Sven AP-B770MV Bedienungsanleitung
www.sven.fi
OPERATION
MANUAL
AP-B770MV
Wireless Stereo Headphones
with Microphone
ENG
1
Operation Manual
Congratulations on your purchase of the SVEN stereo headphones!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
APPLICATION
SVEN AP-B770MV wireless stereo headphones with microphone are
designed for operation with PC, notebookes and other mobile devices by
means of data transfer via Bluetooth protocol. They can be also used in
internet telephony, during video conferences, in multimedia applications, in
interactive games, for speech recognition and foreign language teaching.
PACKAGE CONTENTS
•Stereo headphones – 1 pc
•Power cord USB to mini USB – 1 pc
•User’s Manual – 1 pc
•Warranty card – 1 pc
SAFETY PRECAUTIONS
•Don’t use the stereo headphones while driving.
•Don’t use the stereo headphones at high volume for a long time (more than
15 minutes), as this may cause hearing impairment.
SPECIAL FEATURES
• 3.0 Bluetooth wireless signal transmission
• Operation time with battery up to 22 hours
• Radius of operation up to 10 m
• Track switching control possibility
• Call acceptance function
AP-B770MV
ENG
2
DESCRIPTION
a: next track
b: Рlay/Рause
c: previous track
dCHARGE: mini USB jack for
battery charging
eMIC: microphone
f: headphones on/offand
call control button
gV-: volume down button
hV+: volume up button
iLED indicator
CONNECTION AND OPERATION
Device switching on/off
•Press and hold down the button funtil the battery beeps to switch on
the headset. During the headphones switching on the LED iwill start
blinking blue color. Press once more and hold down the button funtil the
battery beeps to switch offthe device. During the headphones switching off
the LED iwill blink red three times.
Control buttons
Jointly with a telephone:
•to receive an entry call press the button f. Press the button fonce
more to finish the call f;
•when the button fis pressed long (~2 sec.), the last call dialing will start;
•when the button fis pressed short (less than 2 sec.) (not in the call
mode) the voice activated dialing function is activated (depending on a tele-
phone configuration).
In the player mode:
•when buttons cor aare pressed long, track/video rewinding will be
started.
Headset charging
•Connect the headset to PC with the USB to mini USB cable (included).
The indicator ilights red during charging.
a
b
c
di
h
g
f
e
Fig. 1. Headphones description
Wireless Stereo Headphones
with Microphone
ENG
3
Operation Manual
•When the device is fully charged, the indicator will blow out.
•When the battery is low-charged, it beeps several times and the indicator
iwill blink red.
•The battery is used in the headphones as an integral part of the device,
so do not try to remove or replace it as it can result in the warranty
cancellation or to a damage of the device.
Bluetooth technology
•Wireless data transfer via the Bluetooth protocol allows connecting head-
phones without wiring to compatible devises. Maximum radius of action of
data transfer is 10 m. Such obstacles as walls or other electronic devices
can interfere with the signal transfer.
Headset to a device interface
•It is necessary first to interconnect the device with a sound source (see the
connection diagram in Fig. 2) to transfer signals via Bluetooth. To do this,
switch on the headset not releasing the button fwhile the search mode
will start, LED indicator iwill alternate blue light with red one.
•It is necessary to select the search mode of a Bluetooth device on a sig-
nal source (telephone, notebook, smartphone, etc.), the «AP-B770MV» name
will be displayed on the screen with which connection is to be required*.
•If connection is successful, there will be a short sound signal in the
headphones; the search mode indication on the headphones is over. If no
devices will be connected, the search mode will be turned offautomatically
in three minutes and the headphones will go to the standby mode. If the
interface of devices has been failed, it is necessary to switch the system in
the search mode once more (switch offand on)**.
Fig. 2. Connection diagram
Phone
PC Headphones
AP-B770MV
4
ENG
•The indicator ion the headphones blinks blue short during the data
exchange with a device connected via Bluetooth.
* You might have to enter “0000” code to connect some models of devices
via Bluetooth.
** If the item has been already registered in the device list of a source, then
the second search mode activation is not obligatory. Choose only the item
name and the “connect” command on the source.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit
Sensitivity, dB
Frequency range, Hz
Impedance, Ohm
Membrane, mm
Connection type
Bluetooth supported profiles
Radius of operation, m
Operation time with battery
Weight, g
Value
headphones: 106 ± 2
microphone: -58 ± 2
headphones: 20 – 22 000
microphone: 100 – 10 000
32
Ø 40
Bluetooth 3.0 + EDR
HSP, HFP, A2DP, AVRCP
10
up to 22 hours
210
Notes. Technical specifications given in this table are supplemental informa-
tion and cannot give occasion to claims. Technical specifications are subject
to change without notice due to the improvement of SVEN production.
Technical support is on www.sven.fi
Wireless Stereo Headphones
with Microphone
Модель: AP-B770MV
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024, РФ,
г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi
Гарантийный срок: 12 мес.
Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the control
of Oy Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka,
Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
