Superlux E12A Bedienungsanleitung
1
English
Contact
Marketing and sales
Goang-Fann Co., Ltd.
+886-2-26931323
Manufacturing & logistics
Superlux Enterprise
Development ( Shanghai ) Co., Ltd.
E12A
LAVALIERE ELECTRET
CONDENSER MICROPHONE
2
DESCRIPTION
The E12A omni lavaliere mini clip-on
condenser microphone is ideal for
inconspicuous recording. Its tailored
frequency response gives accurate, intel-
ligible speech recognition, making it well
suited for the interview programs of TV
and radio stations for recording where
ambient noise is not an issue.
FEATURES
• Professional headworn vocal
microphone, especially designed for
hands-free microphone applications
• Low-profile design, with adjustable
band to properly position the
microphone
E12A
LAVALIERE ELECTRET
CONDENSER MICROPHONE
• Subminiature lavaliere design.
Small, unobtrusive mounting
hardware
• Tailored sound for clarity of vocal
sound
3
SPECIFICATIONS
E12ATQG E12AXLR E12ADXLR
With Wireless system PS418S Preamp
(Phantom power only)
PS418D Preamp
(Either phantom power or
battery)
Type Back electret,
Ø4mm (Ø0.16”)
Back electret,
Ø4mm (Ø0.16”)
Back electret,
Ø4mm (Ø0.16”)
Polar Pattern Omni Omni Omni
Frequency
Response 20-20,000 Hz 20-20,000 Hz 20-20,000 Hz
Low Frequency
Filter N/A N/A PS418D: 80Hz, 12 dB/oct
Sensitivity -33 dBV/Pa (22.4 mV) Phantom:
-42 dBV/Pa (7.9 mV)
Phantom:
-42 dBV/Pa (8 mV)
Battery:
-47 dBV/Pa (4.5 mV)
Output
Impedance 200 Ω 200 Ω Phantom: 200 Ω
Battery: 600 Ω
Min. Load
Impedance 1,000 Ω 1,000 Ω Phantom: 1,000 Ω
Battery: 2,000 Ω
Equivalent
Output Noise N/A Phantom: 18 dB Phantom: 18 dB
Battery: 20 dB
Max. SPL N/A Phantom: 137 dB SPL Phantom: 137 dB SPL
Battery: 129 dB SPL
S/N Ratio N/A Phantom: 76 dB Phantom: 76 dB
Battery: 74 dB
Dynamic Range N/A Phantom: 119 dB Phantom: 119 dB
Battery: 109 dB
*Note:Specications are subject to change.
4
E12ATQG E12AXLR E12ADXLR
Power
Requirements
2.5-9V DC Phantom:
12-52V DC 3.5mA
Phantom:
12-52V DC 3.5mA
Battery:
1.5V AA/UM3
Connector TA4F, 1.5-meter cable TA3F, 1.5-meter cable TA3F, 1.5-meter cable
Finish Black Black Black
Dimensions
E12A: 10.5×7×4mm
(0.41"×0.28"×0.6")
E12A: 10.5×7×4mm
(0.41”×0.28”×0.6”)
PS418S: Ø21×106mm
(0.83"×4.18")
E12A: 10.5×7×4mm
(0.41”×0.28”×0.6”)
PS418D: 84×63×22.5mm
(3.3"×2.48"×0.89")
Net Weight
E12A (With lavaliere) :
19g (0.7 oz)
E12A (With lavaliere) :
19g (0.7 oz)
PS418S: 118g (4.2 oz)
E12A (With lavaliere) :
19g (0.7 oz)
PS418D: 245g (8.6 oz)
E12ATQG
E12AXLR
E12ADXLR 1.5V AA
Battery
PS418S
Preamp
PS418D
Preamp
S53
Windscreen Clip
S53
Windscreen Clip
S53
Windscreen Clip
INCLUDED
5
7.3 mm
(0.29 in.)
4.0 mm
(0.16 in.)
2.5 mm
(0.10 in.) 6.0 mm
(0.24 in.)
10.5 mm
(0.42 in.)
7.3 mm
(0.29 in.)
Ø8.4 mm
(0.33 in.)
Ø10.5 mm
(0.42 in.)
Ø2.0 mm
(0.08 in.)
4.0 mm
(0.16 in.)
10.6 mm
(0.42 in.)
46.9 mm (1.84 in.)
Unit:mm
6
Unit:mm
Ø21 mm
(0.83 in.)
Ø19 mm
(0.75 in.)
0.8 mm
(0.03 in.)
106 mm
(4.18 in.)
63 mm
(2.5 in.)
84 mm
(3.3 in.)
PS418S Preamp
(E12AXLR)
PS418D Preamp
(E12ADXLR)
7
Type of directivity
Omni
With equal sensitivity in all directions,
an omni microphone doesn’t need
to point toward the sound source. It
features low handling and wind noise.
It is welcomed for news gathering and
music recording applications.
Type of transducer
Condenser
With an extremely light weight dia-
phragm, it is very sensitive to sound.
Very small versions are available for
hidden applications. High performance
condenser microphones are regarded as
standard equipment in recording studios
for extreme detail capturing. They oper-
ate with phantom or battery power.
KNOWING YOUR MICROPHONE
E12A FREQUENCY RESPONSE (OMNI)
E12A
8
!
WARNING! INDICATES A POTENTIALLY HAZARDOUS SITUATION WHICH IF MISHANDLED
COULD RESULT IN DEATH OR SERIOUS PERSONAL INJURY OR PROPERTY DAMAGE.
※Do not expose the unit to rain or an environment where it may be splashed by water or other liquids
as doing so may result in re or electric shock.
※Do not attempt to modify this product. Doing so could result in personal injury and/or product failure.
※Do not subject to extreme force and do not pull on the cable, it might cause the product failures.
※Keep this product and the equipment which used together dry and avoid to exposure to extreme
high temperature and humidity.
LIMITED WARRANTY
For compliance with the instructions which record in the user manual, Superlux Enterprise provide one year
period warranty for all material and producing quality from purchase date. This warranty term will adjust
according to different country or area. Please contact local distributor to receive more information. In the validity
period, if there’s any material, producing quality, or any function unavailable, Superlux will repair or replace the
parts. This warranty is only for the product which selling by distributor or agent which authorized by Superlux.
However, the situation below is excluded in the warranty :
The damage which caused by accident, abuse, improper instructions, self-modication and repair, or damage
from transportation, not complying with the instructions which record in the manual, repair by the company
which didn’t authorized by Superlux Enterprise, request by distributor without authorized, or the serial number
sticker on Superlux product is unidentied, modied, or removed. All repair of Superlux products can only
accept from repair centre, distributor or agent which authorized by Superlux. Unauthorized repair, maintenance
and modication will not receive relevant warranty and will be excluded in the warranty. Any repair guarantee
under warranty need to provide selling receipt from authorized distributor or agent to make sure your Superlux
product still in the warranty period. To obtain the original authorized repair warranty, please contact authorized
www.superlux.com.tw
P/N:LB100E12A01EN SEP, 2021
