Supermicro SuperServer E100-8Q Bedienungsanleitung

USER'S MANUAL

Revision 1.0b

SuperServer®E100-8Q

and E100-8QE

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and

documentation, is the property of Supermicro and/or its licensors, and is supplied only under a

license. Any use or reproduction of this product is not allowed, except as expressly permitted by

the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class

A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instruction manual, may cause harmful

interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your

own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Manual Revision 1.0b

Release Date: August 24, 2015 mk

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

iii

Preface

About This Manual

This manual is written for professional system integrators and PC technicians. It

provides information for the installation and use of the system. Installation and

maintainance should be performed by experienced technicians only.

Please refer to the system specications page on our Web site for updates on

supported memory, processors and operating systems (www.supermicro.com).

Preface

SuperServer E100-8Q User's Guide

Contents

Chapter 1 Introduction..............................................................................1-1

1-1 Overview ......................................................................................................... 1-1

1-2 Motherboard Features..................................................................................... 1-1

Processors ...................................................................................................... 1-1

Memory ........................................................................................................... 1-1

Storage............................................................................................................ 1-1

Expansion Slots .............................................................................................. 1-2

Input/Output..................................................................................................... 1-2

1-3 Chassis Features ............................................................................................ 1-3

System Power................................................................................................. 1-3

1-4 Models............................................................................................................. 1-3

1-5 System Installation and Setup ........................................................................ 1-4

Unpacking the System .................................................................................... 1-4

Warnings and Precautions.............................................................................. 1-4

Adding Components to Your System.............................................................. 1-4

Radio Capability.............................................................................................. 1-4

Operating System ........................................................................................... 1-4

Connecting Power........................................................................................... 1-4

1-6 System Interface ............................................................................................. 1-5

1-7 Contacting Supermicro.................................................................................... 1-6

Chapter 2 Advanced Motherboard Setup ..............................................2-1

2-1 Handling the Motherboard .............................................................................. 2-1

Precautions ..................................................................................................... 2-1

2-2 Processor ........................................................................................................ 2-2

2-3 Memory ........................................................................................................... 2-2

2-4 Input/Output Ports........................................................................................... 2-2

Front Ports ...................................................................................................... 2-2

Rear Ports....................................................................................................... 2-2

2-5 Motherboard Details........................................................................................ 2-3

2-6 Connector Denitions...................................................................................... 2-5

2-7 Jumpers........................................................................................................... 2-8

2-8 LED Indicators................................................................................................. 2-8

Chapter 3 Advanced Chassis Setup........................................................3-1

3-1 Removing Power............................................................................................. 3-1

3-2 Removing the Chassis Covers........................................................................ 3-2

3-3 Adding Radio Antennas .................................................................................. 3-3

Chapter 4 Standardized Warning Statements for AC Systems ............ 4-1

About Standardized Warning Statements....................................................... 4-1

Warning Denition ........................................................................................... 4-1

Installation Instructions.................................................................................... 4-4

Circuit Breaker ................................................................................................ 4-5

Power Disconnection Warning........................................................................ 4-6

Equipment Installation..................................................................................... 4-8

Restricted Area................................................................................................ 4-9

Battery Handling............................................................................................ 4-10

Redundant Power Supplies .......................................................................... 4-12

Backplane Voltage (if applicable to your system)......................................... 4-13

Comply with Local and National Electrical Codes........................................ 4-14

Product Disposal........................................................................................... 4-15

Hot Swap Fan Warning (if applicable to your system) ................................. 4-16

Power Cable and AC Adapter ...................................................................... 4-18

Appendix A System Specications ........................................................ A-1

FCC Statement...........................................................................................A-2

IC Statement .............................................................................................A-3

Contents

SuperServer E100-8Q User's Guide

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: +1 (408) 503-8000

Fax: +1 (408) 503-8008

Email: [email protected] (General Information)

[email protected] (Technical Support)

Website: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: +31 (0) 73-6400390

Fax: +31 (0) 73-6416525

Email: [email protected] (General Information)

[email protected] (Technical Support)

[email protected] (Customer Support)

Website: www.supermicro.nl

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: +886-(2) 8226-3990

Fax: +886-(2) 8226-3992

Email: [email protected]

Website: www.supermicro.com.tw

Chapter 1

Introduction

1-1 Overview

The E100-8Q is a compact, Internet of Things (IoT) Gateway system comprised

of the E100-015E chassis and the A1SQN single processor motherboard. The

E100-8QE model is an extended temperature model, but otherwise similar. Refer

to our website for information on operating systems that have been certied for use

with the system (www.supermicro.com).

For your system to work properly, please follow the links below to download all

necessary drivers and utilities, and the user’s manual for your system.

• Supermicro product manuals: http://www.supermicro.com/support/manuals/

• Product drivers and utilities: ftp://ftp.supermicro.com

• Product safety info:

http://www.supermicro.com/about/policies/safety_information.cfm

If you have any questions, please contact our support team at:

[email protected].

This manual may be updated periodically without notice, with revisions available

on the Supermicro website.

1-2 Motherboard Features

The gateway system is built around the A1SQN, or A1SQN-E for extended

temperature capabilities. It is an embedded processor motherboard based on the

Intel Quark SoC X1021 (System on a Chip). A list of the primary features follows.

Figure 1-1 displays a block diagram of the chipset.

Processors

The motherboard supports a single Intel Quark SoC X1021 64-bit, 32 nm 2.2W

processor.

Memory

The board supports up to 512 MB of embedded ECC DDR3-800 memory.

Chapter 1: Introduction

1-1

1-2

SuperServer E100-8Q User's Manual

Storage

System storage is a microSDHC memory card up to 32GB in an internal slot.

Expansion Slots

The system has two internal mini PCI-E 2.0 slots and one ZigBee module socket.

Input/Output

The front of the chassis includes one USB 2.0 host and one USB 2.0 device port

and two LAN ports. A reset button is also provided on the front of the unit.

The rear of the unit includes a COM port and an external I/O connector for RS-485,

DIO and ADC.

Figure 1-1. System Block Diagram

Note: This is a general block diagram. Please see Chapter 2 for details.

Legacy SPI

SD/eMMC

UART #1

USB Device

USB 2.0

Dual 10/100

Ethernet MAC

PCIe/USB Host

PCIe

SPI #0

SPI #1

UART #0

DDR3

SPI Flash 8M

2X4 Header

Bootloader

MicroSD Slot

DB-9 RS-232 XCVR

Type -B

Type -A

RJ-4510/100

Base T PHY

RJ-4510/100

Base T PHY

JTAG Debug

Header

EEPROM TPM

Full/Half Length Mini

PCIe

Half Length Mini

PCIe

ADC, 8Channel,

12-bit

RS-485 XCVR

ZigBee Module

Header

DDR3 X8 256MB Rank 0

DDR3 X8 256MB Rank 1

X16

Intel QUARK

2X10 Terminal Block Socket

Half Duplex

X1021

TX/RX

JTAG/ITP

DIO/PWM

8 Channel

1-3

Chapter 1: Introduction

1-3 Chassis Features

The E100-015E is a compact box PC chassis.

System Power

The system is powered by an external power adapter that connects to the front of

the chassis. The external power adapter uses 100-240V AC input, and provides

12V DC, 15W output to the system.

1-4 Models

The E100-8Q gateway can be sold with various radio capabilities. The models are

listed.

Module Model Name

3G(WCDMA)+WiFi SYS-E100-8Q-THAW/ SYS-E100-8QE-THAW

3G(WCDMA)+Zigbee US SYS-E100-8Q-THE3/ SYS-E100-8QE-THE3

3G(WCDMA)+Zigbee EU SYS-E100-8Q-THE2/ SYS-E100-8QE-THE2

3G(CDMA)+WiFi SYS-E100-8Q-TDAW/ SYS-E100-8QE-TDAW

3G(CDMA)+Zigbee US SYS-E100-8Q-TDE3/ SYS-E100-8QE-TDE3

WiFi+Zigbee US SYS-E100-8Q-AWE3/ SYS-E100-8QE-AWE3

WiFi+Zigbee EU SYS-E100-8Q-AWE2/ SYS-E100-8QE-AWE2

3G(WCDMA) SYS-E100-8Q-TH/ SYS-E100-8QE-TH

3G(CDMA) SYS-E100-8Q-TD/ SYS-E100-8QE-TD

Zigbee US SYS-E100-8Q-E3/ SYS-E100-8QE-E3

Zigbee EU SYS-E100-8Q-E2/ SYS-E100-8QE-E2

WiFi SYS-E100-8Q-AW/ SYS-E100-8QE-AW

1-4

SuperServer E100-8Q User's Manual

1-5 System Installation and Setup

The gateway system is shipped with the processor and the motherboard installed

in the chassis. Several steps are necessary to begin using your system.

Unpacking the System

Inspect the box in which the system was shipped and note if it was damaged. If the

system itself shows damage, le a damage claim with the carrier.

Warnings and Precautions

• Use a regulating uninterruptible power supply (UPS) to protect the system from

power surges, voltage spikes and to keep your system operating in case of a

power failure.

• Review the electrical and general safety precautions in Chapter 4.

Adding Components to Your System

• Drives and Storage: The only internal storage supported is a microSD memory

card up to 32GB. It must be added to the system for use. An external USB ash

drive can be plugged in to the front of the chassis for additional storage.

• Input/Output: See Chapter 2 for I/O ports and connect them as needed.

Radio Capability

The gateway can be purchased with radio options. It supports 3G, WiFi, or ZigBee.

See Section 1-4 for a list of possible congurations.

Operating System

Normally, the system requires Wind River Linux. The operating system can be

installed in either a microSD memory card or a USB ash drive. Please refer to the

operating system image installation guide for instruction. To validate the system

compliance to the Intel Gateway Solution, you may register this system at: https://

registrationcenter.intel.com using the serial number found on the side of the chassis

(Figure 1-2).

Connecting Power

To power up the system, screw the connector of the power adapter cord onto the

jack on the front right of the chassis.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Supermicro Server Handbücher

Supermicro

Supermicro A+ Server AS-2025HS-TNR Bedienungsanleitung

Supermicro

Supermicro SuperServer SYS-511R-ML Bedienungsanleitung

Supermicro

Supermicro AS-1020S-8 Bedienungsanleitung

Supermicro

Supermicro SUPERSERVER 1015B-3 Bedienungsanleitung

Supermicro

Supermicro BPN-SAS3-116EL1 Bedienungsanleitung

Supermicro

Supermicro SuperServer SYS-210GP-DNR Bedienungsanleitung

Supermicro

Supermicro SuperServer SYS-221GE-NR Bedienungsanleitung

Supermicro

Supermicro SuperServer 530MT-H12TRF Bedienungsanleitung

Supermicro

Supermicro TwinPro 1029TP-DTR Bedienungsanleitung

Supermicro

Supermicro Supero SUPERSERVER 5086B-TRF Bedienungsanleitung

Supermicro

Supermicro AS-4124GS-TNR Bedienungsanleitung

Supermicro

Supermicro superserver 2028TP-VRL Serie Bedienungsanleitung

Supermicro

Supermicro SuperServer 6014H-i Bedienungsanleitung

Supermicro

Supermicro FatTwin AS-F2014S-RNTR Bedienungsanleitung

Supermicro

Supermicro SuperServer SYS-210SE-31D Bedienungsanleitung

Supermicro

Supermicro SuperServer SYS-2049U-TR4 Bedienungsanleitung

Supermicro

Supermicro SuperServer 6048R-TXR Bedienungsanleitung

Supermicro

Supermicro A+ SERVER 1012C-MRF Bedienungsanleitung

Supermicro

Supermicro SuperStorage Server SSG-6049P-E1CR60H Bedienungsanleitung

Supermicro

Supermicro SuperServer 1029P-WT Bedienungsanleitung

Supermicro

Supermicro SuperServer 610C-TR Bedienungsanleitung

Supermicro

Supermicro SuperStorage 2029P-E1CR48H Bedienungsanleitung

Supermicro

Supermicro 1027R-73DAF Bedienungsanleitung

Supermicro

Supermicro SuperStorage SSG-6029P-E1CR24H Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
