10
Instant Fit Earbud or Custom Eartip ................................ 13
Operation
On & Off........................................................................... 15
Switch: Volume Control & Multimemory .......................... 15
Telephone Use.................................................................. 18
Direct Audio Input (DAI)................................................... 21
Accessories
Wireless Accessories ........................................................ 23
Hearing Instrument Care
Instrument Care................................................................ 24
Standard Tubing Care ...................................................... 25
Thin Tubing Care.............................................................. 26
Service and Repair............................................................ 28
Troubleshooting Guide .................................................... 29
Tips for Better Communication
For You ............................................................................. 30
For Your Family and Friends............................................. 31
Safety Information .................................................................. 32
FDA Information
Required Information ....................................................... 34
FCC Information ..................................................................... 36
Limited Warranty...................................................................... 37
4
Overview
Features, Controls and Identification
Your hearing instrument controls include:
1. Earhook
2. Microphones
3. Switch
4. Battery compartment (on/off control)
5. Side indicator RED is for RIGHT ear,
BLUE is for LEFT ear.
6. Tamper resistant battery compartment lock
Your hearing instrument can be identified by:
7. Location of serial number
8. Location of manufacturer’s name and
model name
Comfort Fit Solutions:
9. Standard Earmold with tubing
10. Thin tube with Instant Fit Earbud
11. Thin tube with Custom Eartip
5
mini BTE Overview
7
8
4
00-000000
SERIAL NUMBER
6
5
11
10
9
1
2
3
6
Preparation
Batteries
Your hearing instrument uses a battery as its power
source. The battery size can be identified by
the brown (312) color code on the packaging.
To insert or replace the battery:
1. Use the nail grip on the battery door.
2. Open the battery door gently and remove
the old battery.
3. Remove the tab from the new battery.
4. Line up the battery’s plus “+” sign (flat side of
the battery) with the battery door “+” sign.
5. Close the battery door.
7
Preparation
1 2
3
35
4
8
Preparation
Battery Indicator Tones
An indicator will sound when the battery’s voltage is
low. You have approximately 5 minutes* to replace
the battery. An indicator will sound just before the
battery stops working.
* Actual time between low battery indicator and shut
down will vary depending on environmental noise
levels and brand of battery used.
Tamper Resistant Battery Compartment
To lock the battery door:
Use an appropriate tool to
slide the recessed switch to
the left until it “clicks” and
the colored mark is visible.
To unlock the battery door:
Slide the recessed switch to
the right until it “clicks” and
the colored mark disappears.
Locking the door is not
required for operation.
9
Preparation
Helpful Hints
• NEVERFORCETHEBATTERYDOORSHUT;
thiscouldresultinseriousdamage;ifthedoor
will not close securely, check that the battery
is inserted correctly
• Donotopenthebatterydoortoofaror
damage is likely to occur
• Disposeofusedbatteriesimmediatelyinthe
proper waste or recycling container
• Batteriesvaryinsizeandperformance.Your
hearing care professional is your best source for
lifespan estimates and verification that you are
using the proper size and type.
Keep out of reach of children and pets
Check your medications before taking them –
batteries have been mistaken for pills
Never put batteries in your mouth, as they
can easily be swallowed
National Button Battery Ingestion Hotline:
202-625-3333
m WARNING:
10
Insertion and Removal
Custom Earmold
To insert the Custom Earmold and hearing instrument:
1. HoldtheCustomEarmoldwithyourthumband
forefinger on the outer side near the tubing.
2. Tilt your hand slightly forward and gently insert the
canal tip of the Custom Earmold into your ear canal.
3. Rotate the Custom Earmold backward.
4. Softly press the Custom Earmold into place with
your fingertip.
5. Carefully place the BTE behind your ear wrapping
the earhook over the top of your ear.
To remove the hearing instrument and
Custom Earmold:
Take the instrument from behind your ear and gently
pull the Custom Earmold outward. Pulling lightly down
on the earlobe may help loosen the Custom Earmold
as it is removed.
My hearing instrument uses:
A Custom Earmold. See below.
An Instant Fit Earbud or Custom Eartip.
See page 13.
