TC Electronic TouchMonitor TM7 Bedienungsanleitung

TM7/TM9

TouchMonitor

USER‘S MANUAL

Platform engineered and designed by in Germany

EN-2 Manual TouchMonitor TM7/TM9

User‘s Manual

for

TC TouchMonitor TM7/TM9

Manual Version: 2.0

Issued: 15.09.2011

Software-Version:2-nn (09.2011)

TC Electronic A/S, Sindalsvej 34, DK-8240 Risskov, Denmark,

www.tcelectronic.com, [email protected]

RTW GmbH & Co.KG, Elbeallee 19, 50765 Köln, Germany,

www.rtw.de, rtw@rtw.de

WEEE Reg.-no.: DE 90666819

Category: 9

Device type: These instruments comply with and fall under

category 9 Monitoring and control equipment of

Annex 1B of the RoHS-Directive 2002/95/EC.



Please note:

The gures in this operating manual are carefully created and

are used to illustrate the descriptions. However, they may differ

a little bit from the displays of your unit.

This manual and the available rmware/rmware updates can

be found on our web site:

http://www.tcelectronic.com/touchmonitor-support.asp.

The package contains a USB ash device soruce by a third

party company. The device is certied by Shenzhen BSE Tech-

nology Co., Ltd. to be CE conform (E07002566) and RoHS

compliant (R0808179).

EN-3Manual | TouchMonitor TM7/TM9 Safety Instructions

Safety Instructions

The following symbols may be marked on the panels or covers of

equipment or module and are used in this manuals with these terms:

WARNING!

This symbol alerts you to a potentially hazardous condition, such as

the presence of dangerous voltage that could pose a risk of electrical

shock. Refer to the accompanying Warning Label or Tag, and exercise

extreme caution.

ATTENTION!

This symbol alerts you to important operating considerations or a po-

tential operating condition that could damage equipment. If you see

this marked on equipment, consult the Operating manual for precauti-

onary instructions.

NOTE

This symbol points your attention to speciﬁc characteristics that are

no malfunctions.

General Safety Instructions

• Studycarefullyandunderstandallsafetyandoperatinginstruc-

tions before you install and operate the unit!

• Heedallwarningsontheunitandinthesafetyandoperatinginst-

ructions before you install and operate the unit!

• Alwaysfollowtheseinstructionstoensureagainstinjurytoyour-

selfanddamagetotheunitorotherobjectsconnectedtotheunit.

• Keepallsafetyandoperatinginstructionsforfuturereference!

Topreventpossibleelectricalshock,death,re,injuriesandmalfunc-

tions, use this product only as speciﬁed.

The units of the TouchMonitor series are designed for indoor use only

and may only be operated with a power supply unit provided for it.

Safety InstructionsEN-4 Manual | TouchMonitor TM7/TM9

WARNING!

Alwaysfollowthesafetyprecautionsbelowtoavoidthepossibilityofseriousinjuryorevendeathfromelectricalshock,short-circuiting,dama-

ges, ﬁre, or other hazards. These precautions include, but are not limited to, the following:

• Avoidexposedcircuitry.Donottouchexposedconnectionsand

components when power is present.

• Powerdisconnect.Thepowercordoftheexternalpowersupply

disconnectstheproductfromthepowersource.Donotblockthe

power cord or power supply; it must remain accessible to the user

at any time.

• Turnoffanddisconnectthepowersupplyimmediatelyittheunit

produces unusual smells, noises or smoke, or if foreign substan-

ces(e.g.liquids)orforeignobjectsentertheunit.

• Donotcovertheunitanddonotplaceanyobjectsoranything

containing liquids on it.

• Donotinsertyourngersoranyotherobjectsintothehousing.

• Donotoperatewithoutcoverplatesorpanels.

• Donotoperatewithsuspectedfailures.Ifyoususpectthereisda-

mage to the unit, have it inspected by qualiﬁed service personnel.

• Donotoperateinwet/dampconditions.

• Donotoperateinexplosiveatmosphere.

• Donotoperateindustyenvironments.

• Donotopenthehousing.Inside,therearenouser-serviceable

parts.Anynecessaryservicingshallbeperformedbyaproperly

qualiﬁed technician.

• Donotattempttorepairanypartoftheunit.Repairsshallonlybe

carried out by qualiﬁed personnel.

• Neverremoveanypartsfromtheunitanddonotmakeanymodi-

ﬁcations to the unit without the express written consent of RTW.

Modiﬁcations can cause both safety hazards and affect the unit’s

EMI-CE conformity.

• Onlyusethepowercordandpowersupplyspeciedforthispro-

duct and certiﬁed for the country of use.

• Connectanddisconnectproperly.Useonlyconnectorsspecied

for this product and ﬁx them tight before use.

• Observeallterminalratingsandmarkingsontheproduct.Consult

the operating manual for further ratings information before making

connections to this product.

• Donotapplyapotentialtoanyterminalthatexceedsthemaxi-

mum rating of that terminal.

EN-5Manual | TouchMonitor TM7/TM9 Safety Instructions

ATTENTION!

Alwaysfollowthesafetyprecautionsbelowtoavoidthepossibilityofphysicalinjurytoyouorothers,ordamagetotheunitorotherproperty.

These precautions include, but are not limited to, the following:

• Donotoperatetheunitwithoutadequateventilationtopreventthe

internal temperature from becoming too high.

• Thereforealsokeepawaytheunitfromdirectincidentsolar

radiation

• Keepproductsurfacescleananddry.Onlyuseadrycloth.

• Neveruseanysolventbasedliquidsforcleaningthehousing

surfaces and the display.

• Donotplacetheunitinanunstablepositionwhereitmight

accidently fall over.

• Beforeconnectinganydevicestotheunitmakesurethatthe

power supply is disconnected.

• Beforemovingtheunit,removeallconnectedcables.

• Whentransportingormovingtheunit,alwaystakecarenotto

scratch or damage the housing surfaces and the display.

Environmental ConsiderationsEN-6 Manual | TouchMonitor TM7/TM9

Environmental Considerations

Observe the following information about the environmental impact

of the product and the following guidelines when recycling an instru-

ment or component (product end-of-life handling):

• EquipmentRecycling.

 Productionofthisequipmentrequiredtheextractionanduseof

natural resources. The equipment may contain substances that

could be harmful to the environment or human health if improperly

handled at the product’s end of life. In order to avoid release of

such substances into the environment and to reduce the use of

natural resources, we encourage you to recycle this product in an

appropriate system that will ensure that most of the materials are

reused or recycled appropriately.

• BatteryRecycling.

 ThisproductmaycontainaNickelCadmium(NiCd)orlithiumion

(Li-ion) rechargeable battery, which must be recycled or disposed

ofproperly.Pleaseproperlydisposeoforrecyclethebatteryac-

cording to your local government regulations.

• RestrictionofHazardousSubstances

This product has been classiﬁed as Monitoring and Control equip-

ment,andisoutsidethescopeofthe2002/95/ECRoHSDirec-

tive.Thisproductmaycontainlead,cadmiumand/ormercuryin

slightquantities.Pleasedisposeoforrecycletheelectronicparts

or devices according to your local government regulations.

EN-7Manual | TouchMonitor TM7/TM9 Index of Content

Index of Content

Safety Instructions 3

General Safety Instructions 3

Warning! 4

Attention!5

EnvironmentalConsiderations6

IndexofContent7

BeforeYouBegin9

Introduction 9

ScopeofDelivery11

Installation 13

Connection14

PinAssignment15

GettingStarted17

SystemStart-up17

AdapttheTouchMonitortoyourAudioSystem18

CreateYourOwnPreset20

WorkingwithInstrumentsandPresets25

SoftwareModules(LicencesHandling)27

SoftwareUpdate31

Specications(Extract)33

ECDeclarationofConformity35

LicensesoftheImplementedSoftware36

EN-8 Manual | TouchMonitor TM7/TM9

EN-9Manual | TouchMonitor TM7/TM9 Before You Begin | Introduction

BeforeYouBegin

Introduction

Thank you for purchasing a model of the TouchMonitor series. With

the TouchMonitor range you are able to meet the growing require-

ments in today‘s production, post-production, and broadcast world.

Equippedwithhigh-grade7“or9“touchscreensandaneasy-to-use

GUI,TouchMonitorentersanewlevelofprofessionalaudiometering

in terms of precision, performance, efﬁciency and ﬂexibility.

Before You Begin | IntroductionEN-10 Manual | TouchMonitor TM7/TM9

Simpleandexible

The graphical user interface used in the TouchMonitor range is con-

trolled simply by using your ﬁnger or a mouse. Instruments can be

scaled, randomly positioned and combined in almost every way for

optimized use of available screen space. Even multiple instruments of

the same type, assigned to different input channels and conﬁgurations,

canbedisplayedsimultaneously.Acontext-sensitive,on-screenhelp

feature and the intuitive operatable menu system supports the user,

allowing him to make setup changes with ease.

AudioI/Ooptions

The TouchMonitor perfectly integrates into today‘s analog and digital

audio and video studio environments. It handles input signals of vari-

ousformats:analog,AES3,andAES3id.Inaddition,theTouchMonitor

TM9hasanoptiontoaccept3GSDIsignals.Thisoptionworksasan

audio deembedder for mixed use with other audio interfaces display-

ing up to 32 input channels simultaneously.

Licences

Atotallymodularsoftwareconceptmeansthatyouonlyhaveto

purchase features that you actually require. This puts you in control,

deﬁning the functionality of a TouchMonitor that suits your needs

best.Newinstrumentsandfunctionscanbeaddedassoftware

modules to the device at any time. Simply purchase and activate the

corresponding licence.

Many display functions are available to choose from: the unique RTW

SurroundSoundAnalyzer,theReal-TimeAnalyzer(RTA),EBUR128-,

ITUBS.1770/1771-,ATSC-A/85-,andARIB-compliantloudness

meters, and the Radar Loudness display acc. to the Loudness Radar

Meter of TC electronic®.
