ST3300

User Manual

Suntech International Ltd.

ST3300 User Manual

1. Introduction

This document describes features, protocols and detail operation of ST3300.

If there is another operation description document for special buyer to customize or model and

the contents of the document is different with this, customizing document should be applied for

special buyer.

2. Overview

Device consists of WCDMA, GPS and event parts.

The main purpose of device reports getting GPS position and other informs of vehicle to server

periodically.

Device can control or check connected lines and support additional functions.

2-1. Operation Mode

The device has 3 operation modes, driving, parking and emergency.

** Driving : Driving status when ignition is on.

** Parking : Parking status that starts if ignition is off during more than T1.

** Emergency : Once panic button is On or any other status as per designed.

The device sends emergency reports until A1 times or receiving server acknowledge.

2-2. Report

AVL reports GPS and some information at predefined interval, depending on the current modes.

Also, AVL sends some alerts, for example, movement at the parking condition, changing of

connected input line and so on.

Device distinguishes all reports with 6 types, Status report, emergency, event, alert, alive and

command response.

Device can store reports when reporting route (For example, WCDMA condition) is not successful.

Storage capacity is up to 2,000 status reports, 50 emergency reports, 50 alert reports (include

event reports) and 1500 bytes as command response. In case of status reports, oldest report is

erased and new report is buffered when the buffer is full and new status report enters (FIFO).

When reporting condition is recovered, device starts sending all buffered reports.

Also, this capacity can increase if it is needed.

Each type of reports has priority, and priority is as below.

Emergency  Command Response  Alert  Status Report  Alive (Lowest)

ST3300 User Manual

Emergency is the first to be sent after recovering WCDMA condition.

2-3. Setting Parameter

Parameters of device can be changed by WCDMA or SMS, and some control can be realized also

in the same way.

Detail protocols are described in Chapter 4.

2-4. Features

Key features are described here;

- Power Down

Device can process two steps of power-down, Sleep and Deep Sleep, for reducing power

consumption when the vehicle is parked.

- LED Indicator

LED indicates WCDMA and GPS states. It’s helpful to check error cause.

- Events

Device has 2 output lines, 3 input lines and ignition line.

- Update Firmware by Over The Air (FOTA)

When Firmware of device has some error or has to be changed for a new service to be

implemented, device can update internal ROM file by over the air (FOTA), remotely via WCDMA.

Customers do not need to visit every vehicle to download the new firmware.

Method of FOTA describes at “SunTech_OTA_UA_Protocol” document in detail.

- Parking Lock

Device can check whether the vehicle moves off the preset parking boundary or starts driving

without ignition on. In the case that it notes the unauthorized moving or driving, it sends

emergency report immediately.

- Over speed

Device can check speed of vehicle and send alert of over-speed to server.

- GPS Antenna Checking

Device can alert when GPS antenna is disconnected.

ST3300 User Manual

It’s applicable only for models that have external antenna.

- Main Power Checking

The device can recognize the main power and inform to server when main power line is

disconnected or main power drops below preset value.

It’s applicable only for battery model.

- Battery Error Alert

Device can alert about battery error related on charging.

It’s applicable only for battery model.

3. Protocol Construction

All command and reports are string and follows below format.

Every filed is distinguished by semi colon.

All report string from device is ended by ‘＼r’ (0x0D).

Command message format (from server to device)

HDR DEV_ID VER Field 1 Field 2 …Field n

Field Definitions Remark

HDR String “ST3300” + Command type

DEV_ID 6 char. Device ID of AVL

VER “02” Protocol Version. This is fixed with “02”.

Field 1 ~ n String Contents

Device ID is unique number of each device that consists of 6digits.

If the command has invalid value or DEV_ID of the command that is sent by WCDMA or SMS is

not matched with DEV_ID of the unit.

Report message format (from device to server)

HDR DEV_ID SW_VER Field 1 Field 2 …Field n

Field Definitions Remark

HDR String “ST3300” + Report type

ST3300 User Manual

DEV_ID 6 char. Device ID of AVL

VER “001” Software version that the device has.

Field 1 ~ n String Contents

4. Commands

When the device is received a command, it responds with response string and changes some

parameters or acts related operation.

4-1. Network Parameters Setting

HDR DEV_ID VER AUTH APN USER_ID USER_PWD SEVER_IP SEVER_PORT

B_SEVER_IP B_SEVER_IP SMS_NO PIN_NO

● Definition : Set network parameters and PIN number.

Field Definitions Unit Remark

HDR “ST3300NTW” Command type

DEV_ID 6 char. Device ID

VER “02” Protocol Version

AUTH ‘0’ /‘1’/’A’ WCDMA authentication

0 : PAP(‘NO’ in Synctrack)

1 : CHAP(‘YES’ in Synctrack)

A : Automatic WCDMA set.

In this case, parameters in APN, USER_ID and

USER_PWD field should be empty.

APN String Access Point Name

USER_ID String ID for WCDMA Access

USER_PWD String Password for WCDMA Access

SEVER_IP String Server IP Address

SEVER_PORT String Server Port

B_SEVER_IP String Backup Server IP Address

B_SEVER_PORT String Backup Server Port

SMS_NO String Phone number what the device sends SMS report to.

This can be used for backup in the area that if WCDMA

condition is not good. Or, it can be used main report

method when IP and Port are empty.

ST3300 User Manual

For no use, it should be empty.

PIN_NO String PIN Number to release PIN lock if it is enabled

[command] ST3300NTW;850000;02;0;internet;;;111.111.111.111;8600;;;;

[response] ST3300NTW;Res;850000;010;0;internet;;; 111.111.111.111;8600;;;;

ST3300NTW;Res;850000;010;A1;tim.br;tim;tim; 111.111.111.111;8600;;;;

<notes>

** If network does not require User ID and Password, these fields should be empty.

Automatic WCDMA Set

It the device is set to ‘Automatic WCDMA Set’, the device set WCDMA parameters automatically depending

on inserted SIM.

For example, if Airtel SIM is inserted, the device set AUTH to 0, APN to “aitelWCDMA.com”, USER_ID and

USER_PASS to empty.

And the device reports response string after adding real WCDMA parameters when automatic WCDMA set

is selected.

4-2. Report Parameter Setting

HDR DEV_ID VER T1 T2 T3 A1 SND_DIST T4 SMS_T1 SMS_T2 SMS_PACK_NO

ANGLE_RPT RPT_TYPE

● Definition : Set parameters related on report interval.

Field Definitions Unit Remark

HDR “ST3300RPT” Command type

DEV_ID 6 char. Device ID

VER “02” Protocol Version

T1 String Sec Interval for sending status report in parking mode

Range : 0 ~ 86400

If 0, report in parking will be sent only one time when

vehicle starts parking.

T2 String Sec Interval for sending status report in driving mode

Range : 0 ~ 60000

ST3300 User Manual

If 0, report in driving will be sent only one time when

vehicle starts driving.

T3 String Sec Interval for sending status report in emergency mode

Range : 0 ~ 9999

If 0, emergency report will be sent only one time when

emergency state occurs.

A1 String Number of attempts for emergency report until the device

gets acknowledge from server

If 0, no emergency report will be sent.

SND_DIST String Meter Distance interval for sending status report.

Range : 0 ~ 60000 (60km)

If 0, status report related on moving distance is disabled.

If not 0, stats report is send when traveled distance

reaches predefined SND_DIST.

T4 String Sec Interval for sending keep alive string

SMS_T1 String Min Interval for sending status report in parking mode

SMS_T2 String Min Interval for sending status report in driving mode

SMS_PACK_NO String Report No in one SMS message

ANGLE_RPT String Degree Report STT message if it’s greater than ANGLE_RPT.

0 : Disable

Range : 1 ~ 179

RPT_TYPE String Set the type of reporting.

0: FIFO : First in First Out.

1: LIFO : Last In First Out.

[command] ST3300RPT;850000;02;180;120;60;3;0;0;0;0;0;0;0

[response] ST3300RPT;Res;850000;010;180;120;60;3;0;0;0;0;0;0;0

<notes>

** If report interval is set big number, network may disconnect WCDMA connection because WCDMA

communication is not progressed for a long time. So, unit may not receive command by WCDMA. T4 is for

protecting against this disconnection by sending short data with short term.

** Alive report can be sent only when the device has no data to send during T4 interval.

4-3. Event Parameter Setting

ST3300 User Manual

HDR DEV_ID VER IGNITION T1 T2

IN1_TYPE IN2_TYPE IN3_TYPE IN1_CHAT IN2_CHAT IN3_CHAT

OUT1_TYPE OUT2_TYPE OUT1_ACTIVE OUT2_ACTIVE

PULSE1_NO PULSE1_ON PULSE1_OFF PULSE2_NO PULSE2_ON PULSE2_OFF

IN4_TYPE IN5_TYPE IN4_CHAT IN5_CHAT BAUD

● Definition : Set parameter related event.

Field Definitions Unit Remark

HDR “ST3300EVT” Command type

DEV_ID 6 char. Device ID

VER “02” Protocol Version

T1 String Sec Delay for entering idle mode after ignition goes to off

T2 String Sec Delay for entering active mode after ignition goes to on

IN1_TYPE ‘0’ ~ ‘7’ 0 = Falling Edge

1 = Rising Edge

2 = Both Edge (Falling & Rising)

3 = Panic Button

4 = Call1 Button

5 = Call 2 Button

6 = Reserved

7 = Anti-Theft Button

13 = Disable Immobilizer if it’s activated by jammer

detector.

Default = ‘3’.

Only the device that included voice option (audio circuit)

can be set to ‘Call1 Button’ or ‘Call2 Button’.

IN1_CHAT String 100ms Input1 chattering time.

Range : 0 ~ 9999

Default = 3 sec.

If 0, input1 is not checked.

ST3300 User Manual

OUT1_TYPE ‘0’ ~ ‘5’ 0 = GPIO

1 = immobilizer

2 = Immobilizer & Auto active

Auto active means immobilizer is activated

automatically

when the vehicle starts parking.

3 = Pulse

4 = LED Out for indicating call status. Refer 7-2-3.

5 = Buzzer

OUT1_ACTIVE ‘0’ or ‘1’ 0 = Open when out1 is active

1 = GND when out1 is active

PULSE1_NO String Pulse number when out1 type set to pulse.

Range : 0 ~ 9999

If pulse no is 9999, pulsing runs permanently.

PULSE1_ON String 100ms Active time of pulse1

Range : 0 ~ 9999

It should be set with even number.

PULSE1_OFF String 100ms Inactive time of pulse1

Range : 0 ~ 9999

It should be set with even number.

BAUD ‘0’ ~ ‘4’ It’s available when extra events support RS232.

Baud-rate

0 = No use

1 = 4800bps

2 = 9600bps

3 = 19200bps

4 = 38400bps

5 = 115200bps

If the device does not support RS232, it should be 0.

ST3300 User Manual

[command] ST3300EVT;850000;02;1;60;0;3;2;2;30;20;20;1;0;1;0;0;0;0;0;0;0;0;0;0;0;0

[response] ST3300EVT;Res;850000;010;1;60;0;3;2;2;30;20;20;1;0;1;0;0;0;0;0;0;0;0;0;0;0;0

<notes>

** If IGNITION is set to ‘0’, device doesn’t check driving or parking state of the vehicle. It reports status

string with idle mode always, and cannot support parking lock and the service that enters sleep or deep

sleep automatically when the vehicle is parked.

** If IGNITION is set to ‘2’, the device checks driving or parking state of the vehicle with voltage range of

vehicle’s battery. We named it as ‘Virtual Ignition’. Virtual ignition can operate when the device installed

into real vehicle and it may be need adjustment of voltage range for special vehicle. For setting method,

please refer 6.3.

** In case of pulse, pulse time may have tolerance about dozens of ms.

** Immobilizer, LED Blink line and Buzzer type cannot set both OUT1 and OUT2 simultaneously.

** In case that a event is set to “door sensor”, active state means door is opened.

** If device has the Handsfree kit, e

ach time the volume up button is pressed once, the speaker volume is turned up as below.

0 -> 1 -> 2 -> 3 -> 4 ->5 ->0 -> 1 -> 2 ->3 -> 4 -> 5 - > 0 -> 1 -> ….

(0 : Volume mute, 5 :Max Volume)

Type of no supported event line is fixed to “No Use”.

Below table is for example of 4 line event model.

Field Definitions Unit Remark

HDR “ST3300EVT” Command type

DEV_ID 6 char. Device ID

VER “02” Protocol Version

IGNITION ‘0’ ~ ‘2’ Ignition using state

0 : Not use ignition

1 : Use ignition Line

2 : Virtual ignition(power)

3 : Virtual ignition (motion)

T1 String Sec Delay for entering idle mode after ignition goes to off

T2 String Sec Delay for entering active mode after ignition goes to on

Inhaltsverzeichnis

Andere Sun-Tech GPS Handbücher

Sun-Tech

Sun-Tech ST940 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4300 Bedienungsanleitung

Sun-Tech

Sun-Tech ST3500 Bedienungsanleitung

Sun-Tech

Sun-Tech ST410 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4345 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4950 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4940B Bedienungsanleitung

Sun-Tech

Sun-Tech ST4315 Bedienungsanleitung

Sun-Tech

Sun-Tech ST300 Series Bedienungsanleitung

Sun-Tech

Sun-Tech ST4940 Bedienungsanleitung

Sun-Tech

Sun-Tech ST310U Bedienungsanleitung

Sun-Tech

Sun-Tech ST4290L Bedienungsanleitung

Sun-Tech

Sun-Tech ST4310P Bedienungsanleitung

Sun-Tech

Sun-Tech ST4950 Technische Daten

Sun-Tech

Sun-Tech ST210 Bedienungsanleitung

Sun-Tech

Sun-Tech ST690 Bedienungsanleitung

Sun-Tech

Sun-Tech ST500 Bedienungsanleitung

Sun-Tech

Sun-Tech ST310U Bedienungsanleitung

Sun-Tech

Sun-Tech ST4330 Bedienungsanleitung

Sun-Tech

Sun-Tech ST940 Bedienungsanleitung

Sun-Tech

Sun-Tech ST3940 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4340 Bedienungsanleitung

Sun-Tech

Sun-Tech ST240 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4340LC Bedienungsanleitung

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

Magellan

Magellan eXplorist 100 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung
