1 Introduction

Welcome to select our IP Phone and thanks for your trust and support to our company. We sincerely hope

you can enjoy the convenience and capabilities brought forward by our products.

IP Phone provides all the features and functionalities of conventional phone and more. Our IP phone

guarantees rich function and superb voice quality at mass-affordable price, which is fully compatible with

SIP industry standard and able to interoperate with most SIP compliant devices and software on the

market.

This manual provides the information on basic operations and functions for IP Phone, which would assist

users the fast access to learn basic functions and be familiar with operating these functions.

△

!CAUTION

Although the adapter of IP Phone is compliant with UL standard, please do not attempt to use other

difference power adapter or cut off power supply during configuration or updating phone. Using

other power adapter may damage IP phone and will void the manufacturer warranty.

HTTP://www.suncti.co.th UserManual

2 Installation

2.1 Installation

a) Insert handset cord into the handset jack and the other end to the left jack of IP Phone

b) Insert the power adapter’s plug into the phone Power jack and the 2-prong plug end of which into

grounded power outlet

c) Connect one end of the network cable to the WAN port, which is indicated as , the other end to

the internet.

d) If need to set up small LAN network, find the network cable in the box and connect it between LAN

port, which is indicated as and your PC (PC is not required to set up for making a call)

2.2 Typical Product network connecting Diagrams

IP PHONE

HTTP://www.suncti.co.th UserManual

2.3 package

Unpacking the package of IP Phone and please clearly check the box contents according to below packing

list .If you find any contents missing or damaged, contact the place of purchase.

Components Packing List

Components Quantity

Main Unit 1 Unit

Handset 1 PCS

Cord 1 PCS

Adapter 1 PCS

RJ45 network cable 1 PCS

User Manual 1 Volume

IP Phone are designed to look alike conventional phones, the following photo shows a broad overview of

the IP Phone.

2.4 Key introduction

There are 34 keys on the phone. Definitions of each is stated as below

Key Button Mode Definitions

In the dial-up mode Decimal digit number 0-90 -9

In the keypad

configure mode

Rapid first press display the digit number 0-9,rapid

second press display the English character or others

In the dial-up mode As one part of phone number when call out

In the call hold mode Ready to call a third party’s number to make

three-way (or conference) calling

In the keypad

configure mode

Equal to the dots notation when input IP address

Ex. 192.168.10.202

# In the dial-up mode As one part of phone number if “#” is the first

dialed number, otherwise as the ending symbol to

end up dialing

MENU In the IDLE mode Enter menu mode and display the tree menu system

Callers In the IDLE mode Check the Income/Outgoing/Missed calls record

Flexible Function Key

HTTP://www.suncti.co.th UserManual

Key Button Mode Definitions

Three flexible

Function Keys

In the IDLE mode or

In the keypad

configure mode

Select the relevant function on the LCD

HOLD In the keypad

configure mode

Temporarily hold the active call

Transfer In the keypad

configure mode

Transfer the active call to another party

REDIAL In the dial-up mode Redial the number last dialed

In the IDLE mode Enter hands-free mode

In the keypad

configure mode

Go back to previous menu item/ Go down to lower

menu items

UP/Down

In the idle mode Continuous thrice press display assigned WAN Port

IP, gateway’s IP and the phone number registered

on public server

Left/Right In the keypad

configure mode

Choose the item on the menu

MUTE In the dial-up mode Mute an active call;

Memory Key

1~4

In the IDLE mode Show the corresponding recorded phone NO.

Rls In any mode Exit to the default idle mode

Directory In the IDLE mode Access to phone book.

Hand free In the IDLE mode Enable Hand free function

In the IDLE mode Adjust the dialing ring volume

In the hand free mode Adjust the hand free volume

In the dial up mode Adjust the handset volume

HTTP://www.suncti.co.th UserManual

3 Product Overview

S01 IP Phone is a next generation IP network telephone based on industry open

standard SIP (Session Initiation Protocol).S01 series IP Phone offer customer superb

sound quality and rich functionalities at mass-affordable price.

3.1 Software Features

zSupport two modes: Bridge and Router (NAT&NAPT)

zNetwork Protocols: TCP/UDP/IP,ICMP,HTTP,DHCP Client （WAN

Interface）,DHCP Server（LAN Interface）,DNS Client, DNS Relay, SNTP, PPPoE,

FTP,TFTP

zVOIP Protocols: Support H323 (V4)&SIP (RFC3261, RFC3262, RFC3264,

RFC3265) synchronously

zVoice Codecs: G.711（A-law/U-law）,G.723.1(High/low),G.729

zNAT transversal: Support STUN client, etc. Can modify SIP register port, HTTP

server port, Telnet server port and RTP port

zSupport two SIP server synchronously：Can register two different SIP server, and

can make a call by either proxy

zSupport standard voice features such as numeric Caller ID Display, Call Waiting,

Hold, Transfer, Do-Not-disturb, Forward, in-band and out-of-band DTMF, Hotline

(off-hook autodial), auto answer, ban outgoing

zFull duplex hand free speakerphone, redial, call log, volume control, voice record

with indicator

zSupport standard encryption and authentication (DIGEST using MD5, MD5-sess)

zSupport Silence Suppression, VAD (Voice Activity Detection), CNG (Comfort

Noise Generation), Line Echo Cancellation (G.168), and AGC (Automatic Gain

Control)

zProvide easy configuration thru manual operation (phone keypad, Web interface

and Telenet) or automated centralized configuration file via TFTP or HTTP

zSupport firmware upgrade via TFTP/FTP and HTTP

zSupport syslog, can send event of phone to syslog server

HTTP://www.suncti.co.th UserManual

3.2 Hardware Specifications

The below table describes the hardware specifications of S01 Phone

Item S01

Power Adapter Input: 100-240VAC 50~60Hz

Output: +5VDC, 1200mA

CPU Infineon PSB21553 150MHz

WAN 10/100Base T RJ-45 for LANPort

LAN 10/100Base T RJ-45 for PC

Power Consumption Idle:1.4W / Active:1.8W

LCD size 3 inch (74×28mm)

Operating Temperature 0～40℃(32°～104℉)

Storage Temperature -10°～60(14°～140℉)

Relative Humidity 10～65% (Non-condensing)

Dimension (W×H×D) 11.6× 8× 3 inch (29.5×20.5×7.5cm)

Weight (packaging

included)

2.07 lb. (0.94kg)

Certification CE / FCC Part 15 Class B

HTTP://www.suncti.co.th UserManual

4 Basic Operations

4. 1 Dialing and Making Calls

4.1.1Dialing General PSTN Phone or Extension.

There are three dialing modes:

1. Pick up handset or press SPEAKER button, and then enter the phone

numbers, IP phone will send out the numbers with the DTMF tones.

2. In the off hook mode or Hands-free mode, Press the REDIAL/SEND button

directly to redial the number last called. Once pressed, the last dialed number

will be displayed on the LCD with DTMF tones and an outgoing call is sent.

3. Make use of Speed dialing mode: enter PBOOK→SPEED DIAL→INPUT

INDEX submenu to input the index which correspond to the phone number you

want to dial, then the phone could automatically dial the number.

Process: PBOOKENTER—INPUT INDEX (1,2,3…) + #

4.1.2 IP to IP Calling

Making IP to IP calling is nearly same as dialing general PSTN Phone, there are

three ways to set IP phone number and domain (more details please refer to 5.2.4)

1. “Peer to Peer” calling mode: direct make calls and no need to set phone

number thru proxy server (user could refer to Dial peer setting on web

configuration charter).The phone should be operated under following

condition (satisfy one option)

zRequirement 1 both two phones are assigned the public IP address

individually

zRequirement 2 both two phones using private IP address should be on

the same LAN.

2. Dialing the IP number configured by public agency, both two phones should

be already registered on the public server.

3. Dialing the IP number configured by private agency, both two phones

should be already registered on the private server.

Examples:

To dial a number on the proxy, such as 1001, simply pick up handset or press

speakerphone, dial 1001 and then press the REDIAL/SEND button.

To dial a PSTN number such as 62281486, you might need to enter in some prefix

number followed by the phone number. Please check with your VoIP service provider

to get the information. If your phone is assigned with a PSTN-like number such as

62281493, most likely you just follow the rule to dial 62281486 as if you were calling

from a regular analog phone, followed by pressing the REDIAL/SEND button.

Inhaltsverzeichnis

Andere Suncti IP-Telefon Handbücher

Suncti

Suncti S03 Series Bedienungsanleitung

Beliebte IP-Telefon Handbücher anderer Marken

Alcatel

Alcatel 4028 Bedienungsanleitung

Polycom

Polycom Polycom VVX 600 Bedienungsanleitung

Polycom

Polycom SoundPoint IP 450 Bedienungsanleitung

Cisco

Cisco SPA-500 Series Bedienungsanleitung

Polycom

Polycom SoundPoint IP 650 Bedienungsanleitung

Proximus

Proximus Maestro 3016 IP Bedienungsanleitung

Fanvil

Fanvil X4 Bedienungsanleitung

Cisco

Cisco 7962 Bedienungsanleitung

Snom

Snom 320 Bedienungsanleitung

Yealink

Yealink Yealink SIP-T46G Bedienungsanleitung

Avaya

Avaya 4625SW Bedienungsanleitung

Yealink

Yealink SIP-T52S Bedienungsanleitung

Nortel

Nortel 1140E Bedienungsanleitung

Nexotek

Nexotek NT-P500 Bedienungsanleitung

Avaya

Avaya Integral 5 R3.0 Bedienungsanleitung

GE 28320EE2 - Dect 6.0 InfoLink 2 Bedienungsanleitung

Avaya

Avaya 4600 Series Service-Handbuch

Mitel

Mitel MIVOICE OFFICE 400 6940 SIP Bedienungsanleitung
