SV431DPU3A2

4-Port KVM Switch for DisplayPort

Computers - USB 3.0

*actual product may vary from photos

Instruction manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction manual

Table of Contents

Introduction............................................................................................1

Product diagram........................................................................................................................................ 1

Package contents...................................................................................................................................... 2

System requirements............................................................................................................................... 2

About USB 3.0 and USB 3.1 Gen 1....................................................................................................... 2

KVM switch setup...................................................................................3

Attach the rubber feet............................................................................................................................. 3

Connect a console to the KVM switch............................................................................................... 3

Connect computers to the KVM switch ............................................................................................ 3

About video adapters.............................................................................................................................. 4

About drivers.............................................................................................................................................. 4

Troubleshooting........................................................................................................................................ 4

Operating the KVM switch....................................................................5

About the LED indicators ....................................................................................................................... 5

Select a port................................................................................................................................................ 5

Start AutoScan ........................................................................................................................................... 5

Change the AutoScan interval time ................................................................................................... 6

About the virtual USB HID function ................................................................................................... 6

Using hotkey commands ......................................................................7

Enable hotkey commands ..................................................................................................................... 7

Select a port................................................................................................................................................ 7

Start AutoScan ........................................................................................................................................... 7

Change the AutoScan interval time ................................................................................................... 7

Start a manual scan.................................................................................................................................. 8

Turn on audio lock.................................................................................................................................... 8

Alternative hotkey commands............................................................................................................. 8

Instruction manual

Technical support...................................................................................9

Warranty information............................................................................9

Instruction manual

Introduction

You can use the SV431DPU3A2 to control four DisplayPort computers with a single

monitor, keyboard, mouse, and audio peripheral set. The KVM switch features a built-in

two-port USB hub that’s separate from your keyboard and mouse, enabling you to

share USB peripheral devices between each connected computer. The KVM switch also

supports USB 3.0 technology, so you can achieve data transfer rates up to 5Gbps.

Product diagram

Console USB keyboard

and mouse port

USB 3.0 ports

Port selection buttons

Port selection/link LEDs

Power button

Front view

Back view

Power input

port Console USB

keyboard and

mouse ports

Console audio

port PC USB ports USB 3.0 port

PC audio port

(x4)

Console DisplayPort port PC connection

ports

Instruction manual

Package contents

• 1 x 4-port DisplayPort KVM switch

• 4 x rubber feet

• 1 x universal power adapter (NA/EU/UK/AU)

• 1 x quick-start guide

System requirements

• Host computer with a USB 2.0 or USB 3.0 port

• Computer equipped with DisplayPort

• Display device (for example, monitor, TV, and so on) equipped with DisplayPort

• USB keyboard and mouse support

The maximum resolution for this KVM switch is 4K at 30 Hz. In order to obtain that

resolution, the monitor and computer that you’re using must support 4K at 30 Hz.

Note: To obtain the maximum USB throughput, you must use a computer with a USB

3.0 port.

System requirements are subject to change. For the latest requirements, please visit

www.StarTech.com/SV431DPU3A2.

About USB 3.0 and USB 3.1 Gen 1

USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard oers speeds up to

5Gbps.

Instruction manual

KVM switch setup

Attach the rubber feet

To ax the rubber feet to the bottom of the KVM switch, peel o the backing on each

of the four rubber feet and stick them to the bottom of the KVM switch in the indicated

areas.

Connect a console to the KVM switch

1. Turn o your computer and any devices or peripherals that are connected to it (for

example, printers, external hard drives, and so on).

2. Connect a monitor to the Console DisplayPort port on the KVM switch.

3. Connect a USB keyboard and mouse to the Console USB keyboard and mouse

ports on the KVM switch.

4. If necessary, connect speakers or a headset to the Console audio port on the KVM

switch.

Connect computers to the KVM switch

You can connect up to four computers to the KVM switch.

1. Turn o the computers that you want to connect to the KVM switch and any devices

or peripherals that are connected to the computers (for example, printers, external

hard drives, and so on).

2. Connect a male-to-male DisplayPort cable to the computer’s DisplayPort port and

to one of the numbered PC connection ports on the KVM switch.

3. Connect a USB A to B cable to the computer’s USB port and to the same numbered

PC USB port on the KVM switch that you connected the DisplayPort cable to in

step 2.

4. If you’re using audio, connect a set of audio cables to the speaker port on your

computer and to the same numbered PC audio port on the KVM switch that you

connected the DisplayPort cable to in step 2.

5. Repeat steps 1 to 4 for any additional computers that you want to connect to the

KVM switch.

Note: If you want to use USB 3.0 peripherals between all of the connected computers,

make sure that the peripherals are connected to the USB 3.0 ports on the KVM switch.

6. Connect the universal power adapter to a wall outlet and to the Power input port

on the KVM switch.

Instruction manual

7. To turn on the KVM switch, press the Power button. The LED indicator should

illuminate to indicate that the KVM switch is receiving power.

8. Change the focus of the KVM switch to the computer or device that you connected

to the KVM switch and turn on the computer or device. Wait for it to fully load and

then test the keyboard and mouse functionality of the connected computer or

device.

9. Repeat step 8 for all of the connected computers or devices.

You should now be able to switch between the connected computers or devices. If

you’re experiencing issues with this KVM switch, see the “Troubleshooting” topic.

About drivers

You don’t need to install any drivers for this KVM switch, as the keyboard and mouse

use generic USB drivers that are already installed on any operating system that

supports USB technology.

Troubleshooting

If you experience issues using this KVM switch and you’re using a PC, you might want

to make the following changes to the BIOS settings on your computer:

1. Set HALT ON ERROR to All but keyboard.

2. In PNP AND PCI SETUP, do the following:

• Set PNP OS INSTALLED to YES.

• Set USB IRQ to ENABLED.

About video adapters

If you use a video adapter with this KVM switch, you must use an active video adapter.

If you use a passive video adapter, you might encounter performance issues.

Check with the manufacturer to determine if the video adapter that you want to use is

an active adapter.

Instruction manual

Operating the KVM switch

About the LED indicators

The KVM switch features ve LED indicators: One LED indicator for each of the four port

connections and one power LED.

LED Behavior Signicance

Port selection/link

LEDs

The green LED

is illuminated.

The port is active and the connected

computer or device is turned on.

The red LED

is illuminated.

The computer or device connected to

the port is currently selected.

The LED is

blinking.

The KVM switch is completing an

auto scan.

Power LED The LED

is illuminated.

The KVM switch is turned on.

Select a port

To select a port, press one of the numbered Port selection buttons on the front of the

KVM switch.

Note: When you switch between ports, it takes some time for the video signal to be

communicated. After you select a port, wait three to four seconds before you select a

dierent port.

Start AutoScan

When you start the AutoScan feature, the system automatically scans through the

computers that are turned on and connected to the KVM switch in sequence for a xed

interval of time.

If any keyboard or mouse activity is detected during the AutoScan, the scanning is

suspended until the activity stops. AutoScan then resumes with the next computer in

the sequence.

• To start AutoScan, press Port selection button 3 and Port selection button 4

simultaneously.

• To end AutoScan, press any of the numbered Port selection buttons on the front of

the KVM switch.

Instruction manual

Change the AutoScan interval time

You can set the AutoScan interval time to one of four options: 3, 8, 15, or 30 seconds.

By default, the AutoScan interval time is set to 3 seconds after a blackout or restart.

When you set the AutoScan interval time, the KVM switch beeps a specic number of

times to indicate the duration of time that you’re setting:

Number of beeps Corresponding AutoScan interval

1 3 seconds

2 8 seconds

3 15 seconds

4 30 seconds

• To change the AutoScan interval time, press and hold Port selection button 1 and

Port selection button 2 simultaneously until you hear the number of beeps that

corresponds to the duration of time that you want to set.

About the virtual USB HID function

The virtual USB HID function can simulate the USB Human Input Device (for example,

keyboard or mouse) on all of the computers connected to the KVM switch. This can

save you time when you switch ports.

• To use this function, do one of the following:

• Connect the USB device to the Console USB keyboard and mouse port on the

front of the KVM switch.

• Connect the USB device to any of the three Console USB keyboard and

mouse ports on the back of the switch.

Andere Handbücher für SV431DPU3A2

Inhaltsverzeichnis

Andere StarTech.com Schalten Handbücher

StarTech.com

StarTech.com P2DD46A22-KVM-SWITCH Bedienungsanleitung

StarTech.com

StarTech.com MSTCDP122HD Bedienungsanleitung

StarTech.com

StarTech.com STARVIEW SV231DDUSB Bedienungsanleitung

StarTech.com

StarTech.com VS424HDPIP Bedienungsanleitung

StarTech.com

StarTech.com D86A2-2-PORT-8K-KVM Bedienungsanleitung

StarTech.com

StarTech.com SV831DUSBA Bedienungsanleitung

StarTech.com

StarTech.com SV231DVIUDDM Bedienungsanleitung

StarTech.com

StarTech.com StarView SV821 Bedienungsanleitung

StarTech.com

StarTech.com ST222MX Bedienungsanleitung

StarTech.com

StarTech.com SV215MICDVIA Bedienungsanleitung

StarTech.com

StarTech.com SV431HU34K6 Bedienungsanleitung

StarTech.com

StarTech.com SV5CONS Bedienungsanleitung

StarTech.com

StarTech.com ICUSB23216FD Bedienungsanleitung

StarTech.com

StarTech.com StarView SV431H Bedienungsanleitung

StarTech.com

StarTech.com 5G4AINDRM-USB-A-HUB Bedienungsanleitung

StarTech.com

StarTech.com HB31C3A1CDPPD3 Bedienungsanleitung

StarTech.com

StarTech.com SV211KDVI Bedienungsanleitung

StarTech.com

StarTech.com VS421HDDP Bedienungsanleitung

StarTech.com

StarTech.com HB30C1A1CPD Bedienungsanleitung

StarTech.com

StarTech.com MSTCDP123DP Bedienungsanleitung

StarTech.com

StarTech.com ConvergeAV VS410HDMIE Bedienungsanleitung

StarTech.com

StarTech.com IES61002POE Bedienungsanleitung

StarTech.com

StarTech.com VS221HDQ Bedienungsanleitung

StarTech.com

StarTech.com 35BAYFWUSB Handbuch

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
