Strong FS Series Betriebshandbuch

Product Data Sheet

FS SERIES

Fully Assembled Rack System w/ DC Fans

SR-FS-SYSTEM-DC-42U

Product Overview

Package Contents

A Top Cover

B Welded Frame

C Front Door - Tinted Glass

D Side Panel (x2)

E Rear Panel

F Bottom Cover

G 2U Rack Shelf (x8)

H 2U Vented Panel (x8)

I Low-ProleFine-FloorCasters(x4)

J DC Fans (x2)

K Locking Door Latch

L Door Latch Plate

M Ground Studs (x4) (located on top and

bottom covers in the rear of rack)

N Nylon Washers (x3)

O Pre-installed Bushings (x3)

Key Features

•1000 lbs. max load capacity

•Tamper resistant lock on reversible tempered

glass front door

•Removable side and rear panels for easy

serviceability

•Front and rear rails tapped with 10/32

threads to allow for mounting of components

in front or rear of rack

•Superb ventilation system - Strategically

placed fans* & vents to ensure that

equipment stays cool

• Lowprole,neoor,lockingcasters

•Fits through a standard doorway even with

the casters on

•Lifetime limited warranty

*Notes: Fans are always on, we recommend they

are plugged into a switching surge

protector or AV receiver.

Please be sure to check with local

authorities in regard to code

requirements for compliance.

If the door is rubbing against the base,

then add the necessary amount of nylon

washers (N) onto the bottom hinge pin

to allow for extra clearance.

CAUTION!

Whenloadingequipmentintocabinet,ensurethat

thecastersarelocked,andloadheavierequipment

at the bottom of the rack.

Reversing Front Door

Tools Required:

#2 Phillips Head Screwdriver

Reversal Steps

1. Removebothsidepanels(D),andopenthefrontdoor(C).

2. Remove the Door Latch (K) by removing the clamp with a

#2Phillipsscrewdriver,andslidethelatchoutofthedoor.

3. Remove the Latch Plate (L) using a #2 Phillips screwdriver.

4. Pull the top and bottom hinge pins out of the locking

position and slide the door up and out. Remove the

bottom,pre-installedbushing(O).

5. Insert the bushing into the opposite bottom hinge pin hole.

6. Flipthedoorover,alignthebottomhingepinoverthe

grommet,andslideintoplace.Repeatforthetophingepin.

7. Attach the Latch Plate (L) to the rack opposite the door

hinges using a #2 Phillips screwdriver.

8. InserttheDoorLatch(K)intothedoor,andsecurewiththe

clamp using a #2 Phillips screwdriver.

9. Closeandlatchthedoor,andreattachthesidepanels(D).

M - Ground Studs (not shown)

N - Nylon Washers (3) (not shown)

O - Pre-installed Bushings (3)

Product Data Sheet

FS SERIES

Fully Assembled Rack System w/ DC Fans

Lifetime Limited Warranty

All StrongTM products have a Lifetime Limited Waranty. This warranty includes parts and labor repairs on all

components found to be defective in material or workmanship under normal conditions of use. This warranty

shallnotapplytoproductsthathavebeenabused,modied,ordisassembled.Productstoberepairedunderthis

warrantymustbereturnedtoSnapAVoradesignatedservicecenterwithpriornoticationandanassignedreturn

authorization number (RA).

For Technical Support: 1.866.838.5052

Lifetime

year

SR-FS-SYSTEM-DC-42U

Product A-Racking Height B-Height (Overall) C-Height (With Casters) D-Width (Overall) E-Depth (Overall) F-Usable Depth G-Depth (Door Open)

SR-FS-SYSTEM-DC-42U

42U 76.8 79.7 21.12” 23.14” 18.25” 43.2”

Dimensions

B C

See Detail A

Detail A

.75 in.

12.3 in.

4.7 in.

Front Side

Top

Back
