Tally T9312 Bedienungsanleitung

T9312

Maintenance manual Laser printer

Exploded Views and Parts List

5-2

5-1 Main Exploded View

12-1

Location No. Description Code Q'ty

1 ELA HOU-HOUSING T9312C 398 471 1

2 UNIT-LSU 398 425 1

3 ELA UNIT-MOTOR 398 464 1

4 ELA UNIT-DEVE ASSY 1

5 MEC RACK-MPF 1

6 MEA RACK-FEEDER CST 398 473 1

7 CBF-HARNESS-MOTOR 1

8 MEA UNIT-FEEDER 398 427 1

9 PMO-CAP SENSOR 1

10 SHIELD-PCU 1

11 PCT-INSULATOR PCU 1

12 PBA MAIN-ENGINE_V2 398 432 1

12-1 FUSE-CARTRIDGE 396 403 1

13 ELA UNIT-FRAME BASE 398 433 1

14 PBA MAIN CTRL-LOW 398 470 1

15 ELA UNIT-FUSER 398 472 1

16 CBF HARNESS-LSU 1

17 PBA PWR-HVPS_HAWK 398 495 1

18 MEA RACK-HOU EXIT 398 496 1

19 PMO-DUCT FAN 1

20 PMO-DUMMY FACE MAIN(L) 1

21 PMO-DUMMY FACE MAIN(R) 1

5-3

Exploded Views and Parts List

Main Parts List

Exploded Views and Parts List

5-4

5-2 Cover Exploded View

16 4

13 15

3-1

3-3

3-2

3-4

3-5

3-6

5-5

Exploded Views and Parts List

Cover Parts List

Location No. Description Code Q'ty

0 ELA HOU-COVER MAIN (T9312) 398 471 1

1 PMO-COVER OPEN 1

2 PMO-COVER MAIN 1

3 MEA UNIT-MP TRAY 398 438 1

3-1 PMO-COVER-MP 1

3-2 PMO-TRAY LINK MP 2

3-3 PMO-TRAY EXTENSION MP 1

3-4 PMO-TRAY HOLDER MP 1

3-5 IPR-GUIDE LATCH 1

3-6 PMO-SIDE GUIDE MP 1

4 STOPPER HINGE OPEN 2

5 PMO-LENS LED 1

6 PMO-KEY BUTTON 1

7 PMO-KEY SAVE MODE 1

8 PBA LED PANEL-II 399 454 1

9 PMO-GUIDE EXIT 1

10 PMO-BUSHING F/DOWN 1

11 PMO-COVER REAR 398 439 1

12 PMO-STACKER REAR 398 440 1

13 IPR-SPRING LOCKER REAR 398 441 2

14 PMO-COVER CONTROLLER 398 442 1

15 PMO-CAP REAR 398 443 1

16 PMO-SUPPONT MAIN 1

17 PMO-STOPPER_EXIT,P 1

S1 SCREW-TAPTITE 7

Exploded Views and Parts List

5-6

5-3 Frame Exploded View

29-4

29-1

29-2

29-3

25-1

25-2

24-2

24-1

22-1

22-3

22-2

22-4

14 13

16-1

16-2

16-3

16-4

19-2

18-218-1

19-1

15-1

15-2

15-3

30-3

30-2

30-1

31-2

31-3

31-1

32-1

32-2

28-1

28-2

5-7

Exploded Views and Parts List

Frame Parts List

Location No. Description Code Q'ty

0 ELA UNIT-FRAME BASE 1

1 FAN-DC-HAWK 398 444 1

2 PMO-GUIDE RIB 1

3 CBF HARNESS-INLET ASS'Y 1

4 PMO-HOLDER WIRE 1

5 PMO-KEY DEVE HAWK 1

6 CBF HARNESS-ENGINE_CONTROL 1

7 CBF-HARNESS_FUSER 1

8 PBA SUB-EXIT SENSOR 398 445 1

9 CBF-HARNESS-THERMISTOR JOINT 1

11 PBA SUB-FUSER_SW 398 446 1

13 PMO-FRAME COVER 1

14 IPR-TERMINAL FU 2

15 ELA-UNIT-HOLDER TR L 398 447 1

15-1 PMO-BUSHING TR 1

15-2 SPRING TR L HAWK 1

15-3 PMO-TRANSFER HOLDER L 1

16 ELA-UNIT-HOLDER TR R 398 448 1

16-1 PMO-BUSHING TR 1

16-2 SPRING TR R HAWK 1

16-3 PMO-TRANSFER HOLDER R 1

16-4 IPR-PLATE TR 1

17 GEAR-TR 29 398 449 1

18 ELA UNIT-GUIDE DEVE L 398 450 1

18-1 PMO-GUIDE DEVE L 1

18-2 SPRING GUIDE DEVE 1

19 ELA UNIT-GUIDE DEVE R 398 451 1

19-1 PMO-GUIDE DEVE R 1

19-2 SPRING GUIDE DEVE 1

20 ELA HOU-VARISTOR 1

Exploded Views and Parts List

5-8

Frame Parts Lists

Location No. Description Code Q'ty

21 IPR-TERMINAL TR HAWK 1

22 ELA UNIT-SENSOR DEVE 1

22-1 PBA -SUB SWITCH 398 452 1

22-2 PMO-HOLDER ACTUATOR 1

22-3 PMO-ACTUATOR DEVE 1

23 GROUND FU 1

24 ELA UNIT-TERMINAL TR L 399 455 3

24-1 ICT-SHAFT HV LARGE 3

24-2 SPRING-HV LARGE 3

25 ELA UNIT-TERMINAL TR S 399 456 1

25-1 ICT-SHAFT HV LARGE 1

25-2 SPRING-HV SMALL 1

26 GROUND-HVPS 1

27 IPR-REMOVE KEY XEROX 1

28 ELA UNIT-ACTUATOR FEED 399 457 1

28-1 PMO-ACTUATOR FEED 2

28-2 PMO-HOLDER ACTUATOR 2

29 ELA UNIT-GUIDE TRANSFER 1

29-1 PMO-HADER PLATE SAW 1

29-2 IPR-PLATE SAW 1

29-3 IPR-GUIDE TRANSFER HAWK 1

29-4 PMO-GUIDE RIB TR 1

30 ELA UNIT-GUIDE FEED 398 453 1

30-1 PMO-GUIDE OPTIC 1

30-2 GUIDE FEED 1

30-3 PMO-HOLDER G/PAPER 1

31 ELA UNIT-PTL 398 454 1

31-1 GUIDE PLATE FEED 1

31-2 PMO-HOLDER PTL 1

31-3 PBA SUB-PTL 1

5-9

Exploded Views and Parts List

Location No. Description Code Q'ty

32 ELA UNIT-EMPTY ACT 399 458 1

32-1 PMO-ACTUATOR EMPTY HAWK 1

32-2 SPRING EMPTY 1

33 PMO-HINGE GUIDE FEED 1

34 IPR-GND ICU 2 1

35 PMO-CAP SENSOR 399 459 1

36 GND MP 1

38 GROUND MOTOR 1

39 IPR-GUIDE_DUST 1

41 IPR-OPC HAWK 1

42 CAP CONNECTOR L 1

43 CAP CONNECTOR U 1

44 MEC-ROLLER TRANSFER 398 455 1

45 GEAR-IDLE27 398 467 2

46 RING-CS 2

47 WASHER-PLAIN 2

48 IPR-WASHER SPRING SU 1

Frame Parts Lists

Exploded Views and Parts List

5-10

5-4 Exit Exploded View
