PCISOUND4LP
4 Channel Low Prole PCI Sound Card
with AC97 3D Audio Eects
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected
names and/or symbols of third-party companies not related in any way to StarTech.com.
Where they occur these references are for illustrative purposes only and do not represent an
endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to
which this manual applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges
that all trademarks, registered trademarks, service marks, and other protected names and/or
symbols contained in this manual and related documents are the property of their respective
holders.
Instruction Manual i
Table of Contents
Introduction........................................................................................................................................................1
Package Contents.....................................................................................................................................1
Hardware Guide ...............................................................................................................................................2
Installation............................................................................................................................................................3
Hardware Installation..............................................................................................................................3
Software Installation ...............................................................................................................................3
Specications.....................................................................................................................................................4
Technical Support.....................................................................................................................................5
Warranty Information.............................................................................................................................5
Instruction Manual 1
Introduction
Thank you for purchasing a StarTech.com Multi-Channel Dual Prole Sound Card. Providing
users with high quality sound to ensure a rich audio experience, PCISOUND4LP is designed to
t into a slim form factor or low prole PC case and provides optimum connectivity options to
ensure a smooth user experience.
Features
• Legacy Audio SBPro compatible and DOS support
• Maintains clear audio for excellent performance
• Supports EAX, Karaoke Key and Echoing
• True Full-Duplex playback/capture with dierent sampling rate up to 48KHz stereo
• Supports earphones as well as two and four channel speaker mode
• Built-in 32WEarphone buer
Package Contents
• 1 x 4-channel PCI Sound Card
• 1 x Driver CD
• 1 x Instruction Manual
• 1 x Standard Bracket
Instruction Manual 2
Hardware Guide
1
2
3
4
5
6
7
1. Line In (blue) – Line-In Connect to the audio output port of stereo
2. Mic In (pink) – Connect to the Microphone (Mono)
3. Front-Speaker (green) – Output to speakers with the amplier or ear
phones or Audio-in of home stereo
4. Rear-Speaker (black) – Connect to the rear speakers while four
channel speakers mode is enabled
In addition to the rear panel jacks, this 4 Channel Sound Card also has the following
internal connections:
5. Aux-in
6. Analog CD/IN Port (Signals: L-G-G-R)
7. Analog CD/IN Port (Signals: G-R-G-L)
Instruction Manual 3
Installation
Please Note: It is recommended that you remove any previously installed sound card and
drivers, prior to installing PCISOUND4LP, to avoid any hardware or software conicts.
If previously installed drivers are not removed, the PCISOUND4LP may not function properly.
Please Note: If your computer has on-board sound you will need to disable it on the
motherboard. For more information please review the documentation that accompanied your
computer/motherboard at the time of purchase.
Hardware Installation
1. Make sure that your system is unplugged and you are grounded.
2. Remove the cover of your system (see your computer’s user manual for details, if necessary)
and gently turn your computer onto its side, so that the PCI expansion slot openings on the
motherboard are facing upwards.
3. Locate an empty PCI slot (usually white in color) and remove the metal plate that covers the
corresponding bracket on the rear panel of the computer.You may need a Phillips screwdriver
to perform this step. Retain the screw! You will need it to secure the card later.
4. Gently insert the card into the empty slot, making sure it is rmly seated.
5. Secure the card in place using the screw you removed in Step 3.
6. Replace and secure the computer cover, then turn the power to the computer back on and
proceed to the following section.
Software Installation
Please note: When you start the computer following the hardware installation, Windows® will
detect the addition of the sound card as a “Multimedia Audio Controller” device. Click the Cancel
button to cancel the driver installation for the device at this moment. The driver for this device
will be installed in the next step.
1. Insert the Driver CD into the CD/DVD-ROM drive. Click the Start button
on the taskbar, and select Run.
2. In the Command Line that appears, type: X:\SOUND\CMedia8738\setup.exe (Where X:\ is
the CD/DVD-ROM drive assignment).
3. Follow any on-screen instructions to complete the software installation.
4. Restart your system.
5. Once you have rebooted the computer, PCISOUND4LP is ready to be used.
Instruction Manual 4
Specications
Bus Type PCI 32 Bit
PCI Specication PCI 2.2 Compliant
Duplex Mode: Supports Full Duplex Mode
Channels 4-Channel 16-bit stereo sound card
Internal Connectors 1 x Auxiliary connector
2 x CD audio connectors
External Connectors
Line In: 1 x 3.5mm audio jack for connecting
auxillary devices
Microphone: 1 x 3.5mm audio jack for connecting
a microphone
Audio Out: 2 x 3.5mm audio jacks for front and
rear speakers
Instruction Manual 5
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commit-ment to provide
industry-leading solutions. If you ever need help with your product, visit www.startech.com/
support and access our comprehensive selection of online tools, documentation,
and downloads.
Warranty Information
This product is backed by a lifetime warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for
the periods noted, following the initial date of purchase. During this period, the products may
be returned for repair, or replacement with equivalent products at our discretion. The warranty
covers parts and labor costs only. StarTech.com does not warrant its products from defects or
damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers,
directors, employees or agents) for any damages (whether direct or indirect, special, punitive,
incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss,
arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If
such laws apply, the limitations or exclusions contained in this statement may not apply to you.
Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need. From
the latest technology to legacy products — and all the parts that bridge the old
and new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they
need to go. Just talk to one of our tech advisors or visit our website. You’ll be
connected to the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products
and to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology
parts. StarTech.com was founded in 1985 and has operations in the United States,
Canada, the United Kingdom and Taiwan servicing a worldwide market.
