StarTech.com StarView SV221DVI Handbuch

StarView DVI KVM Switch

SV221DVI

SV421DVI

Instruction Guide

The Professionals’ Source For Hard-to-Find Computer Parts

DVI

K V M S W I T C H

* Actual product may vary from photo

*SV421DVI shown

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Using Your KVM Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Introduction

Thank you for purchasing a StarTech.com StarView DVI KVM switch. Now you can

share your DVI monitor or flat panel display, keyboard, and mouse between two

(SV221DVI) or four (SV421DVI) DVI-enabled computers. These KVM switches are

designed especially for DVI-I interfaces to ensure the distortion-free, crystal-clear images

associated with flat panel monitors.

Features

•Allows you to share one DVI monitor, PS/2 mouse, and PS/2 keyboard between

multiple computers

•DVI-I interface supports both digital and analog video signal transmission

•Supports PS/2 keyboards and mice, including M/S Intellimouse®, Intellimouse

Explorer®, and Logitech Netmouse®

•Supports high digital resolution of up to 1600x1200 and analog resolution of up to

1920x1440

•Support for multiple operating systems: Windows XP, 2000, Me, 98, 95, DOS, Linux,

etc.

Package Contents

This package should contain:

•1x StarView DVI KVM switch

Installation

1. Make sure that all your computers and peripherals are turned off.

2. Connect your keyboard, monitor, and mouse to the console ports (with the white

background) on the back of the KVM switch.

3. Connect each of your PCs to one of the numbered PC ports on the back of the switch.

You can use individual standard PS/2 keyboard, PS/2 mouse, and DVI video cables

to connect the KVM switch to your PCs.

Note: Your KVM switch is powered by the PS/2 ports. Once your KVM switch is

connected to your PC’s PS/2 ports, the KVM is powered.

4. Turn on your connected computers. Do not perform any activities on the KVM switch

until the PCs have properly booted or your DVI interface may not be properly

initialized.

Using Your KVM Switch

There are two ways to access your connected computers: the front panel pushbutton or a

hotkey sequence.

Using the Pushbutton

Pressing the pushbutton on the front of the KVM switch allows you to scroll through

your computers sequentially.

Using the Hotkey Commands

Akeyboard hotkey sequence consists of three keystrokes. Each hotkey sequence starts

with two Scroll Lock keystrokes. You must strike the Scroll Lock key twice in two

seconds or less in order for the hotkey sequence to be acknowledged.

Troubleshooting

Keyboard/mouse problems

•You should have connected your keyboard, mouse, and monitor to the KVM switch

before connecting the switch to your computer. If you reversed this process, try

rebooting your PCs.

•Make sure the mouse/keyboard are properly connected to the KVM switch and that

you have installed the proper drivers for your mouse/keyboard.

•Try rebooting your KVM switch by pressing ScrLk + ScrLk + End.

•If your keyboard/mouse came unplugged while in operation, you may need to

reboot your PCs in order to get the switch to recognize the keyboard/mouse again.

Command Hotkey Sequence Description

Select PC ScrLk + ScrLk + 1 (2, 3, 4) Selects the PC plugged into Port 1 (2, 3, 4)

Next lower PC ScrLk + ScrLk + Up Selects the next (lower) PC.

Next higher PC ScrLk + ScrLk + Down Selects the next (higher) PC.

Start Autoscan ScrLk + ScrLk + S Starts autoscan mode. You can quit

autoscan mode by pressing any key.

Autoscan Beep ScrLk + ScrLk + B Toggles on/off the confirmation beep

while in autoscan mode.

Reset KVM ScrLk + ScrLk + End Resets the KVM switch.

Video problems

•If your screen won’t show properly on your monitor, first make sure that all your

cables are firmly seated in their proper ports.

•If your screen is coming up blank or striped, the resolution on your PC may be higher

than the maximum resolution supported by the KVM (1920 x 1440 analog, 1600 x

1200 digital). Adjust the screen resolution and frequency until they are in the

supported range.

•If there is ghosting, speckles or stripes on your screen, there may be excessive

electromagnetic interference from an external source. Check the path of your video

cable for strong electromagnetic sources like motors or power cables. Try and keep

your video cables as far as possible from these external sources.

Technical Specifications

SV221DVI SV421DVI

User Ports 1 1

Computer Ports 2 4

Analog Resolution 1920 x 1440 1920 x 1440

(Maximum Pixels)

Digital Resolution 1600 x 1200 1600 x1200

(Maximum Pixels)

PC Connectors:

Keyboard 2 x PS/2 6-pin mini Din female 4 x PS/2 6-pin mini Din female

Mouse 2 x PS/2 6-pin mini Din female 4 x PS/2 6-pin mini Din female

Monitor 2 x DVI-I Single link female 4 x DVI-I Single link female

Console Connectors:

Keyboard 1 x PS/2 6-pin mini Din female 1 x PS/2 6-pin mini Din female

Mouse 1 x PS/2 6-pin mini Din female 1 x PS/2 6-pin mini Din female

Monitor 1 x DVI-I Single link female 1 x DVI-I Single link female

Power PS/2, 9V 500mA (optional) PS/2, 9V 500mA (optional)

Dimensions 3.3 x 5.1 x 1.75“ 4.25 x 8.75 x 1.75”

LxW x H (86 x 140 x 45mm) (107 x 223 x 45mm)

Weight 1.14 lbs (520g) 2.2lbs (1kg)

Operating Temp. 32~104ºF (0~40ºC) 32~104ºF (0~40ºC)

Safety Standards FCC, CE FCC, CE

Technical Support

The following technical resources are available for this StarTech.com product:

On-line help:

We are constantly adding new information to the Tech Support section of our web site. To

access this page, click the Tech Support link on our homepage, www.startech.com. In the

tech support section there are a number of options that can provide assistance with this

card.

Knowledge Base - This tool allows you to search for answers to common issues using

key words that describe the product and your issue.

FAQ - This tool provides quick answers to the top questions asked by our customers.

Downloads - This selection takes you to our driver download page where you can

find the latest drivers for this product.

Call StarTech.com tech support for help:

USA/Canada: 1-519-455-4931

UK/Ireland/Europe: 00-800-7827-8324

Support hours: Monday to Friday 9:00AM to 5:00PM EST (except holidays)

Warranty Information

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted below,

following the initial date of purchase. During this period, the products may be

returned for repair, or replacement with equivalent products at our discretion. The

warranty covers parts and labor costs only. StarTech.com does not warrant its products

from defects or damages arising from misuse, abuse, alteration, or normal wear and

tear.

Limitation of Liability

In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or

agents) for any damages (whether direct or indirect, special, punitive incidental,

consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss,

arising out of related to the use of the product exceed the actual price paid for

the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Revised:August 5, 2003
