Supertrax Cosmic Bedienungsanleitung

Cosmic Kids Ride on Car

Installation and Operation Instructions

Please read this instruction manual carefully. It is important to read and

follow all of the steps during assembly to ensure proper operation and safety

of the child. Please keep this manual for future reference.

Scan this QR Code to

view the Range Rover

Assembly Video

SPECIFICATIONS:

Car Type:

Range Rover Style

Battery Type:

12V7AH

Electric Motor:

12V30W(Drive) 12V8W(Steering)

Age Range:

2 –5 Years

Max. Weight:

65 lbs

Product Size:

50”L x 34”W x 25”H

Avg. Speed:

2 –3 MPH

Charging time:

8-12 hrs

Avg. Use Time:

1-2 Hrs (depending on use)

Remote Battery:

2 - AA (not included)

IMPORTANT!

•Assembly of car and charging of

battery is only to be done by an

adult.

•WARNING!! NOT TO BE USED

ON STREETS or IN TRAFFIC.

•Never modify the electric circuit

system or tamper with electric

system. Can cause permanent

damage.

•Please check the product

regularly for any loose parts or

wires to ensure proper

operation.

•Adult supervision is

recommended during operation

by child to avoid injury. Safety

equipment is recommended.

•Please make sure that the child

uses caution to avoid falls and

collisions causing injury to the

child or third party.

•Do not pick up vehicle by

steering wheel.

•Do not pick up battery by wires

or charger.

•Keep all plastic bags out of the

reach of young children.

•Not recommended for children

under the age of 2 yrs. due to

small parts that could cause a

choking hazard.

•Battery must be charged for a

minimum of 8-12 hours prior to

first use of the car to avoid

damage to the battery. Power

switch must be in off position

when charging.

•Battery charger should be

examined for damage prior to

each use. It is important to

inspect the cord and both ends

for damage. If damage is found,

DO NOT USE THE CHARGER!

charger.

•Please retain instruction manual

for future reference.

•Please retain packaging in the

event it is necessary to return.

All assembly videos can be found on YouTube

under SUPERtrax

PARTS LIST:

Car Body

Windshield

Screws

Front Wheels

Seat

Wheel Covers

Rear Spoiler

Rear Wheels

Steering Wheel

Drive Motor

Remote Control

Rearview Mirror

Charger

ASSEMBLY INSTRUCTIONS:

Front Wheel Assembly: Locate the Front axle, both on the left and right side of the

vehicle and insert the wheel as shown in the illustration above.

Rear Wheel Assembly: (Rear Wheels have a hub) Insert the wheel aligning

the hole within the wheel with the rear axle. Push rear wheels on both sides

of the rear axle at same time until you hear it click. Once inserted tug on

wheels to make sure wheels are secured.

Installation of the Steering Wheel: Connect the wires (connect the red, black &

white wires together and connect the green & black wires to the black wire). Cut

the wire tie holding wires together then push the wires gently into the steering

column and align the chrome pins and the holes and insert steering wheel firmly.

Windshield Assembly: Align the tabs on bottom of windshield with the tabs on

body of the car and push in until you hear a click. Then insert the screws on both

sides of the windshield (located by mirrors) to secure windshield firmly.

Connect the Battery Power: Connect the plug-in unit of the motor and car wire

one, then connect the red power wire (remove the plastic cover) with the battery

positive polarity (red wire). (This step is typically completed when the vehicle is

tested prior to being shipped out).

Circuit Diagram:

Fuse: This car has an auto-reset fuse. If the car stops suddenly during

operation, it is likely due to an instantaneous and excessive current, causing

the fuse to trip. If this occurs, simply stop vehicle operation for 30-60

seconds. To avoid the fuse tripping and power being cut off, please keep the

following in mind:

-Do not overload the vehicle; the maximum load is 65 pounds.

-Do not drag, pull, tow or haul anything in or behind the vehicle.

-Do not allow water or any other liquids to contact the battery or any other

electrical component on the vehicle.

-Do not change the circuit system or attempt to rebuild or reassemble the

electrical structure of the vehicle.

Installation of Seat: Insert the seat, secure at a good position and screw firmly in

position at both the left and right sides of the saddle.

Installation of the Rear Spoiler: Connect the wires, then align the tabs on bottom

of rear spoiler with the tabs on the body of car and push in until you hear a click.

Charging the battery: The charging port is located on the right side of the

dashboard. Plug the charger into the charging port first, then plug the charger into

wall outlet. BATTERY MUST BE CHARGED FOR A MINIMUM OF 12 HOURS BEFORE

INITIAL USE TO AVOID DAMAGE TO THE BATTERY.

Replacement Fuse for Battery: If the fuse is broken or burned out, there is a spare

fuse in the fuse box located under the seat or behind the body of the car. Replace it

and restart the car.

Please Note: As a safety precaution and to avoid damage to the charger, the car

will not power up while charger port is plugged into the car.

Remote Control Instructions: For the first time use of remote control or after replacing

the battery, you need to sync the remote to the car.

1) Press the car-select button down until the remote indicator light is

flashing, turn on car, and when the light stops flashing pairing has

been successful.

2) Repeat if this does not happen.

3) Once paired for the first time, no need to pair remote for later use

unless batteries are changed in the remote.

4) To use speed selection button, you press button until speed

indicator light is set at desired speed. 1st light low speed, 2nd light

medium speed, 3rd light high speed.

5) Emergency brake. Press & hold stop button down to stop motion

of the car immediately. Release the button to restore the normal

functions of the car.

Once battery is fully charged, disconnect from charger. Depress power button to turn on the car. Once power is

on, all lights light up, accompanied by the sound of the engine. (If no sound is heard, turn up the volume) To allow

child to operate the car, remote control/manual switch must be set to the manual position. To move the car

forward, forward/reverse switch must be set to the forward position and to move the car backward, the switch will

need to be set to the reverse position. To operate the car using the remote control, remote control/manual switch

must be set to the remote-control position. The buttons found on the handlebars are for the horn and the on-board

music. There is a MP3 interface located on the dash area with a volume knob to control the level of sound.

All assembly videos can be found on YouTube

under SUPERtrax

WARNING:

- Use only the rechargeable battery and charger supplied with

your vehicle. NEVER substitute the battery or charger with

another brand. Using another battery or charger may cause

damage.

- NEVER modify the electric circuit system. Tampering with the

electric system may cause permanent damage to the system.

- Do not allow direct contact between battery terminals.

- Do not allow any type of liquid on the battery or its

components.

- Charge the battery in a well-ventilated area ONLY. Do not

charge near or around flammable materials.

- NEVER pick up the battery by the wires or charger. Damage can

occur to the battery and may cause a fire. Pick up the battery by

the case ONLY.

- Charge the battery in a dry area ONLY.Wash hands after

handling.

- Do not open the battery. Battery contains lead acid and other

materials that are toxic and corrosive.

- Do not open the charger. Exposed wiring and circuitry inside

case could cause electric shock. NEVER allow a child to handle

or charge the battery. Battery is heavy and contains lead acid

(electrolyte).

- Do not drop the battery. Permanent damage to the battery

could occur or cause serious injury. Before charging the

battery, check for wear or damage to the battery, charger, its

supply cord and the connectors. DO NOT charge the battery if

any damage to parts has occurred.

- Do not allow the battery to drain completely. Recharge the

battery after each use or once per month if not used regularly.

- Do not charge the battery upside down.

- Always secure the battery with the bracket. Battery can fall out

and injure a child if vehicle tips over.

- The Power Switch must be turned in the OFF position when

charging.

- When the car begins to run slowly, recharge the battery.

GENERAL MAINTENANCE:

It is the parent’s responsibility to check main parts of the toy before using. Regularly

examine the car for potential hazard, such as damage to the battery, charger, cable

or cord, and plug. Also, check that all screws are tightened throughout the car. In

the event of such damage, the toy must not be used until that damage is repaired

or replaced.

•Make sure the plastic parts of the vehicle are not cracked or broken.

•Occasionally use a lightweight oil to lubricate moving parts such as wheels.

•Park the vehicle indoors or cover it with a tarp to protect it from wet weather.

•Keep the vehicle away from sources of heat, such as stoves and heaters. Plastic

parts may melt.

•Recharge the battery after each use. Only an adult should handle the battery.

Recharge the battery at least once a month when not being used.

•Do not wash the vehicle with a hose. Do not wash the vehicle with soap and

water. Do not drive the vehicle in rainy or snowy weather as water will damage

the motor, electric system and battery.

•Clean the vehicle with a soft, dry cloth. To restore shine to plastic parts, use a

non-wax furniture polish. Do not use car wax. Do not use abrasive cleaners.

•Do not drive the vehicle in loose dirt, sand or fine gravel which could damage

moving parts, motors or the electric system.

•For extended times when the car will not be used, the power switch needs to be

in the off position and the electrical connections should be disconnected from

the battery.
