Sure Electronics TA2024 Bedienungsanleitung

2 X 15Watt Class-D Audio

Amplifier - TA2024

User’s Guide

2 X 15WATT CLASS-D AUDIO

AMPLIFIER - TA2024

USER’S GUIDE

A-AB32155_Ver1.0_Page i

Table of Contents

Chapter 1. Overview ..........................................................................................................1

1.1 Overview.............................................................................................................. 1

1.2 Features............................................................................................................... 1

Chapter 2. How to Connect Load .....................................................................................3

Chapter 3. Mechanical Drawing........................................................................................4

Chapter 4. Contact Us .......................................................................................................5

2 X 15Watt Class-D Audio Amplifier - TA2024

A-AB32155_Ver1.0_Page ii

NOTES:

Product Version ：Ver 1.4

Document Version ：Ver 1.0

2 X 15WATT CLASS-D AUDIO

AMPLIFIER - TA2024

USER’S GUIDE

Chapter 1. Overview

1.1 Overview

Thanks for using this 2 X 15Watt Class-D Audio Amplifier by Sure Electronics. This

product provides an easy engineering evaluation platform for Tripath Technology’s

TA2024 product. It is capable of delivering up to 15W each channel. Powered by DC 12V,

it can be used to drive any passive 4 or 8Ωspeakers.

FIGURE 1-1 TOPVIEW

Note: All the diagrams in this manual are for reference only.

1.2 Features

yClass-T architecture

yProprietary Digital Power Processing Technology

yRequires single +12V power source

yOutput Power (per channel @ VS = 12V):

15W per channel (4Ω, 10% THD+N)

10W per channel (4Ω0.1%, THD+N)

y“Audiophile performance” typically:

0.04% THD+N (9Wrms, 4Ω)

0.18% IHF-IM (1Wrms, 4Ω)

yEfficiency - >88% @ full power (RL = 8Ω)

yNo heat sink required up to 15W per channel

yMUTE and SLEEP inputs

yTurn-on & turn-off pop suppression

yIntelligent short-circuit protection

yIntelligent over-temperature protection

A-AB32155_Ver1.0_Page 1

2 X 15Watt Class-D Audio Amplifier - TA2024

A-AB32155_Ver1.0_Page 2

yTakes standard audio line output from any sound system

yCost-effective 2-layer PCB design

y36-pin Power SOP package

2 X 15WATT CLASS-D AUDIO

AMPLIFIER - TA2024

USER’S GUIDE

Chapter 2. How to Connect Load

FIGURE 2-1 LOAD CONNECTION

Note:

1. GND should be connected to GND or the housing of your instrument.

2. There are two audio-input methods. One is via audio input. Another is via terminals

(J2, J5).

3. There are two audio-output methods. One is via terminals (J3and J9). Another is

via corresponding banana jack.

A-AB32155_Ver1.0_Page 3

2 X 15WATT CLASS-D AUDIO

AMPLIFIER - TA2024

USER’S GUIDE

Chapter 3. Mechanical Drawing

FIGURE 3-1 MECHANICAL DRAWING

A-AB32155_Ver1.0_Page 4

2 X 15WATT CLASS-D AUDIO

AMPLIFIER - TA2024

USER’S GUIDE

Chapter 4. Contact Us

Sure Electronics Co., Ltd.

East zone, 3F, Building 6

Jingang Technology Innovation Center

No.108 Ganjiabian Rd (ZIP: 210000)

Qixia District

Nanjing

P.R.China

Tel: +86-25-68154800-860

Fax: +86-25-68154891-832

Website: www.sure-electronics.com

Email: customerservice@sure-electronics.com

A-AB32155_Ver1.0_Page 5
