Sun Microsystems Fire V210 Bedienungsanleitung

Power

Ethernet Ports

Serial Ports

See the Sun Fire V210 and V240 Server

Installation Guide for more details.

See the Sun Fire V210 and V240 Server

Installation Guide for more details.

Sun Fire V240 Server

Input Parameter

SERIAL MGT : RJ-45 connector, use this port for server

management using the ALOM software.

10101: DB-9 connector, use this port for general purpose

serial data transfer.

NET MGT: RJ-45 connector, 4 use this port for making an

Ethernet connection to the ALOM software.

NET 0-3: autonegotiating 10/100/1000Base-T

AC Inlet

Voltage (RMS)

Frequency

90V to 264V

47 Hz to 63 Hz

Front Panel

Hard disk driveHard disk drive

Front bezelFront bezel

On / Standby switchOn / Standby switch

System keyswitchSystem keyswitch

DVD-ROM driveDVD-ROM drive

Sun Fire V240 Server

System

configuration

card

System

configuration

card

Open bezelOpen bezel

LocatorLocator

Service required

Server active

Sun Fire V210 Server

3Attach the Cables

Sun Fire V210 Server

Server Power On and Operation

1. Set up a console connection to the server

using the server's SERIAL MGT port.

2. Power on either from the keyboard or by

using the On/Standby switch.

Note: the server goes into Standby power

mode as soon as the power cable is connected

to the power inlet.

See the Sun Fire V210 and V240 Server

Installation Guide for more details.

LockedLocked

Forced

standby

Forced

NormalNormal

DiagnosticsDiagnostics

Ensure keyswitch is in Normal ( ) position

before continuing (Sun Fire V210 Server does

not have a keyswitch).

Sun Fire V240 Server

Keyswitch Positions

USB

NET 0-3

10101

Open bezelOpen bezel

10101 SCSI

Hard disk driveHard disk drive

Front bezelFront bezel System

configuration

card

System

configuration

card

On / Standby switchOn / Standby switch

DVD-ROM driveDVD-ROM drive

SERIAL MGT

NET MGT

Power inlet

USB

NET 0-3

SCSI

Power inlet NET MGT

SERIAL MGT

LocatorLocator

Service required

Server active

Fold

Fold Fold

Fold
