Symcod LS6300 Bedienungsanleitung

Manual

LS6300

Laser Barcode Scanner

Version: 30/04/2013

WWW.SYMCOD.COM

Introduction

The Symcod LS6300 is an affordable scanner solution for operation

management. Always looking for reliable and economical solution, this

model has been specially selected by Symcod for its excellent value for

money. Recommended for light industrial operation, it is design without

mechanical moving parts which is an asset.

Examples of uses

•Time & attendance

•Inventory management

•Document tracking and more

Characteristic

•Built-in 1D laser engine, no moving parts

•Multi-selection for different use

•High resolution up to 4 mils

•Multi-interface

Programmation guide

1. Use the cable required for the selected interface

2. Connect the cable to the device

3. Scan the « Default » code to reset the scanner to the factory configuration.

4. Go to « OUTPUT MODE » section

5. USB configuration, scan code under : “OUTPUT MODE – KEYBOARD / USB”

6. RS-232 configuration, scan code under : “OUTPUT MODE – SERIAL RS232”

RESET CONFIGURATION TO DEFAULTS

OUTPUT MODE –

KEYBOARD / USB

OUTPUT MODE –

SERIAL RS232

OUTPUT

MODE

OUTPUT MODE – WAND

RS-232

USB

Multi-Interface Functions – 1

GOOD READ BEEP TONE

NONE

BUZZER /

LED

GOOD READ BEEP TONE

RESET

DECODE OPTIONS REVERSE IMAGE –

ENABLE


DECODE OPTIONS REVERSE IMANGE

DISABLE

DECODE OPTIONS SEND BAR CODE ID -

DISABLE

CODE ID

DECODE OPTIONS SEND BAR CODE

ID – AS A PREFIX

DECODE OPTIONS SEND BAR CODE ID -

RESET

DECODE OPTIONS SEND BAR CODE

ID – AS A SUFFIX

Multi-Interface Functions – 2

SCAN MODE

SINGLE SCAN

READING

MODE

SCAN MODE – SINGLE SCAN NO

TRIGGER

SCAN MODE – MULTISCAN

NO TRIGGER

SCAN MODE - PULSE

LASER/CCD TIMEOUT

5 SECONDS

LASER/CCD TIMEOUT

2 SECONDS

LASER/CCD PULSE RATE - 7

LASER/CCD PULSE RATE - 3

Keyboard Language

USA (Original setting) Italian

Norway France

Germany Vietnam

Sweden Spain

Denmark Portugal

Switzerland Hungary

*As a general rule, the following characters are not supported by the scanner for

countries other than United States:

@ | $ # { } [ ] = / ‘ \ < > ~

Symbologies On/Off - 1

CODE 11 - ENABLE CODE 11

CODE 11 - DISABLE

CODE 39 ENABLE CODE 39

CODE 39 DISABLE

FULL ASCII ENABLE

FULL ASCII DISABLE

Symbologies On/Off - 2

CODE 93 - ENABLE

CODE 93

CODE 93 - DISABLE

CODE 128 - ENABLE CODE 128 CODE 128 - DISABLE

CODE 128 ISBT - ENABLE CODE 128 ISBT - DISABLE

CODABAR - ENABLE CODABAR

CODABAR - DISABLE

I2OF5 - ENABLE

INTERLEAVE

2 OF 5

I2OF5 - DISABLE

ID2OF5 - ENABLE INDUSTRIAL 2 OF 5

ID2OF5 - DISABLE

Symbologies On/Off - 3

MSI - ENABLE

MSI

MSI - DISABLE

UPC-A ENABLE UPC/EAN UPC-A DISABLE

UPC-E ENABLE UPC-E DISABLE

EAN-13 ENABLE

EAN-13 DISABLE

EAN-8 ENABLE

EAN-8 DISABLE

Symbologies Set Up - 1

CODE 11 ID CHARACTER – “m”

CODE 11

CODE 11 ID CHARACTER – “Z”

CODE 11 DOUBLE CHECK

ENABLE

CODE 11 DOUBLE CHECK

DISABLE

CODE 39 SS CHAR - NONE CODE 39 CODE 39 SS CHAR ‛+’

CODE 39 SEND START/STOP

CHARS ENABLE

CODE 39 SEND START/STOP

CHARS DISABLE

CODE 39 ID CHARACTER ‛a’

CODE 39 ID CHARACTER ‛Z’

CODE 39 DOUBLE CHECK

ENABLE

CODE 39 DOUBLE CHECK

DISABLE
