Sunricher SR-2202T1 US Bedienungsanleitung

Wall mounted single color DMX512 Master

SR-2202T1(US)

Parameter

Installation

Remote

Part No. Operation Voltage Output Dimensions (mm)

Wiring diagram

Product Size

2 zone

Back lighting for finding in the dark

Italian/ Australian, US wall mounted size available as wel l.

Touch sensitive

Glass interface

SR-2202T1(US) 12-24VDC DMX512 Signal 75x120x29.1

D- GN D

Power Supply

12-24VDC

Vin D+

Power Supply

12-36VDC

110V-230VAC

SR-2202T1(US)

GND

110V-230VAC

D1 D1 D2 D 2

SR-2102 B

DMX 512 D eco de r

GND

whit e

D1 D1 D2 D 2

SR-2102 B

DMX 512 D eco de r

GND

whit e

D1 D1 D2 D 2

SR-2102 B

DMX 512 D eco de r

GND

whit e

Operation

After connect well with DMX decoders, please set the DMX

decoders address as below:

DMX decoder’s address 001 is controlled by Zone 1

DMX decoder’s address 005 is controlled by Zone 2

Zone 1 Zone 2

Short press on

Long press dim up

Short press off

Long press dim down

120.0

75.0

29.1

ISO 90 01：2 000

Warranty Agreement

1) We provide lifelong technical assistance with this product:

5-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The

warranty is for free repair or replacement and covers manufacturing faults only.

For faults beyond the 3-year warranty we reserve the right to charge for time and parts.

2) Limited Warrenty

Any defects caused by wrong operation.

Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and

replacement of chips.

Any damages due to transportation, vibration etc. after purchase.

Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.

Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near

harmful chemicals.

Product has been updated

3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.

Safety & Warnings

1) The product shall be installed and serviced by a qualified person.

2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof

enclosure.

3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.

4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the

product.

5) Never connect any cables while power is on and always assure correct connections to avoid short circuits

before switching on.

7) For update information please consult your supplier.

Please ensure that the cable is secured tightly in the connector
