SyChip WLAN6060SD Bedienungsanleitung

WLAN6060SD Card

User Manual

02/12/2003

preliminary

Confidential Information

Note: SyChip, Inc. reserves the right to make changes in specifications at anytime and without notice.

The information furnished in this data sheet is believed to be accurate and reliable. However, no

responsibility is assumed by SyChip for its use, nor any infringements of patents or other rights of third

parties resulting from its use. No license is generated under any rights of SyChip or its supporters unless

specifically agreed.

WLAN6060SD Card User Manual

WLAN6060SD Card User Manual Version Control

Version Date Author Engineering

Approval

Marketing

Approval

Operation

Approval

Mark

Preliminary 02/12/2003 PG

SyChip Confidential Page 2 of 21 SyChip_WLAN6060SD

WLAN6060SD Card User Manual

Table of Content

1INTRODUCTION INFORMATION...................................................................................................................5

1.1 Introduction.................................................................................................................................................................... 5

1.2 About this User Manual:............................................................................................................................................... 6

1.3 Safety Precautions.......................................................................................................................................................... 7

1.4 Limitation of Liability .................................................................................................................................................. 7

1.5 Usage Conditions............................................................................................................................................................ 7

1.6 Warning .......................................................................................................................................................................... 7

1.7 Caution............................................................................................................................................................................ 7

1.8 Handling Instructions.................................................................................................................................................... 7

1.9 Notes................................................................................................................................................................................ 7

2WLAN6060SD PACKAGE CONTENTS .........................................................................................................7

3WLAN6060SD SPECIFICATIONS..................................................................................................................7

4INSTALLATION AND CONFIGURATION ......................................................................................................8

4.1 Preparation..................................................................................................................................................................... 8

4.2 Supported Devices.......................................................................................................................................................... 8

4.3 Installing WLAN6060SD Card and Software ............................................................................................................. 8

4.4 Configuring WLAN6060SD Card ................................................................................................................................ 9

4.4.1 Pegasus Card Configuration........................................................................................................................................ 9

4.4.2 Status Tab.................................................................................................................................................................... 9

4.4.3 Configuration Tab ..................................................................................................................................................... 11

4.4.4 Encryption Tab.......................................................................................................................................................... 12

4.4.5 Advanced Setting Tab ............................................................................................................................................... 13

4.4.6 Host Scan Tab ........................................................................................................................................................... 14

4.4.7 About Tab ................................................................................................................................................................. 16

4.5 Removing the radio card ............................................................................................................................................. 16

5TROUBLESHOOTING ..................................................................................................................................16

SyChip Confidential Page 3 of 21 SyChip_WLAN6060SD

WLAN6060SD Card User Manual

6DOCUMENTATION UPDATES.....................................................................................................................17

7CONTACT INFORMATION ...........................................................................................................................17

8LEGAL INFORMATION ................................................................................................................................18

8.1 Applying the Regulatory Country Stamp .................................................................................................................. 18

SyChip Confidential Page 4 of 21 SyChip_WLAN6060SD

WLAN6060SD Card User Manual

1 Introduction Information

1.1 Introduction

SyChip WLAN6060SD Network Interface Card

WLAN6060SD Card from SyChip Inc is a Secure Digital Card form factor Wireless LAN NIC(Network

Interface Card) incorporating the popular wireless Ethernet standard 802.11b. It uses Direct Sequence

Spread Spectrum (DSSS) Wireless LAN technology to provide bandwidths of up to 11Mbps at ranges of

up to 400 feet. This card enables next generation Pocket PC/PDAs, Cellular Phones, and Ultra-thin

notebook computers to access the internet, email, corporate networks and transfer streaming video or

audio, images or large files from a WLAN-enabled environment. It allows an extension of the corporate

resources by enabling the mobile workforce and telecommuters. The card is idea for vertical markets such

as manufacturing floors, car rentals, retail spaces, hospitals etc. In the consumer market, this WLAN card

is ideal for users of next generation Palms, Pocket PCs, Smartphones, printers and scanners. Additionally,

the card gives users the ability to work whilst away from the office by connecting to the rapidly

expanding public hotspot infrastructure. Such venues as coffee shops, airports, shopping malls, hotels, etc

are offering this capability based on the IEEE802.11b standard. For mobile applications, battery life is

extended through the use of enhanced power saving features, which reduce the current drain whilst in

standby mode (the card is in this state for the majority of the time as it awaits data destined for it).

Not only does the WLAN6060SD Card roam seamlessly among multiple 802.11b wireless network

access point, it also operates in peer to peer mode (without an access point) to download data from

wirelessly equipped laptops without a cradle or network connection, and can share data directly with

wireless PDAs.

This is a complete WLAN solution incorporating the Baseband Processor, Mac, Memory, VCO,

Transceiver, Antenna, antenna switch and power amplifier and to realize a complete design. The card will

be fully WiFi certified.

SyChip Confidential Page 5 of 21 SyChip_WLAN6060SD

WLAN6060SD Card User Manual

Key Features:

• Wi-Fi Certified – interoperable with other Wi-Fi certified WLAN products

• Very small footprint: card measured 54.0x24.0x2.1mm3.

• Complete IEEE802.11b functionality integrated BB/MAC, RF, VCO, PA and SD interface

• Reduced power consumption in standby mode

• User definable transmit power settings in Ad Hoc Mode

• Will support Win2000/NT/XP, WinCE (v3.0 or greater), Palm OS

• Support infrastructure or Peer to Peer connectivity

Warnings:

THIS EQUIPMENT COMPLIES WITH PART 15 OF THE FCC RULES. ANY CHANGE OR

MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFACTURER COULD VOID THE

USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO

THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL

INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

1.2 About this User Manual:

This User Manual contains:

• Information of safety and handling of WLAN6060SD Card

• WLAN6060SD Card installation procedures for Pocket PC/PDA

• Basic configuration and settings of WLAN6060SD Card for Pocket PC/PDA

• Troubleshooting of WLAN6060SD Card

• Update and support information

• Legal Information

Please be sure to read this User Manual before using the WLAN6060SD Card to ensure its proper

handling.

• Please be sure to read “Safety Precautions” in the document since these describe important safety

issues

SyChip Confidential Page 6 of 21 SyChip_WLAN6060SD

THIS WAS DEVICE WAS EVALUATED FOR BODY SAR IN A PDA WITH A SEPARATION 

DISTANCE OF 0.0 CM. FAILURE TO INSTALL THIS DEVICE AS DESCRIBED WILLWILL 

RESULT IN A FAILURE TO COMPLY WITH FCC RULES FOR RF EXPOSURE AND IS 

DISCOURAGED. ONLY ANTENNAS APPROVED WITH THE DEVICE MAY BE USED. NO 

EXTERNAL ANTENNAS MAY BE USED. THIS DEVICE MAY NOT BE CO-LOCATED WITH 

OTHER TRANSMITTERS WITHOUT FURTHER APPROVAL BY THE FCC.

WLAN6060SD Card User Manual

•

After reading this document, keep it in a convenient place for future reference.

Concerning the display of device certification:

This product has been certified as conforming to technological standards for a wireless device as a small

electrical data transmission system under electrical transmission law. Therefore, you do not need a license

from a government agency to operate this system.

However, the following actions are punishable by law:

Disassembly or modification of this product

Removal of identification labels on the back of this product

1.3 Safety Precautions

1.4 Limitation of Liability

1.5 Usage Conditions

1.6 Warning

1.7 Caution

1.8 Handling Instructions

1.9 Notes

2 WLAN6060SD Package Contents

WLAN6060SD Card package from SyChip includes:

1 WLAN6060SD Card

1 WLAN6060SD software and document CD

3 WLAN6060SD Specifications

Supported Operating System: Win CE3.0 (Pocket PC2002)

Certification: Wi-Fi (802.11b)

Size (LxWxH mm3): 54.0x24.00x1.6 (2.1mm high for extended antenna section)

Weight(g): 4.3

SyChip Confidential Page 7 of 21 SyChip_WLAN6060SD

WLAN6060SD Card User Manual

Transmit Power(dBm): 13.0

Power ratings:

DC (V) 3.3 (2.7~3.6)

Current Consumption(mA): 297 (max)

35 (average)

15 (sleep)

Security Standards: WEP 64/128

4 Installation and Configuration

4.1 Preparation

Before operating the WLAN6060SD Card, refer to Applying the Regulatory Country Stamp. Once the

regulatory stamp is affixed, register the WLAN6060SD Card at www.sychip.com/products/reg.

Before beginning the installation, verify the hardware package contains:

• A WLAN6060SD Card

• A WLAN6060SD Card software and documentation CD

4.2 Supported Devices

The WLAN6060SD card can be used in any platform that has the proper SDIO interface and Software

drivers.

Refer to the documentation on the enclosed CDROM for installation and usage instructions.

4.3 Installing WLAN6060SD Card and Software

WLAN6060SD Host Device

SDIO Slot

The WLAN6060SD Card driver and utility installation requires a connection through Microsoft

ActiveSync between the desktop or notebook PC and the host device. The installation installer on the

CDROM downloads the necessary files to the host device through the desktop or notebook PC.

SyChip Confidential Page 8 of 21 SyChip_WLAN6060SD

WLAN6060SD Card User Manual

1. Establish an ActiveSync connection between the desktop or notebook PC and the host device.

2. Insert the WLAN6060SD Card Software and Documentation CDROM into the CDROM drive on

the desktop or notebook PC.

An HTML (Web) page automatically displays

3. Click Software Installation

A File Download window display

4. Check the Run this program from its current location option and click OK.

5. Follow the instruction displayed by the installer.

6. Finish of the installation of WLAN6060SD software to the host device.

4.4 Configuring WLAN6060SD Card

After installed the driver into host device, you can now plug in the WLAN6060SD card into SDIO slot in

your host device. You will see an icon appearing on the low right corner bar.

4.4.1 Pegasus Card Configuration

You need to configure the Pegasus card before you can be connected to the network. Double click the

Pegasus icon, a “Pegasus Wireless Settings” windows will pop up.

4.4.2 Status Tab

The status tab screen shows some important parameters that card is working with:

Figure 1 Status window

Information Field

• Current Channel

SyChip Confidential Page 9 of 21 SyChip_WLAN6060SD

WLAN6060SD Card User Manual

It shows the RF channel number currently used by the card.

• Current TX Rate

It shows the current transmit speed that can be 1Mb/s, 2Mb/s, 5.5Mb/s, and 11 Mb/s depending on the

link quality.

• Link Quality

It gives both percentage and graphic display for signal to noise ratio.

• Signal Strength

It gives both percentage and graphic display for signal strength in Receiver.

• Station IP Info

This block gives the card IP information that include:

 IP Address

 Subnet Mask

 Gateway Address

 DHCP Server

 MAC Address

Check with your network administrator for IP configuration information.

• BSS ID

It shows the MAC address of the Access Point the card associating with.

Operation Button

• Disable Radio

This button is used to disable the radio link from the card.

• Rescan

Press this button to start a rescan in current radio channel.

• Renew IP

Renew IP button allows one to reapply IP address from DHCP server.

SyChip Confidential Page 10 of 21 SyChip_WLAN6060SD

Inhaltsverzeichnis

Andere SyChip Netzwerkkarte Handbücher

SyChip

SyChip WLAN6065SD Bedienungsanleitung

Beliebte Netzwerkkarte Handbücher anderer Marken

FirstComm

FirstComm OBiWiFi5G Bedienungsanleitung

Sun Microsystems

Sun Microsystems Interface Adapter Bedienungsanleitung

TRENDnet

TRENDnet TU2-ETG Bedienungsanleitung

YASKAWA

YASKAWA SI-EN3 Bedienungsanleitung

Paradyne

Paradyne BitStorm 2600 IP DSLAM Bedienungsanleitung

Belkin

Belkin F5D7050 Bedienungsanleitung

3Com

3Com EtherLink 3C509B Bedienungsanleitung

TRENDnet

TRENDnet TEG-PCITX Bedienungsanleitung

Cisco

Cisco MC16E Bedienungsanleitung

Delta Electronics

Delta Electronics Braking Modules VFDB Series Bedienungsanleitung

TwinMOS

TwinMOS Booming Bedienungsanleitung

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Bedienungsanleitung

Buffalo

Buffalo AirStation WLI-PCM-L11GP Bedienungsanleitung

National Instruments

National Instruments NI 9234 Bedienungsanleitung

Hama

Hama 49276 Bedienungsanleitung

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Bedienungsanleitung

Compaq

Compaq Wireless LAN 100 Bedienungsanleitung

Bose

Bose PowerMatch Dante Bedienungsanleitung
