Sun Microsystems SUN BLADE 150 Bedienungsanleitung

Sun Blade™ 150

DIMM Installation Guide

Please

Recycle

Sun Microsystems,Inc. has intellectual property rights relating to technology embodied in the

product that is described in this document. In particular, and without limitation, these intellectual

property rights may include one or more of the U.S. patents listed at http://www.sun.com/patents

and one or more additional patents or pending patent applications in the U.S. and in other countries.

This document and the product to which it pertains are distributed under licenses restricting their

use, copying, distribution, and decompilation. No part of the product or of this document may be

reproduced in any form by any means without prior written authorization of Sun and its licensors, if

any.

Third-party software, including font technology, is copyrighted and licensed from Sun suppliers.

Parts of the productmay be derived from Berkeley BSD systems, licensed from the University of

California. UNIX is a registered trademark in the U.S. and in other countries, exclusively licensed

through X/Open Company, Ltd.

Sun, Sun Microsystems, the Sun logo, AnswerBook2, docs.sun.com, Sun Blade, and Solaris are

trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and in other countries.

All SPARC trademarks are used under license and are trademarks or registered trademarks of

SPARC International,Inc. inthe U.S.and in othercountries. Products bearingSPARC trademarks are

based upon an architecture developed by Sun Microsystems, Inc.

The OPEN LOOK and Sun™ Graphical User Interface was developed by Sun Microsystems, Inc. for

its users and licensees. Sun acknowledges the pioneering efforts of Xerox in researching and

developing the concept of visual or graphical user interfaces for the computer industry. Sun holds a

non-exclusive license from Xerox to the Xerox Graphical User Interface, which license also covers

Sun’s licensees who implement OPEN LOOK GUIs and otherwise comply with Sun’s written license

agreements.

Use, duplication, or disclosure by the U.S. Government is subject to restrictions set forth in the Sun

Microsystems, Inc. license agreements and as provided in DFARS 227.7202-1(a) and 227.7202-3(a)

(1995), DFARS 252.227-7013(c)(1)(ii) (Oct. 1998), FAR 12.212(a) (1995), FAR 52.227-19, or FAR 52.227-

14 (ALT III), as applicable.

DOCUMENTATION IS PROVIDED "AS IS" AND ALL EXPRESS OR IMPLIED CONDITIONS,

REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF

MERCHANTABILITY, FITNESS FOR APARTICULARPURPOSEORNON-INFRINGEMENT,ARE

DISCLAIMED, EXCEPT TOTHE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE

LEGALLY INVALID.

InstallingDIMMsinthe

SunBlade150System

Verifying the Current DIMM Configuration

Before you start to install additional DIMMs, perform the following

procedures.

1. Reboot your system.

The banner screen is displayed at the top of your monitor screen as

your system reboots (FIGURE 1).

2. Read the banner screen on your monitor to verify the amount of

memory already installed in your system.

Note – The Sun Blade 150™ system reports the CPU as an

UltraSPARC™ IIe processor. The CPU in your system is an

UltraSPARC IIi processor.

FIGURE 1 Banner Screen Example

Supported DIMM Configurations

You can install one, two, three, or four DIMMs.

The first DIMM must be installed in slot 1.

Subsequent DIMMS must be installed in order. Do not leave empty

DIMM slots between filled DIMM slots.

Preparing for Installation

Before installing any components, you must power off the system,

remove the system cover, and attach an antistatic wrist strap.

Powering Off the System

1. Exit from any applications that are running.

2. Choose one of the two power-off methods, orderly or immediate:

■To perform an orderly power off:

a. Press the power switch and immediately release it (FIGURE 2).

Sun Blade 150, UltraSPARC-IIe 650 MHz, Keyboard Present.

OpenBoot 4.6, 128 MB memory installed, Serial #54528.

Ethernet address 8:0:20:1a:b3:c8, Host ID: 7200d500.

The system shutdown menu is displayed.

b. Select Shutdown.

The system performs internal shutdown procedures.

■To perform an immediate power off, press and hold the power

switch for four seconds before releasing it.

Caution – The immediate power-off method does not

perform an orderly shutdown of the operating system and

data might be lost.

3. Verify that the power-indicator LED on the power switch turns

off.

4. Turn off power to the monitor and to all external devices.

Removing the System Cover

1. Disconnect the system power cord to ensure that all power is

removed from the system (FIGURE 2).

2. Disconnect any cables that are attached to external devices, such

as the monitor, keyboard, and mouse.

Caution – Pressing the power switch does not remove all

power from the system. A standby voltage remains in the

power supply. To remove all power from the system, you

must disconnect the system power cord.

3. At the system back panel, remove the two screws that secure the

cover.

4. Slide the cover back to the end of the system chassis and lift the

cover off.

Attaching an Antistatic Wrist Strap

Caution – When handling DIMMs or other internal

components, always wear an antistatic wrist strap to

equalize all electrical potentials within the system.

1. Unwrap the first two folds of the wrist strap and wrap the

adhesive side firmly against your wrist.

2. Peel the liner from the copper foil at the opposite end of the

wrist strap.

3. Attach the copper foil end of the wrist strap to the system chassis

to provide a ground for electrostatic discharge (FIGURE 2).

FIGURE 2 Preparing for DIMM Installation

Power switch

Installing the DIMMs

Note – For maximum performance, the DIMMs in the Sun

Blade 150 system have been specifically designed for it. Do

not use DIMMs from a different system to upgrade or

replace the DIMMs in this system. Verify with your Sun

sales or service representative that the DIMMs you order

have been certified by Sun for the Sun Blade 150 system.

1. Power off the system, remove the cover, and attach an antistatic

wrist strap as described in “Preparing for Installation” on page 2.

Caution – DIMMs are extremely sensitive to static

electricity. Ordinary amounts of static electricity from

clothing or the work environment can destroy or damage

DIMMs.

Caution – Hold DIMMs only by the edges to avoid

damaging them (FIGURE 3).

FIGURE 3 Unpacking the DIMM

2. Push apart the ejection levers at each end of an empty DIMM

connector on the motherboard (FIGURE 5).

3. Unpack the DIMM, holding it only by the edges (FIGURE 3).

Note – When installing additional DIMMs, first fill slot 1

(the connector closest to the motherboard edge), then fill

towards the CPU (FIGURE 4).

4. Position the DIMM in the connector, ensuring that the alignment

notches on the bottom of the DIMM are aligned with the

connector alignment keys (FIGURE 5).

5. Press firmly on both top corners of the DIMM at the same time

until the DIMM is fully seated.

Caution – Seating the DIMM into a slot unevenly can cause

short circuits that damage the system. Ensure that all

contacts engage at the same time. Do not rock the DIMM

into place. You should hear a “click” when the DIMM is

properly seated (FIGURE 5).

6. Verify that the ejection levers close over the notches on both ends

of the DIMM.
