Stiga Garden Combi

13-2511-21

GARDEN

GARDEN COMBI

A ride-on lawnmower with collector. The versatile machine can

also use Multiclip and Rear Discharge.

Compact dimensions but great features.The rider has an excellent

collection, but can also be driven through tall grass thanks to the

rear discharge (accessry). The collector (capacity 170 litres) is eas-

ily empty from the driving seat, a buzzer will tell you when it will

be full.

The ride-on lawn mower can be quickly converted to a Multiclip

machine let you save time, have fertilised garden and reduce noise

emissions.

Handiness and compact dimensions permit you to cut your small

garden as weel as trim around trees and edges. The deck has also

a unique system for easy cleaning.

Adjustable seat

Equipped with an environment friendly 12,5 hp engine. The

machine has gear transmission. The cutting width is 72 cm.

Garden Combi (13-2511-21)

ENGINE

Brand Briggs & Stratton

Power 12,5 hp I/C OHV/AVS

Cylinders 1 cyl

Speed 1,5-7 km/h

Safety brake Yes

Battery 12V / 18Ah

FUEL

Type of fuel Petrol

Tank volume 4 l

SPEED CONTROL

Type of transmission Transaxle

Number of gears 5 + R

STEERING

Type of steering Front wheel steering

WHEELS

Wheel size Front 11 inches. Rear 15 inches

Bearings Plain

Tyre pressure Front 1,5 bar. Rear 1 bar

Driving Rear wheel drive

CUTTING INFORMATION

Type of cutting system Collecting / Multiclip

Cutting heights 30-80 mm in 7 steps

Cutting width 72 cm

Cutting height adjustment Central

Grasscatcher capacity 170 litres

CONTROLS

Electric starter Yes

Gear lever Hand control

MEASURES & WEIGHT

Weight 160 kg

Gross weight 185 kg

Package size WxHxL 80x103x168 cm

Type of package Carton on wooden pallet

Units on pallet 1

Largest measures WxHxL 76x110x186 cm

SEAT

Type of seat Comfort seat

Seat adjustable horizontally Yes

OTHER FACTS

CE-mark Yes

EAN bar code 7313321305956

Other features GS-mark

Multiclip kit included
