Targus DEFCON CL Bedienungsanleitung

NOTEBOOK SECURITY

DEFCON®CL

LAPTOP CABLE LOCK

410-1862-206B / PA410B(AP)

1 YEAR LIMITED WARRANTY: We pride ourselves

on the quality of our products. For complete warranty

details and a list of our worldwide offices, please

visit www.targus.com. Features and specifications

are subject to change without notice. All trademarks

and registered trademarks are the property of their

Inc. Manufacturer/Importer: Targus Asia Pacific Ltd.,

Unit 1202-07, 12/F, Tower 2, Metroplaza, No. 223 Hing

Fong Road, Kwai Fong, N.T., Hong Kong User Guide

用戶指南 / 用户指南 / 説明書 / 사용자 가이드

Targus Notebook Security DEFCON®CL Laptop Cable Lock

Thank you for purchasing the Targus Notebook Security DEFCON®

CL Laptop Cable Lock. The DEFCON®CL helps protect your

valuable notebook computer from theft using a resettable four-

digit combination lock. The resettable combination lock eliminates

the need for keys and enables you to change your combination

periodically for increased security.

Introduction

In addition to this user’s guide, this package contains:

• DEFCON®CL Laptop Cable Lock

• DEFCON®SecureSpacers

• DEFCON®Security Base Plate

WARNING: TO USE THE DEFCON CL OR RESET THE COMBINATION YOU MUST SET THE

LOCK TO THE CURRENT COMBINATION.

Table of Contents

English ........................................................................................ 3

繁體中文 ................................................................................. 15

中文简体字 ........................................................................... 27

日本語 ..........................................................................................39

한국어 ....................................................................................... 51

Targus Notebook Security DEFCON®CL Laptop Cable Lock

Setting the Combination

2 Using the dials, enter the current combination. If you are setting the

combination for the first time, enter the preset combination 0000. The

combination appears in the windows.

3 Using a small flat-head screwdriver or similar object, push in and rotate

the reset screw 90 degrees clockwise so that the screw’s groove appears

horizontal.

6 Record the combination in either the space provided at the end of this

guide or another secure, easy-to-find place.

4 Using the dials, enter the new combination.

5 Rotate the reset screw 90 degrees counterclockwise, back to its original

vertical position, to save the new combination.

Locking button

Combination dials

Reset screw

Combination windows

DEFCON CL

Unlocking the combination lock

Locking the combination lock

Testing the Combination

Before attaching the lock to your notebook computer:

1 Turn the dials to disguise the combination.

2 Return to the combination you set.

3 Check that the locking button depresses completely.

1 Locate the combination dials and windows on the lock.

7. To reset your combination lock, repeat above steps.

Targus Notebook Security DEFCON®CL Laptop Cable Lock

Securing the DEFCON CL

Select an object in the room to which you will secure your notebook computer

with the DEFCON CL. Choose a large, heavy piece of furniture such as a

table or desk, or an immovable fixture such as a closet hanging bar.

1 Take the looped end of the cable and wrap it around the selected object.

NOTE: WRAP THE CABLE AROUND A PART OF THE OBJECT THAT WILL DETER AN

INTRUDER FROM SLIPPING THE CABLE OFF (FOR EXAMPLE, A TABLE OR DESK LEG

WITH A CROSS BAR OR A DRAWER HANDLE).

2 Feed the lock through the looped end of the cable as shown.

Securing the DEFCON CL to an object

Locking the DEFCON CL to your

Notebook Computer

NOTE: HOLD THE DEFCON CL WITH BOTH HANDS FOR ADDITIONAL STABILITY

WHILE INSERTING OR REMOVING THE LOCK.

1 Using the dials, enter the correct combination. The combination appears

in the windows.

Secure Spacer

Locking button

Locking teeth

DEFCON CL

2 Press and hold the locking button to align the locking teeth.

NOTE: FOR THE LOCKING BUTTON TO DEPRESS COMPLETELY YOU MUST ENTER

THE CORRECT COMBINATION.

Targus Notebook Security DEFCON®CL Laptop Cable Lock

NOTE: DUE TO THE VARIATION IN THE SIZE OF THE SECURITY SLOTS ON VARIOUS

NOTEBOOK MODELS, YOU MAY FIND THAT THERE IS SOME SLACK BETWEEN THE

LOCK AND THE COMPUTER. THE SUPPLIED DEFCON SECURESPACERS ARE THE

BEST SOLUTION FOR OPTIMAL FIT AND SECURITY.

3 Insert the DEFCON CL into your notebook computer’s lock slot and

release the locking button.

4 Turn the dials to conceal your combination.

Using the DEFCON

SecureSpacers

1 Insert your DEFCON locking device into the computer’s lock slot.

2 Pull the DEFCON locking device away from the computer and check

whether the gap is excessive.

3 If so, try each of the SecureSpacers to determine which one fits the gap.

The SecureSpacers come in three sizes: 1.6 mm, 0.8 mm, and 0.4 mm.

NOTE: DO NOT REMOVE THE ADHESIVE STRIP FROM ANY OF THE SECURESPACERS

UNTIL YOU DECIDE WHICH ONE TO USE.

4 Once you know which SecureSpacer you are going to use, remove the

locking device from the computer. Then remove the adhesive strip from

the back of the SecureSpacer and attach the spacer to the DEFCON

lock.

Targus Notebook Security DEFCON®CL Laptop Cable Lock

Unlocking the DEFCON CL

WARNING: DO NOT ATTEMPT TO REMOVE THE DEFCON CL WITHOUT USING THE

COMBINATION. TO DO SO WILL PHYSICALLY DAMAGE YOUR NOTEBOOK COM-

PUTER.

1 Using the dials, enter the correct combination. The combination appears

in the windows.

2 Press and hold the locking button to realign the locking teeth.

3 Remove the DEFCON CL from your notebook computer’s lock slot.

DEFCON Security Base Plate

Included with your DEFCON CL Combo Cable Lock is the Security Base

Plate for the security of desktop computers.

Using the DEFCON Security Base

Plate

1 Choose a solid location to attach the DEFCON Security Base Plate: a

piece of furniture, or metal cabinet. If you plan to use the two screws,

you can use the base plate as a template to pre-drill the holes.

2 Use the abrasive pad, then the alcohol wipe to prepare the area when

you will attach the DEFCON Security Base Plate.

3 After the alcohol dries, remove the backing on the base plate to expose the

adhesive and place it on the prepared location. If desired, secure the base

with the two screws.

Targus Notebook Security DEFCON®CL Laptop Cable Lock

Specifications

General

Weight: 6.5 ounces (184.3 g) overall

Locking device

Dimensions: 1.22 x 1.17 x 0.81 inches

(31 x 29.9 x 20.8 mm)

Color: Black Nickel

Cable

Length: 6 feet 5 inches (2.0 m)

Diameter: 0.16 inches (4 mm)

Material: Vinyl coated steel

NOTE: WHEN USING THE ADHESIVE BACKING, APPLY AT ROOM TEMPERATURE

-60°F (16°C), AND ALLOW IT TO BOND FOR MORE THAN 24 HOURS. NOT REC-

OMMEND TO USE IN OUTDOOR OR HIGH HUMIDITY ENVIRONMENT. BONDING TO

GLASS, CERAMIC TILE, WATER-ABSORBENT MATERIALS, COPPER, BRASS, OR

PLASTICIZED VINYL WITHOUT PRIMER SURFACE ARE NOT RECOMMENDED. TAR-

GUS RECOMMENDS USING BOTH ADHESIVE AND SCREW TO PROVIDE MAXIMUM

SECURITY. USING ONLY THE ADHESIVE PROVIDES MARGINAL SECURITY.

4 Place the DEFCON Security Base Plate cover as shown and slide it to the

left or right to secure it in place.

5 Insert your DEFCON cable lock.

Targus Notebook Security DEFCON®CL Laptop Cable Lock

Recording Your Combination

For your convenience, record your combination in the space provided.

When recording the combination, read from top to bottom using the

number closest to the locking button as the starting point.

Targus assumes no responsibility for lost, misplaced or forgotten

combinations.

Top combination

window

Locking

button

Bottom

combination Window

感謝你購買Targus筆記型電腦鋼纜鎖，這款鋼纜鎖，設有一個可

重複設置的4位元數的數位密碼鎖，可以保護你心愛的筆記型電腦

免受盜賊扒竊。這可以為你免去攜帶鑰匙的麻煩，同時也可以讓

你根據實際的安全需要，隨時改變你的開鎖密碼。

筆記本型電腦鋼纜鎖

除了使用手冊以外，包裝中還包括︰

•－鋼纜鎖

•－安全緩衝墊

提醒︰您必須輸入您當前的密碼，才可以使用鋼纜鎖或重設鋼纜鎖的密

碼。

Targus Notebook Security DEFCON®CL Laptop Cable Lock

設置密碼鎖

2.轉動密碼盤，輸入當前的密碼組合；如果你是第一次設置密碼，請輸入預

設的密碼組合0000，密碼將會顯示在密碼窗上

3.用扁口的螺絲刀或者類似工具，順時針轉動重設螺絲90度，使得重設螺絲

的溝槽呈水平狀

鎖鍵

密碼轉盤

重設螺絲

密碼窗

鋼纜鎖

打開數位密碼鎖

1.找到密碼轉盤和密碼窗

6.在說明書相應的地方記下密碼，或者其他任何安全而且又容易尋找的地方

記錄下您的密碼

4.轉動密碼盤，輸入新的密碼組合

5.逆時針轉動重設螺絲90度，使它的溝槽恢復其原來的垂直狀態，這樣便設

置了新的密碼

鎖上密碼鎖

檢查密碼

在把鎖插入你的筆記型電腦前

1.轉動密碼盤到任意的數字

2.轉動密碼盤，回到你所設置的密碼

3.檢查鎖鍵是否可以完全壓到底

7.如果要重設你的密碼，請重複以上步驟

Targus Notebook Security DEFCON®CL Laptop Cable Lock

固定鋼纜鎖

選擇房間裏的一個您將要和筆記型電腦鎖在一起的固定物體建議選擇大而重

的傢俱，如桌子、椅子，或者一些不可移動的裝置，比如壁櫥的把手

1.以鋼纜尾端的環形圈為起端，圍著所選的固定物體環繞一圈；

注意︰將鋼纜繞在一些無法輕易脫卸的物體上（比如桌子或椅子的交

叉腳座，或抽屜的把手）

2.將鋼纜穿過鋼纜的槽柄

用鋼纜鎖固定筆記本型電腦

用鋼纜鎖固定筆記型電腦

注意︰當插入及解鎖時，請雙手握住鋼纜鎖，以增強操作時的穩定

性。

1.轉動密碼盤，輸入正確的密碼組合。相應的密碼組合出現在密碼視窗中

安全緩衝墊

鎖鍵鎖齒

鋼纜鎖

2.按住鎖鍵，讓它和鎖齒等高

注意︰必須輸入正確的密碼組合，鎖鍵才能完全壓到底部
