T50C

p/n 021-3304-000 (120V)

SERVICE MANUAL

CONTENTS:

Notices

Specifications

Parts lists:

Main PCB assembly

FX PCB assembly

Chassis assembly

Cabinet assembly

Footswitch assembly

End item

Schematics/diagrams

sunn



is a registered trademark of

Fender Musical Instruments Corp., 7975 North Hayden Road, Scottsdale, AZ 85258

Sunn T50C

SERVICE MANUAL

MARCH 2000

IMPORTANT NOTICE:

The information contained herein is CONFIDENTIAL and PROPRIETARY to Fender Musical Instruments Corp. It is

disclosed solely for use by qualified technicians for purposes of equipment maintenance and service. It is not to be

disclosed to others without the expressed permission of Fender Musical Instruments Co. All specifications subject to

change without notice.

For warranty repair service, only Fender specified part numbers are to be used. It is recommended they also be used

for post-warranty maintenance and repair.

Parts marked with an asterisk (*) indicate the required use of that specific part. This is necessary for RELIABILITY

and SAFETY requirements. DO NOT USE A SUBSTITUTE!

A coded naming convention is used in the description of certain parts. The codes and what they mean are as follows:

CAPACITOR CODES HARDWARE CODES

CAP AE = Aluminum Electrolytic BLX = Black Oxide

CAP CA = Ceramic Axial CR = Chrome Plated

CAP CD = Ceramic Disk HWH = Hex Washer Head

CAP MPF = Metalized Polyester Film M = Machine Screw

CAP MY = Mylar NI = Nickel Plated

CAP PFF = Polyester Film/Foil OHP = Oval Head Phillips

PB = Particle Board

RESISTOR CODES PHP = Pan Head Phillips

PHPS = Pan Head Phillips Sems

RES CC = Carbon Comp SMA = Sheet Metal "A" Point

RES CF = Carbon Film SMB = Sheet Metal "B" Point

RES FP = Flame Proof SS = Stainless Steel

RES MF = Metal Film TF = Thread Forming

RES WW = Wire Wound ZI = Zinc Plated

Sunn T50C

SPECIFICATIONS

Product Release No.: PR 425 (This is not a model number)

Part Number: 120V Version : 21-3304

240V Aust : 21-3334

230V UK : 21-3344

230V : 21-3364

100V : 21-3374

Power Requirement: 325W

Power output: 50 Watts RMS (High output)

12.5 Watts RMS (Low output)

1 kHz sine wave into 16Ω@ <3% THD (Presence @ "1")

Input impedance: 1 MΩ

Tubes: Two 6L6GC Tubes p/n 053980

Two 12AX7A Tubes p/n 023572

Five 12AX7WA Tubesp/n 013341

One 12AT7 Tube p/n 023531

Speaker: Celestion G12T75, 12 in, 16Ω

Fuse: F1: F3A 250V fuse for 100V and 120V versions

T1A 250V fuse for 230V and 240V versions

F2: T100mA (All versions)

Footswitch: 3 Button Footswitch p/n 055771

(Controls Channel, Effects Loop Select, and Reverb)

Dimensions: Height: 22" (55.9 cm)

Width: 24.5" (62.2 cm)

Depth: 11.6" (29.5 cm)

Weight: 75 lbs. (33.8 kg)

Product specifications are subject to change without notice

Sunn T50C

PARTS LIST

NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY

MAIN

PRINTED CIRCUIT BOARD ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

10055364000 MAIN PCB FAB SUNN T50C

2 0051660000 BRACKET R/A PC MNT #6-32 BK1 BK2

2 0028953000 CAP AE AX 100uF 350V +50%-10% C201 C202

1 0038690001 CAP AE AX 1uF 100V 20% C17

2 0025960001 CAP AE AX 22uF 16V 20% C33 C36

3 0024819000 CAP AE AX 22uF 500V +50%-10% C203 C204 C207

1 0038693001 CAP AE AX 47uF 16V 20% C1

2 0024820000 CAP AE AX 47uF 350V 20% C208 C209

2 0041589000 CAP AE AX 47uF 500V +50%-10% C205 C206

2 0028494000 CAP AE RDL 1000uF 35V 20% C214 C215

2 0031040000 CAP AE RDL 100uF 100V 20% C210 C211

2 0028482003 CAP AE RDL 220uF 50V 20% C212 C213

3 0036954003 CAP AE RDL 22uF 63V 20% C216 C217 C220

1 0020883002 CAP CD 10pF 1000V 10% C38

3 0051458003 CAP CD 470pF 500V 10% C8 C18 C31

1 0051408003 CAP CD 47pF 500V 5% C3

1 0011435002 CAP CD 680pF 1000V 10% C16

2 0025951002 CAP CD 750pF 1000V 10% C13 C15

1 0025995002 CAP CD 8200pF 1000V 20% C200

2 0034788003 CAP CR .1uF 50V 20% .2" LS C224 C225

3 0027272003 CAP MPF .047uF 63V 10% C21 C32 C34

1 0027280003 CAP MPF .15uF 63V 10% C221

1 0027278003 CAP MPF .1uF 63V 10% C219

1 0027281003 CAP MPF .22uF 63V 10% C222

2 0027286003 CAP MPF .47uF 63V 10% C218 C223

2 0033477003 CAP MPF .68uF 63V 10% C7 C11

1 0024823000 CAP MPF RDL .01uF 400V 10% C22

6 0024833000 CAP MPF RDL .022uF 400V 10% C9-10 C12 C19 C20 C42

5 0024845000 CAP MPF RDL .047uF 400V 10% C2 C14 C23-24 C39

2 0024846000 CAP MPF RDL .047uF 630V 10% C44 C45

2 0024853000 CAP MPF RDL .1uF 250V 10% C41 C43

1 0037666002 CAP PFF .001uF 400V 10% C5

1 0047065002 CAP PFF .0015uF 400V 10% C37

1 0026202000 CAP PFF .0022uF 400V 10% C4

1 0037040002 CAP PFF .0033uF 400V 10% C35

2 0025962000 CAP PFF .0047uF 400V 10% C6 C40

2 0041510000 CONTROL SNAPIN 25K B R17 R38(CH 1 MID, CH 2 MID)

1 0047031000 CONTROL SNAPIN 25k 30C TAPER R103 (PRESENCE

1 0037600000 CONTROL SNAPIN 100k B TAPER R90(REVERB)

2 0047540000 CONTROLSNAPIN250k15ATAPER R18 R37(GAIN, CH 2 BASS)

3 0037597000 CONTROLSNAPIN250k30ATAPER R15 R36 R40(CH 1 TREB, CH 2 TREB, CH 2 VOL)

2 0041507000 CONTROL SNAPIN 1M 10A TAPER R7 R16(CH 1 VOL, CH 1 BASS)

2 0026133000 CONTROL TRIM 25k LIN R212 R213(BAL, BIAS)

Sunn T50C

MAIN

PRINTED CIRCUIT BOARD ASSEMBLY (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

17 0026730001 DIODE 1N4006 800V 1A D13 D14 D17 D200-207 D210-213 D236 D237

14 0006260001 DIODE 1N4448 SIGNAL LL D1 D9 D10 D216 D218 D221-227 D229 D231

2 0029690001 DIODE HV 3kV 200mA LL D12 D16

2 0031635001 DIODE ZEN 1N5240B 10V 5% LL D217 D228

2 0031019001 DIODE ZEN 1N5245B 15V 5% LL D2 D3

2 0028119060 DIODE ZEN 1N5353B 16V 5W 5% D214 D215

2 0041811060 DIODE ZEN 1N5368B 47V 5W 5% D208 D209

6 0026000001 FASTON TAB, .187" P14-17 P63 P64

23 0025802000 FASTON TAB, .250" P8 P35 P36 P39 P40 P42-55 P65 P68 P70 P71

1 0022546000 FUSEHOLDERPCBMTGUNIVERSAL F2

1 0022548000 CARRIER, FUSE 5mm F2

1 0013004000 FUSE TD 100mA 20mm x 5mm 250V F2

1 0027416000 HDR .1 CTR 8 CKT SQ PIN P13

3 0031611000 IC OP-AMP DUAL PC4560 U1 U3-4

1 0037117000 JACK PCB MONO CLOSED CKT J1(INPUT)

1 0025933000 JACK PHONO DUAL PC MTG J4(REVERB)

3 0026481000 JACK TIP J7-9(V9, GND, V10)

1 0028039000 LED RED 5x5mm SLB-55VR3 D232

1 0030754000 LED RED T-1 3mm DIFFUSED D220

1 0033177000 LEDRED/GREEN5x5mmBI-COLOR D18

2 0036178000 SPACER LED .5x.1 BRN @ D18 D220

2 0036613000 RELAY DPDT DIP 24VOLT 8.3mA K1-2

2 0026368001 RES CF 1/2W 5% 100ohm LL R216 R217

1 0025941001 RES CF 1/2W 5% 560ohm LL R121

1 0025113001 RES CF 1/2W 5% 10k LL R104

1 0031065001 RES CF 1/2W 5% 91k LL R108

9 0025116001 RES CF 1/2W 5% 100k LL R3 R11 R13 R21 R31 R34 R88 R95 R109

1 0025117001 RES CF 1/2W 5% 220k LL R207

1 0036957001 RES CF 1/2W 5% 470k LL R26

6 0024969001 RES CF 1/4W 5% 1.5k LL R4 R22 R46 R85 R86 R231

6 0024997001 RES CF 1/4W 5% 100k LL R110 R111 R223 R224 R237 R243

10 0024981001 RES CF 1/4W 5% 10k LL R10 R20 R25 R30 R33 R44 R210 R225-227

1 0024937001 RES CF 1/4W 5% 10ohm LL R126

1 0024998001 RES CF 1/4W 5% 120k LL R211

1 0024999001 RES CF 1/4W 5% 150k LL R99

2 0024985001 RES CF 1/4W 5% 15k LL R221 R242

1 0025058001 RES CF 1/4W 5% 180k LL R82

1 0024955001 RES CF 1/4W 5% 180ohm LL R222

1 0024986001 RES CF 1/4W 5% 18k LL R27

1 0028862001 RES CF 1/4W 5% 1.3k LL R220

8 0025069001 RES CF 1/4W5% 1M LL R1 R6 R19 R41 R43 R91 R105 R106

6 0025059001 RES CF 1/4W5% 220k LL R5 R24 R29 R39 R84 R93

1 0029455001 RES CF 1/4W 5% 2.4k LL R102

1 0024971001 RES CF 1/4W 5% 2.2k LL R101

3 0024987001 RES CF 1/4W 5% 22k LL R42 R120 R125

1 0029450001 RES CF 1/4W 5% 240k LL R80

1 0025077001 RES CF 1/4W 5% 3.3M LL R94

1 0024989001 RES CF 1/4W 5% 33k LL R35

2 0025079001 RES CF 1/4W 5% 4.7M LL R81 R87

Sunn T50C

MAIN

PRINTED CIRCUIT BOARD ASSEMBLY (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

11 0025065001 RES CF 1/4W 5% 470k LL R8-9 R23 R28 R92 R96 R97 R219 R229 R230 R240

2 0024961001 RES CF 1/4W 5% 470ohm LL R107 R122

3 0024993001 RES CF 1/4W5% 47k LL R45 R47 R100

1 0025066001 RES CF 1/4W 5% 560k LL R79

1 0024962001 RES CF 1/4W 5% 560ohm LL R236

1 0028948001 RES CF 1/4W 5% 6.2k LL R228

1 0024979001 RES CF 1/4W 5% 6.8k LL R241

2 0024995001 RES CF 1/4W 5% 68k LL R2 R14

1 0025068001 RES CF 1/4W 5% 820k LL R239

3 0024964001 RES CF 1/4W 5% 820ohm LL R12 R32 R89

2 0029613001 RES CF 1/4W 5% 91k LL R214-215

2 0027349001 RES FILM 1W 5% 10k LL R203 R204

1 0028029001 RES FILM 1W 5% 1.5k LL R218

1 0027347001 RES FILM 1W 5% 2.2k LL R83

6 0027354001 RES FILM 1W 5% 220k LL R118 R119 R123 R124 R205 R206

1 0016979001 RES MF 1/4W 1% 215k LL R233

1 0017191001 RES MF 1/4W 1% 36.5k LL R238

1 0016971001 RES MF 1/4W 1% 33.2k LL R235

2 0017372001 RES MF 1/4W 1% 51.1k LL R232 R234

1 0029870001 RES MOX 2W 5% 1.5k LL R200

1 0036921001 RES MOX 2W 5% 1k LL R201

1 0041740110 RES MOX 2W 5% 4.7k LL R202

2 0033095001 RES MOX FP 1W 5% 1ohm LL R114 R115

2 0041256000 RES WW 5W 10% 470ohm R116 R117

2 0029047000 RES WW 7W 10% 270ohm R208 R209

5 0051442000 SOCKET, TUBE 9PIN PCB MOUNT @V1-5

1 0028091000 SWITCHPUSHSLFLKSHORTSTROKE S4(CH SELECT)

1 0028104000 BUTTON PUSH BLACK @ S4

1 0049976000 SWITCHTOGGLEDPSTDCW/NUTS S3(OUTPUT PWR)

1 0028503000 THERMISTOR 10 ohm 5A C60-11 RT1

1 0041261000 VOLT REF LM4040DCZ-10 TO-92 U2

2 0014689003 XSTR N-CH JFET J111 TO-92 Q5 Q6

2 0041465003 XSTR N-CH JFET J113 TO-92 Q1 Q4

2 0016739003 XSTR NPN 2N4401 TO-92 Q7 Q8

1 0016742003 XSTR PNP 2N4403 TO-92 Q9

FX LOOP

PRINTED CIRCUIT BOARD ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

10055809000 PCB FAB FX LOOP SUNN T50C

1 0048914000 CABLE RIBBON 8 CKT 7" P13

1 0038690001 CAP AE AX 1uF 100V 20% C30

1 0009512001 CAP AE AX 22uF 25V 20% C28

1 0052003003 CAP MPF .1uF 250V 10% C27

Sunn T50C

FX LOOP (cont)

PRINTED CIRCUIT BOARD ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1 0024823000 CAP MPF RDL .01uF 400V 10% C25

1 0024845000 CAP MPF RDL .047uF 400V 10% C29

1 0024876000 CAP MPF RDL .68uF 250V 10% C26

4 0047540000 CONTROLSNAPIN250k15A TAPER R49 R51 R63 R65(CH 1 SEND,CH 2 SEND,CH 1 RETRN,CH 2 RETRN)

6 0006260001 DIODE 1N4448 SIGNAL LL D4 D7 D219 D230 D233 D234

1 0031635001 DIODE ZEN 1N5240B 10V 5% LL D8

2 0031019001 DIODE ZEN 1N5245B 15V 5% LL D5 D6

5 0051658000 JACK MONO R/A J2 J3 J5 J6 J12(SEND, RETURN,EXT AMP IN,MAIN AMP OUT,FTSW)

1 0028039000 LED RED 5x5mm SLB-55VR3 D235

2 0036613000 RELAY DPDT DIP 24VOLT 8.3mA K3 K4

2 0025116001 RES CF 1/2W 5% 100k LL R57 R69

2 0024969001 RES CF 1/4W 5% 1.5k LL R56 R70

1 0024997001 RES CF 1/4W 5% 100k LL R62

2 0024981001 RES CF 1/4W 5% 10k LL R55 R68

4 0024937001 RES CF 1/4W 5% 10ohm LL R61 R77 R78 R98

2 0024965001 RES CF 1/4W 5% 1k LL R60 R75

6 0025069001 RES CF 1/4W 5% 1M LL R53 R54 R67 R71 R72 R76

2 0025059001 RES CF 1/4W 5% 220k LL R58 R59

1 0024987001 RES CF 1/4W 5% 22k LL R73

1 0024989001 RES CF 1/4W 5% 33k LL R48

1 0028948001 RES CF 1/4W 5% 6.2k LL R74

4 0024980001 RES CF 1/4W 5% 8.2k LL R50 R52 R64 R66

1 0028091000 SWITCHPUSHSLFLKSHORTSTRK S5(LOOP EFFECTS)

1 0048451000 BUTTON PUSH OFF WHITE @ S5

1 0041465003 XSTR N-CH JFET J113 TO-92 Q2

1 0016739003 XSTR NPN 2N4401 TO-92 Q3

CHASSIS ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

2 0028069000 BUSHING SNAP 3/4x1-1/8 WHT @ PWR XFMR

2 0018022000 BUSHING SNAP 5/16x17/32 BLK @ CHOKE

2 0012560000 BUSHING SNAP 5/8x27/32 BLK @ OUTPUT XFMR

1 0021741000 HOLDER DIAL LITE ASSY PILOT @ PILOT LIGHT

1 0031625000 NUT 1/16-27 HOLDER PILOT LIGHT @ PILOT LIGHT

1 0032219000 COLLAR-PILOT LIGHT @ PILOT LIGHT

1 0021642000 PILOT LIGHT #T47 @ PILOT LIGHT

1 0025718000 JEWEL PILOT LITE RED #20 @ PILOT LIGHT

1 0036570000 SWITCH TOGGLE DPST W/NUTS PWR SWITCH

1 0026472000 SWITCH SLIDE DPTT IMPED. SELECTOR

1 0051855000 SWITCH ROCKER DPST W/BEZEL SUNN STANDBY SWTCH

1 0047213000 CONN. AC LINE MALE IEC IEC PWR JACK

1 0036702000 FUSE HOLDER 3AG FINGER GRIP @ LINE FUSE F1

1 0077982000 FUSE QA 1-1/4x1/4" 250V 3A LINE FUSE F1 (120V/100V UNITS)

Ref 0020793000 FUSE QA 20mm x 5mm 250V 1.6A LINE FUSE F1 (230V/240V UNITS)

Sunn T50C

CHASSIS ASSEMBLY (cont)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

Ref 0036703000 FUSE HOLDER 5mm FINGER GRIP @ V8-9 PROTECT, @ F1 EXP.

1 0013004000 FUSE 100mA TIME 5mm V8-9 PROTECT F2

1 0021550000 JACK PHONE TIP SHUNT 12A MAIN SPKR JACK J8

1 0021956000 JACK PHONE OPEN CKT 11 EXT. SPKR JACK J9

10055362000 CHASSIS SUNN T50C

1 0053892000 COVER BOX BIAS CONTROLS

2 0023572000 TUBE 7025/12AX7A CHINESE V1 V2

1 0023531010 TUBE 12AT7 CHINESE V5

5 0013341000 TUBE 7025/12AX7WA RUSSIAN MADE V3 V4 V6 V7 V8

2 0053980000 TUBE 6L6GC SVETLANA V9 V10

3 0023598000 TUBE SHIELD @V6 V7 V8

5 0053893000 TUBE SHIELD MODEL T @V1 V2 V3 V4 V5

2 0023580000 TUBE SOCKET 8 PIN @ V7 V8 V9 V10

2 0020424000 TUBE RING UNIVERSAL (277H-2) @ V7 V8 V9 V10

3 0023606000 TUBE SOCKET 9 PIN @ V5 V6 V10

15 0024604000 KNOB BLACK W/WHITE STAMP 1-10 @ ALL CONTROLS

2 0024969001 RES CF 1/4W 5% 1.5K LL @ V9 V10

2 0026730001 DIODE 1N4006 800V LL @ V9 V10

2 0022293000 WSHR FLAT .473x.750 NI @ PWR SWTCH & ARENA/CLUB SWTCH

4 0026501000 SCREW C 1/4-20x1/2" HH BLX @ PWR XFMR

4 0028272000 NUT KEP 1/4x20 FOJ @ PWR XFMR

8 0022319000 WSHR FLT 1/4x9/16 NI @ PWR XFMR

Ref 0047163000 TUBING SHRINK 1" BLACK @ PWR XFMR PRI. LEADS

4 0026553000 SCREW M 8-32 x 3/8" PHP BLX @ OUTPUT XFMR

4 0022004000 NUT KEPS #8-32 ZINC @ OUTPUT XFMR

2 0097360000 NUT HEX 4-40 EX LOCK @ IEC PWR JACK

2 0014172000 SCREW M 4-40 x 1/4" PHP BLX @ IEC PWR JACK

2 0031153000 WSHR FLAT 3/8 x .614" NI @ SPKR JACKS J8 J9

2 0016436000 WSHR LCK INTL 3/8 x .687 x .035 NI @ SPKR JACKS J8 J9

2 0016352000 NUT HEX 3/8-32 x 3/32 TK NI @ SPKR JACKS J8 J9

2 0021568000 SCREW M 6-32 x 3/16" PHP NI @ IMPED. SELECTOR

2 0014999000 SCREW M 6-32x1/4 PHP BLX @ BK1 BK2 BIAS BOARD

2 0026564000 WSHR FLAT .284x1/2 ZI @ BIAS AND BALANCE

16 0032806000 SCREW TF 6-32x1/4" PHP BLX @ CHOKE , SOCKETS, COVER BOX

2 0038900000 SCREW TF 6-32x1/4" PHP ZI @ CHASSIS GNDS

24 0031184000 SCREW M 6-32x1/4 PHP BLX ITLW @ STANDOFFS

5 0053479000 NUT HEX 7/16 20 x 1/8 NI @ FX BOARD JACKS

5 0053480000 WSHR FLAT .442x.692 NI @ FX BOARD JACKS

Ref 0012398000 TUBING SHRINK 3/16 BLACK @ PILOT LIGHT WIRES

10055365000 PCB ASSY MAIN PCB T50C

10055810000 PCB ASSY FX LOOP T50C

10055372000 FRONT PANEL SUNN T50C

1 0049009000 XFMR OUTPUT PROSONIC OUTPUT XFMR T2

1 0055358000 XFMR POWER T50C

1 0037099000 XFMR OUTPUT DUAL 12AT7 TO REVERB REVERB XFMR

1 0036486000 CHOKE CHOKE L1

Sunn T50C

CAB ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

8 0002971000 CORNER NOTCHED NI

1 0027846000 HANDLE 9.25" NO LOGO

1 0032524000 INSERT HANDLE

2 0019279000 HANDLE CAP 2 HOLE NI

4 0051049000 FOOT RUBBER

8 0022244000 SCREW M10-32 x 1 1/8 OHP NI

16 0026571000 SCREW SMAB 8x5/8 THP NI

12 0021972000 NUT T 10-32 X 3/4 STR 3 PRNG BLX

4 0023505000 MTG PLATE SWIVEL CASTER

16 0027199000 SCREW SMAB 10 X 3/4 PHP NI

Ref 0055366000 GRL CLTH FRM 1/2" PB

Ref 0037788000 GRL CLTH BLK/SILVER

Ref 0027648000 TAPE ALUM 6" X 60 YDS

ref 0051343000 VINYL TOLEX

ref 0029085000 VELCRO STRIP LOOP 1.5 BCK

ref 0029086000 VELCRO STRIP HOOK 1.5" WD BLK

FOOTSWITCH ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1 0028895000 CABLE ASSY FTSW RT ANG 12'

3 0006260001 DIODE 1N4448 SIGNAL

1 0031017000 DIODE ZEN 1N5223B 2.7V 5%

3 0028039000 LED RED 5x5mm SLB-55VR3

1 0028109000 HSG END CUP LEFT FTSW

1 0028141000 HSG FTSW 3 BUTTON

1 0028143000 HSG END CUP RIGHT FTSW

1 0037036000 JACK PCB MONO CA (099-0912-000)

1 0053898000 PCB FAB FTSW 3 BTN SUNN BASS

1 0055593000 PCB ASSY FTSW 3 BTN DSP/T50C

1 0055770000 PLATE FTSW 3 BTTN SUNN T50C

3 0028714000 SWITCH PUSH SPDT

8 0028684000 SCRW SMB 6x3/8 PH PHS BLX

1 0031647000 NUT HEX 12mmx1mm NI @ JACK

3 0031899000 WSHR NYL .485x.775x.150 TK

3 0034921000 SPACER RND NYL .147x.250x.780

END ITEM ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1 0055361000 CABINET ASSY T50C

1 0051363000 CHASSIS ASSY. 120V DOM.

1 0051370000 CHASSIS ASSY. 240V AUST.

1 0051369000 CHASSIS ASSY. 230V

Sunn T50C

END ITEM ASSEMBLY (cont)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1 0051368000 CHASSIS ASSY. 100V JAP.

1 0047248000 CORD PWR W/IEC CONN DOM

1 0047250000 CORD PWR W/IEC CONN 240V AUST

1 0047249000 CORD PWR W/IEC CONN 240V UK

1 0047251000 CORD PWR W/IEC CONN 230V EUR

1 0053997000 CORD PWR W/IEC CONN 100V JAP

1 0051380000 NAME PLATE SUNN

1 0055771000 FOOTSWITCH ASSY 3 BUTTON SUNN

4 0017439000 SCRW SMA 6x1/2 PHP BLX @ LOGO

4 9904101550 SCREW M 8-32x1-1/4 OHP BLX WX CHASSIS TO CAB

4 0029527000 WSHR FNSH 8-5/8 FLNGD BLX WX CHASSIS TO CAB

3 0029828000 SCRW PB 8x3/4 PHP BLX @ REV. BAG & CABLE CLAMP

2 0022327000 WSHR FLAT 8x7/16 NI @ REV. BAG

1 0012582000 CLAMP CABLE NYL SCRW MNT 1/4 @ REV. CABLE

1 0031849000 REVERB BAG

1 0028453000 PAD CARDBOARD REVERB

1 0025722000 CABLE REVERB 1100mm

1 0064063000 REVERB UNIT 4 SPRING 4AB3C1B

1 0053982000 SPEAKER 12" 16 OHM 100W

4 0023513000 CASTER SWIVEL

1 0028044000 CABLE ASSY SPKR RT ANG 33"

Inhaltsverzeichnis

Andere Sunn Verstärker Handbücher

Sunn

Sunn T Bedienungsanleitung

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
