NOTECONS01

KVM Console to USB 2.0 Portable

Laptop Adapter

*actual product may vary from photos

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to

which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual i

Table of Contents

Introduction........................................................................................................................................................1

Packaging Contents ................................................................................................................................1

System Requirements ............................................................................................................................1

Installation............................................................................................................................................................2

Driver Installation......................................................................................................................................2

Hardware Installation..............................................................................................................................2

LED Indicators .............................................................................................................................................3

Using the USB Crash Cart Adapter........................................................................................................4

Zooming.........................................................................................................................................................4

Toolbar.............................................................................................................................................................5

Video Menu ..................................................................................................................................................7

Keys Menu Item.........................................................................................................................................8

Mouse Menu................................................................................................................................................9

Toolbar Menu ..............................................................................................................................................11

Troubleshooting...............................................................................................................................................12

Specications.....................................................................................................................................................13

Technical Support...........................................................................................................................................14

Warranty Information....................................................................................................................................14

Instruction Manual 1

Introduction

Packaging Contents

• 1 x USB Crash Cart Adapter

• 1 x USB to PS/2 adapter

• 1 x USB A to Mini-B cable

• 1 x Driver and Software CD-ROM or USB ash drive

System Requirements

Notebook Requirements

• USB 2.0 enabled notebook computer

• 20MB available hard drive space

• 24-bit capable display

• Windows XP(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/ Server 2008 R2, Mac OS x, and Linux

Fedora(FC10/ FC11)/ Ubuntu (8.10/9.4)

Server Requirements

• VGA enabled video card (DVI supported via optional DVIVGAMF adapter)

• USB or PS/2 keyboard support

• USB mouse support

Instruction Manual 2

Installation

Driver Installation

Windows 2000/XP/ Vista

Before installing the software on Windows, please disconnect the USB Crash Cart Adapter and

cancel any dialog windows regarding“Add new hardware”. These windows can interfere with the

installation process.

1. Insert the provided CD or USB ash drive and run the setup.exe installation program.

2. Proceed through the installation prompts, until complete.

3. Once complete, the software and drivers will have been installed on the system.

4. Connect the USB Crash Cart Adapter to a free USB port on the notebook using the supplied

USB mini-B to A cable. The other connections to a server are not needed at this point.

5. A message should pop-up entitled Found New Hardware.

6. Windows should nd the device driver les and install them automatically. This is a one-time

step.

7. The product is ready to be used now, and the main application may be launched now. There

is no need to reboot.

Mac OS X

1. Insert the provided CD or USB ash drive into the computer.

2. Double-click on the MacOSX-install.dmg le that you nd on the media.

3. After a short delay to verify that disk image, a nder window will open showing the

application and a link to /Applications. Drag the main application onto the Applications

link.

4. The application is now installed and ready for use: Find it in /Applications and double click

on it to start.

5. If you would like to add this application to the Dock, you can drag and drop it from /

Applications onto the Dock.

6. Connect the USB Crash Cart Adapter to a free USB port on the notebook using the supplied

USB mini-B to A cable.

Hardware Installation

Once the drivers and software for the USB Crash Cart Adapter are installed on the notebook

computer, it can be plugged into the server.

Connect the attached DE-15 VGA cable and the USB type A cable into the desired server. For

DVI-I (analog) computer systems, please use a DVI to VGA adapter (StarTech.com ID: DVIVGAMF).

A USB to PS/2 adapter is included for systems that require a PS/2 connected keyboard (mouse

will not be available).

Instruction Manual 3

LED Indicators

Server KB/Mouse: This lights up when the emulated USB keyboard/mouse is working. It will

blink briey whenever the emulated mouse moves, or emulated key is pressed. Constant ashing

indicates some problem with the USB connection to the server. This can happen if disconnected,

or if the host’s operating system is not enumerating the USB device.

Server VGA: This indicates a valid VGA video signal is being received. It will be o if nothing is

connected (and in some power saving modes) and may ash if an unsupported video mode or

other trouble is seen with the video signal. This light will not turn on, regardless of the video

input status, until the adapter is connected to the application software at least once.

User Console Link/Activity: This lights up when a good connection to the laptop is established.

If ashing, it indicates the USB to the laptop is not connected or being ignored. Blinks briey

when video data is sent to the laptop.

If all the lights are o, then this means the USB Crash Cart Adapter has no power from either

USB connection. Under normal operation, either USB port can provide enough power to

operate the unit. The USB keyboard/mouse emulation is always active, even if the laptop USB is

disconnected.

When used in PS/2 mode, the topmost light indicates correct PS/2 keyboard operation. Power is

received from the PS/2 port as it would be from USB port.

Instruction Manual 4

Using the USB Crash Cart Adapter

Once connected, the real-time video from the attached host computer is shown centered in the

main window.

Zooming

By design, this program will never show scroll bars. The entire video picture is always completely

visible. It is generally scaled down to t into the available space inside the program window. You

can make it larger by resizing the main window. Similarly, if you maximize the main window, the

size of the video image will be maximized.

In the Zoom menu, there are a number of buttons which set the zoom factor and resize the

window to achieve that zoom factor. For example, if the attached server is running at XGA

resolution (1024 x 768), and you select 50% zoom, the main window will be set to a size of

approximately 512 x 384. Please keep in mind that not all zoom factors will be possible; your

notebook’s screen may be too small for the larger percentages. If so, the software will make it as

big as it can.

Since many notebooks have smaller screens, you may wish to run this program maximized. Full-

screen mode is supported, where the window decorations are removed and other applications

are hidden. Click on the full-screen/window icon ( ) on the toolbar or select it from the Zoom

menu.

To get out of full screen mode, click the icon again. If the toolbar is disabled when you enter

full-screen mode, a smaller toolbar is provided with only the Fullscreen and Quit options. This

toolbar oats and may be moved out of your way, but cannot be removed.

Instruction Manual 5

Also in the Zoom menu is an option to center the window on the screen. This can be handy

when it is o the edge of the screen. There is also a shortcut for maximize (toggle). This is the

same as clicking the maximize button in the title bar of the main window.

More Tips

• If the laptop is widescreen (16:10 aspect, or 1280x800, etc), it may be helpful to locate the

toolbar along the left or right vertical edge. This provides more usable screen height, and

if the server’s screen is square (4:3 aspect) the left and right vertical edges would not be

used.

• This program does not enlarge video, only shrink it. Therefore, text mode (720x480 or similar)

will not be enlarged to ll your screen.

• The toolbar is automatically disabled when you select a Zoom factor below 50%. You need to

enable it manually when you return to a larger size.

• Unusable parts of the window are shown in grey. This happens because the video is scaled by

an integer factor of 1/16 and due to other rounding issues.

Toolbar

There is an optional toolbar along the top edge of the window. This toolbar may be hidden,

detached or dragged onto the other three edges of the window. It provides a number of

shortcuts and some status information. All functions are duplicated in the pull down menu, so it

is optional.

You can move and/or detach the toolbar by dragging the handle

( ) on the left/top edge. Once detached, the red X or circle in the upper corners can be used to

close it. When dragging or moving the toolbar, you can stick it (dock) to the top/bottom edge,

if in horizontal mode, or left/right edges if vertical. Some of these features are available in the

Toolbar menu as well.

The right most status area of the toolbar reports some statistics while the system is running.

The rst number is the USB bandwidth, in bits per second. When no motion is detected by our

hardware video compression, no bits are sent. Noisy video cards and ongoing video animations,

will cause a constant stream of USB trac.

The next two numbers (ex. 30Hz and 44fps) report the achieved frame rates for the hardware

and software components respectively. The hardware number (Hz) will range from 1 to 85Hz, but

is typically 30Hz or 60Hz. The software number is limited to 60 fps (frames per second) maximum

and varies depending what other software on your laptop is doing.

Instruction Manual 6

From left to right:

1. ( ) Change orientation of tool bar between horizontal (shown) and vertical.

2. ( ) Quit the Pocket Console application immediately.

3. ( ) Fine-tune video picture.

4. ( ) Open Video-related settings window.

5. ( ) Take a snapshot of screen, save as PNG, JPG, BMP le.

6. ( ) Toggle full-screen vs. windowed mode.

7. ( ) Go to 100% zoom, or largest possible.

8. (56%) Shows current zoom factor as a percentage.

9. ( ) Keyboard status (red X shown if trouble). Click to open special keys window.

10. (USB) USB or PS/2 mode for keyboard.

11. ( ) Caps lock indicator (green if active, shown inactive). Click to simulate pressing caps lock.

12. ( ) Num lock indicator/button.

13. ( ) Scroll lock indicator/button.

14. ( ) Send Ctrl-Alt-Del to the server.

15. (15.8 Mbps...) Status area. Shows USB bandwidth, hardware and software frame rates.

Instruction Manual 7

Video Menu

There are three functions available under the Video menu: Auto ne-tune picture, Video Settings

and Save PNG snapshot.

Auto ne-tune picture

Use to automatically adjust the sampling phase of the video. This makes the picture sharper and

reduces USB trac. This is generally not required since this operation is automatically performed

when video is applied. The picture will freeze for about one second while the calibration is

performed.

Settings

Picture Positioning

These four arrows may be used to ne-tune the

position of the video image. These are the same as

the centering controls found on video monitors. Save

your changes with the Save button. The adjusted

values will be used automatically whenever this

same video mode is seen again. The Auto button

will attempt to automatically center the video image

within the program window.

Sampling Phase (Sharpness)

This slider allows you to override the automatic phase

adjustment. Press Auto to perform auto phase again.

The numbers shown under the slider are the phase

(angle) of the control.

Noise Filters

The hardware implements two lters to reduce USB trac and improve picture quality. By

default they are both enabled and set to one. You may override and save customized settings

(which will apply to all video modes).

The rst ‘Noise’ lter helps to remove speckle noise. There is usually no visual eect to this lter,

except that at high values, moving the mouse may leave some pixels behind.

The second‘Flatness’lter converts regions that are nearly all the same colour into exactly the

same colour to aid compression. At higher values, color banding will be much more visible.

Save PNG snapshot

Use this function to record a copy of the window contents and save it into a PNG, JPG or BMP le.

The snapshot happens as soon as the menu item (or toolbar ) is clicked. You are then given

a chance to choose where the image le should be stored. A default lename is provided based

on the current time.

Snapshots are always stored at full resolution and contain the whole screen.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere StarTech.com Adapter Handbücher

StarTech.com

StarTech.com USB2105S Bedienungsanleitung

StarTech.com

StarTech.com DKT31CHPDL Bedienungsanleitung

StarTech.com

StarTech.com DKT30CHV Bedienungsanleitung

StarTech.com

StarTech.com PEX16S952LP Bedienungsanleitung

StarTech.com

StarTech.com ST3300GU3B Bedienungsanleitung

StarTech.com

StarTech.com USBBT2EDR4 Bedienungsanleitung

StarTech.com

StarTech.com ICUSB232PRO Bedienungsanleitung

StarTech.com

StarTech.com US1GA30SFP Bedienungsanleitung

StarTech.com

StarTech.com MDP2HDMIUSBA Bedienungsanleitung

StarTech.com

StarTech.com PEX2S552B Bedienungsanleitung

StarTech.com

StarTech.com USB32HDEH Bedienungsanleitung

StarTech.com

StarTech.com WIF2HDMC Bedienungsanleitung

StarTech.com

StarTech.com ICUSB232DB25 Bedienungsanleitung

StarTech.com

StarTech.com ST1000BT32 Bedienungsanleitung

StarTech.com

StarTech.com SAT2M2NGFF25 Bedienungsanleitung

StarTech.com

StarTech.com WIFI2HDMC Bedienungsanleitung

StarTech.com

StarTech.com USB External Sound Card Adapter Bedienungsanleitung

StarTech.com

StarTech.com USB2VGAPRO2 Bedienungsanleitung

StarTech.com

StarTech.com Thunderbolt TB3DKM2DPL Bedienungsanleitung

StarTech.com

StarTech.com EC4S952 Bedienungsanleitung

StarTech.com

StarTech.com ESATAPLT2M Systemhandbuch

StarTech.com

StarTech.com 109B-USBC-HDMI Bedienungsanleitung

StarTech.com

StarTech.com USB32HD4K Bedienungsanleitung

StarTech.com

StarTech.com USB32DP24K60 Bedienungsanleitung

Beliebte Adapter Handbücher anderer Marken

PCB Piezotronics

PCB Piezotronics 090B274 Bedienungsanleitung

Auvidea

Auvidea J20 Produkthandbuch

Gossen MetraWatt

Gossen MetraWatt AT3-III E Bedienungsanleitung

Akribis

Akribis ITF-21-BISS-MIT Bedienungsanleitung

Tenda

Tenda W54U Bedienungsanleitung

ROHO

ROHO AGILITY Bedienungsanleitung

PROLiNK

PROLiNK WN2001 Bedienungsanleitung

Hawking

Hawking HUF2 Bedienungsanleitung

Airlink101

Airlink101 AWLC4030 Bedienungsanleitung

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Bedienungsanleitung

Philips

Philips SWA4554S/10 Bedienungsanleitung

JVC

JVC TS-C9D2B Gebrauchsanweisung

NETGEAR

NETGEAR A6100 Bedienungsanleitung

D-Link

D-Link DWA-121 Bedienungsanleitung

Philips

Philips SWA2037 Bedienungsanleitung

Basalte

Basalte 0610-20 Bedienungsanleitung

Yealink

Yealink EHS40 Bedienungsanleitung

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Bedienungsanleitung
