Swann IP3G1000 Bedienungsanleitung

MPEG4/MJPEG

Network Camera

Quick Installation Guide

- 1 -

1 Getting Started

Package Contents

Check the items contained in the package carefully. You should

have the following items. Once any item contained is damaged or

missing, contact the authorized dealer of your locale.

5One MPEG4/MJPEG Network Camera.

5One AC Power Adapter.

5One External Antenna (for wireless model).

5One Camera Stand.

5One Ethernet Cable (RJ-45 type).

5One Installation CD-ROM.

5One Quick Installation Guide.

System Requirement

Networking

LAN: 10Base-T Ethernet or 100Base-TX Fast Ethernet.

WLAN: IEEE 802.11b/g (for wireless model).

Accessing the Camera using Web Browser

Platform: Microsoft® Windows® 2000/XP/Vista

CPU: Intel Pentium III 800MHz or above

RAM: 512MB

Resolution: 800x600 or above

User Interface: Microsoft® Internet Explorer 6.0 or above

Mozilla Firefox 2.00 or above

Apple Safari 2 or above

- 2 -

2 Setting Up the Camera

Installing the Camera Stand

The camera comes with a camera stand, which uses a swivel ball

screw head to lock to the camera’s screw hole. When the camera

stand is attached, you can place the camera anywhere by

mounting the camera through the three screw holes located in the

base of the camera stand.

The Camera Stand

- 3 -

Connecting the Camera to LAN

Use the provided Ethernet cable to connect the camera to your

local area network (LAN).

When you connect the AC power adapter, the camera is powered

on automatically. You can verify the power status from the Power

LED on the front panel of the camera.

Once connected, the Link LED starts flashing green light and the

camera is on standby and ready for use now.

Connecting the Ethernet Cable

- 4 -

Connecting the Camera to WLAN

If you use a wireless network in your application environment, you

need to attach the included external antenna to the camera.

When the camera is powered on, the camera will automatically

search any access point with “default” SSID.

NOTE If the camera cannot to your wireless network, you need to

install the camera in LAN and proceed with WLAN settings.

Connecting the

External Antenna

- 5 -

3 Accessing the Camera

Using IP Finder

1. Insert the Installation CD-ROM into your computer’s CD-ROM

drive to initiate the Auto-Run program.

2. Click the IP Finder item to launch the utility. The control

panel will appear as below.

3. Once you get the IP address of the camera, launch the Web

browser or Ultra View to access your camera.

TIP The Installation CD-ROM provides a setup program that

allows you to install IP Finder on your computer. To install

IP Finder, click Install Software then select IP Finder on

the Auto-Run screen.

Display the

connected camera

(

)

Click Search to find the IP address of the connected camera(s).

Click Change IP to modify the IP address of the selected camera.

Click Exit to close the utility.

- 6 -

Accessing to the Camera

1. Open the Web browser on your computer (for example,

Microsoft Internet Explorer in this guide)

2. Type the default IP address (192.168.0.30) or the IP address

found by IP Finder in the Address bar, and then press [Enter].

3. When the login window appears, enter the default User name

(admin) and password (admin) and press OK to access to the

main screen of the camera’s Web Configuration.

Enter the IP address

of the camera here.

Enter the User

name and

Password.

- 7 -

4. Click Setup and then Smart Wizard to set up your camera

quickly. The Smart Wizard will guide you through the

necessary settings with detailed instructions on each step.

- 8 -

4 Tips

For more information, please refer to the Advanced Installation

Guide on the provided Installation CD-ROM.

For details of operating Ultra View, please refer to the Software

User Guide on the provided Installation CD-ROM.

If you have any problem on the product(s), please contact your

local authorized dealer.
