StarTech.com SATDOCKU3S Bedienungsanleitung

Manual Revision: 09/06/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

SATDOCKU3S

SuperSpeed USB 3.0 to 2.5/3.5in

SATA HDD Docking Station

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................1

Packaging Contents .................................................................................................................................1

System Requirements .............................................................................................................................. 1

Front View .................................................................................................................................................... 2

Rear View ...................................................................................................................................................... 2

Installation ..............................................................................................3

Hardware Installation .............................................................................................................................. 3

Driver Installation ...................................................................................................................................... 3

Using the Storage Device ....................................................................................................................... 4

Specications ..........................................................................................6

Technical Support ..................................................................................7

Warranty Information ............................................................................7

Instruction Manual

Introduction

The StarTech.com SATDOCKU3S USB 3.0 Hard Drive Docking Station delivers full and

instant access to any 2.5” or 3.5” SATA hard drive (SATA 1.5/3.0Gbps), without having to

mount the drive inside a computer or install it into an external enclosure. Connected

through a single USB 3.0 SuperSpeed or USB 2.0 HighSpeed connection, the hard drive

docking station provides a convenient, plug-and-play storage solution.

Packaging Contents

• 1 x SATDOCKU3S hard drive docking station

• 1 x USB 3.0 A-B cable

• 1 x Universal Power Adapter

• 3 x Power Adapter Cord (NA/UK/EU)

• 1 x Instruction Manual

System Requirements

• USB enabled computer system with available port

• 2.5” or 3.5” SATA

• Windows 2000/ XP(32/64-bit)/ Server 2003(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-bit)/

Server 2008 R2, and Linux 2.6.31 and up

Instruction Manual

Front View

Rear View

Power Button

Power/Activity LED

Hard Drive slot Hard Drive

Eject button

DC Power

connector

USB 3.0 type B

connector (Host)

Instruction Manual

Installation

WARNING: Hard drives require careful handling, especially when being transported.

If you are not careful with your hard disk, lost data may result. Always handle storage

devices with caution.

Hardware Installation

1. Connect the external power adapter from the hard drive dock to a power outlet.

2. Insert a 2.5” or 3.5” hard drive into the top loading slot. Make sure that the

connectors on the hard drive are facing the same corner of the slot that has a cutout

in the door. The label on the hard drive should face the front of the hard drive dock.

3. Connect the included USB cable from the hard drive dock to an available USB port

on the computer system. The computer can be on or o.

NOTE: A USB 2.0 A-B cable could also be used on the hard drive dock.

4. Press the power button on the top of the hard drive dock. The Power LED under the

power button should light up.

5. To remove the hard drive, make sure it is currently not being accessed by the

computer then unmount or uninstall the disk drive from the operating system (see

documentation for your operating system). Press the power button to turn o

the hard drive dock and wait for the drive to power down. Press the drive ejection

button on the top of the hard drive dock the release the drive. Then pull the drive

from the slot.

Driver Installation

Windows 2000/XP/Vista/7 and Linux

No driver installation is required for these operating systems, as this hard drive dock is

natively supported, so the drivers are already installed.

Instruction Manual

Using the Storage Device

Windows 2000/XP/Vista/7

If you are using a brand new hard drive that does not contain any data, then you will

rst need to prepare the hard drive for use. From the main desktop, right-click on

“My Computer” (“Computer” in Vista/7), then select Manage. In the new Computer

Management window, select Disk Management from the left window panel.

Locate the Disk that says it is “Unallocated” (check hard drive capacity to conrm it’s the

correct hard drive) and then right-click in the section that says “Unallocated” and select

“New Partition”.

Instruction Manual

The New Partition Wizard will appear. Follow the instructions in the wizard to

complete setting up the drive. Once complete, the Disk should show up as “Healthy”

with a drive letter assigned (i.e. E:). This drive letter should now appear within My

Computer.

If you are installing a hard drive that already has data on it, then after plugging it in, the

drive should automatically show up with a drive letter assigned within My Computer.

Instruction Manual

Specications

Bus Interface USB 3.0

Connectors 1 x USB 3.0 type-B

1 x DC Power

LEDs 1 x Power/Activity

Chipset ID ASMEDIA

Maximum Data

Transfer Rate USB 3.0: 5Gbps

Compatible Hard Drives 2.5” or 3.5” SATA 1.5/3.0Gbps with capacity up to

2TB (500GB for 2.5”)

Power Adapter 12VDC, 2.5A, center positive

Dimensions 145.0mm x 93.0mm x 65.0mm

Weight 410g

Compatible Operating

Systems

Windows 2000/ XP(32/64-bit)/ Server 2003(32/64-

bit)/ Vista(32/64-bit)/ 7(32/64-bit)/ Server 2008 R2,

and Linux 2.6.31 and up

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.
