SUNSTONE SUNPLT40 Bedienungsanleitung
Read all instructions before you
operate
your grill.
Save these instructions!
MODEL NO: SUNPLT40
Fuel input rating: 1.7LBS/hr
Ele tri al Rate: 120Va , 60Hz, 485W – 4.4 AMPS
Refer to Intertek’s Dire tory of Building Produ ts
for detailed information.
Minimum learan e from side and ba k of unit to
ombustible onstru tion: 24” (609.6mm) from
sides and 24” (609.6mm) from ba k.
3174816
Certified to:
UL SUBJECT 2728A
ULC/ORD-C2728
ATTENTION: If Fire O urs: Call Fire Department. Do Not: Try to Move Applian e, Try To Smother
Fire, Or Put Water On The Fire. Keep The Applian e Clean – See Instru tion Manual for Cleaning And Proper
Operation. Always Operate Applian e With Doors Of Room Open (For Applian es That Are Intended For
Indoor Use)
ODILY INJURY: Improper Use Can Cause Un ontrolled Fire. To Redu e Fire Risk This Applian e Is
Intended to Burn (pelletized, all natural, wood) Fuel Only. Where (pelletized, all natural, wood) Is the Fuel.
Manufa turer’s Name or Fuel Trade Name and Distin tive Model Designation. Operate Only Per
Manufa turer’s Instru tions. Never Use Gasoline or Lighter Fluid. Always Store Wood Pellets Away from
Heat-Produ ing Applian es and Other Fuel Containers.
ATTENTION: Please read this entire manual before installation and use of the pelletized, all natural,
wood fuel-burning applian e. Failure to follow these instru tions ould result in property damage, bodily
injury or even death. Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
SUNSTONE METAL PRODUCTS LLC.
16004 Central Commerce Dr, Pflu erville Texas 78660.
Business Hours.
Mon. to Thur. 9:00AM to 4:30PM
Closed Fri/Sat/Sun
Tel: 51 -487-5116
Toll Free: 888-934-9449 (Technical Support Line)
Fax: 51 -487-7016
Welcome & Congratulations
Congratulations on your pur hase of a new Sunstone Pellet Grill! We are very proud of our produ t, and we
are ompletely ommitted to providing you with the best servi e possible.
Save these instructions.
How to Obtain Service
Before you all
Please make sure you have the following information:
MODEL NUM ER | DATE OF PURCHASE| INVOICE NUM ER.
To installer or person assembling grill: Leave this manual with grill for future referen e.
To consumer: Keep this manual for future referen e.
For warranty servi e, onta t SUNSTONE Customer Servi e Department at (888)-934-9449 or email:
servi e@sunstonemetalprodu ts. om.
ENGLISH
WARNING:
Indi ates an imminently hazardous
situation whi h, if not avoided, will result in death or
serious injury.
VOLTAGE:
Indi ates a potentially hazardous
situation whi h, if not avoided, may result in minor or
moderate ele tri al sho k.
EXPLOSION:
Indi ates an imminently hazardous
situation whi h, if not avoided, will result in possible
explosion and ause death or severe injury.
ODILY INJURY:
Indi ates a potentially hazardous
situation whi h, if not avoided, may result in minor or
moderate personal injury, or property damage.
HOT SURFACE:
Indi ates an imminently hazardous
hot
surfa e whi h, if not avoided, will result in
serious
burn or injury.
LIVE CIRCUIT:
Indi ates a potentially hazard from
Live ele tri al urrent that if extreme aution is not
used, may result in minor or moderate personal injury,
or property damage.
ATTENTION: Indi ates a potentially hazardous
situation whi h, if not avoided, may result in minor or
moderate personal injury, or property damage.
INDEX DIRECTORY
HAZARDS & WARNING SIGNS
Copyright 20
23
. All rights
reserved. No part
of this manual may be opied, transmitted,
trans ribed, stored in a retrieval system, in
any form or by any means without
expressed written permission.
ATTENTION: Do not use spirit, petrol, gasoline, lighter-fluid or kerosene for
lighting or refreshing a fire in your grill. Keep all such liquids well away from the
appliance when in use.
ATTENTION: A MA OR CAUSE OF FIRES IS FAILURE TO MAINTAIN
REQUIRED CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS
OF UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN
ACCORDANCE WITH THESE INSTRUCTIONS.
PREPERATION
-
REQUIRMENTS
PAGE 1
STARTUP
–
PELLET STORAGE
PAGE 1
Countertop support: The ountertop should be able to support the weight of the pellet grill
and any other items that will be pla ed on it. It's important to ensure that the ountertop is
strong and stable enough to support the weight of the grill, as well as any movement or
vibration aused by the operation of the grill.
Adequate clearance: The area beneath the pellet grill should be lear and free of any
obstru tions or ombustible materials that ould be damaged by heat or sparks. Ensure
that there is adequate learan e of at least 6” behind the grill for air flow and to allow the
hood to open without any obstru tion.
Ventilation: The grill should be in an area that allows for proper ventilation, with suffi ient
spa e around the grill to prevent any heat buildup or damage to the ountertop. It's
important to maintain a learan e of 24” Minimum between the grill and any nearby
Combustible Materials, and Never build your island using ombustible materials to prevent
any safety hazards, risk of fire or injury.
Power source: The Pellet Grill is 120Va , 60HZ, 485W – 4.4 AMPS and requires an ele tri al
outlet that an deliver 120 volts of alternating urrent (Va ) at 60 hertz (Hz), with a
minimum of 4.4 amps of urrent. Ensure that the ele tri al outlet is properly grounded and
in good ondition to prevent any safety hazards.
Safety precautions: Follow all safety pre autions and guidelines provided in this Manual
during the installation and operation of the pellet grill. Never leave the grill unattended,
always use the grill in a safe and responsible manner, and follow all lo al odes and
regulations related to the installation and operation of outdoor ooking equipment.
PREPERATION
–
CHECKLIST
PAGE 2
Check List for pellet grill Startup and Usage:
Transformer Ele tri al Plug is properly installed.
Keep ele tri al supply ords away from heated surfa es.
Do not use your grill in the rain or around any water sour e.
After a period of storage or non-use, he k the burn grate for obstru tions and the
hopper for air blo kage. Clean before use.
If the grill is stored outside during the rainy season or seasons of high humidity, are
should be taken to ensure that water does not get into the hopper.
Always dis onne t the power before performing any servi e or maintenan e.
This pellet ooking applian e is designed and approved for pelletized, all natural,
wood fuel only. Any other type of fuel burned in this applian e will void the warranty
and safety listing.
Only use all-natural wood pellets designed for burning in pellet barbe ue grills. Do
not use fuel with additives.
Maintain a minimum 24-in h learan e to ombustible materials.
Ensure that all pa kaging has been removed from the interior of the grill.
Make sure that all parts and omponents are properly installed.
By following this he klist, you an ensure that your pellet grill is properly installed, safe to
use, and ready to deliver deli ious outdoor ooking experien es. It's important to always
prioritize safety and to follow the manufa turer's instru tions arefully when setting up and
using your pellet grill.
When it omes to pellet storage, there are several methods and re ommendations that an
help ensure the quality and longevity of your pellets.
1. Store in a dry place: It's important to keep your pellets dry, as moisture an ause
them to deteriorate and even mold. Store your pellets in a dry pla e, su h as a garage
or shed, where they are prote ted from the elements.
2. Keep away from heat: Pellets an also be damaged by heat, so it's important to store
them in a ool area away from dire t sunlight or other sour es of heat.
3. Use airtight containers: To keep your pellets fresh and prevent them from absorbing
moisture, onsider storing them in airtight ontainers or bags. This will help to
maintain their quality and ensure they are ready to use when you need them.
4. Keep away from pests: Pellets an attra t pests su h as rodents and inse ts, so it's
important to store them in a lo ation that is ina essible to these pests. Consider
storing them on shelves or in ontainers with tight-fitting lids to prevent any
unwanted visitors.
5. Rotate your stock: To ensure that your pellets are always fresh and ready to use, it's
a good idea to rotate your sto k periodi ally. This means using the oldest pellets first
and replenishing your supply with fresh pellets.
By following these methods and re ommendations, you an ensure that your pellets are
stored properly and are always ready to use when you need them. This will help to
maximize the life and quality of your pellets and ensure that you an ontinue to enjoy your
pellet grill for years to ome.
PREPERATION
–
PELLET STORAGE
PAGE 3
NUM ER
DESCRIPTION # PART NUM ER
1 Temperature Gauge 1PC RUBY-TMETER
2 Left Handle Assembly 3PC PLT40-LHANDLE
3 Right Handle Assembly 3PC PLT40-RHANDLE
4 Hybrid Grill Badge 1PC PLT40-HGBADGE
5 Left Loader Hood 1PC PLT40-LLHOOD
6 Right Grill Hood 1PC PLT40-RGHOOD
7 Hood Bolt S rew Set 4PC PLT40-HBSCREW
8 Halogen Light 3PC PLT40-HLIGHT
9 Grill Smoker Hooks 5PC PLT40-GSHOOKS
10 Pellet Loader Baffle Plate 1PC PLT40-PLBAFFLE
11 Cold Smoker Container Tube 1PC PLT40-CSCTUBE
12 Cork-S rew Pipe Auger 1PC PLT40-CSAUGER
13 Auger Base Trough 1PC PLT40-ABTROUGH
14 Small Motor Assembly 1PC PLT40-SMOTOR
15 Pellet Line Feeder 1PC PLT40-PLFEEDER
16 Cold Smoker Shute Box 1PC PLT40-CSSHUTE
17 Cold Smoker Ignition Sti k 1PC PLT40-CSIGNITION
18 Combustion Chamber 1PC PLT40-CCHAMBER
19 Power Line Plug 1PC PLT40-PLINE
20 Thermometri Assembly 1PC PLT40-THERMO
21 Warming Ra k - Small 1PC PLT40-WSRACK
22 Warming Ra k - Medium 1PC PLT40-WMRACK
23 Straight Cooking Grate 1PC PLT40-SCGRATE
24 Cooking Grate w/Insert 1PC PLT40-ODAGRATE
25 Oil Defle tor Assembly 1PC PLT40-ODEFLECTOR
26 Oil Defle tor Inset Panel 1PC PLT40-ODEFPANEL
27 Main Combustion Chamber 1PC PLT40-MCCHAMBER
28 Oil Baffle Support Panel 1PC PLT40-OBAFSPANEL
29 Main Ignition Sti k 1PC PLT40-MIGNITION
30 Ele tri Rotating Fan 2PC PLT40-ERFAN
31 Rotating Fan Cover 1PC PLT40-RFCOVER
32 Control Panel 1PC PLT40-CPANEL
33 Main Control Panel 1PC PLT40-MCPANEL
34 Front Panel Speed Rail 1PC PLT40-FPSRAIL
35 Front Base Venting Panel 1PC PLT40-FBVENTING
36 Oil Tray Assembly 2PC PLT40-OTRAY
GRILL
PARTS
–
PARTS LIST
PAGE 4
GRILL
PARTS
–
DIAGRAM
PAGE 5
Refer to page 4 Parts List
Product Size
Overall Width-------------------- 40"
Overall Height------------------- 30.94"
Overall Depth-------------------- 30.14"
Firebox Size
Box Width ---------------------- 38.43"
Box Height---------------------- 1 6 . 8 4 "
Box Depth----------------------- 21.85"
MEASURMENTS
–
TECHNICAL
PAGE 6
FRONT VIEW
SIDE VIEW
BACK VIEW
TOP VIEW
ATTENTION
: Never build an en losure under the Grill or partition side walls, the Grill
must be Free Hanging supported by the ountertop only! Must have lear a ess to
underside of Grill within rea h of at least Two Vents.
MEASUREMENTS
-
CUT
-
OUT
PAGE 7
Countertop Slide-in Installation
Grill Cut-out Depth -------------------------------------------------------------
-----
22 In h Depth
Grill Cut-out Height (Allow ¾” Air-Flow Gap Below Drip Pan) -------
-----
17-1/8 In h Height
Grill Cut-out Width--------------------------------------------------------------
-----
38-1/2 In h Width
Make 1-3/4” W x1”D Not h Cut-Out on both sides of ut-out ounter edge, to allow grill to
slide flush against the island finish wall.
Leave Minimum ¾” Gap below Drip Pan for Air/Gas Ventilation
Must have TWO Vents in HIGH position for Air Cir ulation
TOP VIEW
FRONT VIEW
SIDE VIEW ISO VIEW
