Thank you for choosing SYNCO Mic-E10,
Please read this manual carefully before use and follow all instructions mentioned herein.
Mic-E10 Microphone User Manual
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@syncoaudio.com
www.syncoaudio.com
https://www.facebook.com/syncomicrophones
Guangzhou Zhiying Technology Co., Ltd
Package List.....................................................................................................................................1
Feature Introduction.......................................................................................................................2
Caring For Your SYNCO Mic-E10 Microphone..............................................................................2
Operations........................................................................................................................................3
① The Use of Windshield
② Mounting the Mic-E10 Microphone
③ Powering the Mic-E10 Microphone
Specications..................................................................................................................................5
Warranty...........................................................................................................................................7
Contents
1www.syncoaudio.com www.syncoaudio.com 2
Feature Introduction
Package List
Caring For Your SYNCO Mic-E10 Microphone
Cardioid directivity minimizes undesired peripheral sound
Broad balanced range of frequency response
Built in 180Hz 12dB low cut
Gold-plated XLR connector for ideal signal transmission
Aluminium alloy housing with strong anti-interference
Support 1.5V AA battery and 48V DC phantom power
Easy to use with ON/OFF switch
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to prevent mechanics
damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any malfunctions happened.
Remove the battery for long time storage.
Failure to follow all the instructions may result in mechanics damage.
SYNCO Mic-E10 Microphone x1
XLRM to 3.5mm Cable (3m) x1
User Manual x1
Cotton Windshield x1
H-25 Mount
(5/8” & 3/8” screw accessible) x1
(Package includes the following items)
User Manual
3www.syncoaudio.com www.syncoaudio.com 4
1. The Use of Windshield
Mic-E10 comes with the Cotton Windshield to eliminate the noise caused by wind while recording. Please
install the windshield to the microphone as shown below.
2. Mounting the Mic-E10 Microphone
The Mic-E10 is supplied with a H-25 Mount (5/8” & 3/8” screw accessible) for attaching accessories like
boompole, mic stand.
3. Powering the Mic-E10 Microphone
The Mic-E10 requires 48V DC phantom power or one 1.5V AA battery.
For accessories with 3/8” screw, tighten the accessory with the H-25 mount directly.
For accessories with 5/8” screw, unscrew and remove the 3/8” thread and connect with the accessory
via 5/8” screw.
For devices WITH 48V phantom power like audio mixer, connect the Mic-E10 with your devices via XLR
audio cable (not included) and power the microphone with the device.
(Note: Please do not install battery in the battery plate when using phantom power. Connect all cables
before supplying phantom power to the microphone and never remove the microphone cable while
the power is connected.)
Place the microphone into the mount with the ON/OFF switch facing upwards as shown below. Make
sure the mount rmly secure the microphone in place.
For devices WITHOUT 48V phantom power like DSLR, camera and camcorder, please use a 1.5V AA
battery to power the microphone. Install the battery in the battery plate as shown below. Then connect
the microphone with your devices via XLRM to 3.5mm Cable or XLR audio cable.
(Note: XLRM to 3.5mm Cable (included) is for devices with 3.5mm jack, like DSLR and camera. The
devices with XLR connector require XLR audio cable but not included.)
Slide the ON/OFF switch to ON side to turn on the microphone.
Operations
5/8” screw 3/8” screw
①
①
②
②
③
Warranty does not apply to human errors.
5www.syncoaudio.com www.syncoaudio.com 6
1. Polar Pattern: Cardioid
Specications
Transducer
Polar Pattern
Frequency Response
Built-in Bass
Signal/Noise
Sensitivity 48V/1.5V
Output Impedance 48V/1.5V
Max.Input SPL 48V/1.5V
Dynamic Range 48V/1.5V
Power Supply
Output Interface
Dimensions
Net Weight
Back Electret Condenser
Cardioid
50Hz-18000Hz
180Hz 12dB
75 dB 1kHz at 1Pa
- 35dB±2dB(0dB=1V/Pa at 1KHz)
250Ω±30%
130 dB SPL / 115 dB SPL
106 dB / 91dB,1 kHz at Max SPL
48V DC, 2mA/1.5V AA/ UM3
XLRM Connector
Φ1.06”×7.87” (27×200mm)
6.4oz/180g
2. Performance Parameter
7www.syncoaudio.com www.syncoaudio.com 8
WARRANTY
Warranty Period
Thank you for purchasing SYNCO products.
1. Customers are entitled to free replacement or repair service in case of quality defect(s) found in the
product under normal use within 30 days upon receipt of the product.
2. Original SYNCO products are entitled to 12-month limited warranty service. The warranty period begins
on the date of purchase of brand new, unused products by the rst end-user.
Within the warranty period, if product defect or failure is attributable to material defection or
technological problem, the defective product or defective part will be repaired or replaced without charge
(service and materials fee).
Warranty Exclusions and Limitations
Faults resulted from inappropriate use of a product without following its operation specication
Articial damage, e.g. crash, squeeze, scratch, or soaking
Modications to a product by its user or a third party without prior written consent of SYNCO, e.g.
replacement of element or circuit, label alteration
The code on product is inconsistent with that of warranty certicate, or the code on the product or
warranty certicate is altered or torn o
All consumable accessory attached to a product, like cable, wind mu, battery
Faults as a result of force majeure, such as re, ood, lightning, etc.
Warranty Claim Procedure
If failure or any problem occurs to your product after purchase, please contact a local agent for
assistance, or you can always contact SYNCO’s customer service through email at
support@syncoaudio.com.
Please retain your sales receipt and warranty certicate as proof of purchase. If any of these documents
is missing, only sales return or chargeable service will be provided.
If the SYNCO product is out of the warranty coverage, the service and the parts cost will be charged.
9www.syncoaudio.com
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us via Email：
support@syncoaudio.com
Customer Name:
Phone Number:
Email:
Address:
Sales Date:
Model:
Product Code:
Dealer:
Service Date:
Technician:
Issue:
Solved Unsolved Returned(Replaced)
