Planning Information
Undercounter Model UC-24C
Combination Refrigerator/Freezer
1
Dimensions in parentheses are in
millimeters unless otherwise specified.
2/07
Clear ice bucket
Spill-proof cantilever
glass shelf
Location of rating/
serial number plate
Wine storage
shelf
Overlay or stainless
steel application
Automatic ice
maker
Easy-access
electronic controls
Freezer storage
Two-litre bottle
door storage
Model UC-24C
Sub-ZeroUndercounter units simplify life at home by
bringing refrigeration anywhere it's needed. Fresh
greens in the kitchen island. Ice, soda and snacks in
the media room. Chilled wine and mineral water in the
master suite. Imagine how this innovative built-in unit
can serve you.
The refrigerator/freezer Model UC-24C can be fitted
with a custom overlayor stainless steel door front
panel. Aclassic stainless steel door panel with tubular
handle is available as a sales accessory.
The Model UC-24C offers more features than ever
with easy-access electronic controls, LCD display, a
spill-proof cantilever glass shelf as well as wine
storage and two-litre bottle storage in the door.
The Sub-Zero Undercounter
refrigerator/freezer Model UC-24C can
accommodate an overlay or stainless
steel door front panel. A classic stainless
steel door panel and tubular handle is
available as a sales accessory.
This appliance will be certified by Star-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
Planning Information
Undercounter Model UC-24C
2
Dimensions may vary by ± 1/8"(3).
Dimensions in parentheses are in
millimeters unless otherwise specified.
FEATURES
Refrigerator/freezer with wine storage to
accommodate eight (750 ml) bottles
Can be fitted with a custom overlay or stain-
less steel door front panel
Classic stainless steel door panel with
tubular handle available as a sales accessory
Easy-access electronic controls with LCD
display
Roller-glide wine storage shelf faced with
natural cherry wood has a three-quarter
extension for easy access
An adjustable spill-proof cantilever glass
shelf
Automatic ice maker with clear ice bucket
Two-litre bottle storage in the door
Optional lock available as a sales accessory
UL approved for US and Canada
Two, five and twelve year residential
warranty—exclusions apply, see warranty at
the end of this guide
OVERALL DIMENSIONS
90˚
253/8"
(645)
TOP VIEW
F
FRONT VIEW SIDE VIEW
(CABINET DIMENSION)
4
(102)
DOOR FRAME
(597)
1
2
23
30
(767)
DOOR
FRAME
*34
(864)
(587)
1
8
23
3
16
23 7
8
(606)
*
1/2"(13) +
_ADJUSTMENT IN LEVELING LEGS
Planning Information
Undercounter Model UC-24C
Dimensions in parentheses are in
millimeters unless otherwise specified. 3
SPECIFICATIONS
Model UC-24C Undercounter Refrigerator/Freezer
Overall Width 237/8"(606)
Overall Height 34" (864)
Overall Depth 24" (610)
Refrigerator Capacity 3.6 cu ft (102 L)
Wine Storage Capacity 8 Bottles (750 ml)
Freezer Capacity 1.1 cu ft (31 L)
Door Swing Clearance 253/8"(645)
Electrical Requirements 115 V AC, 60 Hz
15 amp dedicated circuit
Plumbing Requirements 1/4"copper line
Water Supply 20–100 psi
Annual Energy Usage 434 kWh / $ 40
(based on 9.06 cents per kilowatt hour)
Shipping Weight 130 lbs (59 kg)
Specifications are subject to change without notice.
MODEL
Refrigerator/Freezer UC-24C
Classic stainless steel door front panel is
available as a sales accessory and
includes a tubular handle.
ACCESSORIES
Classic stainless steel door front
panel with tubular handle
Classic stainless steel tubular
handle for overlay application
Polished chrome handle for
overlay application
UL approved door lock kit
Accessories are available through your
Sub-Zerodealer. To obtain local dealer
information, visit the Locator section of
our website, subzero.com.
Planning Information
Undercounter Model UC-24C
4
INSTALLATION SPECIFICATIONS
DIMENSIONS
Finished Rough Opening Width 24" (610)
Finished Rough Opening Height 34 1/2"(876)
Finished Rough Opening Depth 24" (610)
Location of Electrical Within shaded area
Location of Plumbing Within shaded area
See Installation Instructions shipped with unit for detailed specifications.
341/2"
(876)
ROUGH
OPENING
HEIGHT
341/4"
(870)
MINIMUM
HEIGHT
REQUIRED
24" (610)
ROUGH OPENING
WIDTH
151/2"
(394)
2
LOCATE ELECTRICAL
AND WATER LINE
WITHIN SHADED AREA
L
3" (76)
2" (51)
FRONT VIEW
ANTI-TIP BRACKET
24"
(610)
ROUGH
OPENING
DEPTH
LOCATE WATER LINE
WITHIN SHADED AREA
3
151/2"
(394)
1/2"(13)
2" (51)
TOP VIEW
F
Dimensions in parentheses are in
millimeters unless otherwise specified.
Planning Information
Undercounter Model UC-24C
Dimensions in parentheses are in
millimeters unless otherwise specified. 5
INSTALLATION NOTES
Refer to the illustrations and specifications
for overall dimensions, finished rough opening
dimensions and installation specifics.
For corner installations, you need allow for a
minimum 3" (76) filler so the door can open to
90˚. If you are using some larger handle
hardware, you will also need to take that into
account.
The anti-tip bracket must be installed to
prevent the unit from tipping forward.
When planning to install the Undercounter
unit next to adjoining cabinetry, you must make
provisions to allow the door to open to a
maximum of 145˚ and not interfere with the
door panel. Refer to the full-scale illustration on
page 9 for cabinetry dimensions.
For the overlay application, you will need to
provide a decorative door panel. Refer to the
overlay door panel information on page 6. You
must also supply your own handle hardware.
For the overlay application, the weight limit
for the decorative door panel is 20 lbs (9 kg).
The panel must be a minimum of 5/8"(16) thick.
Rough in the water supply line for the auto-
matic ice maker.Connect a 1/4"OD copper line
to the house supply, being sure to use an easily
accessible shut-off valve between the supply
and the unit. This shut-off valve should not be
installed behind the unit.
Donot use self-piercing valves. A saddle
valve kit (4200880) is available from your
Sub-Zero dealer. To obtain local dealer informa-
tion, visit the Locator section of our website,
subzero.com.
Aline filter is required when water condi-
tions have a high sediment content. The ice
maker operates on water pressure of 20 psi
(1.4 bar) to 100 psi (6.9 bar). In some cases a
reverse osmosis water filter system may not be
able to maintain the minimum water pressure
consistently.
A115 V AC, 60 Hz, 15 amp fused electrical
supply is required. It is recommended that a
separate circuit, serving only this appliance, be
provided.
The Model UC-24C is equipped with a power
supply cord with a 3-prong grounding plug
which must be plugged into a mating 3-prong
grounding type wall receptacle. The electrical
outlet must be placed so the grounding prong
is to the right of the thinner blades. The
outlet must be flush with the back wall. Locate
electrical within the shaded area shown in the
installation illustration on page 4.
You must follow all National Electrical Code
regulations. In addition, be aware of local codes
and ordinances when installing your service.
Refer to the Undercounter Installation
Instructions packed with the appliance, which
provides step-by-step procedures for making
sure the unit is installed properly.
Planning Information
Undercounter Model UC-24C
Dimensions in parentheses are in
millimeters unless otherwise specified. 6
OVERLAY DOOR PANEL
Undercounter models come ready to accept a custom
overlay panel. The overlay door panel design allows for a
decorative panel to cover the door trim for a seamless
appearance that will compliment surrounding cabinetry.
You may also choose to match the handle hardware of
surrounding cabinetry or use a Sub-Zero accessory handle
available through your Sub-Zero dealer. To obtain local
dealer information, visit the Locator section of our website,
subzero.com. Handles are mounted directly to the overlay
panel. Panels are mounted on the door using the Inte-
grated technique of mounting brackets.
IMPORTANT NOTE: The weight of the door panel cannot
exceed 20 lbs (9 kg).
When planning to install an Undercounter model next to
adjoining cabinetry, you must make provisions to allow the
door to open to a maximum of 145˚ and not hit the door
panel. Refer to the full-scale illustration on page 9.
Refer to the following chart and the OverlayDoor Panel
illustration for panel specifications for Model UC-24C.
OVERLAY P ANEL DIMENSIONS
Door Panel Width 23 3/4"(603)
Door Panel Height 301/16"(764)
Door Panel Weight 20 lbs (9 kg) max
Panel Thickness 5/8"(16) min
W
H
Overlay Door Panel
Planning Information
Undercounter Model UC-24C
Dimensions in parentheses are in
millimeters unless otherwise specified. 7
WOOD FACING WINE SHELVES
Sub-Zero has provided a natural cherry wood facing to the
wine shelf in the Model UC-24C. If, however, you would
like to replace this strip with wood more complementary
to your design and surrounding cabinetry, you can.
The Wine Shelf Wood Facing illustration on page 8 can be
used as a full-scale template. You must follow the layout
of this format to accommodate the shelves properly. To
remove the cherry strips, take the shelves out and merely
remove the screws.
Reverse the procedure to affix the new wood. If you
choose to stain or seal the wood facing, be aware that
some of these substances are hazardous and will damage
stored wine.
HARDWARE CONSIDERATIONS
When using an Undercounter model in an overlay applica-
tion, you must provide your own handle hardware. It is
recommended you use our optional handles available as
sales accessories.
For Model UC-24C, the handle must be fastened directly to
the overlay panel, regardless of the type of handle used.
Optional stainless steel handles are available in a variety of
diametersand lengths in the classic stainless steel finish
and polished chrome.Contact your Sub-Zerodealer for
specifics. Toobtain local dealer information, visit the
Locator section of our website, subzero.com.
Planning Information
Undercounter Model UC-24C
Dimensions in parentheses are in
millimeters unless otherwise specified. 8
191/2"(495)
Maximum Thickness
FRONT VIEW SIDE VIEW
11/2"(38)
5/8"
(16)
7/64"
(3)
5/64"
(2)
23/64"
(9)
9/16"(14)
27/32"
(21)
WINE SHELF WOOD FACING
FULL-SCALE TEMPLATES
The full-scale illustrations on this page and the following
page enable you to understand some of the unique situa-
tions you may face as you design the Undercounter units
into homes. These templates can be easily photocopied or
used in your tracings.
WINE SHELF WOOD FACING
For Model UC-24C, use the full-scale illustration above as
atemplate if you choose to replace the natural cherry
wood facing with wood more complementary to your
design and surrounding cabinetry.
Planning Information
Undercounter Model UC-24C
9
Dimensions in parentheses are in
millimeters unless otherwise specified.
DOOR PANEL
SUB-ZERO DOOR
145˚*
1
2
(13)
1
4(6)*
1
8(3)
3
4(19)
23 (587)
TO BACK OF
APPLIANCE
1
8
*UNDERCOUNTER
UNIT MUST EXTEND
A MINIMUM 1/4" (6)
BEYOND THE FRONT
SURFACE OF
ADJOINING
CABINETRY TO
ALLOW THE MAXIMUM
DOOR SWING
SUB-ZERO
DOOR
DOOR
PANEL
24 (610)
CABINETRY
OPENING
23 (600)
DOOR PANEL
WIDTH
3
4
DOOR CLOSED AND 145˚ MAX OPENING
Andere Handbücher für UC-24C
5
Inhaltsverzeichnis
Andere Sub-Zero Kühlschrank Handbücher
Sub-Zero
Sub-Zero 600 Series BI-36UG Bedienungsanleitung
Sub-Zero
Sub-Zero PRO 48 Bedienungsanleitung
Sub-Zero
Sub-Zero 600 Series BI-48S Bedienungsanleitung
Sub-Zero
Sub-Zero IC-30FI Bedienungsanleitung
Sub-Zero
Sub-Zero UC24CILH Bedienungsanleitung
Sub-Zero
Sub-Zero 648PRO Bedienungsanleitung
Sub-Zero
Sub-Zero IC-30RID Bedienungsanleitung
Sub-Zero
Sub-Zero IC-24R Bedienungsanleitung
Sub-Zero
Sub-Zero 611G Bedienungsanleitung
Sub-Zero
Sub-Zero BI-36UFD Bedienungsanleitung
Sub-Zero
Sub-Zero IC-24R-RH Bedienungsanleitung
Sub-Zero
Sub-Zero 600 Series BI-36R Bedienungsanleitung
Sub-Zero
Sub-Zero DEC3650RL Bedienungsanleitung
Sub-Zero
Sub-Zero UC-24BG Bedienungsanleitung
Sub-Zero
Sub-Zero ICBBI-36R Leitfaden
Sub-Zero
Sub-Zero 601R Bedienungsanleitung
Sub-Zero
Sub-Zero INTEGRATED REFRIGERATION Bedienungsanleitung
Sub-Zero
Sub-Zero 700TR Bedienungsanleitung
Sub-Zero
Sub-Zero Wolf 500 Series Bedienungsanleitung
Sub-Zero
Sub-Zero 695/F Leitfaden
Beliebte Kühlschrank Handbücher anderer Marken
Bonnet Neve
Bonnet Neve SKYVIEW PLUS Bedienungsanleitung
Zanussi Electrolux
Zanussi Electrolux ZERB 8441 Bedienungsanleitung
Sharp
Sharp SJ-BA31IEXW2-EU Bedienungsanleitung
CORBERO
CORBERO CC2300MCW Bedienungsanleitung
KitchenAid
KitchenAid 2205264 Bedienungsanleitung
Stengel
Stengel KU 1101 A++ Bedienungsanleitung
