EFX-1

Bi-pole/Di-pole

Surround Loudspeaker

Operator Manual

Tannoy North America Inc.

335 Gage Ave., Suite #1 Kitchener, Ontario Canada N2M 5E1

Tel:(519)745-1158 Fax:(519)745-2364 Toll Free Dealer Faxline:(800)525-7081

e-mail: [email protected]

www.tannoy.com

Important Note: To obtain best results from this Tannoy product, please be sure to read this

manual carefully before installation.

Introduction

Congratulations on your purchase of Tannoy EFX-1 Bi-pole/Di-pole surround loudspeakers. This

product has been developed to compliment Tannoy loudspeakers and a wide range of other home

theater systems. It offers the flexibility of side or rear wall mounting with the option of bi-pole or di-

pole output characteristics. When included in your home theater loudspeaker system the EFX-1 will

add unprecedented spaciousness to movie soundtracks, while maintaining true left and right channel

separation.

Features

* Separate midrange and bass enclosures to minimize coloration

* 2 x soft dome ferrofluid-cooled treble units

* 2 x polypropylene midrange units

* 1 x polypropylene bass unit

* Bi-pole or di-pole system output options

* Treble frequencies can be selected as bi-pole or di-pole independently

* Midrange frequencies can be selected as bi-pole or di-pole independently

* Side or rear wall mounting

* Compact design

* Simple mounting system

* Paintable to match your rooms decor.

Description

The EFX-1 is a wall-mount surround loudspeaker for home theater applications. It offers the choice

of bi-pole or di-pole operation, which can be changed at the flick of a switch. In addition to the

conventional choices of bi-pole or dipole operation, the EFX-1 can operate with the treble units in

dipole mode and the midrange units in bi-pole mode or vice versa. This gives unusual flexibility in

choosing the optimum spacial effects characteristics for home theater surround-channel set-up. We

do recommend that either full bi-pole or di-pole modes be used in most circumstances.

The system uses a carefully designed sealed trapezoidal cabinet and incorporates two three

quarter-inch soft dome treble units, two three-inch midrange units and a five-inch bass unit (fig.1).

The midrange units use separate internal enclosures from the bass unit to minimize coloration.

Connection is by means of five-way binding posts on the rear of the cabinet (fig.2).

(fig.1) (fig.2)

Installation

The unit is installed using the familiar “keyhole” mounts on the rear of the cabinet (fig.3). The

enclosed mounting template should be used for defining relative mounting bolt locations once final

cabinet positioning has been decided. Be sure to keep the template level horizontally. Once in the

correct position mark the center of each hole with a pen or nail. Remove the self adhesive template

and re-apply it to the adjacent wall once again being sure to stay level. You can re-apply the self

adhesive lable several times if required.

(fig.3)

The EFX-1 must be mounted so that the midrange

and treble units are at the sides of the bass unit

and not above and below the bass units (fig.4).

The grille cover should be removed to confirm

proper cabinet orientation.

Alternatively, the EFX-1 may be mounted on small shelves symmetrically placed along the chosen

wall. The same care should be taken in ensuring that the shelf is suitable for the weight and

dimensions of the EFX-1.

The ideal location for the EFX-1 is symmetrically along the side walls slightly behind the main

seating area. If this location is not available, the EFX-1 can be mounted symmetrically along the

rear wall at approximately the outer edges of

the main listening area. Care should be taken

to avoid corners whenever possible (fig.5).

Corner mounting is not recommended.

Height from the floor should be around

two-thirds of the way up the wall, using the

same height for both left rear and right rear

units (fig.6).

Please remember that symmetrical placement

means predictable and complementary left and

right performance. This is true for all

loudspeakers in a room. Once the location of

the units has been decided and a secure

mounting method implemented, the EFX-1 may

be carefully lifted off the wall at any time to

facilitate connection.

Couch

Center Right

Left

Suggested side wall location

Suggested

rear wall

location

Top View Speaker Placement

(fig.5)

(fig.6)

(fig.4)

Ensure that the wall fastening is

designed to accept the weight of the

EFX-1 system.

Failure to do so will result in the

EFX-1 becoming detached from

the wall, with the possibility of

serious injury to the installer or

other persons.

Setting up the controls

The EFX-1 gives unique flexibility in surround effects options. The following describes operation fea-

tures of the EFX-1. We encourage you to experiment with the available controls to find the option

that suits your environment and taste. However, do remember that you should choose the same set-

tings for both the right rear effects and left rear effects channels.

Bi-pole: With all switches set in the bi-pole mode (all switches to the left, fig.7) all the speaker

units will operate in-phase with one another (they all push air together or pull air together). The drive

unit arrangement on the EFX-1 ensures a broad and expansive sound field in this mode.

Di-pole: With all switches set in the di-pole mode (all switches to the right, fig.8) the drive units

on the two sides are out-of-phase with one another (one side pushes while the other side pulls). An

even more expansive sound field can be obtained in this mode.

EFX-1 Options: You may wish to experiment further by setting the high frequencies in the di-pole

mode with the midrange frequencies in the bi-pole mode, or vice versa. Choose the same settings

for both loudspeakers.

(fig.7)

(fig.8)

Limited Warranty

The Tannoy EFX-1 is warranted against failures due to defective parts or faulty workmanship for a

period of five years after delivery to the original owner. During this period, Tannoy will make any

necessary repairs without charge for parts or labor. The owner must prepay shipping charges to the

TGI repair facility, or an authorized Tannoy repair station. Return shipping charges (via UPS Ground)

will be paid by TGI.

This warranty applies only to the original owner and is not transferable. It does not apply to repairs

done other than by the TGI repair facility or an authorized Tannoy Repair Station. This warranty may

be cancelled by Tannoy at its sole discretion if the EFX-1 has been subjected to physical abuse or

has been modified in any way without written authorization from TGI. TGI’s liability under this

warranty is limited to repair or replacement of the defective unit.

Tannoy will not be responsible for incidental or consequential damages resulting from the use or

misuse of its products. Some states and provinces do not allow the exclusion of incidental or

consequential damages, so the above limitations may not apply to you. This warranty gives you

specific legal rights, and you may also have other rights, which vary from state to state and province

to province. A copy of the original purchase invoice showing the purchase date must accompany

warranty claims.

Please be very careful to observe correct polarity (the + wire to the + terminal (“red”), the – wire to

the – terminal (“black”)) when making connections (fig.2).

Service

Before returning any equipment for repair, please be sure that it is adequately packaged against

damage in shipment, and that it is insured for the full retail value of the unit. We suggest that you

save the original packaging and use it to ship the product for servicing. Also, please enclose a note

giving your name, address, telephone number and a description of the problem.

NOTE: All equipment being returned for repair must have a Return Authorization (RA) number. To

get an RA Number, please call the Tannoy North America office between 9 a.m. and 5 p.m. EST, at

519.745.1158. Tannoy North America’s shipping address is 335 Gage Avenue, Suite 1, Kitchener,

Ontario, Canada N2M 5E1. Please display your RA Number prominently on all packages.

Specifications

Frequency Response: 80 Hz – 20 kHz typical in-room

Power Handling: 100 Watts program

Sensitivity: 87 dB 1 Watt input @ 1 Meter anechoic

90 dB 1 Watt input @ 1 Meter typical in-room

Impedance: 6 Ohms nominal

Weight: 13 lbs - 6kg Each

Dimensions: 13” w x d 61/2” d x 10” h - w 33cm x d 16cm x h 25cm

Drive Unit Complement

Bass Unit: 1 x 5” - 120 mm polypropylene drive unit

Midrange unit: 2 x 3” - 75 mm polypropylene drive units

Treble unit: 3/4” - 19 mm woven fabric soft dome treble units with ferrofluid

cooling

Tannoy North America Inc.

335 Gage Ave., Suite #1 Kitchener, Ontario Canada N2M 5E1

Tel:(519)745-1158 Fax:(519)745-2364 Toll Free Dealer Faxline:(800)525-7081

e-mail: [email protected]

www.tannoy.com
