TC8619
4 Channel
Ethernet-over-T1/E1
Multiplexer
User Manual
MNL-86190-01-01
2 TC8619 Rev 1.1 User Manual
All Rights Reserved
Copyright © 2022 by TC Communications. Products described in this publication are protected
by one or more U.S. and foreign patents.
Trademarks
The TC Communications® logo is a registered trademark.
JumboSwitch® is a registered trademark of TC Communications.
Other product and brand names may be trademarks or registered trademarks of their respective owners
Documentation Disclaimer
This document is provided “as-is” and is to be used only as a general guide. TC Communications disclaims all
warranties, express or implied, regarding the accuracy of the information. TC Communications shall not be liable for
any indirect, special, incidental, or consequential damages (including damages for loss of business, loss of profits,
loss of business information, business interruption or other pecuniary loss) arising out of errors in this document.
The information given in this document is reviewed regularly and any necessary corrections will be included in
subsequent editions. We appreciate any suggested improvements. We reserve the right to make technical
improvements without notice.
Dissemination or reproduction of this document, or evaluation and communication of its contents, is not authorized
except where expressly permitted. Violations are liable for damages. All rights reserved, particularly for the
purposes of patent application or trademark registration. This document contains proprietary information, which is
protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced or
translated to another language without the prior written consent of TC Communications.
Record of Revisions
Revision Date Description of Changes
1.1 07/07/2022 Initial Release of TC8619.
TC Communications
17881 Cartwright Road
Irvine, California U.S.A. 92614
Tel. (949) 852-1972
Fax (949) 852-1948
E-Mail: [email protected]
Website: tccomm.com
TC8619 Rev 1.1 User Manual 3
Guide to Alert Symbols
These alert symbols are used in Caution, Warning, and Danger notes.
Symbol Meaning
Pinching or crushing hazard
Electrical hazard.
Equipment alert: be careful of
damage from static electricity
General alert: used for all
other hazardous conditions
(referring to people, not
equipment).
TABLE OF CONTENTS
TOC-1 TC8619 Rev 1.1User Manual
1Introduction
1.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2.2 Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2 Installation
2.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.3 Equipment Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.4 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.5 Dry Contact Alarm Relay (DCAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.6 System Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.7 System Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.7.1 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.7.2 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
3 Quick Start Guide
3.1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
4 Tutorial
4.1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Latched Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2.1 Latched Alarm Clearing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.3 T1/E1 Local Loopback Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
5 Troubleshooting
5.1 General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 All LEDs are OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.3 Alarm LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Appendix A 19” Rack Mount Card Cage
A.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.3 Chassis Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Appendix B Push Button & LED Functions
B.1 CLEAR ERROR Button Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.1.1 CLEAR ERROR Push Button Functions. . . . . . . . . . . . . . . . . . . . . . B-1
B.2 LED Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.3 CSU Loop Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
Appendix C Return Policy
C.1 Return Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
C.1.1 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
C.1.2 Limitation of Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
TC8619 Rev 1.1User Manual 1-1
Chapter 1 Introduction
1.1 General Information
This manual is intended to describe the features and functionality in addition to
aiding in the planning, configuring, commissioning and maintaining of the TC8619
Ethernet-over-T1/E1 multiplexer.
1.2 Product Description
The TC8619 is a 4 Channel Ethernet-over-T1/E1 multiplexer with built-in power
redundancy.
TC8619 can support either T1 or E1 upon the order.
Extensive diagnostics include DIP switches for T1/E1 Loopback and other
application configuration switches. Each unit also provides multiple LEDs for
Alarm, Power, Vcc, T1/E1 Status, and Link and Duplex LEDs for each channel.
The built-in sync mechanism verifies both device and T1/E1 link operation. No
other test equipment is required for link and device verification.
The TC8619 is compatible with standard 100ΩT1 for copper line lengths up to
6000ft and up to 2.5km for 75Ω/ 120ΩE1 (copper line length is the distance
between the TC8619 and the T1/E1 cross-connect). The T1/E1 uses an RJ-48
connector and the Ethernet channels use RJ-48 connectors. Optional BNC adapter
cable is available for 75 Ohm E1. Power is 12VDC standard or optional 24VDC,
-48VDC, 125VDC, or 115/230VAC with an external power cube. Optionally, a high
temperature version (-20°C to 70°C) and extreme temperature version (-40°C to
80°C) are also available.
*Note: Check factory for availability
Chapter 1 Introduction Product Description
1-2 TC8619 Rev 1.1User Manual
Figure 1-1 TC8619 Front and Rear Panels
1.2.1 Features
• 10/100 Base-T Ethernet with IEEE 802.1p support
• T1 Features:
• ESF Framing
• Supports Line Length up to 3000ft (T1)*
• E1 Features:
• PCM31C Framing
• Supports Line Length up to 2.5km
• Very Low Latency ~ 600μs
• LEDs for Link (L) and Duplex (D) (to monitor Ethernet status)
• LEDs for "SYNC", "AMI", "BPV", "LOS", "AIS", "RAI", "CRC" (to monitor
each T1/E1 channel status)
• LEDs for "PWR A," "PWR B," "Vcc," & "ALM" (to monitor each unit's
power supply and alarm condition status)
• Built-in Power Redundancy
• Diagnostic DIP Switches for T1/E1 Loopback test.
• Rack Mount or Stand Alone
*Note: For line lengths beyond 655ft additional testing is required.
1.2.2 Applications
The TC8619 offers an inexpensive, plug and play method for connecting Ethernet
devices over existing T1/E1 links. Popular applications include:
Chapter 1 Introduction Product Description
TC8619 Rev 1.1User Manual 1-3
• Bridging Ethernet LANs over Existing T1/E1 Telecom Network
• Extending Ethernet Networks by Utilizing TDM Telecom Infrastructure (i.e.
T1/E1 Landline, or T1/E1s/PDH/SDH Microwave Carrying T1/E1)
• Demarcation Between the Carrier’s and Customer’s Networks
• Bonded Transparent LAN Service
Figure 1-2 Typical Application using TC8619 Ethernet-over-T1/E1
Multiplexer
T1/E1
Ethernet
TC8619
IP Based
Voter
TC8619
IP Based
Repeater/Receiver
Ethernet
Chapter 1 Introduction Specifications
1-4 TC8619 Rev 1.1User Manual
1.3 Specifications
Ethernet Capacity
Channels 4 ports - 10/100 Base-T Ethernet Channels
Electrical
Ethernet Connectors RJ-48F
T1/E1 Connector RJ-48F
System
Bit Error Rate 1 in 109or better
Unit Status Indicators PWR A, PWR B, Vcc
T1/E1 Status Indicators ALARM, SYNC, AMI, BPV, LOS, AIS, RAI,
CRC, RMT
Ethernet Status Indicators Link (L) and Duplex (D)
Diagnostic Functions T1/E1 Loopback
Power Source
Standard 12VDC @300mA
Optional 24VDC, -48VDC, 125VDC, or 115/230VAC
with an external power cube
Temperature
Operating -10°C to 50°C
Optional Hi-Temp Version -20°C to 70°C
Optional Extreme-Temp Version -40°C to 80°C
Storage -40°C to 90°C
Humidity 95% non-condensing
Chapter 1 Introduction Specifications
TC8619 Rev 1.1User Manual 1-5
Physical (Standalone Unit)
Height (3.53 cm) 1.40"
Width (18.14 cm) 7.20"
Depth (24.89 cm) 9.80"
Weight (0.9 Kg) 2.0 lbs.
Physical (Rack mount 1U “Pizza Box” with two cards)
Height (4.45 cm) 1.75"
Width (48.26 cm) 19.0"
Depth (22.86 cm) 9.0"
Weight (1.86 Kg) 4.1 lbs.
TC8619 Rev 1.1User Manual 2-1
Chapter 2 Installation
2.1 General Information
The installation section describes how to:
• Unpack the unit
• Ensure an optimum site location
• Install the power supply and dry contact connection
2.2 Unpacking
Before unpacking any equipment:
• Inspect all shipping containers for evidence of external damage caused during
transportation
• Inspect for damage after it is removed from the containers
2.3 Equipment Location
The TC8619 should be located in an area that provides adequate light, work space
and ventilation.
IMPORTANT Any claims concerning shipping damage should be made directly to
the pertinent shipping agencies. Any discrepancies should be
reported immediately to the Customer Service Department at TC
Communications, Inc. at (949) 852-1973.
Important Avoid locating it next to any equipment that may produce electrical
interference or strong magnetic fields, such as elevator shafts or
heavy duty power supplies.
As with any electronic equipment, keep the unit from excessive
moisture, heat, vibration and freezing temperatures.
