FF71ES

COMPACT REFRIGERATOR-FREEZER

INSTRUCTION

MANUAL

FELIX STORCH, INC.

770 Garrison Avenue

Bronx, New York 10474

www.summitappliance.com

Write Serial Number here:

___________________________

IMPORTANT SAFEGUARDS

Your safety and the safety of others are very important to us. We have

provided several important safety messages in this manual. Always read and

obey all safety messages. Serious injury or even death can result if you do not

follow these instructions. All safety messages will tell you what the potential

hazard is, how to reduce the chance of injury, and what can happen if the

instructions are not followed.

WARNING! To reduce the risk of fire, electric shock or injury when

using your appliance, follow these basic precautions:

•This unit is not designed to operate in enclosed spaces. When placing your

unit, make sure you allow adequate airflow on all sides.

•Use two or more people to move and install this appliance.

•Plug into a grounded 3-prong outlet.

•Do not remove ground prong, nor use a 3/2 adapter.

•Do not use an extension cord.

•This appliance is designed for free-standing installation only. It should not

be recessed or built in.

•Use care not to plug into outlets controlled by wall switches.

•Disconnect power before servicing.

•After service, replace all parts and panels before operating.

•Do not store or use gasoline or other flammable items in the area of this or

any appliance, as the fumes can create a fire hazard or explosion.

•Use nonflammable cleaners.

•When replacing a light bulb, unplug the appliance or turn off power at the

circuit breaker or fuse box in order to avoid touching a live wire. Turning the

thermostat to OFF turns off the compressor, but does not disconnect power

to other electrical components.

•Never unplug your appliance by pulling on the power cord. Always grip the

plug firmly and pull straight out from the socket.

•Be careful not to roll over or damage the cord when moving the appliance.

•Do not pinch, knot or bend the power cord in any manner.

•Replace or repair any electric service cord that has become damaged or

frayed.

•Unplug the appliance before making repairs or cleaning. We recommend

that servicing be done by a qualified technician.

If your electricity goes off, follow this procedure:

•Call your power company to see how long the power will be out.

•If service is to be interrupted for less than 24 hours, keep the appliance

closed as much as possible. This will help keep food from spoiling.

•If service is to be interrupted for more than 24 hours, remove food and

store in a refrigerated food locker or other refrigerator.

RISK OF CHILD ENTRAPMENT !

Old appliances can represent a suffocation hazard to children.

•Remove door(s) from your old appliance.

•Leave shelves or baskets in place.

•If an old appliance contains refrigerants, it must be recycled by a

licensed service or disposal agency.

– SAVE THESE INSTRUCTIONS –

TECHNICAL INFORMATION

Model: FF71ES

Type: Compact refrigerator-freezer

Color: White

Capacity: 4.8 cubic feet

Electrical Input: 115V AC / 60Hz

Energy Consumption: 346 kWh/yr

Energy Star approved: Yes

Refrigerant: R134a

Installation: Free-standing

Unit Weight: 102.0 lbs

Unit Dimensions: 18.75"W x 23.0"D x 46.0"H

LOCATION OF PARTS

1. Discharge air outlet Since cold air flows through this outlet into the

refrigerator, be sure to avoid blocking it with

stored food.

2. Suction inlet Air which was circulated throughout the

refrigerator is sucked through this opening.

3. Temperature control Regulates temperature inside the refrigerator.

4. Plastic-coated shelves Odor resistant, rustproof

5. Freezer shelf

6. Vegetable crisper

7. Interior light

8. Light switch

9. Freezer temperature control

10.

Evaporating tray (not shown)

Water evaporation takes place outside the unit.

11. Ice cube tray

12. Upper door rack

13. Bottom door rack

14. Glass shelf

15. Adjustable legs Use these to stabilize the refrigerator.

INSTALLATION

•Remove the exterior and interior packing.

Before Using Your Refrigerator-Freezer

•Check to be sure refrigerator and freezer shelves are installed and that

the strips of tape holding them in place have been removed.

•Before connecting the unit to the power source, let it stand upright for

at least ½ hour. This will reduce the possibility of a malfunction in the

cooling system from handling during transportation.

•Clean the interior surfaces with lukewarm water using a soft cloth. Any

plastic odor that you notice when you first open the doors will dissipate

once the appliance is operating.

•This appliance is designed to be free-standing only, and should not be

recessed or built-in.

Installation of Your Appliance

•Place your appliance on a floor that is strong enough to support it when

it is fully loaded. Be sure the appliance is level. (Level your refrigerator-

freezer by adjusting the legs at the front.)

•Allow at least 4” of clearance at the sides and the top, and 5 inches

between the back of the unit and the wall behind, which allows the

proper air circulation to cool the compressor. This improves cooling

efficiency and saves energy.

•Do not cover the top of the unit with a mat or cloth. This will help

maintain the operating efficiency of the appliance.

•Locate the refrigerator away from direct sunlight and sources of heat

(stove, heater, radiator, etc.). Direct sunlight may affect the acrylic

coating and heat sources may increase electrical consumption.

Extremely cold ambient temperatures may also cause the refrigerator

to perform improperly.

•Avoid locating the refrigerator in moist areas.

•This refrigerator-freezer is equipped with a three-prong plug and is

grounded to eliminate electrical hazards. In order to make it effective,

the unit must be plugged into a grounded electrical outlet.

•Do not use an extension cord.

Test Run

Before using the refrigerator-freezer, clean it and make a test run to see if the

following steps can be completed. If not, check the electrical supply. If the

cause of trouble cannot be located, contact your Summit dealer.

1. Set the Temperature Control Knob to the OFF position and then plug the AC

cord into an electrical outlet of 115 volts, 60 Hz. The motor should not run.

2. Set the Temperature Control Knob at the MAX position and let the unit

operate for 20 minutes. The freezer compartment should get slightly frosted

and the motor should run smoothly with a soft hum.

3. Then rotate the Temperature Control Knob counterclockwise toward the

MIN position. Before the pointer of the knob reaches the MIN position, the

motor should turn off.

Reversing the Door Swing

The doors of the refrigerator-freezer can be hinged on either side so that the

door swing can be suited to the location of the installation.

Tools Required:

•standard screwdriver

•large Phillips head screwdriver

•socket wrench (3/8")

In order to reverse the position of the door hinges, refer to the disassembly

diagram on the following page and follow this procedure.

1. Remove the hinge cap by twisting it off.

2. Remove the upper hexagonal-head screws. The top hinge and the freezer

door can now be removed.

ATTENTION

This appliance is equipped with a special Thermo-

stat Control Device. If the unit is turned off or

unplugged, YOU MUST ALLOW THREE (3)

MINUTES BEFORE RESTARTING OR REPLUG-

GING THE UNIT.

The unit will not start if you attempt to restart it in

less than three minutes.

3. Remove the middle hexagonal screws. The middle hinge and the

refrigerator door can now be removed.

4. Remove the cover for the middle hinge holes and re-attach it symmetrically

to the holes on the other side.

5. Tilt the refrigerator back or lay it on its back for steps 6, 7 and 8. Use a pad

or blanket to protect the floor and to avoid scratching the painted finish.

6. Remove the leveling legs by turning them counterclockwise. Remove the

lower hexagonal-head screws, two on the hinge side and one near the front

corner of the other side.

7. Attach the bottom hinge symmetrically to the other side of the cabinet with

the screws removed in Step 6. (Do not tighten screws completely.)

8. Attach the left side leg and the leg spacer to the other side hole which was

positioned symmetrically.

9. Remove the upper hinge plastic pins and insert them in the holes from

which the screws were removed in Step 2.

10.Take off the hinge collar caps from both the freezer and refrigerator doors

using a screwdriver and insert them in the hinge collar on the opposite side.

11.Attach the shaft to the hinge bottom. Attach the refrigerator door to the

shaft.

12.Rotate the middle hinge 180°. Attach it to the refrigerator door and secure it

with screws. (Do not tighten screws completely.)

13.Attach the upper hinge to the freezer door. Attach the freezer door to the

middle hinge and use the screws to attach the upper hinge. (Do not tighten

screws completely.)

14.The direction in which the doors open has now been changed; however, the

following points should be checked:

a. Make sure the doors are on straight.

b. Make sure there is no space between the door gaskets and the

refrigerator and freezer units themselves when the doors are closed.

c. Make sure that the gasket on the hinge side is not caught between the

door and the unit when the door is opened or closed. (If the door is

forced closed when the gasket is caught, the gasket might be damaged.)

d. When checking the above points, if it is discovered that the doors are not

installed properly (this is apt to happen on the first try), loosen the screws

holding the upper hinge, straighten the door and tighten the screws

slowly with the socket wrench. After making sure that the doors are

installed correctly, tighten all the screws holding the hinge.

If they are not tightened, the doors may slip out of position or there may

be an opening between the doors and the unit.

15. Stand the unit back in the upright position.

OPERATION

Refrigerator temperature can be regulated by adjusting the Temperature

Control Knob. The closer to the MAX position the control knob is set by rotating

it clockwise, the lower the refrigerator temperature becomes.

Temperature Control

Refrigerator temperature will vary depending on the quantity of food stored and

on the frequency with which the door is opened. Set the Temperature Control

Knob at the MAX position only when ice cubes are needed in a hurry.

This refrigerator may turn on and off more frequently than regular size

refrigerators. This is normal because of its compactness.

Due to its frost-free operation, this refrigerator-freezer does not require manual

defrosting.

Defrosting

The ice cube tray is flexible. Twist the tray to

remove ice cubes.

Ice Cube Tray

Do not use boiling water or a metal instrument

such as a knife or screwdriver to remove the ice

cube tray, because this may damage plastic parts

or the evaporator.

CLEANING AND MAINTENANCE

Turn off the refrigerator and remove foods, shelves, trays, etc. Wash the interior

liner with a solution of warm water and two tablespoonfuls of baking soda per

quart. Then rinse and wipe. Do not use soaps, detergents, scouring powder,

spray cleaners or the like on the liner, as these may cause odors in the

refrigerator compartment.

Wash ice cube tray, drip trays and shelves in a mild detergent solution and dry

with a soft cloth.

Usually the Temperature Control Knob

should be set at the middle position (3).

Wipe the exterior surface with a soft cloth dampened with soapy water and then

dry with a soft cloth. A spray appliance cleaner may be used for the exterior

only.

Use only lukewarm soapy water to clean the door gaskets.

Never use acids, chemical thinner, gasoline, benzene or the like for cleaning

any part of the refrigerator. Boiling water and benzene may deform or damage

plastic parts.

•Short vacations: Leave the unit operating during vacations of less

than three weeks.

Vacation Time

•Long vacations: If the appliance will not be used for several months,

remove all food and unplug the power cord. Clean and dry the interior

thoroughly. To prevent odor and mold growth, leave the doors open

slightly, blocking them open if necessary.

1. Remove all the food.

Moving Your Refrigerator

2. Securely tape down all loose items inside your refrigerator.

3. Tape the door shut.

4. Be sure the refrigerator stays secure in the upright position during

transportation. Also protect the outside of the refrigerator with a blanket

or similar item.

•The appliance should be located in the coolest area of the room, away

from heat-producing appliances and out of direct sunlight.

Energy-Saving Tips

•Let hot foods cool to room temperature before placing in the

refrigerator or freezer compartment. Overloading the refrigerator forces

the compressor to run longer.

•Be sure to wrap foods properly, and wipe containers dry before placing

them in the unit. This cuts down on frost build-up inside the

refrigerator/freezer.

•To allow proper air circulation, keep a space between stored foodstuffs.

To inhibit drying and to cut down on odors, be sure food is packed well.

•Refrigerator shelves should not be lined with aluminum foil, wax paper,

or paper toweling. Liners interfere with cold air circulation, making the

refrigerator less efficient.

•Organize and label food to reduce door openings and extended

searches. Remove as many items as needed at one time, and close

the door as soon as possible.

Inhaltsverzeichnis

Andere Summit Kühlschrank Handbücher

Summit

Summit FF410WH Bedienungsanleitung

Summit

Summit ASDR1524 Bedienungsanleitung

Summit

Summit FF32L Bedienungsanleitung

Summit

Summit ADRD18 Bedienungsanleitung

Summit

Summit FF7L-BLSSTB Leitfaden

Summit

Summit AL750 series Leitfaden

Summit

Summit SPR275OS2D Bedienungsanleitung

Summit

Summit FDRD15SS Bedienungsanleitung

Summit

Summit CP972SS Bedienungsanleitung

Summit

Summit FFBF192SSBI Bedienungsanleitung

Summit

Summit FF1425SS Bedienungsanleitung

Summit

Summit FF1117BL Series Bedienungsanleitung

Summit

Summit FF7LBI Leitfaden

Summit

Summit GLOBAL INDUSTRIAL GIDIFFBF283SS Bedienungsanleitung

Summit

Summit FF882 Bedienungsanleitung

Summit

Summit FFBF249SS2 Bedienungsanleitung

Summit

Summit FFBF287SSIM Bedienungsanleitung

Summit

Summit ingenious Bedienungsanleitung

Summit

Summit FF1084W Bedienungsanleitung

Summit

Summit Accucold FF7LBIVAC Bedienungsanleitung

Summit

Summit SPR7OS SERIES Bedienungsanleitung

Summit

Summit CP351W Bedienungsanleitung

Summit

Summit FF41ES Bedienungsanleitung

Summit

Summit FFBF285SS Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
