USER’S MANUAL
Wireless Optical Mouse
RX-360 Art
Wireless
2
2
2
3
3
6
6
Congratulations on your purchase of the SVEN PC mouse!
Please read the following instructions carefully before connecting, operating
or adjusting this product. Besides, please keep this Manual in a safe place
for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information in this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SPECIAL FEATURES ....................................................
2. PACKAGE CONTENTS ..................................................
3. SYSTEM REQUIREMENTS ............................................
4. DESCRIPTION ...........................................................
5. INSTALLATION ...........................................................
6. TROUBLESHOOTING ................................
...................
7. TECHNICAL SPECIFICATIONS ...........................
.............
Technical support is on www.sven.fi.
ENG
1
User’s Manual RX-360 Art
Wireless
1. FEATURES
•Blue LED advanced optical technology
•Stylish ergonomic design
• 2.4 GHz USB nano receiver included (range of action up to 10 m)
•Effective on most surfaces
•High speed operation
•Resolution 1200 dpi
•USB interface
•Battery long service life (1 year)
•Installation drivers for Windows XP/Vista/7/8 are not required
•Сonvenient with laptops
2. PACKAGE CONTENTS
•Optical mouse — 1 рс
•2.4 GHz USB nano receiver — 1 рс
•AA battery — 1 рс
•User’s Мanual — 1 рс
•Warranty card — 1 рс
3. SYSTEM REQUIREMENTS
•Windows XP/Vista/7/8.
•Free USB port.
ENG
2
Wireless Optical Mouse
a
4. DESCRIPTION
aScroll wheel
bON/OFF power switch
cBattery compartment
dOptical sensor
eNano receiver
fUSB connector
e
f
d
b
c
e
Fig. 1. Top view
Fig. 2. Bottom view Fig. 3. Nano receiver
5. PREPARATION TO OPERATION
•Open the cover of the mouse battery compartment c, insert the AA
battery into the battery compartment observing the polarity and close the
cover of the battery compartment (see Fig. 4).
•Сonnect the included nano receiver eto a free PC USB port (Fig. 5).
ENG
3
User’s Manual RX-360 Art
Wireless
ENG
4
Wireless Optical Mouse
Fig. 4. Battery installation
Fig. 5. Receiver connection
AA battery
Battery
compartment
Improper installation of
batterуcan result in failure
of the mouse!
•Switch on the mouse with the power switch b(ON position). Press any
button of the mouse or rotate the scroll wheel to activate the mouse. If the
mouse has been connected correctly, it will be switched on automatically.
Battery compartment
cover
This device meets the highest standards of energy conservation.
Use the switch bon the bottom of the mouse to switch it on/off –
it will help you to extend the mouse battery life.
Important
•After finishing your work switch offthe mouse with the power switch b
(OFF position). After this you can extract the receiver efrom the PC USB
port and insert it into the mouse (Fig. 6). When using the receiver again,
extract it from the mouse (Fig. 7) and connect it to the PC USB port again.
•Do not place the receiver in a metal confined space (table drawer, box,
safe), as metal screen does not transmit radio signals.
•If the battery is discharged, the mouse works by fits. It means that the
battery should be replaced with a new one, as it is shown in Fig. 4.
Fig. 6. Fitting the receiver
into the mouse case
Fig. 7. Extraction of the receiver
from the mouse case
ENG
5
User’s Manual RX-360 Art
Wireless
ENG
6
Wireless Optical Mouse
Notes:
• Technical specifications given in this table are supplemental infor-
mation and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to
the improvement of SVEN production.
7.
TECHNICAL SPECIFICATIONS
Parameter
OS compatibility
Mouse type
Resolution, dpi
Quantity of buttons
Interface
Dimensions, mm
Weight, g
Value
Windows XP/Vista/7/8
wireless 2.4 GHz
1200
2 + 1 (scroll wheel)
USB
94 × 40 × 58
79
6. TROUBLESHOOTING
Solution
1. Make sure that the nano receiver has been
inserted into a USB port and its distance to
the mouse is less than 10 m.
2. Check whether the battery has been
installed correctly.
3. Check if the battery is charged, replace the
battery with new one if necessary.
4. Address the nearest authorized service center.
Problem
The mouse does not
work.
Модель:
RX-360 Art Wireless
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
