STRATUS 2 Post Overhead Li Installaon & Operaon & Maintenance Instrucons

Model No.: SAE-C12X

2 Post Overhead Li

Single (1) Point Manual Release

Liing Capacity:12000LBS

Important Note

1.This equipment can not be installed, operated or repaired without reading instrucons.

2.Electricty must be hooked up by cered electrician.

3.Do not use this equipment beyond its rated capacity.

CONTENTS

1-Equipment descripon

…………………………………………………………………………………………………

1.1-Descripon ……………………………………………………………………………………………………………3

1.2-Technical specicaons………………………………………………………………………………………………3

1.3-Installaon requirement………………………………………………………………………………………………5

2-Specicaons of concrete………………………………………………………………………………………………6

3-Installaon steps…………………………………………………………………………………………………………7

4-Operaon and use………………………………………………………………………………………………………18

4.1-Operaon ……………………………………………………………………………………………………………18

4.2-Raising Liing…………………………………………………………………………………………………………18

4.3-Stopping ………………………………………………………………………………………………………………18

4.4-Lowering ………………………………………………………………………………………………………………18

5-Safety ……………………………………………………………………………………………………………………18

5.1-Important Reminder…………………………………………………………………………………………………18

5.2-Vehicle Posion………………………………………………………………………………………………………19

5.3-Risk of Vehicle falling o from the li…………………………………………………………………………19

6-Maintenance ……………………………………………………………………………………………………………19

6.1-Every Month …………………………………………………………………………………………………………19

6.2-Every 3Month ………………………………………………………………………………………………………19

6.3-Every 6Month ………………………………………………………………………………………………………20

6.4-Every 12 Moth ………………………………………………………………………………………………………20

7-Troubleshoong guide …………………………………………………………………………………………………20

8-Structure and Parts List…………………………………………………………………………………………………21

8.1-Main column assembly……………………………………………………………………………………………21

8.2-Sun-column assembly………………………………………………………………………………………………21

8.3-Block assembly………………………………………………………………………………………………………22

8.4-Cross arm assembly…………………………………………………………………………………………………22

8.5-Cylinder assembly……………………………………………………………………………………………………23

8.6-Three-secon arm assembly………………………………………………………………………………………23

8.7-Main column safety lock assembly………………………………………………………………………………24

8.8-Secondary column safety lock assembly…………………………………………………………………………25

1.-Equipment Descripon

1.1-Descripon

This 2 Post Overhead Li is an advanced car maintenance equipment, mainly used for automove repair and

maintenance.

1.2-Technical Specicaons

Model SAE-C12X

Liing capacity 12000lbs;5500KG

Overall Hight 173 3/8″;4403mm

Overall Width 155 1/8″;3940mm

Liing height 74 13/16";1900mm

Min. height 4 5/8";118mm

Column inside 129 15/16";3300mm

Drive through 115 11/16";2939mm

Liing me About 60 sec.

Lowering Time About 40 sec.

Column thickness of steel 6.0mm

Carriage thickness of steel 6.0mm

Arms thickness of steel 7.75mm

Arm range 35 1/16"-70 7/8";890-1800mm;

Diameter of cable Φ9mm

Voltage 220V

Power 3.0Kw/4Hp

Frequency 60Hz

Phase 1Ph

Breaker 30A

Hydraulic oil 3-5 Gallons AW46/AW32

Shipping Size 118"×44″×28";2997×1118×712mm

Equipment weight 2360lbs/1071KG

Installaon( See Fig 1 )

FIG 1

Features (See Fig 2)

FIG 2

1.3-Installaon requirement

Tools required

Name


Rotary hammer drill(Φ19)

carpenter's chalk

Hammer

Screw Sets

Level bar

Tap measure

English spanner(12")

Pliers

Ratchet spanner with socket(28#)

Socket head wrench(3#,5#,8#)

Lock wrench

Wrench set(10#,13#,14#,15#,17#,19,24#,27#,30#)

2-Specicaons of concrete ( See Fig 3 )

Specicaons of concrete must be adhered to the specicaon as following. Failure to do so may result in li and/or

vehicle falling.

◇Concrete must be thickness 200mm minimum and without reinforcing steel bars, and must be completely dry

before li installaon.

◇Concrete must be in good condion and must be of test strength 3500psi(245kg/cm²)minimum.

◇Floor must be level with no cracks or holes.

Steps of installaon

◇Locaon of installaon

Check and insure the installaon locaon( concrete, layout, space size etc.) is suitable for li installaon.

◇Use a carpenter's chalk line to establish installaon layout of baseplate( See Fig4).

FIG 3

FIG 4

3-Installaon steps

Step 1:Check the pats before assembly

Packaged li and hydraulic power unit( See Fig 5 )

Step 2:Move aside the parts and check the parts according to the shipment parts list (See Fig 6).

FIG 5

FIG 6

Step 3: Spare parts in the accessories box.

Serial

number

Name Photo Parameter Quanty

1Arm sha Φ40×250L 4

2Arm sha xing screw

Countersunk Hexagon Screw M10×15L 4

3Arm boom pad Φ70mm 4

4Increased set Φ60×100L 4

5Heightening bracket 2

6Heightening sleeve bracket xing

screw

Hexagon socket screws M8×10L 2

7An-collision tape 2

8An-collision rubber strip xing screws

Hexagon socket screws M8×30 4

9Power unit frame 1

10 Power unit frame xing screws

Hexagon socket screws M10×16L Each 2

11 Power unit xing screws

Hexagon Screw M8×25L Each 4

12 Manual unlocking lever M10 Each 1

13 Safety lock release cable 1

14 Wire rope U-shaped chuck M3 2

15 Expansion screw

M20×160L 14

Serial

number

Name Photo Parameter Quanty

16 Plasc gasket 15

17 Plasc cable e 30

18 Main column upper limit switch 1

19 Main column upper limit switch xing screw Phillips round head screws M5×10L 2

20 Upper limit plate and limit switch M4×10 and M4×25 1

21 Upper limit board 1

22 Upper limit plate xing screw Hexagon Screw M10×20L Each 4

23 Two cross arm connecng screws Hexagon Screw M8×20L Each 6

24 Two-secon cross arm end xing screws Hexagon Screw M10×25L Each 8

25 Heightening secon and column connecng

screw

Hexagon socket screws M10×12L Each 16

26 Wire rope support frame at the upper end of

the heightening secon

27 Fixing screws for the upper wire rope sup-

port frame of the heightening secon

Hexagon socket screws M5×10L 4

28 Plasc buckle cover xing screw Phillips round head screws M6×8L 8

29 Increased fuel-saving pipe pressure pocket 6

30 Increased the fuel-saving pipe pressure pock-

et xing screw

Hexagon socket screws M6×10L Each 12

31 Block rubber cover 2

32 Locking and unlocking rope seat assembly

accessories

33 User’s manual 1

Step 4: Install anchor bolts

Posion the columns on the installaon layout of baseplate. Install the anchor bolts. Check the columns plumbness

with level bar, and adjusng with the shims if the columns are not vercal. Do not ghten the anchor bolts (See Fig 7).

Note: Anchor bolts driven into the ground at least 150mm.(See Fig 8)

FIG 8

FIG 7
