Summit FF-1074W Bedienungsanleitung

Two-Door Frost Free Refrigerator

Le Manuel de Deux Portes Dégivrent le

Réfrigérateur

El Manual de Dos Puertas Descongela el

Refrigeradore

User Manual (Features may vary by model)

Model # FF-874W, FF-1074W, FF-1274W

Guide de l’Utilisateur (Les caractéristiques Peuvent Varier par le Modéle)

Modéle # FF-874W, FF-1074W, FF-1274W

Manual del Usuario (Las caracteristicas Pueden Variar por el Modelo)

Para Modelo de # FF-874W, FF-1074W, FF-1274W

SAFETY PRECAUTIONS

Read all of the instructions before using this appliance. When using this

appliance, always exercise basic safety precautions, including the

following:

1) Use this appliance only for its intended purpose as described in this use

and care guide.

2) This refrigerator must be properly installed in accordance with the

installation instructions before it is used. See grounding instructions in the

installation section.

3) Never unplug your refrigerator by pulling on the power cord. Always

grasp the plug firmly and pull straight out from the outlet.

4) Repair or replace immediately, all electric service cords that have become

frayed or otherwise damaged. Do not use a cord that shows cracks or

abrasion damage along its length, the plug or the connector end.

5) Unplug your refrigerator before cleaning or before making any repairs.

Note: If for any reason this product requires service, we strongly

recommend that a certified technician performs the service.

6) Do not use any electrical device or any sharp instrument in defrosting your

refrigerator.

7) If your old refrigerator is not being used, we recommend that you remove

the doors and leave the shelves in place. This will reduce the possibility of

danger to children.

8) After your refrigerator is in operation, do not touch the cold surfaces in

the freezer compartment, particularly when hands are damp or wet. Skin

may adhere to these extremely cold surfaces.

9) Do not refreeze foods which have been thawed completely. The United

States Department of Agriculture in Home and Garden Bulletin No. 69

reads: “…You may safely refreeze frozen foods that have thawed if they

still contain ice crystals or if they are still cold-below 40˚F.“

“…Thawed ground meats, poultry, or fish that have any off-odor or

off-color should not be refrozen and should not be eaten. Thawed ice

cream should be discarded. If the odor or color of any food is poor or

questionable, discard it. The food may be dangerous to eat.“

“…Even partial thawing and re-freezing reduce the eating quality of

foods, particularly fruits, vegetables, and prepared foods. The eating

quality of red meats is affected less than that of many other foods. Use

refrozen foods as soon as possible, to save as much of its eating quality

as you can.“

EnglishEnglish

Thank you for using our Summit

product. This easy-to-use manual will

guide you in getting the best use of

your refrigerator.

Remember to record the model and

serial number. They are on a label in

back of the refrigerator.

Model number

Serial number

Date of purchase

Staple your receipt to your manual. You will need it to obtain

warranty service.

10) This refrigerator should not be recessed or built-in in an enclosed

cabinet. It is designed for freestanding installation only.

11) Do not operate your refrigerator in the presence of explosive fumes.

SAVE THESE INSTRUCTIONS

for future use

DANGER

Risk of child entrapment. Before you throw away your old

refrigerator or freezer, take off the doors. Leave the shelves

in place so that children may not easily climb inside.

EnglishEnglish

Table Of Contents

PAGE

Safety Precautions...........................................................................1

Parts And Features ..........................................................................4

Installing Your Refrigerator ...........................................................5

Unpacking Your Refrigerator...................................................................5

Adjusting Your Refrigerator.....................................................................5

Proper Air Circulation ............................................................................5

Electrical Requirements ...........................................................................6

Door Alignment .....................................................................................7

Reversing the Door Swing.......................................................................8

Refrigerator Features And Use .................................................. 10

General Features................................................................................. 10

Refrigerator Interior Shelves................................................................. 10

Crisper and Crisper Cover................................................................... 11

Food Storage Information .................................................................... 12

Normal Operating Sounds................................................................... 13

Proper Refrigerator Care and Cleaning ................................... 14

Cleaning and Maintenance.................................................................. 14

Light Bulb Replacement........................................................................ 15

Power Interruptions ............................................................................. 15

Vacation and Moving Care.................................................................. 15

Troubleshooting............................................................................. 16

Warranty Information.................................................................. 18

EnglishEnglish

Parts And Features

EnglishEnglish

1. Ice Cube Trays

2. Full-Width Freezer Door Shelves

3. Full-Width Door Shelf

4. Adjustable Front Leveling Legs

(not shown)

5. Clear Crisper

6. Clear Glass Crisper Cover

7. Adjustable Full-Width Wire Shelves

(number will vary by model)

8. Adjustable Mechanical

Temperature Control

9. Interior Light

10. Freezer Shelf

11. Gallon Storage Compartment

12. Can Storage (not on all models)

13. 1/2 Width Shelf Storage

Compartment (not on all models)

14. Half-Width Shelf, 2 Liter Bottle

Storage Compartment

15. Crisper Humidity Control

16. Air Flow Control

17. Condiments Storage Shelf

(not on all models)

(Features may vary per model)

Unpacking Your Refrigerator

1. Remove all packaging material. This includes the foam base and

all adhesive tape holding the refrigerator accessories inside an outside.

Slide out and remove plastic or foam guard used to secure the

compressor from shipping damage due to vibration and shock.

2. Inspect and remove any remains of packing, tape or printed materials

before powering on the refrigerator.

Adjusting Your Refrigerator

Leveling Your Refrigerator:

• Your refrigerator has two leveling legs which are located in the

front corners of your refrigerator. After properly placing your

refrigerator in its final position, you can level your refrigerator.

• Leveling legs can be adjusted by turning them counterclockwise to raise

your refrigerator or by turning them clockwise to lower your refrigerator.

The refrigerator door will close easier when the leveling legs are raised.

Proper Air Circulation

• To ensure that your refrigerator works at the maximum efficiency it was

designed for, you should install it in a location where there is proper air

circulation, plumbing and electrical connections.

• The following are recommended clearances around the

refrigerator:

Sides……………3/4" (19mm)

Top....................1" (25mm)

Back..................1" (25mm)

Installing Your Refrigerator

EnglishEnglish

Electrical Requirement

• Make sure there is a suitable power outlet (115 volts, 15 amps outlet)

with proper grounding to power the refrigerator.

• Avoid the use of three-plug adapters or cutting off the third grounding

in order to accommodate a two-plug outlet. This is a dangerous practice

since it provides no effective grounding for the refrigerator and may

result in shock hazard.

Installation Limitations

• Do not install your refrigerator in any location not properly insulated or

heated, e.g. garage etc. Your refrigerator was not designed to operate

in temperature settings below 55˚ Fahrenheit.

• Select a suitable location for the refrigerator on a hard, even

surface away from direct sunlight or heat source, e.g. radiators,

baseboard heaters, cooking appliances etc. Any floor unevenness should

be corrected with the leveling legs located on the front bottom corners of

the refrigerator.

Use of Extension Cords

• Avoid the use of an extension cord because of potential safety

hazards under certain conditions. If it is necessary to use an extension

cord, use only a 3-wire extension cord that has a 3-blade grounding

plug and a 3-slot outlet that will accept the plug. The marked rating of

the extension cord must be equal to or greater than the electrical rating

of the appliance.

Freezer Door: (see fig. # 1)

1. Remove hinge cover screw.

2. Remove the top hinge cover.

3. Loosen the top hinge screws using a Phillips head screwdriver.

4. Adjust the door or put a spacer in between and then tighten the screws.

5. Replace the top hinge cover.

Door Alignment

Reversing the Door Swing

fig. # 1

Hinge

cover

Top hinge

EnglishEnglish

Left/right door opening method:

This product allows you to reverse the door opening from left to right and

back. You can select your preference of door opening by following the

procedure to make the change.

Dismantling: (see fig. # 1 and fig. # 2)

1. Affix refrigerator and freezer door by sticking adhesive tape on both

sides to hold doors in place.

2. As shown in fig. 1, dismantle the hinge cover on the upper part of

freezer door with a Phillips head screwdriver. Then remove the three

screws that hold the hinge. Take out the hinge by pulling it vertically,

and keep it in a safe place.

3. Remove the adhesive tape on freezer door, lift it and take off the door,

and carefully put it aside.

4. Dismantle two screws of the central hinge, lift it and take off the central

hinge, and keep them in a safe place. (see fig # 2)

5. Remove the adhesive tape on refrigerator door, lift it and take

refrigerator door, and carefully put it aside.

6. Remove the doorstoppers from the refrigerator and freezer doors.

7. Insert left side doorstopper (provided in your packing) on the left side

bottom hole of the refrigerator door and on the left side bottom hole of

the freezer door. Fasten with screws provided.

screw holes

doorstopper (right side)

middle pivot pin

central hinge

fig. # 2

EnglishEnglish

Reinstallation: (see fig. # 3 and fig. # 4)

1. Remove the lower pivot pin from the lower hinge by turning counter

clockwise. Move the pin to the opposite hole and tighten. (see below)

2. Tilt refrigerator on a 45-degree angle to have access to the

bottom front.

NOTE: Two People Required.

lower pivot pin

fig. # 3

bottom of unit

bottom hinge

3. Remove both left and right front feet from bottom.

4. Loosen the screws holding the bottom hinge

and remove it.

5. Align the holes in the bottom hinge to the corresponding holes on the

opposite side of the cabinet. Insert and tighten the screws. Reinstall both

front feet.

6. To install refrigerator door: Line up the left bottom hole of the

refrigerator compartment door over the bottom hinge pin. Move

door forward to make it straight and align with central hinge.

Install the central hinge again, and turn the hinge axle until it

completely enters the door body. Secure it with the screws provided.

(see fig. 4)

NOTE: Remove plugs from doorframe and install on other side.

7. To install freezer door: Lineup left bottom hole of the door over the

central hinge middle pin. Move door forward to make it straight

and align with freezer compartment. Place over left side the top hinge,

align holes with hole on the refrigerator top and tighten with the

screws provided.

doorstopper (left side)

middle pivot pin

central hinge

screw holes

fig. # 4

EnglishEnglish

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Summit Kühlschrank Handbücher

Summit

Summit BRF36FD Series Bedienungsanleitung

Summit

Summit FF7L Leitfaden

Summit

Summit ADRD24 Bedienungsanleitung

Summit

Summit CT66L Leitfaden

Summit

Summit FFRF24SS Bedienungsanleitung

Summit

Summit FF22BDRSS Bedienungsanleitung

Summit

Summit FF1118W Series Bedienungsanleitung

Summit

Summit FF-1074 Series Bedienungsanleitung

Summit

Summit FF412ES Bedienungsanleitung

Summit

Summit FF7BBISSTB Leitfaden

Summit

Summit Accucold FF6W Series Bedienungsanleitung

Summit

Summit FFBF240W Bedienungsanleitung

Summit

Summit FF101W Bedienungsanleitung

Summit

Summit FF31L7 Bedienungsanleitung

Summit

Summit FF43ES Bedienungsanleitung

Summit

Summit FF-874 Series Bedienungsanleitung

Summit

Summit CT66BADACSS Bedienungsanleitung

Summit

Summit FF1843BCSSADA Bedienungsanleitung

Summit

Summit FFAR12W7 Bedienungsanleitung

Summit

Summit FFBF240W Bedienungsanleitung

Summit

Summit FF1325SSIM Bedienungsanleitung

Summit

Summit CP351W Bedienungsanleitung

Summit

Summit SCRR230 Bedienungsanleitung

Summit

Summit CT66BI series Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
