Sun ™GigabitEthernet PCI
Adapter 1.0 Product Notes
Part No.: 805-1138-10
Revision A, August 1997
SunSoft, Inc.
Copyright 1997 Sun Microsystems, Inc., 901 San Antonio Road • Palo Alto, CA 94303 USA. All rights reserved.
This product or document is protected by copyright and distributed under licenses restricting its use, copying, distribution, and decompilation.
No part of this product or document may be reproduced in any form by any means without prior written authorization of Sun and its licensors,
if any. Third-party software, including font technology, is copyrighted and licensed from Sun suppliers.
Parts of the product may be derived from Berkeley BSD systems, licensed from the University of California. UNIX is a registered trademark in
the U.S. and other countries, exclusively licensed through X/Open Company, Ltd.
Sun, Sun Microsystems, the Sun logo, AnswerBook, SunDocs, and Solaris]are trademarks, registered trademarks, or service marks of Sun
Microsystems, Inc. in the U.S. and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks
of SPARC International, Inc. in the U.S. and other countries. Products bearing SPARC trademarks are based upon an architecture developed by
Sun Microsystems, Inc.
The OPEN LOOK and Sun™ Graphical User Interface was developed by Sun Microsystems, Inc. for its users and licensees. Sun acknowledges
the pioneering efforts of Xerox in researching and developing the concept of visual or graphical user interfaces for the computer industry. Sun
holds a non-exclusive license from Xerox to the Xerox Graphical User Interface, which license also covers Sun’s licensees who implement OPEN
LOOK GUIs and otherwise comply with Sun’s written license agreements.
RESTRICTEDRIGHTS: Use, duplication, or disclosure by the U.S. Government is subject to restrictions of FAR 52.227-14(g)(2)(6/87) and
FAR 52.227-19(6/87), or DFAR 252.227-7015(b)(6/95) and DFAR 227.7202-3(a).
DOCUMENTATION IS PROVIDED “AS IS” AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-
INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID.
Copyright 1997 Sun Microsystems, Inc., 901 San Antonio Road • Palo Alto, CA 94303 Etats-Unis. Tous droits réservés.
Ce produit ou document est protégé par un copyright et distribué avec des licences qui en restreignent l’utilisation, la copie, la distribution, et la
décompilation. Aucune partie de ce produit ou document ne peut être reproduite sous aucune forme, par quelque moyen que ce soit, sans
l’autorisation préalable et écrite de Sun et de ses bailleurs de licence, s’il y en a. Le logiciel détenu par des tiers, et qui comprend la technologie
relative aux polices de caractères, est protégé par un copyright et licencié par des fournisseurs de Sun.
Des parties de ce produit pourront être dérivées des systèmes Berkeley BSD licenciés par l’Université de Californie. UNIX est une marque
déposée aux Etats-Unis et dans d’autres pays et licenciée exclusivement par X/Open Company, Ltd.
Sun, Sun Microsystems, le logo Sun, AnswerBook, SunDocs, et Solaris sont des marques de fabrique ou des marques déposées, ou marques de
service, de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays. Toutes les marques SPARC sont utilisées sous licence et sont des
marques de fabrique ou des marques déposées de SPARC International, Inc. aux Etats-Unis et dans d’autres pays. Les produits portant les
marques SPARC sont basés sur une architecture développée par Sun Microsystems, Inc.
L’interface d’utilisation graphique OPEN LOOK et Sun™ a été développée par Sun Microsystems, Inc. pour ses utilisateurs et licenciés. Sun
reconnaît les efforts de pionniers de Xerox pour la recherche et le développement du concept des interfaces d’utilisation visuelle ou graphique
pour l’industrie de l’informatique. Sun détient une licence non exclusive de Xerox sur l’interface d’utilisation graphique Xerox, cette licence
couvrant également les licenciés de Sun qui mettent en place l’interface d’utilisation graphique OPEN LOOK et qui en outre se conforment aux
licences écrites de Sun.
CETTE PUBLICATION EST FOURNIE "EN L’ETAT" ET AUCUNE GARANTIE, EXPRESSE OU IMPLICITE, N’EST ACCORDEE, Y
COMPRIS DES GARANTIES CONCERNANT LA VALEUR MARCHANDE, L’APTITUDE DE LA PUBLICATION A REPONDRE A UNE
UTILISATION PARTICULIERE, OU LE FAIT QU’ELLE NE SOIT PAS CONTREFAISANTE DE PRODUIT DE TIERS. CE DENI DE
GARANTIE NE S’APPLIQUERAIT PAS, DANS LA MESURE OU IL SERAIT TENU JURIDIQUEMENT NUL ET NON AVENU.
1
Sun GigabitEthernet PCI Adapter
Product Notes
These release notes provide the latest software information about the Sun
GigabitEthernet PCI Adapter 1.0. It is a supplement to the Sun GigabitEthernet PCI
Adapter 1.0 User’s Guide.
Quick Installation Instructions
This section provides you an overview of what you must do to install and configure
the Sun Gigabit Ethernet PCI Adapter. For more detailed instructions, refer to the
Sun GigabitEthernet PCI Adapter 1.0 User’s Guide.
▼To Install the Adapter
1. Shutdown and power off the system that will receive the adapter(s).
2. Install Gigabit Ethernet adapter into appropriate slot(s) within your system.
3. Power on the system and watch for the Gigabit adapter device information to be
displayed on the system console. If you don’t see the adapter, you may need to
repeat step 1 to ensure that the adapter has been properly seated.
2Sun GigabitEthernet PCI Adapter 1.0 Product Notes • August 1997
▼To Install the Software
1. Become root.
2. Place the CD-ROM into the CD-ROM drive.
3. Mount the CD-ROM on a local directory.
If the Volume Manager (vold) is running, on your machine, then the CD-ROM is
mounted automatically under /cdrom/sungige_1_0 when it is loaded in the drive
4. Access the package directory.
5. Install the software by entering pkgadd -d . (don’t forget the dot):
The screen displays a list of packages available for installation:
6. Press Return.
The pkgadd command starts the installation script.
7. Respond to the prompts in the script.
#cd /cdrom/sungige_1_0/Product
#pkgadd -d .
The following packages are available:
1 SUNWvge Sun GigabitEthernet Adapter 1.0
(sparc) 1.0.0
2 SUNWvts Online Validation Test Suite 2.0
(sparc) 2.1, REV=35.97.05.30
Select package(s) you wish to process (or ‘all’ to process all
packages). (default: all) [?, ??, q]
Sun GigabitEthernet PCI Adapter Product Notes 3
8. When you have finished loading the software, unmount the CD-ROM directory:
If the automounter fails to flush a previous mount point, you may see the following
directory:
If this should happen, remove the empty directory.
▼Configure the Host Files
1. Enter echo <interface-name>/etc/hostname.vge0.
The variable <interface-name> represents the name to be associated with the first
gigabit ethernet adapter (for example,
echo myhostname-ge0 /etc/hostname.vge0)
2. Assign the IP address by using vi or a similar text editor to edit the /etc/hosts
file.
For the example in Step 1, to assign the IP address 192.170.87.32 to the interface
myhostname-ge0, you would add the following entry to your /etc/hosts file:
3. Reboot your system.
#cd /
#eject /cdrom
/cdrom/sungige_1_0#1
#rmdir /cdrom/sungige_1_0#1
192.170.87.32 myhostname-ge0
#reboot -- -r
4Sun GigabitEthernet PCI Adapter 1.0 Product Notes • August 1997
Documentation Updates
This section corrects or updates the Sun GigabitEthernet PCI Adaper 1.0 User’s Guide.
Hardware Requirements
The Sun Gigabit Ethernet PCI Adapter 1.0 User's Guide incorrectly states that the PCI
adapter will be supported on the Sun Ultra2. The PCI adapter will be supported on
the Sun Ultra Enterprise 3000 and Sun Ultra Enterprise 4000 and 5000 systems with
PCI I/O cards.
The Ultra Enterprise systems will support 2 Gigabit Ethernet cards.
Installation Correction
On page 6 of Sun Gigabit Ethernet PCI Adapter 1.0 User's Guide, Step 8 in the section
“To Install the Software,” should be amended to include the following:
When you have finished loading the software, unmount the CD-ROM director:
If the automounter failed to flush a previous mount point, you may see the
following directory:
If this should happen, remove the empty directory.
On pages 6 and 7, a textbox shows the command boot -- -r. The correct
command in both instances is as follows:
#cd /
#eject /cdrom
/cdrom/sungige_1_0#1
#rmdir /cdrom/sungige_1_0#1
#reboot -- -r
Sun GigabitEthernet PCI Adapter Product Notes 5
LED Indicators
An explanation of the LED indicators was omitted from the Sun GigabitEthernet PCI
Adapter 1.0 User’s Guide.TABLE 1 explains the LED indicators on the adapter.
GigabitEthernet Link Negotiation
The default configuration for link negotiation is auto. With this setting, the PCI
adapter will use IEEE 802.3z (draft) link negotiation.
If you are connecting the adapter to GigabitEthernet equipment that does not
support link negotiation or if there is a problem establishing a link between the two
devices, link negotiation can be turned off. See “Configuring Driver Parameters” on
page 6 for instructions on how to change the settings. Be sure that both devices are
set to the same speed and duplex configuration.
Purchasing Fiber Cables
You can purchase fiber cables directly from Sun Microsystems, Inc. using the
following part numbers:
■2-meter fiber cable X973A
■15-meter fiber cable X978A
TABLE 1 Sun GigabitEthernet PCI LEDs
Light State Description
Yellow •Off
•On
• Blinking
•Connection is good
•Fault condition detected on this port, which could be the
result of a bad cable or a bad connector; or no cable is
connected to this port
•Data coming in
Green • Off
• Steady
• Flickering
• Blinking
•Port not connected to a device
•Link detected, no data
•Link detected, data detected
•Port has been disabled by software
6Sun GigabitEthernet PCI Adapter 1.0 Product Notes • August 1997
1000BASE-SX Link Characteristics (IEEE P802.3z
draft)
TABLE 2 has been updated to reflect changes in the latest draft from IEEE. TABLE 2
replaces Table B-1 in the Sun GigabitEthernet PCI Adapter User’s Guide
Configuring Driver Parameters
Two new capabilities have been added to the parameters you can change using the
ndd utility: nic_tracing and link_negotiation. The following procedure
reflects these changes and replaces the section by the same name in the Sun
GigabitEthernet PCI Adaper 1.0 User’s Guide.
▼To Temporarily Change a Parameter
Use the ndd(1M) utility to temporarily change a parameter. This change is lost when
you reboot the system.
●To access the parameters you can change using ndd type the following command:
The system returns the following:
TABLE 2 1000BASE-SX Link Characteristics (IEEE P802.3z draft)
Description 62.5 Micron MMF 50 Micron MMF Unit
Operating Range 2 to 160 meters 2 to 550 meters m
#ndd /dev/vge '?'
?
stat_ticks (read and write)
send_max_coalesced_bds (read and write)
recv_max_coalesced_bds (read and write)
nic_tracing (read and write)
link_negotiation (read and write)
instance (read and write)
Sun GigabitEthernet PCI Adapter Product Notes 7
TABLE 3 explains the available parameters and shows the default value as well as the
minimum and maximum allowed values of each.
●To change the default settings, use the following format:
Open Issues
This section addresses Sun GigabitEthernet PCI adapter issues that were not
resolved at the time the Sun GigabitEthernet PCI Adapter 1.0 User’s Guide was printed.
Flow Control
Flow control is not supported in this release.
TABLE 3 Explanation of ndd Parameters
Parameter Meaning Default Minimum Maximum
stat_ticks Minimum number of 100 usec
tics between interrupts 100 0 No limit
send_max_coalesced_bds Number of sends before a
send complete event is set. 60 1 127
recv_max-coalesced_bds Maximum number of receives
that can be bundled into an
event.
61511
nic_tracing (not currently used) 0 0 No limit
link_negotiation Used to set link negotiation to
auto or off 1 for auto 0 for off 1 for auto
instance Used to set the device number
from which the previous data
is extracted.
0 0 Number of
Gigabit
Ethernet
NICs in the
system
#ndd -set /dev/vge parameter_name value
8Sun GigabitEthernet PCI Adapter 1.0 Product Notes • August 1997
Andere Handbücher für 1.0
2
Inhaltsverzeichnis
Andere Sun Microsystems Adapter Handbücher
Sun Microsystems
Sun Microsystems eWay SAP BAPI Bedienungsanleitung
Sun Microsystems
Sun Microsystems SunSwift 600MP series Bedienungsanleitung
Sun Microsystems
Sun Microsystems x4422a Bedienungsanleitung
Sun Microsystems
Sun Microsystems 802-1304-10 Kurzanleitung
Sun Microsystems
Sun Microsystems SunSwiftTM Bedienungsanleitung
Sun Microsystems
Sun Microsystems GigaSwift Ethernet Adapter Bedienungsanleitung
Sun Microsystems
Sun Microsystems GigabitEthernet/S 2.0 Bedienungsanleitung
Sun Microsystems
Sun Microsystems GigabitEthernet PCI Adapter Bedienungsanleitung
Sun Microsystems
Sun Microsystems 805-1797-10 Bedienungsanleitung
Sun Microsystems
Sun Microsystems Sun PCI High Speed Bedienungsanleitung
Sun Microsystems
Sun Microsystems SunFastEthernet Adapter 2.0 Bedienungsanleitung
Sun Microsystems
Sun Microsystems StorEdge Bedienungsanleitung
Sun Microsystems
Sun Microsystems E25544-02 Bedienungsanleitung
Sun Microsystems
Sun Microsystems X1150A Bedienungsanleitung
Sun Microsystems
Sun Microsystems SUN SEEBEYOND eWAY Bedienungsanleitung
Sun Microsystems
Sun Microsystems SunFastEthernet Adapte Bedienungsanleitung
Sun Microsystems
Sun Microsystems LSI22320-SR Bedienungsanleitung
Sun Microsystems
Sun Microsystems Quad FastEthernet Bedienungsanleitung
Sun Microsystems
Sun Microsystems SUN SEEBEYOND eWAY 5.1.1 Bedienungsanleitung
Sun Microsystems
Sun Microsystems SunHSI/S 3.0 Bedienungsanleitung
