TC Electronic D-TWO Bedienungsanleitung

ENGLISH - GERMAN - SPANISH - ITALIAN - FRENCH - JAPANESE

For complete manuals in German, Spanish, Italian and French please download from our website at:

www.tcelectronic.com

D•TWO

MULTITAP RHYTHM DELAY

TC ELECTRONIC

QUICK GUIDE TO THE

QUICK GUIDE

POWER button

Power on/off.

IN LEVEL knob

Adjusts the Input level.

MIX knob

Adjusts the global mix between

dry and wet signal. Fully clock-

wise position is 100% effect.

IN meters

The IN peak meter shows the

Input level of left and right chan-

nels.

The meter range is:

0, -3, -6 ,-12, -18, -24, -40dB.

OVERLOAD LEDS

The OVERLOAD LEDs indicate

one of two situations:

- The Input level is too hot and

therefore overloading.

- There is an internal DSP

overflow.

The Overload LED is lit when

1 sample is @ 0dBFS.

DELAY TIME indicator

The DELAY TIME indicator can

display Delay time in either

ms (milliseconds) or BPM

(Beats Per Minute). This is

selected in Setup. The ms or

the BPM icon next to the Delay

time will be lit accordingly.

The tempo is also indicated via

the blinking TEMPO /RHYTHM

indicator.

SUBDIVISION indicator

The selected subdivision

determines the recalculation of

the tapped tempo. Example:

At 120BPM you tap 1/4 notes.

The tapped time equals 500ms.

If the Subdivision is set to 1/8,

the D-TWO now recalculates

the Delay time to 250ms.

DYNAMIC meter

Indicates the gain reduction on

the Delay Output when using

the Dynamic Delay algorithm.

EDITED icon

This icon will be lit as soon as

the current recalled preset has

been modified.

FACTORY/USER icon

Shows whether you are

operating in the Factory or the

User bank.

MIDI IN icon

Indicates the presence of

incoming MIDI information.

SAMPLE RATE indicator

The SAMPLE RATE indicator

shows the clock source and the

incoming master clock.

The icons 44.1 and 48kHz will

be blinking if no clock or

unacceptable clock is found.

FEEDBACK %

The amount of level fed back to

the delay line.

FEEDBACK #

The number of repeats

allowed.

FB FILTER LEDS

Indicates the Feedback High

and Low Cut filter setting.

FILTER LEDS

Indicates the overall High and

Low Cut filter setting.

PING PONG LEDS

Indicates the panning carried

out.

Revision 1 - SW 1.01

Prod. No: E60500401

QUICK GUIDE

DELAY/TAP key

This key has two functions.

- When the DELAY key LED is

lit, the DELAY wheel changes

the Delay time when dialed.

- When the key is tapped the

D•TWO measures the time

between the last two taps and

the Delay time is calculated

according to the selected

subdivision.

FEEDBACK/RHYTHM key

This key has three functions.

- When the LED is lit the

DELAY wheel is changing

the Feedback level or %.

- When the key is pressed and

held, the DELAY wheel changes

the number of repeats.

- Tap a rhythm pattern of up to

10 taps.

DELAY & FEEDBACK wheel

Sets the Delay time or Feedback

depending on what is selected.

SPATIAL key

Enables/disables the Spatial

function. Double click shortcuts to

the Spatial parameters.

Options are:

- Left channel offset +/-200ms.

- Phase reverse any channel.

RECALL key

Selects the Recall menu.

SETUP key

Enters the Setup menu.

This is where all I/O and

global parameters are located.

STORE key

Selects the Store menu. Presets can

be stored in the User bank only.

Location is selected using the

CONTROL wheel. Operation is

confirmed using ENTER.

CURSOR UP/DOWN keys

Are used to move the cursor around

in the display.

CONTROL wheel

Is used to change values.

ENTER key

Confirms operations.

BYPASS key

Bypasses the unit. There are three

different Bypass modes.

1 Mix 0%: Signal is bypassed

directly to the Output.

2 Fx Input: Input bypass letting the

effects ring out.

3 Fx Output: Kills the effect but

keeps the direct signal level.

The Bypass mode is selected in

the Setup menu.

FILTER key

Enables/disables the Filter

functions. Double click shortcuts

to the Hi and Lo cut filter

parameters.

CHORUS key

Enables/disables the Chorus.

Double click shortcuts to the

Chorus parameters.

REVERSE key

Enables/disables the Reverse

Delay. Double click shortcuts to

the Reverse Delay parameters.

DYNAMIC key

Enables/disables the Dynamic

Delay. Double click shortcuts to

the Dynamic Delay parameters.

PING PONG key

Enables/disables the Ping pong

functions. Double click shortcuts

to the Ping Pong parameters.

EDIT key

Enters the general Edit list. This

is where all preset processing

parameters are located. Use the

CURSOR keys to select parame-

ters.

QUICK GUIDE

Setting up the D•TWO

MIXER

STEREO R

RETURNSSEND

DTWO

MULTITAPRHYTHMDELAY

TWOD

Mode selection

The D•TWO has two operating modes: Regular and Rhythm.

Regular mode

The D•TWO default mode and what you use for standard delay

applications.

Rhythm mode

A unique feature allowing you to tap a specific rhythm of your

choice. The D•TWO automatically enters the Rhythm mode

when FEEDBACK/RHYTHM is tapped.

Connect the D•TWO as illustrated using balanced 1/4” jack cables.

MIXER

RETURNSSEND

DTWO

MULTITAPRHYTHMDELAY

TWOD
