StarTech.com MCM1110GSC Bedienungsanleitung

10/100/1000 RJ45 to SC Fiber Multi Mode Media Converter

StarTech ID: MCM1110GSC

StarTech.com’s high-speed MCM1110GSC gigabit media converter is engineered to make fiber connections

simple, reliable and cost-effective. StarTech.com’s MCM1110GSC is the perfect solution for

connecting buildings to main networks.<br />

<br />

Easy to set up and install in a matter of seconds. This reliable and compact fiber optic media converter

features a heavy-duty power supply to withstand the most challenging environments. It has 6

LED indicators to ensure its continuous operation.<br />

<br />

Supporting a maximum multimode fiber optic cable distance of 550m. Gigabit speeds prevent bottlenecks

and keeps your data flowing quickly and smoothly. Complies with the IEEE 802.3 and 802.3u standard.

Applications and Solutions

> Designed for large, higher speed bandwidth that has a demanding workgroups that require expansion of fast Ethernet Network.

Features

> Supports IEEE 802.3Z/AB 1000Base-T/SX/LX

> Standard RJ-45 connectors for connecting to UTP media, and SC connector for connecting to

fiber media

> An effective solution for bridging between gigabit networks, and extending distance for your

networks

> Auto - negotiation of 10/100 Mbps and Auto - Crossover for TX port.

> Auto detects half/full duplex transfer mode from the TX port.

> Its compact design and weight makes it portable and unobtrusive to carry

> Provides switch configuration of half/full duplex transfer mode for FX port.

> Supports a maximum multi mode fiber optic cable distance of 550m

Specifications

> Color Gray

> Connector Types 1 - Fiber Optic SC Female

> Connector Types 1 - RJ45 Female

> Carton Quantity 20

> Shipping (Package) Weight 1.28 lb [0.58 kg]

> Standard IEEE 802.3/IEEE 802.3U

> Operating Temperature -10 ~ 50 degrees Celsius

> Storage -40 to 70

> Humidity 10% - 90% (non - condensing)

> Fiber Type Multi-Mode

> Wavelength 850nm

> Max Distance 550m / 1600ft

> Min TX Power -6.0dBm

> Max TX Power -12.0dBm

> Sensitivity </= -17.0dBm

> Link Budget 12.0dBm

> Transmit Mode 10/100/1000 Mbps Full/Half Duplex
